5.2 Basic Setup

EN
5.2.1 Video Setup
5
This chapter shows you how to setup the video output of the player. You have to setup
the player's video output mode to correspond to the video input mode of your TV.
When you do not see a normal screen after connecting video cable, check
the following:
1. "TV "– Switch to Video Input Mode: Turn on TV, and switch to video input
mode same as video connection. See TV user manual.
2. "Player" – Switch to Video Output Mode: Press "VIDEO" button repeatedly.
Whenever "VIDEO" is pressed, the video output signal is changed.
3. After you see normal screen, you have to save video configurations of
the player.
TTV Video
Input Mode
Normal Video
S-Video
Component 480i
Component 480p
Component 720p
Component 1080i
NTSC, PAL : Standard of TV Output. Select the corret one for use in your
country.
60
Player Video
Output Mode
TV Out: NTSC C/S-Video
(HD Component OFF)
TV Out: PAL C/S-Video
(HD Component OFF)
TV Out: NTSC C/S-Video
(HD Component OFF)
TV Out: PAL C/S-Video
(HD Component OFF)
TV Out: NTSC C/YPbPr
(HD Component OFF)
TV Out: PAL C/YPbPr
(HD Component OFF)
HD Component Out On 480p
HD Component Out On 720p
HD Comp onent O ut O n
1080i
Connection Jack
of TV, Player
CVBS or Composite
Jack
(Generally Yellow
Jack)
S-Video Jack
Component 3 Jack
* Y(Green), Pb(Blue),
Pr(Red)
Video Cable Type
Yellow RCA Cable
(Supplied)
S-Video Cable
* Black rounded
Component Cable
* Y(Green), Pb(Blue),
Pr(Red)
