TL-SC3430N
Wireless N H.264 Megapixel Surveillance Camera
Rev: 1.0.0
1910010550

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL-SC3430N and is the answer not in the manual?

Questions and answers

Related Manuals for TP-Link TL-SC3430N

Summary of Contents for TP-Link TL-SC3430N

  • Page 1 TL-SC3430N Wireless N H.264 Megapixel Surveillance Camera Rev: 1.0.0 1910010550...
  • Page 2 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
  • Page 3 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 4: Table Of Contents

    CONTENTS Package Contents......................1 Chapter 1 Safety Instructions..................2 Chapter 2 Minimum System Requirement & Product Feature........3 2.1 System Requirement ......................3 2.2 Product Features ......................3 2.3 Physical Overview ......................4 2.4 Mount the Camera ......................6 2.5 Hardware Connection ....................... 7 Chapter 3 Using IP Camera via Web Browser..............9 3.1 Obtain the IP Address .......................
  • Page 5 Europe – EU Declaration of Conformity.................89 Federal Communication Commission Interference Statement ........92...

  • Page 6: Package Contents

    Package Contents The following items should be found in your package: TL-SC3430N Wireless N H.264 Megapixel Surveillance Camera Power Adapter Mounting Bracket with three screws, a Lock Ring, a Brace and a Base Plate RJ45 Cable Quick Installation Guide Resource CD, including:...

  • Page 7: Chapter 1 Safety Instructions

    Chapter 1 Safety Instructions Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to heed the following.

  • Page 8: Chapter 2 Minimum System Requirement & Product Feature

    Chapter 2 Minimum System Requirement & Product Feature 2.1 System Requirement For normal operation and viewing of the network camera, it’s recommended that your system meets these minimum requirements for proper operation: Item Requirements Pentium 4 2.8GHz (or equivalent AMD) Graphic Card 256 MB RAM graphic cards(or equivalent on-board graphic cards) Operating...

  • Page 9: Physical Overview

    Audio compression: G.711 μ law, a law, and AMR Mobile Phone Live View Through 2.5 WAP, 3GPP, 3G Streaming, and 3G Browser Alarm Sending FTP Client / SMTP / Network Storage / Memory Card / HTTP event Security Passward Protecton / HTTPS encryption / IP Filter Alarm Buffer Recording image and audio file pre-and-post disconnection up to 5 sec.

  • Page 10: Bottom View

    Built-in Microphone: The location where the voice from your partner comes out. SD/SDHC Card Slot: Supports SD/SDHC memory card. 2.3.2 Bottom view Power Connector: The power connector is where you connect the power adapter. RESET: Please take the following steps to reset the camera to its defaults. Keep the camera powered on, then press and hold the Reset button for more than 15 seconds.

  • Page 11: Mount The Camera

    Step 1. Press the WPS button on the router supporting WPS for 2 seconds. Step 2. Press the WPS button on the Camera within 2 minutes. Lock Ring: It is used to adjust the angle of the Camera. Base Plate: It is used to support the Camera and can be fixed to a flat surface with the supplied screws.

  • Page 12: Hardware Connection

    DHCP feature is enabled. If not, please refer to your router’s instruction to enable For TL-SC3430N, if your router supports WPS (Wi-Fi Protected Setup), you can also use WPS to setup a wireless connection quickly. You can also choose Wired Connection.
  • Page 13 2.5.2 Method 2: WPS Connection Power on the Camera and make sure that the Power LED is blue before WPS Connection. Then take the following steps. A. Press the WPS button on the router supporting WPS for 2 seconds. Press the WPS button on the Camera within 2 minutes. After you press the WPS button on the Camera, the Power LED will turn purple and flash, and when the WPS Connection is established successfully, it will return blue.

  • Page 14: Chapter 3 Using Ip Camera Via Web Browser

    Chapter 3 Using IP Camera via Web Browser 3.1 Obtain the IP Address Insert the provided CD into your CD-ROM driver. The Setup Wizard will automatically pop up on your computer’s screen as shown in the figure below. Figure 3-1 Choose the Intelligent IP Installer, and then the next screen appears.
  • Page 15 After the installation is finished, click Start > All Programs > TP-LINK >Intelligent IP Installer to start using the program. Figure 3-3 The following screen will then display. Click the Search button to search Network Cameras in the network; it displays Network Cameras information including IP Address. Figure 3-4...

  • Page 16: Windows Web Browser

    3.2 Windows Web Browser .2 Windows Web Browser The configuration of browser is similar in Windows XP/Vista/7. Here we take IE browser in Windows XP The configuration of browser is similar in Windows XP/Vista/7. Here we take IE browser in Windows XP for example.

  • Page 17: Mac Web Browser

    3.3 Mac Web Browser .3 Mac Web Browser Click the Safari icon. Click the Safari icon. After the home page appears, click Bookmarks and then choose Show All Bookmarks.
  • Page 18 Click Bonjour on the left of the following screen. Double click the Mac address of the Camera in the bookmark list. For example, TP-LINK-001BFE0334A2. Enter the default Name admin and default Password admin. Click Log In. Note: The default user name “admin” and the password “admin”are set at the factory for the administrator. You can change them in the Account Menu.
  • Page 19 The monitor image will be displayed in your browser. In the far left side of main configuration are Setting, Client Setting and Image Setup.

  • Page 20: Chapter 4 Operating Ip Camera Via Mobile Phone

    Chapter 4 Operating IP Camera via Mobile Phone 4.1 Mobile Phone Viewing 4.1.1 3G Mobile Phone Streaming Viewing For 3G mobile phone viewing, type “rtsp://<IP>:<PORT>/video.3gp ” into your 3G Streaming Link. <IP> is the Public IP address of your IP Camera; <PORT> is the RTSP port of your IP Camera (Default value is 554.) Example: rtsp://100.10.10.1:554/video.3gp Note: You can also use RTSP clients (RealPlayer, VLC, QuickTime Player…etc.) to view RTSP streaming, just...
  • Page 21 3. Enter name and password. 4. The TP-LINK User Interface and live Default values are both admin. image will show up in the middle of the Then click Log in screen. Note: It will show continuous snapshots not a real time video streaming. Therefore, the recording feature is disabled.

  • Page 22: Chapter 5 Configuration Of Main Menu

    Chapter 5 Configuration of Main Menu In the left side of main configuration are Setting, Client setting and Image setting. In the right side, you can control Live View in your main Browser. The functions include: Snapshot, Open digital zoom, Audio, and Video Play. Open digital zoom Video Play Audio Play...

  • Page 23: Setting

    5.1.2 Digital zoom in / out the image via the monitor window • Click to display the digital zoom in window. • Pull the to adjust the digital zoom range, and it will be showed on the above window. • Use the left click of your mouse to move to anywhere in the window area.

  • Page 24: Client Setting

    Click Basic folder, there are sub-folders including System, Camera, Network, and Security. Fore more information, you can see Chapter 6. Click Advanced folder, there are sub-folders including FTP Client, SMTP, Network Storage, Memory Card, HTTP event, Schedule, Alarm buffer, Motion detection, Audio detection, and System Log. Fore more information, please see Chapter 7.

  • Page 25: Image Setup

    5.3.4 Video Buffer .3.4 Video Buffer Turn the Video Buffer function On / Off. The Video Buffer function makes the streaming more smooth in Turn the Video Buffer function On / Off. The Video Buffer function makes the streaming more smooth in unsteady network environment, but might cause a little delay in live viewing.

  • Page 26: Chapter 6 Setting-Basic

    Chapter 6 Setting-Basic Click the Basic folder to display the sub folders including System, Camera, Network, and Security. 6.1 System Click the folder of System to display the sub-folders including Information, Date / Time, Initialize, and Language. 6.1.1 Information The Information screen provides the product factory information which includes Product Name, Firmware Version.
  • Page 27 6.1.2 Date / Time The Date/ Time screen displays all options of time setting. Current Date / Time: This displays the current date and time of this IP Camera. PC Clock: This displays the date and time of the monitoring PC clock. Date / Time Format: You can click the pull down box to select different time display formats.
  • Page 28 time display will be the same as the current date / time option. Daylight Saving Time: There are two modes to choose for setting up daylight saving time. By Date: Set the start and end time by select month, day, hour, and minute. By Week Number: Set the start and end time by select month, week, hour, and minute.

  • Page 29: Camera

    6.1.4 Language Upload Language Pack: Clicking “Browse” and selecting the file for updating, the present language display of WEB User Interface could be changed. A confirmation dialogue will appear. Click “OK”, then the update will be applied immediately. The default language is “English”. 6.2 Camera Click the folder of Camera to display the sub folders including General, Stream 1, Stream 2, Advanced and Playback.
  • Page 30 6.2.1 General RTSP: The default value is 554. If the IP Cameras connected with router and installed outside are over 2 sets and all of them need support RTSP, please fill some value in the blank space in the range from 1024 to 65535. RTP Unicast streaming: The default value of port range is 5000 ~ 7999 and can be changed from 1024 to 65535.
  • Page 31 Text Overlay: Some information can be showed on the display screen, such as Date / Time and user-defined text. And the background color can be chosen. Privacy Mask: A specific area of the video image can be covered. 6.2.2 Stream 1 Viewer Authentication: On: If the viewer authentication is On, the users will be requested to key-in username and password when using QuickTime Player to have live viewing.
  • Page 32 20, 25, and 30 fps. The unit “fps” stands for “frames per second”. Note: The frame rate is up to 15 fps at 1280x1024, and up to 30 fps at 640x480. However, if you would like choose frame rate over 15 fps, the IMAGE SIZE of H.264/MPEG-4/MJPEG setting page has to been selected 320x240 or 640x480 at the same time.
  • Page 33 Viewer Authentication: On: If the viewer authentication is On, the users will be requested to key-in username and password when using QuickTime Player to have live viewing. Off: If the viewer authentication is Off, you can have live viewing on computer by QuickTime Player after entering “rtsp://ip:port/video.mp4”...
  • Page 34 Fixed Quality: Select the value of quality among Medium, Standard, Good, Detailed and Excellent. Fixed Bitrate: Set the bitrate of MPEG-4 image transmission for a line. You can select one value among 64Kbps, 128Kbps, 256Kbps, 384Kbps, 512Kbps, 768Kbps, 1Mbps, 1.5 Mbps, 2 Mbps, 3 Mbps, 4 Mbps, 5 Mbps, and 6 Mbps.
  • Page 35 Video / Audio Port: Specify the transmission port number of the video data, from 1124 to 65534. Time-To-Live: Set the maximum TTL that multicast can pass through. Note: Time-To-Live option determines the maximum length of time (measure as the number of network routers that can be passed before data arrives at its destination or is dropped) within which a multicast packet must reach its destination.
  • Page 36 On: If the viewer authentication is On, the users will be requested to key-in username and password when using QuickTime Player to have live viewing. Off: If the viewer authentication is Off, you can have live viewing on computer by QuickTime Player after entering “rtsp://ip:port/video.3gp”...
  • Page 37 Auto: Choose Auto and you have 3 options to adjust the exposure condition. Back Light Compensate: Click it on and it helps avoid problems in situations where the main subject ends up being too dark, such as when shooting people or other subjects in front of a bright background.

  • Page 38: Network

    Snapshot Mirror/ Flip Full Screen Increase Speed Volume Pause Decrease Speed Mute on / Mute off Stop Open Files Open Digital Zoom 6.3 Network Click the folder of Network to display the sub folders including Information, PPPoE, DDNS, UPnP, Bonjour, IP Notification, Wireless and WPS.
  • Page 39 6.3.1 Information Display the MAC address of the device. Obtain an IP address automatically (DHCP): If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server. Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically.
  • Page 40 Use the following IP address: Select this option when the fixed IP address is set. IP address: Enter the IP address of the device. Subnet mask: Enter the subnet mask. Default gateway: Enter the default gateway. Use the following DNS server address: Select this when you set the fixed address as the IP address of DNS server.
  • Page 41 IP Address: The IP address obtained at the PPPoE connecting with network. User ID: Enter the user ID for authentication necessary for PPPoE connections. Type it up to 64 characters. Password: Enter the password for authentication necessary for PPPoE connections. Type it up to 32 characters.
  • Page 42 Point-to-Point Protocol frames insider Ethernet frames. PPPoE connection is used mainly with ADSL service where individual users connect to the ADSL transceiver (modem) over Ethernet work. It also widely used in XDSL (digital affiliate line such as ADSL, VDSL or SDSL) The IP Camera needs to be rebooted after it finishes changing the network completely.
  • Page 43 2. Input all information and follow step by step with DynDNS. 3. Login with new account and click Account → My Hosts → Add Host Services.
  • Page 44 4. Type domain in the Hostname field and select sub-domain. 5. After typing information, check your DDNS service...
  • Page 45 6. Type your DDNS User ID, Password and Host name in Setting → Network → DDNS. After completing setting, reboot IP Camera. 6.3.4 UPnP (Universal Plug and Play) If you have a Router to access to internet and the Router supports UPnP IGD function, you need to turn on the UPnP Port Forwarding function.
  • Page 46 HTTP Port: Enter the HTTP port number and default HTTP port is 80. SSL Port: Enter the SSL port number and default SSL port is 443. RTSP Port: Enter the RTSP port, default value is 554 for computer view. Note: UPnP (Universal Plug and Play): UPnP is a set of computer network protocol.
  • Page 47 Device Name: Enter Device Name you wish. Note: How to use Bonjour in your Windows Browser UI? Please check the link below: http://www.apple.com/support/downloads/bonjourforwindows.html 6.3.6 IP Notification Once IP Notification is set to "On", the Camera will automatically send an e-mail notification to tell users its updated network parameters if the network settings about IP address, network connection type, HTTP port or wireless connection is changed or completed.
  • Page 48 SMTP: Select if SMTP authentication is necessary for sending e-mail. POP before SMTP: Select if POP before SMTP authentication is necessary for sending e-mail. POP server name: It is necessary when the POP before SMTP is selected in Authentication. Type the POP (receiving mail) server name up to 64 characters, or type the IP address of the POP server.
  • Page 49 Status of Wireless Networks The list above is the result of network scan. The network currently linked to will be shown in blue. The following information is provided. ESSID - The name of a wireless network (or ad-hoc device). If the same name occurs several times this means that several access points for that network were found.
  • Page 50 ESSID (ESSID is sometimes written as SSID) - This is the name of the wireless network to which the Camera is ready to connect. The field accepts up to 32 alphanumeric characters. The name must be exactly the same as that used in the wireless access point; otherwise, the connection will not be established.
  • Page 51 Obtain an IP address automatically (DHCP) – If a DHCP server is installed and enabled on the network, to select this for the IP address can be assigned by the DHCP server. Use the following IP address - Select this when the fixed IP address is set. IP address: Enter the IP address of the Camera, which must be in the same subnet with that of the desired AP/ Router.
  • Page 52 2. Secondly, open the router’s Web-based Utility and click QSS link on the left of the main menu. Then the following screen will appear. Click Add device. And then select Enter the new device’s PIN and enter the PIN value of the Camera, click Connect.

  • Page 53: Security

    6.4 Security Click the folder of Security to display the sub folders including Account, HTTPS, and IP Filter. 6.4.1 Account The device fault account and password setting is “admin / admin”. That means everyone who knows IP address can access the device including all configuration. It is necessary to assign a password if the device is intended to be accessed by others.
  • Page 54 The Viewer mode only can view the Live View. Viewer Authentication: Select whether the authentication is needed when users access to live view. On: Authentication is required to let different users have different levels of permission to access the Camera view. Off: Authentication is not required to access the Camera.
  • Page 55 Note: When enable HTTPS with RTSP on mode, the IP Camera only protect the setting such as username and password and do not protect video and audio. When enable HTTPS with RTSP off mode, the IP Camera will protect all setting including video and audio. 6.4.3 IP Filter IP Filter provides the function of controlling the range of IP address, similar with firewall service.

  • Page 56: Chapter 7 Setting-Advanced

    Chapter 7 Setting-Advanced Click the folder of Advanced to display the sub folders including FTP client, SMTP, Network storage, Memory Card, HTTP event, Schedule, Alarm buffer, Motion detection, Audio detection, and System Log. 7.1 FTP Client Use this menu to set up for capturing and sending an image or video clip to an FTP server. By using FTP client function, you can send files which has been shot and recorded linked with the external sensor input or with the built-in motion detection function to FTP server.
  • Page 57 7.1.1 General Select On when you use FTP function. The FTP client Setting screen appears. Select Off, when you do not wish to use the FTP client function. Note: The frame rate and operability on the main viewer may decrease while a file is being transmitted by the FTP client function.
  • Page 58 the external sensor input or by the built-in motion detection function. Select On to send the file to FTP server linked with the alarm detection. Remote Path: Type the path to the destination in FTP server up to 64 characters. Image File Name: Type the file name you want to assign to the files when sending to the FTP server.
  • Page 59 →Audio Detection → Setting”) Network Link Down: Click it on to receive a snapshot or a video clip while network link down. If Attached File Type (go “Setting → Advanced → FTP Client → General” ) was clicked as video clip, you can use Alarm Buffer function as a sensor. It’s for recording audio file in the IP CAM before and after disconnected network.

  • Page 60: Smtp

    number is added to the file name. Sequence number: A consecutive number is added to the Image file name. Sequence number clear: Click Clear and the suffix of the sequence number returns to 1. Interval: Set the periodical sending is effective interval. Min value is 1 min and Max value is 24 hour.
  • Page 61 Network → IP Notification”) SMTP Server Name: Type the SMTP server name up to 64 characters, or the IP address of the SMTP server. SMTP Server Port: You can set port number from 1~65535 according to your mail server. The default value is 25.
  • Page 62 This address is used for reply mail and sending system messages from the SMTP server. Attached File Type: You can choose snapshot or video clip for alarm sending. Select “Snapshot,” one snapshot will be transmitted to the administrator’s e-mail address while motion detection / audio detection triggered.
  • Page 63 Date & time: The date & time suffix is added to the Image file name. The date & time suffix consists of lower two-digits of year (2 digits), month (2 digits), date (2 digits), hour (2 digits), minute (2 digits) and second (2 digits), and consecutive number (2 digits), thus 14-digit number is added to the file name.

  • Page 64: Network Storage

    Image File Name: Type the file name of the image sent by SMTP up to 10 alphanumeric characters, - (hyphen) and _ (under score). Suffix: Select a suffix to be added to the file name sent by SMTP. Date & time: The date & time suffix is added to the Image file name. The date & time suffix consists of lower two-digits of year (2 digits), month (2 digits), date (2 digits), hour (2 digits), minute (2 digits) and second (2 digits), and consecutive number (2 digits), thus 14-digit number is added to the file name.
  • Page 65 7.3.1 General Select On if you would like to use the network storage function. Then choose one protocol between Windows network (SMB/CIFS) and Unix network (NFS). Protocol- Unix Network (NFS): Network storage location: Type the IP or name of specified computer and folder. For example, //IP/folder name or // my_nas:/folder name.
  • Page 66 Network Storage Location: Type the IP or name of specified computer and folder. For example, \\IP\folder name or \\my_nas:\folder name. Workgroup: Type the name of workgroup which the operating computer belongs. User Name: Type the name of workgroup. (If none, please leave it blank.) Password: Type the password for workgroup.
  • Page 67 Alarm Sending: Select On to set to send files with connection to the alarm detection to network storage. Image File Name: Type the file name you want to assign to the file to attach a mail. You can use up to 10 alphanumeric, - (hyphen) and _ (underscore) for naming. Suffix: Select a suffix to add to the file name Date &...
  • Page 68 Note: You can set alarm buffer at alarm buffer screen. (Please go “Setting → Advanced → Alarm Buffer → Setting”) Effective Period: Set the period when the periodical sending is effective. Always: The periodical sending is always effective. Schedule: You can specify the period when the periodical sending is effective in the Schedule setting in the other section.

  • Page 69: Memory Card

    Recording Time: Set the period when the periodical recording is effective. Always: The periodical recording is always effective. Schedule: You can specify the period when the periodical recording is effective in the Schedule setting in the other section. Note: You can set schedule function at schedule screen. (Please go “Setting → Advanced → Schedule →...
  • Page 70 Format: Click Execute to clear up the data in memory card. Card Status: The free space and capacity of memory card. Card staus notification: Select On to enable card status notification. SMTP server name: Type the SMTP server name using up to 64 characters, or the IP address of the SMTP server.
  • Page 71 On: If authentication is necessary for sending e-mail, select one of the authentication methods from the followings. SMTP: Select if SMTP authentication is necessary for sending e-mail. POP Before SMTP: Select when POP before SMTP authentication is necessary for sending e-mail. Recipient E-mail Address: Type the recipient e-Mail address using up to 64 characters.
  • Page 72 Alarm Sending: Select On to set to send files with connection to the alarm detection to memory card. Image File Name: Type the file name you want to assign to the file to attach a mail. You can use up to 10 alphanumeric, - (hyphen) and _ (underscore) for naming. Suffix: Select a suffix to add to the file name Date &...
  • Page 73 Image File Name: Type the file name of the image sent by SMTP up to 10 alphanumeric characters, - (hyphen) and _ (under score). Suffix: Select a suffix to be added to the file name sent by SMTP. Date & time: The date & time suffix is added to the Image file name. The date & time suffix consists of lower two-digits of year (2 digits), month (2 digits), date (2 digits), hour (2 digits), minute (2 digits) and second (2 digits), and consecutive number (2 digits), thus 14-digit number is added to the file name.

  • Page 74: Http Event

    FTP server shutdown: Backup files to memory card when FTP server is shut down. Network storage shutdown: Backup images to memory card when network storage is shut down. 7.5 HTTP event Use this menu to set up for capturing and sending images to an HTTP server. By using HTTP client function, you can send the image file and audio file which has been shot and recorded linked with the built-in motion detection function to HTTP server.
  • Page 75 7.5.1 General Select On when you use the HTTP function. The common setting options are displayed below. Select Off, if you do not wish to use the HTTP function. HTTP event: Set up the HTTP server URL, port, User ID, Password and Proxy Server settings. For example: URL: 192.168.1.107/cgi-bin/operator/ptzset.
  • Page 76 7.5.2 Alarm sending Set to send the mail with connection to the alarm detection by the built-in motion detection function. Select On to send the image and audio file to HTTP server linked with the alarm detection. Alarm sending: Select On to set to send mail with connection to the alarm detection. Alarm Motion Detection: Click it for using Motion Detection function as a sensor.
  • Page 77 Note: You can set motion detection on motion detection page. (Please go to “Setting → Advanced →Motion detection → Setting”) Motion Detection works only when the MPEG4 function is On.
  • Page 78 Parameter: the parameter of CGI (defined in Setting → Advanced → HTTP event → General → URL) is from your target device. For example, move=down. Message: message will show up in the form of Message = PTZ down. If your target device didn’t support the parameter of message, you can’t see the message.

  • Page 79: Schedule

    Parameter: the parameter of CGI (defined in Setting → Advanced → HTTP event → General → URL) is from your target device. For example, move=down. Message: message will show up in the form of Message = PTZ down. If your target device didn’t support the parameter of message, you can’t see the message.

  • Page 80: Alarm Buffer

    menu as the setting menu which is displayed when you click Schedule to set Effective period and Schedule in FTP client, e-Mail (SMTP), Record, and Alarm out setting menu setting menu. Schedule Selection: Select the list box to specify the schedule you want to set. FTP -Alarm / FTP –...

  • Page 81: Motion Detection

    Use alarm buffer function for recording audio and video file in the IP Camera before and after disconnected network. After re-connecting, these files will transmit to FTP client, SMTP, and Network storage. You can set the pre-alarm and post-alarm period up to 5 seconds in Alarm Buffer function screen.

  • Page 82: System Log

    Click it on for using Audio Detection function as a sensor. You can set audio detection function at the audio detection function screen. Threshold: It means the extent which the alarm will be triggered. The default value is 50 and the value range is 0~100.
  • Page 83 Enable Remote Log: Enables user to send the log data to a specified log server.

  • Page 84: Appendix

    Appendix A. Frame-rate and Bitrate Table – Help to set IP Camera with your network environment to access Internet. Base on your network upload environment to choose the suitable Image-Quality setting. For example, if the network environment is ADSL 256Kb (upload) / 2Mb (download), the most fluent Image-Quality needs to set up under 256Kb situation.
  • Page 85 320*240 6144 3600 320*240 2048 2200 320*240 2048 2200 320*240 320*240 A.1.4. MPEG 4@ 15fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 2700 2000 Detailed 1100 Good Standard Medium A.1.5. MPEG4@ 10fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 1800 1400...
  • Page 86 A.1.7. MJPEG @ 15fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 22000 16000 6000 2200 Detailed 12000 7000 3000 1200 Good 7000 5000 2500 1000 Standard 5500 4000 2000 Medium 4000 3000 1200 A.1.8. MJPEG@ 10fps / kbps Quality 1280*1024 1280*720 640*480...
  • Page 87 A.2 VGA Mode A.2.1 H.264 @ 30fps / kbps Quality 640*480 320*240 Excellent Detailed Good Standard Medium A.2.2 H.264@15 fps / kbps Quality 640*480 320*240 Excellent Detailed Good Standard Medium A.2.3 H.264 / kbps, fps Frame-Rate Current Image-Size Bitrate Setting Current Bitrate Setting Frame-Rate...
  • Page 88 A.2.6 MPEG4 / kbps, fps Frame-Rate Current Image-Size Bitrate Setting Current Bitrate Setting Frame-Rate 640*480 6144 6300 640*480 6144 6300 640*480 2048 2200 640*480 2048 2200 640*480 640*480 320*240 6144 5100 320*240 6144 2800 320*240 2048 2200 320*240 2048 2200 320*240 320*240 A.2.7 MJPEG @ 30fps / kbps...

  • Page 89: Storage Requirement Table - Help To Set Recording Storage System

    B. Storage Requirement Table - Help to set Recording Storage System. Please refer to the following table to find out the capability for recording into your hard disk. B.1 Mega Mode B.1.1 H.264 Storage Requirement GB / channel / day @ 15fps Quality 1280*1024 1280*720...
  • Page 90 B.1.4 MPEG4 Storage Requirement GB / channel / day @ 15fps Quality 1280*1024 1280*720 640*480 320*240 Excellent Detailed 58.1 Good 12.5 Standard Medium B.1.5 MPEG4 Storage Requirement GB / channel / day @ 10fps Quality 1280*1024 1280*720 640*480 320*240 Excellent 58.1 Detailed Good...
  • Page 91 Standard Medium B.2.2. H.264 Storage Requirement GB / channel / day @ 15fps Quality 640*480 320*240 Excellent 12.5 Detailed Good Standard Medium B.2.3. H.264 Storage Requirement GB / channel / day Frame-Rate Storage Image-Size Bitrate Setting Current Bitrate Setting Requirement 640*480 6144 6300...

  • Page 92: System Requirement - Help To Setup System

    640*480 2048 2200 182.6 640*480 45.7 640*480 45.7 320*240 6144 5100 423.3 320*240 6144 2800 232.4 320*240 2048 2200 182.6 320*240 2048 2200 182.6 320*240 45.7 320*240 45.7 C. System Requirement – Help to setup System C.1. 16 Channel IP Camera with CIF Performance Equipment Configuration Software: MainConsole Version 2.6.4 Professional...
  • Page 93 Results from Test with a Resolution of 704×480 CCD IPCamera 704x480 Quality Frame Rate CPU Load Bandwidth 16 IP camera Excellent 15~20 Mbps Results from Test with a Resolution of 640×480 CMOS IPCamera 640x480 Quality Frame Rate CPU Load Bandwidth 16 IP camera Excellent 10~15 Mbps...
  • Page 94 Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: Clause Description EN 60950-1: 2001...
  • Page 95 Español Por medio de la presente [nombre del fabricante] declara que el [clase de equipo] [Spanish] cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] [Greek] ΣΥΜΜΟΡΦΩΝΕΤΑΙ...
  • Page 96 Svenska Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de [Swedish] väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

  • Page 97: Federal Communication Commission Interference Statement

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
