Matrix Keyboard
ADTTE
Operator's Manual
8000-2675-02 Rev. D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix Keyboard and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dynamics Matrix Keyboard

Summary of Contents for American Dynamics Matrix Keyboard

  • Page 1 Matrix Keyboard ADTTE Operator’s Manual 8000-2675-02 Rev. D...
  • Page 3 ADTTE Matrix Keyboard Operator’s Manual...
  • Page 4 Our dealers are fully empowered to provide the very best in customer service and support. Dealers should contact American Dynamics at (800) 507–6268 or (561) 912-6259 or on the web at www.americandynamics.net.

  • Page 5: Table Of Contents

    Using This Manual...v Text Conventions ...v Related Documents... vi Support Services ... vi CHAPTER 1: ADTTE MATRIX KEYBOARD OVERVIEW... 1-1 Keypad Overview ... 1-2 CHAPTER 2: GETTING STARTED... 2-1 LCD Display Overview ... 2-1 Understanding the Keyboard Lock Feature ... 2-2 Working with Passwords ...
  • Page 6 N O T E S : ADTTE Matrix Keyboard Operator's Manual...

  • Page 7: Preface: Before You Begin

    Before You Begin The Operator's Manual explains the features, operation, and application of the ADTTE Touch Tracker matrix keyboard (ADTTE matrix keyboard). It explains the tasks that can be performed when using this product as part of your system. Using This Manual This manual is organized as follows: Chapter 1: ADTTE Matrix Keyboard Overview describes the keyboard and its use.

  • Page 8: Related Documents

    If you have a question about controller operation and cannot find the answer in this • manual, consult with your supervisor. If you experience a problem with the ADTTE matrix keyboard, contact the dealer • through whom you originally purchased this product for service or support.

  • Page 9: Chapter 1: Adtte Matrix Keyboard Overview

    C H A P T E R 1 ADTTE Matrix Keyboard Overview The ADTTE matrix keyboard (Touch Tracker) is a video control station that provides the same functions as the AD2079 System Keyboard. It is compatible with all current models of American Dynamics switches.

  • Page 10: Keypad Overview

    8. Lock button toggles the state of the keyboard lock when used with the password. See Chapter 2 for specific instructions. When used with camera selection, this button toggles the camera control lock. See Chapter 3 for specific instructions. ADTTE Matrix Keyboard Operator's Manual...
  • Page 11 See Chapter 3 for more information. This button also serves as the Page Down function during menu programming. ADTTE Matrix Keyboard Overview 16. Iris Close (PG-UP) button adjusts the brightness of a scene by allowing less light into the camera controlled by the keyboard.
  • Page 12 See the system operating instructions for additional information. This button also serves to set the baud rate and display the firmware version of the keyboard. For more information, see Chapter 4. ADTTE Matrix Keyboard Operator's Manual...

  • Page 13: Chapter 2: Getting Started

    C H A P T E R 2 Getting Started This chapter provides an overview of the fields displayed on the LCD. It explains how to determine if the keyboard lock is enabled, as well as providing instructions for locking or unlocking the keyboard. It also explains how to set or change the user-defined password.

  • Page 14: Understanding The Keyboard Lock Feature

    Understanding the Keyboard Lock Feature The keyboard lock feature prevents unauthorized use of the matrix keyboard advanced features. When “L” appears in the lower right corner of the LCD, operators cannot access certain system features. The features that cannot be accessed are...

  • Page 15: Working With Passwords

    Working with Passwords Passwords allow you to limit access to advanced features of the ADTTE matrix keyboard, such as arming/disarming monitors and the dual function menu programming keys. Passwords may be 1 to 4 digits in length and may be any number between 0-9998.
  • Page 16 N O T E S : ADTTE Matrix Keyboard Operator's Manual...

  • Page 17: Chapter 3: Everyday Tasks

    C H A P T E R 3 Everyday Tasks This chapter describes everyday tasks that users can perform with the matrix keyboard. It explains how to control the zoom, focus, and iris settings for the selected camera. It explains how to program and recall Shots and Patterns to simplify surveillance activities.

  • Page 18: Controlling Cameras

    Each camera installed at your facility has a unique identification number. To control a camera, you must first select the camera with the matrix keyboard. Then you can control the zoom, focus, iris, pan and tilt of the selected camera. Figure 3-1 identifies the location of the pan/tilt, zoom and focus controls on the matrix keyboard.
  • Page 19 Figure 3-3: Controlling diagonal camera movement. For cameras that support the variable speed features of the matrix keyboard, the speed that the camera moves is proportional to how far the Tracker Ball moves from its center position. If the Tracker Ball moves slightly to the right, the camera pans slowly to the right.
  • Page 20 To brighten the picture, press the Iris Open button. To darken the picture, press the Iris Close button. The Iris Open and Iris Close buttons are located to the right of (Camera button). Zoom In Focus Far Focus Near ADTTE Matrix Keyboard Operator's Manual...
  • Page 21 I M P O R T A N T The matrix keyboard itself provides no visual indicator that a camera has been locked. However, the keyboard produces an audible tone if an attempt is made to move the locked camera on all but the original keyboard—if audible alerts are enabled.

  • Page 22: Working With Shots

    (located next to lower right corner of LCD) to switch the keyboard Shot function to “recall” mode. Use the Shot button to call up the preset shots that have been defined for cameras. (Camera button) to select the ADTTE Matrix Keyboard Operator's Manual...

  • Page 23: Working With Patterns

    To display a preset shot: 1. Enter the camera number and press 2. Enter the shot number and press Shot. The camera immediately points to the preset shot, and adjusts zoom and focus automatically. Working with Patterns I M P O R T A N T The procedures discussed in this section are supported by the AD168 Matrix Switcher / Controller System equipped with a Control Code Module (CCM).
  • Page 24 • Press Ack to run the pattern repeatedly. The pattern automatically restarts when it finishes. To stop the repeating pattern, issue a camera command (pan, tilt, zoom, focus or iris open/close). (Camera button). (Camera button). ADTTE Matrix Keyboard Operator's Manual...
  • Page 25 Holding Patterns When you place a pattern on “hold”, you cause the pattern to move to its starting position and wait until you are ready to run it. To hold a pattern, do the following: 1. Enter the monitor number and press show the pattern.

  • Page 26: Running Monitor Tours

    Next and Last buttons to manually step through the series of cameras in the tour. To restart the tour, press Run. Because the matrix keyboard works with all current models of American Dynamics switches, you should refer to the system operating instructions for more information about setting up and running monitor tours.

  • Page 27: Acknowledging Alarms

    An auxiliary is a device, such as a light, audible alarm, or door lock, that can be controlled using the matrix keyboard. Auxiliaries may also be initiated automatically in response to an alarm. The Auxiliary On and Auxiliary Off buttons are used to control the operation of both momentary and latched auxiliaries.

  • Page 28: Viewing Satellite Sites

    Site button accesses the satellite sites. Because the keyboard works with all current models of American Dynamics switches, you should refer to the appropriate operating instructions for more information about using the Site feature.

  • Page 29: Chapter 4: Utilities And Advanced User Tasks

    • Adjusting Key Click Volume ...4-5 • Setting Key Click Sound On / Off ...4-5 • Selecting the Language The LCD information on your matrix keyboard can be displayed in a number of languages, including: English • German • French •...

  • Page 30: Arming / Disarming Monitors

    1. Enter the monitor number and press 2. Enter the display/clearance type, then press the Mon Arm Off button. For more information about arming/disarming monitors or Alarm Tours, refer to the matrix switcher operating instructions. (Monitor button). (Monitor button). ADTTE Matrix Keyboard Operator's Manual...

  • Page 31: Displaying The Switching System Main Menu

    For information about the locations of the dual function buttons, refer to Chapter 1, ADTTE Matrix Keyboard Overview. For information about what tasks can be performed from the main menu, refer to the appropriate system's operating instructions.

  • Page 32: Displaying The Firmware Version

    2. Press Clear to refresh the LCD display. Setting the Baud Rate The matrix keyboard supports four baud rates: 1200, 2400, 4800, and 9600 baud. The default setting for the baud rate is 1200. I M P O R T A N T If you set the baud rate incorrectly, the keyboard will not operate.

  • Page 33: Adjusting Lcd Backlighting

    Adjusting LCD Backlighting To adjust the LCD backlighting: 1. Enter 1 and press Config. 2. Use the + and – buttons (located to the right of the LCD) to adjust the backlighting. • Press + to make the LCD backlighting brighter. •...
  • Page 34 N O T E S : ADTTE Matrix Keyboard Operator's Manual...

  • Page 35: Appendix A: Software License Agreement

    A P P E N D I X A Software License Agreement 1. General. Software is being licensed to the Customer pursuant to the following terms and conditions, which supplement any purchase or lease agreement (the "Equipment Agreement") between Customer and Sensormatic Electronics Corporation ("SEC").
  • Page 36 STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES, SO THE ABOVE EXCLUSION DOES NOT APPLY IN SUCH STATES. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. Customer will maintain the Software and ADTTE Matrix Keyboard Operator's Manual SOME...
  • Page 37 SEC AND ITS SUPPLIERS, EMPLOYEES, AGENTS AND FRANCHISEES WILL IN NO EVENT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL OR OTHER DIRECT OR INDIRECT DAMAGES (FOR LOSS OF BUSINESS INFORMATION OR PROFITS OR OTHERWISE) SUFFERED BY CUSTOMER, ANY OF ITS EMPLOYEES OR AGENTS OR ANY OTHER PERSON ARISING OUT OF OR IN CONNECTION WITH THE USE OR INABILITY TO USE THE SOFTWARE OR THE DOCUMENTATION, OR THE MAINTENANCE OR SUPPORT THEREOF, EVEN IF THEY HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
  • Page 38 N O T E S : ADTTE Matrix Keyboard Operator's Manual...

  • Page 39: Glossary

    G L O S S A R Y alarm The system's response when a camera input changes from its normal state to its abnormal state (if the system has been configured to respond to such a condition). When an alarm is triggered, the keyboard beeps until you acknowledge the alarm via the Ack button.
  • Page 40 The utilities are accessed via special keystrokes. zoom To adjust the magnification of the camera lens to make an object appear closer (larger) or farther away (smaller). Glossary-2 ADTTE Matrix Keyboard Operator's Manual...
  • Page 41 I N D E X – A – Alarms acknowledging, 3-11 Arming monitors, 4-2 Auxiliaries controlling, 3-11 – B – Backlighting how to adjust, 4-5 Baud Rate setting / changing, 4-4 values supported, 4-4 – C – Camera controlled by Touch Tracker, 2-1 Camera field, 2-1 Cameras...
  • Page 42 Utilities arming / disarming monitors, 4-2 baud rate, 4-4 firmware version, 4-4 Index-2 language set up, 4-1 main menu, 4-3 – V – Volume adjusting key click volume, 4-5 ADTTE Matrix Keyboard Operator's Manual – Z – Zoom button, 3-4...
  • Page 44 Please visit our website for more information www.americandynamics.net © 2004 Sensormatic Electronics Corporation Product specifications subject to change without notice. Certain product names mentioned herein may be trade names 8000-2675-02 D and/or registered trademarks of other companies.
