4. MAIN COMPONENTS

1. COMPRESSOR
MODEL PART NAME
TUR-60SD HBL27YE-1
TUR-72SD
SK6A1C-H2Y
TST-60SD
TST-72SD CAE4456Y
TUF-60SD CAE2420Z
PART NAME
TUR-60SD HBL27YE-1
TUR-72SD
SK6A1C-H2Y
TST-60SD
TST-72SD CAE4456Y
TUF-60SD CAE2420Z
2. COMPRESSOR RELAY, OVERLOAD
MODEL RELAY
TUR-60SD S068
TUR-72SD
MTRP0052-02
TST-60SD
TST-72SD 3ARR12
TUF-60SD 3ARR12
HORSE
PART NO.
POWER
3952127G10 1/4 HP
3020014540 1/3 HP
30200B4500 1/2 HP
30200R1100 1/2 HP
BASIC COMPRESSOR
MOTOR TYPE MAKER
LBP(CSR) DAEWOO
HBP(RSIR) SAMSUNG
HBP(CSIR) FRENCH TECUMSEH
LBP(CSIR) FRENCH TECUMSEH
PART NO. OVERLOAD
3952127G10 4TM-783SHBZZ
- MST00AL
-
-
TYPE OF
CAPACITY
MOTOR
896 BTU/h LBP
(226 Kcal/h) CSR
4,440 BTU/h HBP
(1,129 Kcal/h) RSIR
5,592 BTU/h HBP
(1,410 Kcal/h) CSIR
2,268 BTU/h LBP
(872 Kcal/h) CSIR
EXCHANGEABLE COMPRESSOR
PART NAME
AEA1410YXA
AEA4440YXA
AKA4460YXA
AJA2419ZXA
PART NO.
3817910600
-
T0889 -
T0593 -
Current
MAKET
(RLA)
3.7A DAEWOO
6.5A SAMSUNG
9.0A TECUMSEH
6.6A TECUMSEH
TYPE OF MAKER
LBP(RSIR) USA TECUMSEH
HBP(CSIR) USA TECUMSEH
HBP(CSIR) USA TECUMSEH
LBP(CSR) USA TECUMSEH
MAKER NOTE
DAEWOO
SAMSUNG
TECUMSEH
TECUMSEH
