TP-Link TL-SC3430 User Manual

H.264 megapixel surveillance camera
Hide thumbs Also See for TL-SC3430:
Table of Contents

Advertisement

Quick Links

TL-SC3430
H.264 Megapixel Surveillance Camera
Rev: 1.0.0
1910010424

Advertisement

Table of Contents
loading

Related Manuals for TP-Link TL-SC3430

Summary of Contents for TP-Link TL-SC3430

  • Page 1 TL-SC3430 H.264 Megapixel Surveillance Camera Rev: 1.0.0 1910010424...
  • Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

  • Page 3: Fcc Statement

    FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 4: Table Of Contents

    CONTENTS Package Contents......................1 Chapter 1 Safety Instruction ..................2 Chapter 2 Minimum System Requirement & Product Feature ........3 System Requirement ....................... 3 Product Features ........................3 Physical Overview ........................4 2.3.1 Front View ......................... 4 2.3.2 Bottom view ....................... 5 Chapter 3 Using IP Camera via Web Browser .............6 Obain the IP Address.......................
  • Page 5 7.1.3 Initialize ........................28 7.1.4 Language ........................ 29 Camera ..........................29 7.2.1 General........................30 7.2.2 H.264........................31 7.2.3 MPEG4 ........................33 7.2.4 MJPEG ........................35 7.2.5 3GPP ........................36 7.2.6 Advanced ........................ 37 7.2.7 Playback ........................38 Network..........................39 7.3.1 Information ......................
  • Page 6 B.1 Mega Mode ........................78 B.2 VGA Mode ........................80 C. System Requirement – Help to setup System ................. 82 C.1. 16 Channel IPCamera with CIF Performance..............82 C.2. 16 Channel IPCamera with D1 Performance ..............82 Europe – EU Declaration of Conformity.................83 Federal Communication Commission Interference Statement ........86...

  • Page 7: Package Contents

    Package Contents The follow items should be found in your package: TL-SC3430 H.264 Megapixel Surveillance Camera Power Adapter Mounting Bracket with three screws, a Lock Ring, a Brace and a Base Plate RJ45 Cable Quick Installation Guide Resource CD, including:...

  • Page 8: Chapter 1 Safety Instruction

    Chapter 1 Safety Instructions Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to heed the following.

  • Page 9: Minimum System Requirement & Product Feature

    Chapter 2 Minimum System Requirement & Product Feature 2.1 System Requirement For normal operation and viewing of the network camera, it’s recommended that your system meet these minimum requirements for proper operation: Item Requirements Pentium 4 2.8GHz (or equivalent AMD) Graphic Card 258 MB RAM graphic cards(or equivalent on-board graphic cards) Operating...

  • Page 10: Physical Overview

    Two-way (full / half duplex) with built-in microphone Audio Audio compression: G.711 μ law, a law, and AMR Instant Messenger Support MSN Live View Mobile Phone Live View Through 2.5 WAP, 3GPP, 3G Streaming, and 3G Browser Alarm Sending FTP Client / SMTP / Network Storage Security Passward Protecton / HTTPS encryption / IP Filter Alarm Buffer...

  • Page 11: Bottom View

    Built-in Microphone: The location where the voice from your partner comes out. 2.3.2 Bottom view Power Connector: The power connector is where you connect the power adapter. RESET: Please take the following steps to reset the camera to its defaults. Step 1.

  • Page 12: Chapter 3 Using Ip Camera Via Web Browser

    Chapter 3 Using IP Camera via Web Browser 3.1 Obain the IP Address Insert the provided CD into your CD-ROM driver. The Setup Wizard will automatically pop up on your computer’s screen as shown in the figure below. Figure 3-1 Choose the Intelligent IP Installer, and then the next screen appears.
  • Page 13 Figure 3-2 After the installation is finished, click Start > All Programs > TP-LINK >Intelligent IP Installer to start using the program. Figure 3-3 The following screen will then display. Click the Search button to search Network Cameras in the...

  • Page 14: Windows Web Browser

    Figure 3-4 3.2 Windows Web Browser Click Link to IE button in Figure 3-4 or launch your web browser, and enter the IP address or host name of the IP camera in the Location / Address field of your browser. Note: If you only want to view the video without accessing Setting screen, enter “http://<IP>/index2.htm”...

  • Page 15: Mac Web Browser

    The monitor image will be displayed in your browser. In the far left side of main configuration are Setting, Client Setting, and Image Setup. For more details, you can check Chapter 6.2、Chapter 6.3、Chapter 6.4 and Chapter 6.5. 3.3 Mac Web Browser Click the Safari icon, and enter the IP address of the IP camera in the Location / Address field of your browser.
  • Page 16 Enter the default account “admin” and default password “admin”.
  • Page 17 Note: The default user name “admin” and the password are set at the factory for the administrator. You can change them in the Account Menu (Please check “Setting → Basic → Security → Account”) The monitor image will be displayed in your browser. In the far left side of main configuration are Setting, Client Setting, and Image Setup.

  • Page 18: Chapter 4 Operating Ip Camera Via Mobile Phone

    Chapter 4 Operating IP Camera via Mobile Phone 4.1 Mobile Phone Viewing 4.1.1 3G Mobile Phone Streaming Viewing For 3G mobile phone viewing, type “rtsp://<IP>:<PORT>/video.3gp ” into your 3G Streaming Link. <IP> is the Public IP address of your IP camera; <PORT> is the RTSP port of your IP camera (Default value is 554.) Example: rtsp://100.10.10.1:554/video.3gp Note: You can also use RTSP clients (RealPlayer, VLC, QuickTime Player…etc.) to view RTSP streaming, just...

  • Page 19: Using Ip Camera Via Iphone

    4.2 Using IP Camera via iPhone You can use TP-LINK Web User Interface via iPhone. Please follow the setting process below. Then you can use TP-LINK Web UI via iPhone. 2. Enter IP address in your web link. 1. Select Safari function 3.

  • Page 20: Chapter 5 Msn Messenger

    Chapter 5 MSN Messenger (Supports up to Windows Live Messenger version 8089) Please see the following steps to set up the Messenger function. Application of a new MSN account: You can download MSN software freely and create a new MSN account (e.g. camera at home@msn.com) to use Microsoft Live Messenger. Login Account and Password: Go to Setting→Basic→Network→Messenger, set the Messenger to “On”.
  • Page 21 Privacy & User & Allow List: Choose “On” at the option of Privacy, then User column will appear and be able to build Allow List, so that only the users listed can access the camera via MSN. Log in Working Account: Use your working account to login in the Messenger software. And add the camera’s MSN account (camera at home@msn.com) as a contact.
  • Page 22 The Camera at home will show up with its Public IP and Private IP after sending a message of “Ping” in the lower key (if the option of IP Notification is “On”). Click the camera icon and select View a contact’s webcam to view the video.
  • Page 23 The IP Camera will accept your invitation; the live video will show up in the right screen after few seconds. 10. Click Action button and choose Start Control Panel to use control panel.
  • Page 24 11. The dialog box will show up with “This application is not part if Window Live Message…….” Tick the box of “Don’t show me this again” and click OK. 12. The IP Camera will accept your invitation to start Control Panel.
  • Page 25 13. You can click Camera icon to snapshot then the picture will send to you immediately. Snapshot 14. You can click paint palette icon showing up with tool bar to set up image. Then, you can use the tool bar to optimize video Brightness , Contrast , Saturation and Hue...
  • Page 26 Image Setup...

  • Page 27: Chapter 6 Configuration Of Main Menu

    Chapter 6 Configuration of Main Menu In the left side of main configuration are Setting, Client setting, Image setting. For more details, please check Chapter 6.2、Chapter 6.3、Chapter 6.4.、Chapter 6.5. In the right side, you can control Live View in your main Browser. The functions include: Snapshot, Open digital zoom, Audio, and Video Play.

  • Page 28: Digital Zoom In / Out The Image Via The Monitor Window

    6.1.2 Digital zoom in / out the image via the monitor window • Click to display the digital zoom in window. • Pull the to adjust the digital zoom range, and it will be showed on the above window. • Use the left click of your mouse to move to anywhere in the window area.

  • Page 29: Setting

    mean you can broadcast to the connected IP Mute off camera(s) via the Ethernet using your microphone Mute on mean you can’t broadcast to the connected IP camera(s) via the Ethernet using your microphone Volume control bar mean you can adjust the sound volume by the control bar 6.2 Setting This function is only for the Administrator.

  • Page 30: Client Setting

    6.3 Client Setting This function is only for the client. Click this button to control Mode, View Size, Protocol, and Video Buffer. 6.3.1 Mode Click the pull-down box to choose video compression mode of LIVE VIEW among H.264, MPEG-4, and MJPEG.

  • Page 31: Image Setup

    6.4 Image Setup The tool bar can be adjusted to optimize video Brightness, Contrast, Saturation and Sharpness. 6.4.1 Brightness The value range is 0~99. The higher value the brightness is, the brighter the image is. 6.4.2 Contrast The value range is 0~99. The contrast is a measure of a display system, defined as the ratio of white to black that the system is capable of producing.

  • Page 32: Chapter 7 Setting-Basic

    Chapter 7 Setting-Basic Click the Basic folder to display the sub folders including System, Camera, Network, and Security. 7.1 System Click the folder of System to display the sub-folders including Information, Date / Time, Initialize, and Language. 7.1.1 Information The Information screen provides the product factory information which includes Product Name, Firmware Version.

  • Page 33: Date / Time

    7.1.2 Date / Time The Date/ Time screen displays all options of time setting. Current Date / Time: This displays the current date and time of this IP Camera. PC Clock: This displays the date and time of the monitoring PC clock. Date / Time Format: You can click the pull down box to select different time display formats.

  • Page 34: Initialize

    Synchronize with NTP: Specify the NTP server name and the Refresh Interval to synchronize the date and time of this IP Camera with those of the time server, known as the NTP server. Time Zone: Select the Time Zone format of Greenwich Mean Time among different cities. The time display will be the same as the current date / time option.

  • Page 35: Language

    7.1.4 Language Upload Language Pack: Clicking “Browse” and selecting the file for updating, the present language display of WEB User Interface could be changed. A confirmation dialogue will appear. Click “OK”, then the update will be applied immediately. The default language is “English.” 7.2 Camera Click the folder of Camera to display the sub folders including General, H.264, MPEG4, MJPEG, 3GPP, Advanced and Playback.

  • Page 36: General

    7.2.1 General RTSP: The default value is 554. If the IP Cameras connected with router and installed outside are over 2 sets and all of them need support RTSP, please fill some value in the blank space in the range from 1024 to 65535. RTP Unicast Streaming: The default value of port range is 5000 ~ 7999 and can be changed from 1024 to 65535.
  • Page 37 H.264: H.264 provides higher compression rate than MPEG-4. Thus, H.264 can decrease the bandwidth usage and further apply on 3G. However, H.264 will occupy more system resources than MPEG-4. As long as the operating system appears operating difficulties under H.264 format, please change to select MPEG-4. Text Overlay: Some information can be showed on the display screen, such as Date / Time and user-defined text.
  • Page 38 network routers that can be passed before data arrives at its destination or is dropped) within which a multicast packet must reach its destination. Image Size: Specify the image size when the network camera transmits. Choose one among 1280 x 1024, 1280 x 720, 640 x 480, and 320 x 240. Frame Rate: Set the frame rate of H.264 image.

  • Page 39: Mpeg4

    7.2.3 MPEG4 Viewer Authentication: On: If the viewer authentication is On, the users will be requested to key-in username and password when using QuickTime Player to have live viewing. Off: If the viewer authentication is Off, you can have live viewing on computer by QuickTime Player after entering “rtsp://ip:port/video.mp4”...
  • Page 40 Note: The frame rate is up to 15 fps at 1280x1024, and up to 30 fps at 640x480. However, if you would like choose frame rate over 15 fps, the IMAGE SIZE of H.264/MPEG-4/MJPEG setting page has to been selected 320x240 or 640x480 at the same time. Quality: Auto: The quality and bitratee will be adjusted automatically according to the frame rate.

  • Page 41: Mjpeg

    7.2.4 MJPEG Viewer Authentication: On: If the viewer authentication is On, the users will be requested to key-in username and password when using QuickTime Player to have live viewing. Off: If the viewer authentication is Off, you can have live viewing on computer by QuickTime Player after entering “rtsp://ip:port/video.mjpg”...

  • Page 42: 3Gpp

    selected 320x240 or 640x480 at the same time. Quality: Auto: The quality and bit rate will be adjusted automatically according to the frame rate. Fixed Quality: Select the value of quality among Medium, Good, Delicate and Excellent. Fixed Bitrate: Set the bitrate of MJPEG image transmission for a line. You can select one among 64Kbps, 128Kbps, 256Kbps, 384Kbps, 512Kbps, 768Kbps, 1Mbps, 1.5 Mbps, 2 Mbps, 3 Mbps, 4 Mbps, 5 Mbps, and 6 Mbps.

  • Page 43: Advanced

    Note: The IP interval value means a RATIO of “ P-frame / I-frame “ in a certain section of frame sequences. The ratio lower, the live view clear. However, live view will lag if the bandwidth isn’t big enough. In this situation, you have to choose another bigger IP interval value to solve the problem.

  • Page 44: Playback

    Shutter Speed: The default value is 1/30 sec. and you can select the value among 1/4, 1/6, 1/12, 1/30, 1/60, and 1/120 sec. Gain: The default value is 2 and the value is adjustable among 0~9. It will influence the brightness of the image.

  • Page 45: Network

    Snapshot Mirror/ Flip Full Screen Increase Speed Volume Pause Decrease Speed Mute on / Mute off Stop Open Files Open Digital Zoom 7.3 Network Click the folder of Network to display the sub folders including Information, PPPoE, DDNS, UPnP, Bonjour, IP Notification and Messenger.

  • Page 46: Information

    7.3.1 Information Display the MAC address of the device. Obtain an IP address automatically (DHCP): If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server. Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically.

  • Page 47: Pppoe

    address of DNS server. Primary DNS server: Enter the IP address of the primary DNS server. Secondary DNS server: Enter the IP address of the secondary DNS server, if necessary. HTTP Port Number: Select 80 in general situations. If you want to use a port number other than 80, select the text box and enter a port number between 1024 and 65535.

  • Page 48: Ddns (Dynamic Dns)

    Primary DNS server: Enter the IP address of the primary DNS server. Secondary DNS server: Enter the IP address of the secondary DNS server. Note: PPPoE (Point-to-Point Protocol over Ethernet): PPPoE is a network protocol for encapsulating Point-to-Point Protocol frames insider Ethernet frames. PPPoE connection is used mainly with ADSL service where individual users connect to the ADSL transceiver (modem) over Ethernet work.
  • Page 49 Server Name: Choose the DDNS Server from the list. User ID: Enter the user ID for authentication necessary for DDNS connections. Type it up to 64 characters. Password: Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters.
  • Page 50 2. Input all information and follow step by step with DynDNS. 3. Login with new account and click Account → My Hosts → Add Host Services.
  • Page 51 4. Type domain in the Hostname field and select sub-domain. 5. After typing information, check your DDNS service...

  • Page 52: Upnp (Universal Plug And Play)

    6. Type your DDNS User ID, Password and Host name in Setting → Network → DDNS. After completing setting, reboot IP Camera. 7.3.4 UPnP (Universal Plug and Play) If you have a Router to access to internet and the Router supports UPnP IGD function, you need to turn on the UPnP Port Forwarding function.

  • Page 53: Bonjour

    HTTP Port: Enter the HTTP port number and default HTTP port is 80. SSL Port: Enter the SSL port number and default SSL port is 443. RTSP Port: Enter the RTSP port, default value is 554 for computer view. Note: UPnP (Universal Plug and Play): UPnP is a set of computer network protocol.

  • Page 54: Ip Notification

    Device Name: Enter Device Name you wish. Note: How to use Bonjour in your Windows Browser UI? Please check the link below: http://www.apple.com/support/downloads/bonjourforwindows.html 7.3.6 IP Notification Once IP Notification is set to "On", the camera will automatically send an e-mail notification to tell users its updated network parameters if the network settings about IP address, network connection type, HTTP port or wireless connection is changed or completed.
  • Page 55 Notify Type: You can select the notify type among DHCP, Static IP, and PPPoE. When the network settings related to the chosen notify type are changed, an e-mail notification will be sent to inform you of the updated network information of the camera. SMTP Server Name: Type the SMTP server name up to 64 characters, or the IP address of the SMTP server.

  • Page 56: Messenger

    SMTP: Select if SMTP authentication is necessary when an e-mail is sent. POP before SMTP: Select if POP before SMTP authentication is necessary when an e-mail is sent. POP server name: It is necessary when the POP before SMTP is selected in Authentication.
  • Page 57 Protocol: support MSN only. Login Account: Camera will use this account to login MSN server. This MSN account should be applied form http://www.msn.com. Password: password for this msn account. Re-type Password: re-type password to double confirm. Alias: This alias will display on MSN like the following which display in red frame. Port Range: Camera will select one port from this port range for video transmission.

  • Page 58: Security

    7.4 Security Click the folder of Security to display the sub folders including Account and HTTPS. 7.4.1 Account The device fault account and password setting is “admin / admin”. That means everyone who knows IP address can access the device including all configuration. It is necessary to assign a password if the device is intended to be accessed by others.

  • Page 59: Https

    The Operator mode can not only view the Live View but also control the PTZ (only for PTZ models). The Viewer mode only can view the Live View. Viewer Authentication: Select whether the authentication is needed when users access to live view.

  • Page 60: Ip Filter

    Note: When enable HTTPS with RTSP on mode, the IP Camera only protect the setting such as username and password and do not protect video and audio. When enable HTTPS with RTSP off mode, the IP Camera will protect all setting including video and audio. 7.4.3 IP Filter IP Filter provides the function of controlling the range of IP address, similar with firewall service.
  • Page 61 list. Allow Range List: Except the default range 0.0.0.0~255.255.255.255, the list allows to add four more sets of allow range at most. Deny Range: You can define the deny range by entering “Start IP address” and “End IP address” Deny Range List: You can define not more than five sets of deny range in the list.

  • Page 62: Chapter 8 Setting-Advanced

    Chapter 8 Setting-Advanced Click the folder of Advanced to display the sub folders including FTP client, SMTP, Network storage, Schedule, Alarm buffer, Motion detection, Audio detection, and System Log. 8.1 FTP Client Use this menu to set up for capturing and sending a image or video clip to an FTP server. By using FTP client function, you can send files which has been shot and recorded linked with the external sensor input or with the built-in motion detection function to FTP server.

  • Page 63: Alarm Sending

    FTP Server Name: Type the FTP server name to upload still images up to 64 characters, or the IP address of the FTP server. User Name: Type the user name for the FTP server. Password: Type the password for the FTP server. Retype Password: To confirm the password, type the same characters as you typed in the Password box.
  • Page 64 Remote Path: Type the path to the destination in FTP server up to 64 characters. Image File Name: Type the file name you want to assign to the files when sending to the FTP server. You can use up to 10 alphanumeric characters, - (hyphen) and _ (underline) for naming. Suffix: Select a suffix to add to the file name Date &...

  • Page 65: Periodical Sending

    Detection → Setting”) For more details, you can check Chapter 9.7. Network Link Down: Click it on to receive a snapshot or a video clip while network link down. If Attached File Type (go “Setting → Advanced → FTP Client → General” ) was clicked as video clip, you can use Alarm Buffer function as a sensor.

  • Page 66: Smtp

    consists of lower two-digits of year (2 digits), month (2 digits), date (2 digits), hour (2 digits), minute (2 digits) and second (2 digits), and consecutive number (2 digits), thus 14-digit number is added to the file name. Sequence number: A consecutive number is added to the Image file name. Sequence number clear: Click Clear and the suffix of the sequence number returns to 1.
  • Page 67 SMTP Server Name: Type the SMTP server name up to 64 characters, or the IP address of the SMTP server. SMTP Server Port: You can set port number from 1~65535 according to your mail server. The default value is 25. Security setting: Tick SSL box if the mail server you use has security restriction.

  • Page 68: Alarm Sending

    Recipient E-mail Address: Type the recipient e-Mail address up to 64 characters. You can specify up to three recipient E-mail addresses. Administrator E-mail Address: Type the Administrator e-Mail address up to 64 characters. This address is used for reply mail and sending system messages from the SMTP server. Attached File Type: You can choose snapshot or video clip for alarm sending.

  • Page 69: Periodical Sending

    File Attachment: Set whether an image file is attached to the mail sent or not. When On is selected, the image file made by the settings below is attached. When Off is selected, only the message is sent. Image File Name: Type the file name you want to assign to the file attached to a mail. You can use up to 10 alphanumeric, - (hyphen) and _ (underscore) for naming.

  • Page 70: Network Storage

    Image File Name: Type the file name of the image sent by SMTP up to 10 alphanumeric characters, - (hyphen) and _ (under score). Suffix: Select a suffix to be added to the file name sent by SMTP. Date & time: The date & time suffix is added to the Image file name. The date & time suffix consists of lower two-digits of year (2 digits), month (2 digits), date (2 digits), hour (2 digits), minute (2 digits) and second (2 digits), and consecutive number (2 digits), thus 14-digit number is added to the file name.

  • Page 71: General

    8.3.1 General Select On if you would like to use the network storage function. Then choose one protocol between Windows network (SMB/CIFS) and Unix network (NFS). Protocol- Unix Network (NFS): Network storage location: Type the IP or name of specified computer and folder. For example, //IP/folder name or // my_nas:/folder name.

  • Page 72: Alarm Sending

    Network Storage Location: Type the IP or name of specified computer and folder. For example, \\IP\folder name or \\my_nas:\folder name. Workgroup: Type the name of workgroup which the operating computer belongs. User Name: Type the name of workgroup. (If none, please leave it blank.) Password: Type the password for workgroup.
  • Page 73 Alarm Sending: Select On to set to send mail with connection to the alarm detection. Image File Name: Type the file name you want to assign to the file to attach a mail. You can use up to 10 alphanumeric, - (hyphen) and _ (underscore) for naming. Suffix: Select a suffix to add to the file name Date &...

  • Page 74: Periodical Recording

    recording video file in the IP CAM before and after disconnected network. Note: You can set alarm buffer at alarm buffer screen. (Please go “Setting → Advanced → Alarm Buffer → Setting”) For more details, you can check Chapter 9.5. Effective Period: Set the period when the periodical sending is effective.

  • Page 75: Schedule

    Cyclic Size: The total amount of files transmitted to the network storage location has to be in the range from 100 to 1024000MB. Recording Time: Set the period when the periodical recording is effective. Always: The periodical recording is always effective. Schedule: You can specify the period when the periodical recording is effective in the Schedule setting in the other section.

  • Page 76: Motion Detection

    Use alarm buffer function for recording audio and video file in the IP Camera before and after disconnected network. After re-connecting, these files will transmit to FTP client, SMTP, and Network storage. You can set the pre-alarm and post-alarm period up to 5 seconds in Alarm Buffer function screen.

  • Page 77: Audio Detection

    Threshold: It means the extent which the alarm will be triggered. The default value is 50 and the value range is 0~100. The larger the value, the higher the threshold. Sensitivity: It means that how often the sensor will scan the image different. The higher sensitivity it is and the more frequently it scans.

  • Page 78: System Log

    Click it on for using Audio Detection function as a sensor. You can set audio detection function at the audio detection function screen. Threshold: It means the extent which the alarm will be triggered. The default value is 50 and the value range is 0~100.
  • Page 79 Enable Remote Log: Enables user to send the log data to a specified log server.

  • Page 80: Chapter 9 Appendix

    Chapter 9 Appendix A. Frame-rate and Bitrate Table – Help to set IPCamera with your network environment to access Internet. Base on your network upload environment to choose the suitable Image-Quality setting. For example, if the network environment is ADSL 256Kb (upload) / 2Mb (download), the most fluent Image-Quality needs to set up under 256Kb situation.
  • Page 81 320*240 2048 2200 320*240 2048 2200 320*240 320*240 A.1.4. MPEG 4@ 15fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 2700 2000 Detailed 1100 Good Standard Medium A.1.5. MPEG4@ 10fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 1800 1400 Detailed Good Standard...

  • Page 82: Vga Mode

    A.1.7. MJPEG @ 15fps / kbps Quality 1280*1024 1280*720 640*480 320*240 Excellent 22000 16000 6000 2200 Detailed 12000 7000 3000 1200 Good 7000 5000 2500 1000 Standard 5500 4000 2000 Medium 4000 3000 1200 A.1.8. MJPEG@ 10fps / kbps Quality 1280*1024 1280*720 640*480...
  • Page 83 Good Standard Medium A.2.2 H.264@15 fps / kbps Quality 640*480 320*240 Excellent Detailed Good Standard Medium A.2.3 H.264 / kbps, fps Frame-Rate Current Image-Size Bitrate Setting Current Bitrate Setting Frame-Rate 640*480 6144 6300 640*480 6144 6300 640*480 2048 2200 640*480 2048 2200 640*480...

  • Page 84: Storage Requirement Table - Help To Set Recording Storage System

    640*480 2048 2200 640*480 2048 2200 640*480 640*480 320*240 6144 5100 320*240 6144 2800 320*240 2048 2200 320*240 2048 2200 320*240 320*240 A.2.7 MJPEG @ 30fps / kbps Quality 640*480 320*240 Excellent 13000 4500 Detailed 6500 2500 Good 5000 2000 Standard 4000 1600...
  • Page 85 Excellent Detailed 16.6 Good Standard Medium B.1.2 H.264 Storage Requirement GB / channel / day @ 10fps Quality 1280*1024 1280*720 640*480 320*240 Excellent 22.5 Detailed 12.5 Good Standard Medium B.1.3 MPEG4 Storage Requirement GB / channel / day Image-Size Bitrate Setting Frame-Rate Setting Storage Requirement 1280*1024 6144...

  • Page 86: Vga Mode

    B.1.5 MPEG4 Storage Requirement GB / channel / day @ 10fps Quality 1280*1024 1280*720 640*480 320*240 Excellent 58.1 Detailed Good Standard 12.5 Medium B.1.6 MPEG4 Storage Requirement GB / channel / day Image-Size Quality Setting Frame-Rate Setting Storage Requirement 1280*1024 6144 431.6 1280*1024...
  • Page 87 Standard Medium B.2.3. H.264 Storage Requirement GB / channel / day Frame-Rate Storage Image-Size Bitrate Setting Current Bitrate Setting Requirement 640*480 6144 6300 522.9 640*480 6144 6300 522.9 640*480 2048 2200 182.6 640*480 2048 2200 182.6 640*480 45.7 640*480 45.7 320*240 6144 6300...

  • Page 88: System Requirement - Help To Setup System

    320*240 45.7 C. System Requirement – Help to setup System C.1. 16 Channel IPCamera with CIF Performance Equipment Configuration Software: MainConsole Version 2.6.4 Professional CPU: Intel Core 2 Quad Q6600 @ 2400 MHz Memory: 1024 MB (2 x 512 DDR2-SDRAM ) Ethernet: Marvell Yukon 88E8052 PCI-E ASF Gigabit Ethernet Controller...

  • Page 89: Europe - Eu Declaration Of Conformity

    Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: Clause Description EN 60950-1: 2001...
  • Page 90 [Spanish] cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] [Greek] ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Français Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est [French]...
  • Page 91 direktiv 1999/5/EG.

  • Page 92: Federal Communication Commission Interference Statement

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
