  • Page 1: User Guide

    Installation User Guide Range CornuFé 1908 - 36"...
  • Page 3 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS WARNING: F THE INFORMATION ON THIS MANUAL IS NOT FOLLOWED EXACTLY A FIRE ELECTRIC SHOCK OR EXPLOSION MAY RESULT CAUSING PROPER TY DAMAGE PERSONAL INJURY OR DEATH —...
  • Page 4 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS This book contains many important safety messages. Always read and obey all safety messages. Installer: Leave these instructions with the appliance WARNING: NEVER use this appliance as a space heater to heat or warm the room.

  • Page 5: Important Safety Instructions

    This appliance is not intended for use by persons (including children) with redu- ced physical, sensory or mental capabilities, or lack of experience and knowled- ge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS u Purchaser of this appliance must post in a prominent location instruction to be fol- lowed in the event the user smells gas. This information shall be obtained by consul- ting your local gas supply company.
  • Page 7 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS u Leak testing of the appliance shall be conducted according to the manufacturer’s instructions. u The inlet gas supply pressure to the appliance must be within the following limits: u Keep this manual for future reference.
  • Page 8 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS u Use Only Dry Potholders or Oven Gloves - Moist or damp potholders on hot surfaces may result in burns from steam. Never let a potholder touch hot heating elements.
  • Page 9 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS store explosives, such as aerosol cans, on or near the appliance. Flammable materials may explode and result in fire or property damage. u Keep oven vent ducts unobstructed. u Placement of Oven Racks - Always place oven racks in desired location while oven is cool.
  • Page 10 Read all instructions before using this appliance. Save these instructions for future reference. MPORTANT AFETY NSTRUCTIONS Exposure to these substances can also be minimized by properly venting with an open window or using a ventilation fan or hood. To reduce the risk from substances in the fuel or from fuel combustion make sure this appliance is installed, operated, and maintained according to the instructions in this booklet.

  • Page 11: Table Of Contents

    CONTENTS ONTENTS IMPORTANT SAFETY INSTRUCTIONS ....................1 DESCRIPTION ................................ 13 1. General description ..........................13 2. Dimensions ............................13 3. Energy power and gas flow rates ....................... 14 4. Power ratings for the electrical elements ..................14 5. Rating plate ............................14 BEFORE DELIVERY .............................
  • Page 12 Dear Customer, Please complete the appliance details below and keep them safe for future reference – this information will enable us to accurately identify your particular appliance and help us to help you. Filling this in now will save you time and inconvenience if you later have a problem with your appliance.
  • Page 13 Xavier Dupuy President and Managing Director...
  • Page 14 DESCRIPTION Installation and User Guide CornuFé 1908 - 36" - USA / Can 08NOTINSTALFE8/USA-1...

  • Page 15: Description

    ESCRIPTION 1. G ENERAL ESCRIPTION CornuFé 1908 - 36" model: FE8XXG0UR1 XX may be replaced by letters or figures. Model consisting of one large vaulted gas oven fitted with an electric grill and a cooktop with 5 gas burners. 2. D...

  • Page 16: Energy Power And Gas Flow Rates

    DESCRIPTION 3. E NERGY OWER AND ATES The gas used can be either natural gas or propane, depending on availability. Refer to pages 40 – 43 for information about adapting your range to the various types of gas. The table below summarize for each gas type and for each burner the gas input ratings (energy power in BTU/hr).

  • Page 17: Before Delivery

    BEFORE DELIVERY EFORE DELIVERY In order to be able to install your appliance as soon as it is delivered, you will have to check that the layout of your kitchen and your gas and electricity supplies are ready for it. All gas and electrical installations must comply with the standards and current regulations, as well as with the requirements of local gas and electricity suppliers.

  • Page 18: Electrical Supply

    BEFORE DELIVERY Fig. 1 To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above the surface units should be avoided. Any element, either an extraction hood or cabinet, situated directly above the range must be made of non-combustible material and placed at no less than 30"...

  • Page 19: Gas Supply

    BEFORE DELIVERY Voltage: 240 V a.c., single-phase, 3 wire system / 60 Hz Power: 2575 W; Intensity: 11 A Wire section: 2 mm / N° AWG 14 Check the power rating at your electric meter (maximal load) to ensure that it is suitable for your model, taking into account all other electrical appliances installed on the same circuit.

  • Page 20: Handling And Installation Instructions

    HANDLING AND INSTALLATION INSTRUCTIONS ANDLING AND NSTALLATION NSTRUCTIONS 1. U NPACKING THE OOKER Do not take any packaging off the cooker until it is directly in front of the place it is to be installed (unless it will not fit through a door in its outer packaging). 2.

  • Page 21: Fitting The Handrail

    HANDLING AND INSTALLATION INSTRUCTIONS 4. F ITTING THE HANDRAIL The handrail is supplied as 2 end pieces with grub screws, 2 plastic friction cups and the rail tube (Fig. 4). Fig. 4 Hold a friction cup by the tabs on one end of the tube. Fit one of the end pieces to the tube and push it on the tube over the friction cup (Fig.

  • Page 22: Height Adjustment And Positioning The Cooker

    HANDLING AND INSTALLATION INSTRUCTIONS 7. H EIGHT ADJUSTMENT AND OSITIONING THE OOKER In order to make sure that the cooktop is perfectly horizontal, especially on old flooring, we advise you to install your stove on a wooden or cement base, the height of which will allow you to bring the cooktop to a level in accordance with its environment or your own requirements.

  • Page 23: Installation Of An Anti-Tip Device

    HANDLING AND INSTALLATION INSTRUCTIONS 8. I NSTALLATION OF AN EVICE WARNING THE ANTI-TIP DEVICE SUPPLIED WITH THE RANGE MUST BE CORRECTLY FIT- TED WHEN THE APPLIANCE IS INSTAL- LED. THIS WILL REDUCE RISK OF TIP- PING OF THE APPLIANCE FROM ABNORMAL USAGE OR BY EXCESSIVE LOADING OF THE OVEN DOOR.
  • Page 24 HANDLING AND INSTALLATION INSTRUCTIONS Drill a 3.5 mm diameter hole in the timber floor and screw the stud directly into the floor. Where the floor consists of tiles, concrete or another hard material, drill a 10 mm diameter hole, push in the plug and screw the stud into it.

  • Page 25: Connections

    CONNECTIONS Attach the chain to the stud with the help of the snap hook. Ensure that everything is properly secured. Slot the drawer back in, ensuring that the stops on each side maintain it firmly against the guide rails. ONNECTIONS This appliance must be installed by a qualified La Cornue professional in accordance with the current regulations in the country where the appliance is installed.

  • Page 26: Electrical Connections

    CONNECTIONS 1. E LECTRICAL CONNECTIONS The appliance must be electrically installed and grounded in accordance with local codes or in the absence of such codes with the latest edition of the "National Electrical Code", ANSI/NFPA 70 in the USA, and CSA C22.2 "Canadian Electrical Code" - in Canada. Disconnect all the power supply circuits before accessing the junction boxes.
  • Page 27 CONNECTIONS 2. Now the terminal block is accessible Terminal block 3. The appliance is shipped with a strain relief device to secure power cord. Insert the power cord through the strain relief and tighten it. 4. Insert the strain relief device into the hole and push it to the left. Tight up the power cord and strain relief device with the screw.

  • Page 28: Gas Connection

    CONNECTIONS 2. G AS CONNECTION The installation of your La Cornue appliance must conform with local codes or, in the absence of local codes, in the USA with the "National Fuel Gas Code", ANSI Z223.1, latest edition, and, in Canada, with CAN/CGA - B149.1, and CAN CGA - B149.2, "Installation Code for Gas Burning Appliances".
  • Page 29 CONNECTIONS Never use an old connector when installing a new range. If the hard piping method is used, you must carefully align Male threaded fitting, the pipe; the range cannot be moved after the connection thread is made. To prevent gas leaks, put pipe joint compound on, 1/2 NPT or wrap pipe thread tape with around, all male...

  • Page 30: Instructions For Use

    INSTRUCTIONS FOR USE NSTRUCTIONS IMPORTANT Please make sure your cooker is unpacked completely before use. Remove all tape and packaging. Make sure the burners are properly placed and level. Take the accessory pack out of the oven. Check to be sure that no parts have come loose during shipping. INITIAL IGNITION Defuse any trapped air from the gas network, starting with each of the burners on the cooktop.
  • Page 31 INSTRUCTIONS FOR USE · Low setting: this is achieved by rotating the knob fully to the left or to the bottom (fig. 12). · Shutoff: bring the knob back to its vertical position by rotating it to the right. In case the burner flame is accidentally turned off, close the burner control knob and do not turn on the burner for at least one minute.

  • Page 32: Starting With The Oven

    INSTRUCTIONS FOR USE 2. S TARTING WITH THE OVEN 2.1. Gas oven with electronic ignition The simmerstat C switches on the heating element on the vault of the oven (grill), the thermostat B switches on the gas burner. The simmerstat and the thermostat are both equipped with indicator lights.
  • Page 33 INSTRUCTIONS FOR USE 2.3. Oven trays There are several different trays in your oven: 1) The large tray with an enameled coating and the pastry tray. Thes are intended exclusively for pastry-making or for ingredients to be grilled under the electric oven grill. The large size of thes trays means that it can be used as a cooking tray itself but is generally used for very large pieces of meat.

  • Page 34: The Cooking Principle

    INSTRUCTIONS FOR USE 3. T HE COOKING PRINCIPLE In the case of natural convection, the heat is generated from below the oven floor and then travels up along the walls of the oven and along the vault. This air flow creates a homogeneous atmosphere in which food is cooked and the temperature also stays very stable.
  • Page 35 INSTRUCTIONS FOR USE Of course, it can also be used for making excellent pastries, pies, quiches and vegetable dishes: the choice of rack level and temperature required calls for just a little more thought. When roasting, whether lamb, turkey, pork or large fish, place the oven rack on the lowest level of the oven.

  • Page 36: Upkeep Of A Cornufé 1908 - 36" Cooker

    UPKEEP Th 1 meringues, rock cakes, petits fours, meringue pies, braised meat, casseroles, braised beef stew Th 2 braised vegetables, sponge fingers, sponge cake, Savoie cake Th 3/4 caramel custard, pudding, macaroons, choux pastry, soufflés, large brioche, cakes, finger biscuits, white meat Th 5/6 large pieces of flaky pastry, tarts, flans, white meat roasts, croissants, fish, gratins Th 7/8 red meat roasts, very rare game Th 1 = 100 / 125 °C (210 / 260 °F)

  • Page 37: Finishes

    UPKEEP Bright coloured enamel fronts Because the enamel is vitrified, you can use a window-cleaning product on a paper towel. As fat may splash and splatter when an oven overheats, use an "Ajax Cream" type product and a sponge for cleaning. Enhanced results can be obtained by using window cleaning products. Stainless steel front panel For routine cleaning, use a special stainless steel cleaning product on a piece of paper towel.

  • Page 38: The Cooktop

    UPKEEP 3. T OOKTOP As your cooker is made up of a number of different elements, we recommend applying a cleaning procedure adapted to each specific case. However, it should be noted that, once you have memorized a few "tips", the maintenance of "La Cornue"...

  • Page 39: The Oven

    UPKEEP Depending on how often you use your stainless steel fittings, thorough cleaning may be necessary to restore them to their initial splendour. To do this, use scouring cream or special powder for stainless steel. After thoroughly removing any baked-on grease from the steel, rinse with clean water. 4.
  • Page 40 UPKEEP Finally, we recommend making a list of all the cleaning products needed for your cooker, all of which are available at a shop near you: For my hob ................................For my oven ................................For my front panel .............................. For my finishes ..............................and, of course, cloths, paper toweling, etc...

  • Page 41: Maintenance

    u Keep appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. u Do not obstruct the flow of combustion and ventilation air u Contact the factory representative to perform maintenance and repairs. u Clean appliance regularly, including special oven surfaces, with recommended cleaning agents. Installation and User Guide CornuFé...

  • Page 42: Conversion To Propane Gas

    Orifices CONVERSION TO PROPANE GAS A conversion kit for Propane gas is supplied with the range. conversion must be performed by a qualified LP gas installer. After conversion the installation must comply with the relevant regulations and also the local electricity supply company require- ments.
  • Page 43 Orifices CONVERSION TO PROPANE GAS The design below shows the location of the orifice for the open top gas burners. Orifices of gas burner are replaced by means of this sequence: 1. Remove the brisk heat grill. 2. Remove the burner head 3.

  • Page 44: Adjustments Of The Top Burner Low Flame Settings

    Bypass screw CONVERSION TO PROPANE GAS Only the low settings for the open top burners can be adjusted by means of the following procedure: 1. Pull off all the control knobs (1). 2. Open oven door and remove the 5 fixing screws (3 screws "a"...

  • Page 45: Gas Pressure Regulator

    Pressure Regulator CONVERSION TO PROPANE GAS The gas pressure regulator is always converted in the following sequence: 1. Remove the 4 fixing screws (a) and pull off the back panel (1). The regulator is now accessible. 2. The regulator has a bayonet mounted top cap. Using a small coin press in and turn the cap to remove it.

  • Page 46: Converting For High Altitude

    Oven Light MAINTENANCE If the range is to be used above 5,000ft (1,500m) the burner orifices must be changed. This conversion must be performed by a qualified gas installer. Read the instructions before converting this appliance. Failure to convert the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.

  • Page 47: Electrical Diagrams

    Electrical diagrams MAINTENANCE BURNER BURNER BURNER BURNER BURNER 14 kV 240 V a.c. Installation and User Guide CornuFé 1908 - 36" - USA / Can 08NOTINSTALFE8/USA-1...

  • Page 48: Gas Oven Wiring - Electronic Ignition

    Electrical diagrams MAINTENANCE Grill Pressure Gas inlet regulator Burner Installation and User Guide CornuFé 1908 - 36" - USA / Can 08NOTINSTALFE8/USA-1...

  • Page 49: Warranty

    WARRANTY YEARS La Cornue company warrants to the original user that performance is effected, within 50 miles from for a period of three years from date of delivery not an office of a qualified service agency of Company to exceed 42 months from date of shipment by except that such obligation to bear labor charges Company that the product(s) manufactured by shall not apply to products or parts installed outside...

  • Page 50: Address

    Address ADDRESS 14, rue du Bois du Pont - Z.I. les Béthunes 95310 Saint-Ouen l'Aumône - FRANCE Phone: + 33 (0)1 34 48 36 36 - Fax: + 33 (0)1 34 64 32 65 La Cornue SAS - B.P. 99006 95070 Cergy Pontoise Cedex - FRANCE e-mail: a.table@la-cornue.com 185 Park Lane, Brisbane, CA 94005 - USA...
