PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 11. Read all instructions before using the appliance. 16.
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.
INSTALLATION 1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. 2. Level, flat location. Install the microwave oven on a level, flat surface. 3.
SPECIFICATIONS 120V AC, 60Hz SINGLE PHASE WITH POWER SUPPLY GROUNDING INPUT POWER 1500 W MICROWAVE ENERGY OUTPUT 1000 W FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W 20.3 x 12.0 x 14.8 in. CAVITY DIMENSIONS (W 14.0 x 9.4 x 14.1 in. CAVITY VOLUME 1.1 cu.ft NET WEIGHT APPROX.
FEATURES DIAGRAM 1 Door latch - When the door is closed, it will 8 Waveguide cover - Protects the microwave outlet automatically shut off. If the door is opened while from splashes of cooking foods. the oven is operating, the magnetron will 9 Roller guide - This must always be used for automatically shut off.
FEATURES DIAGRAM (continued) 1 Time set pad - Used to set the cooking time and 5 Auto Defrost - Used to defrost foods. the present time. (for weight) 2 Display - Cooking time, power level, indicators and 6 Power - Used to set power level. present time are displayed.
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a standard 3-pronged 13 Amp, 120V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “:0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. 1.
WEIGHT DEFROSTING Auto Defrost lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch CARNE pad. The g indicator lights and “500 ” is displayed. CARNE 2. Select the desired defrosting weight. The display will show what you touched.
WEIGHT DEFROSTING (continued) 1. Touch VEGETALES pad. The g indicator lights and “100 ” is displayed. VEGETALES 2. Select the desired defrosting weight. The display will show what you touched. (Refer to the weight defrost chart) 3. Touch COMIENZO pad. VEGETALES DEFROSTING begins.
COOKING IN ONE STAGE 1. Touch POTENCIA pad. The M/W indicator lights and "P-HI" is POTENCIA (Select the desired power displayed. level.) The display will show what you touched. This example shows power level 5. Note : If steps 1 and 2 are omitted, the oven will cook at full power.
COOKING IN TWO STAGES(continued) 1. Touch POLLO pad. The Descong. indicator lights and “ : 0” is POLLO displayed. 2. Touch number pads for the defrosting time you want. The display will show what you touched. 3.Touch POTENCIA pad. The M/W indicator lights and “P-HI” is displayed. POTENCIA (Select the desired power level.
ONE TOUCH COOK ONE TOUCH COOK allows you to cook many of your favorite foods by touching just one pad. 1. Touch POLLO EN SALSA When you touch POLLO EN SALSA VERDE POLLO EN VERDE pad for one serving. pad once, “POL” is displayed. SALSA VERDE After 1.5 seconds, the display is changed into cooking time and the oven starts cooking.
RECETAS INSTRUCTIVO POLLO EN SALSA VERDE Ingredientes Procedimiento: 6 porciones: Paso 1: Corte los bisteces de pechugas de pollo en tiritas de - 500 gr. de bisteces de pechugas aproximadamente 2 cm. de ancho. de pollo cortadas en tiritas. Paso 2: En un refractario, coloque las fajitas de pollo, agregando la - 500 gr.
Page 17
SOPA AZTECA Ingredientes Procedimiento: 6 porciones Paso 1: Deje marinar el chile guajillo en agua caliente por 10 minutos. - 250 gr. de tortillas de maiz en Paso 2: Licue el jitomate, la cebolla, el cubo de caldo de pollo, el chile tiritas previamente fritas.
Page 18
- 1 rama de cilantro Paso 3: Meta al horno y oprima la función “Salsa”. de taza de agua Paso 4: Licue todos los ingredientes (tomates, chiles, cebolla, ajo, - sal al gusto cilantro, agua y sal). Vacie la salsa en un recipiente y adorne con cebolla picada y hojitas de cilantro.
AUTO COOK AUTO COOK lets you reheat or cook many of you favorite foods by repeatedly touching the each pad.When you touch the pad,you can select other food category as shown in below. RECALENTAR and COCCION RAPIDA pads allow you to reheat and cook. 1.
TO SET POWER SAVE MODE 1. Touch the PARAR/BORRAR pad. “ :0” or clock appears in the display. 2. Touch and then hold the PARAR/BORRAR pad for 3 seconds. The display will turn off and a beep sounds. To operate the oven in power save mode, touch any key. Then “...
CARE OF YOUR MICROWAVE OVEN The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. Turn the oven off before cleaning.
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * Sparking in the cavity; * The oven doesn’t work : 1. Check that the power cord is securely plugged in. 1. Check utensils. Metal containers or dishes with 2.
QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven without * Q : What does “standing time” mean? any food in it. Is it damaged? A : “Standing time” means that food should be removed A : Running the oven empty for a short time will not from the oven and covered for additional time to damage the oven.
COOKING INSTRUCTIONS Utensil Guide Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave- safe, you do not need to worry.
USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety Do not operate the oven if door seals or sealing interlocks. surfaces are damaged; or if door is bent; or if hinges Do not place any object between the oven front frame are loose or broken.
MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade sources include radar, radio, television, telecommunication links and car phones. HOW MICROWAVES COOK FOOD In a microwave oven, TRANSMISSION...
COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and cakes, The colder the food, the longer it takes to heat up. Food require standing time(inside or outside of the oven) after from a fridge takes longer to reheat than food at room cooking, to allow heat to finish conducting to cook the temperature.
DEFROSTING GUIDE | Do not defrost covered meat. Covering might allow | When defrosted, food should be cool, but softened in cooking to take place. Always remove outer wrap all areas. If still slightly icy, return to microwave oven and tray. Use only containers that are microwave- very briefly, or let stand a few minutes.
COOKING & REHEATING CHART Reheating chart • Baby food particularly needs to be checked carefully before serving to prevent burns. • When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully. • If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly thawed before following the heating instructions on the packed.
VEGETABLE CHART Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water quantity is recommended - see table. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after cooking.
RECIPES TOMATO & ORANGE SOUP 1 oz.(25g) butter 1. Melt the in a large bowl on P-HI for 1 minute. 2. Add the onion, carrot and potato and cook on P-HI 1 medium onion, chopped 1 large carrot & 1 large potato, chopped for 4 minutes.
BLUE CHEESE & CHIVE JACKETS 1. Prick each potato in several places. Cook on P-HI 2 baking potatoes, (approx.9 oz.(250g) each) for 7-9 minutes. Halve and scoop the flesh into a 2 oz.(50g) butter bowl, add the butter, cheese, chives, mushrooms, 4 oz.(100g) blue cheese, chopped salt and pepper, mix thoroughly.
Page 33
SCRAMBLED EGG 1. Melt the butter in a bowl on P-HI for 1 minute. oz.(15g) butter 2 eggs 2. Add the eggs, milk and seasoning and mix well. 2 tbsp(30ml) milk 3. Cook on P-HI for 3 minutes, stirring every 30 salt &...
