Service Manual

Microwave Oven

Model : KOR-1N1HW
Model: KOR-1N1HS
• Caution:
In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
Jul. 2009

Advertisement

Table of Contents
loading

Related Manuals for Daewoo KOR-1N1HS

Summary of Contents for Daewoo KOR-1N1HS

  • Page 1: Microwave Oven

    Service Manual Microwave Oven Model : KOR-1N1HW Model: KOR-1N1HS • Caution: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other micro- wave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse.

  • Page 3: Exposure To Excessive Microwave Energy

    SAFETY AND PRECAUTIONS CAUTION : This Device is to be Serviced Only by Properly Qualified Service Personnel. Consult the Service Manual for Proper Service Procedures to Assure Continued Safety Operation and for Precautions to be Taken to Avoid Possible Exposure to Excessive Microwave Energy. 1.

  • Page 4: Specifications

    SPECIFICATIONS POWER SUPPLY 120V AC, 60Hz SINGLE PHASE WITH GROUNDING INPUT POWER 1500 W MICROWAVE ENERGY OUTPUT 1000 W FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W 20.3 x 12.0 x 14.8 in. CAVITY DIMENSIONS (W 14.0 x 9.4 x 14.1 in. CAVITY VOLUME 1.1 cu.ft NET WEIGHT APPROX.

  • Page 5: Features Diagram

    2. FEATURES DIAGRAM 1 Door latch - When the door is closed, it will automatically shut off. If the door is opened while the oven is operating, the magnetron will automatically shut off. 2 Door seal - The door seal surfaces prevent microwaves escaping from the oven cavity. 3 Oven cavity 4 Oven lamp - Automatically turns on during oven operating.

  • Page 6: Control Panel

    3. CONTROL PANEL 1 Time set pad - Used to set the cooking time and the present time. 2 Display - Cooking time, power level, indicators and present time are displayed. 3 One Touch Cook - Used to cook specific quantities of food. 4 Auto Cook - Used to reheat or cook many of favorite foods.

  • Page 7: Installation

    INSTALLATION 1. Steady, flat location This microwave oven should be set on a steady, flat surface. 2. Leave space behind and side All air vents should be kept a clearance. If all vents are covered during operation, the oven may overheat and, eventually, cause oven failure.

  • Page 8: Operations And Functions

    OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray must always be in place during cooking. 3.

  • Page 9: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY - Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safe during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit.
  • Page 10 1. To remove cabinet 1) Remove four screws on cabinet back. 2) Push the cabinet backward. 2. To remove door assembly 1) Remove two screws which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.
  • Page 11 3. To remove door parts. DOOR ASSEMBLY: KOR-1N1H9A27 (3511728900) KOR-1N1H9A52 (3511727430) REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3517010800 BARRIER-SCREEN*O GLASS T3.2 KOR-1N1H9A27 3517010820 BARRIER-SCREEN*O TEMP GLASS T3.2 MIRROR KOR-1N1H9A52 3512210800 FRAME DOOR ABS SG-176D, SG-175 KOR-1N1H9A27 3512210550 FRAME DOOR KOR-1N1A SILVER SPRAY KOR-1N1H9A52...
  • Page 12 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ • Loosen two screws on the stopper hinge top, and then push the door to contact the door seal to the oven front surface.
  • Page 13 5. To remove control panel parts. C/PANEL ASSEMBLY: KOR-1N1H9A27(PKCPSWYS00) KOR-1N1H9A52(PKCPSWYS10) REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3518572910 SWITCH MEMBRANE KOR-1N1H9A27 KOR-1N1H9A27 3518572970 SWITCH MEMBRANE KOR-1N1H9A52 KOR-1N1H9A52 3516737800 CONTROL-PANEL ABS VT-0826, AF-348 KOR-1N1H9A27 3516737810 CONTROL-PANEL KOR-1N1H SPRAY KOR-1N1H9A52 PKMPMSZZ10 PCB MAIN MANUAL AS KOR-1N1H9A27...
  • Page 14 6. To remove high voltage capacitor. 1) Remove the screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
  • Page 15 8. To remove wind guide assembly. 1) Remove the screw for earthing. 2) Remove the noise filter from the wind guide. 3) Remove the screw which secure the wind guide assembly. 4) Draw forward the wind guide assembly. 5) Pull the fan from the motor shaft. 6) Remove two screws which secure the motor shaded pole.

  • Page 16: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. (1) Primary interlock switch When the door is closed, the hook locks the oven door.

  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before trouble checking. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed.
  • Page 18 CONDITION CHECK RESULT CAUSE REMEDY Replace Defective Outlet has Check continuity of magnetron Continuity magnetron proper voltage Fuse does not Replace blow. Open power Check continuity of Continuity power supply cord supply cord Replace Normal Defective touch control circuit Replace Display do not shown Malfunction of countdown...
  • Page 19 (TROUBLE 3) No microwave oscillation even though fan motor rotates. CONDITION CHECK RESULT CAUSE REMEDY Continuity Replace Check continuity of high Defective high microwave voltage capacitor terminals voltage oscillation with wires removed transformer Continuity in Replace Check continuity of high voltage Defective high backward rectifier in forward and backward...
  • Page 20 (TROUBLE 4) The following visual conditions inditions indicate a probable defective touch control circuit. 1. Incomplete segments, 1) Segments missing. 2) Partical segments missing. 3) Digit flickering other than normal display slight flickering. 4) " :0" does not display when power is on. 2.

  • Page 21: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly mmeasuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 100 ±...

  • Page 22: Microwave Radiation Test

    2. MICROWAVE RADIATION TEST CAUTION 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4.

  • Page 23: Component Test Procedure

    3. COMPONENT TEST PROCEDURE • High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. • It is neither necessary nor advisable to attempt measurement of the high voltage. • Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor.

  • Page 24: Wiring Diagram

    WIRING DIAGRAM...

  • Page 25: Printed Circuit Board

    PRINTED CIRCUIT BOARD 1. CIRCUIT CHECK PROCEDURE 1. Low voltage transformer check The low voltage transformer is located on the P.C.B. Measuring condition: Input voltage: 120V / Frequency: 60Hz Terminal Voltage LOAD NO LOAD 5-6-7 AC 12.6 V AC 14.7 V NOTE 1.
  • Page 26 Measure Point...
  • Page 27 3. When there is no microwave oscillation 1) When touching Comienzo/Comienzo Rápida pad, oven lamp does not turn on. Fan motor do not rotate, but cook indicator in display comes on. (TRAY LAMP) - Check method POINT STATE RELAY 2 ON 5VDC RELAY 2 OFF 15VDC...

  • Page 28: Pcb Circuit Diagram

    2. PCB CIRCUIT DIAGRAM...

  • Page 29: Pcb Location No

    3. PCB LOCATION NO. NAME SYMBOL SPECIFICATION PART CODE Q’TY BUZZER BM-20K 3515600100 C ARRAY 7P(6) 1000PF M 50V CN6XB-102M CAPACITOR ELEC 50V RS 10uF CEXE1H100A CAPACITOR ELEC 25V RSS 1000MF CEXF1E102V CONNECTOR WAFER YW396-02V 3519150520 CONNECTOR WAFER FCZ 254-11 441M367160 CONNECTOR WAFER YW396-05AV...

  • Page 30: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY...
  • Page 31 REF. NO PART CODE PART NAME DESCRIPTION Q'TY 3511728900 DOOR AS KOR-1N1H9A27 3511727430 DOOR AS KOR-1N1H9A52 PKCPSWYS00 CONTROL-PANEL AS KOR-1N1H9A27 PKCPSWYS10 CONTROL-PANEL AS KOR-1N1H9A52 3510810700 CABINET AS KOR-1N0A9A(KOR-1N1H9A27) 3510810520 CABINET PCM 0.5T SV1401C(KOR-1N1H9A52) 3516004100 SPECIAL SCREW T1 TRS LR4 POLE 4X10 MFZN 3516119600 CAVITY AS KOR-1N0A9A...
  • Page 32 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Jul. 2009...
