Sharp PGLX2000 Quick Manual

Model Shown: PGLX2000
Portable and affordable, these 3D Ready BrilliantColor™ DLP® projectors deliver high image quality and superb reliability
for classroom, meeting room and small office use. With 2,800 lumens and 2,000:1 contrast ratio, these models provide
exceptionally vibrant and realistic image reproduction. The sealed DLP chip with filter-free design helps ensure low
maintenance and operating costs. Built in an ISO 14001 certified factory with standby power consumption as low as
0.5W and estimated lamp life of up to 5,000 hours (in eco mode), these lightweight RoHS compatible projectors are
an environmentally conscious choice.
3D Ready. Incorporating DLP Link™ technology, when used with
compatible 3D field sequential content and active shutter 3D glasses
(not included) that support the DLP Link system, these projectors
captivate audiences with breathtaking 3D imagery. (Please refer
to product operation manual for more specific 3D compatibility
information.) When not being used for 3D projection, these models
offer full compatibility with traditional "2D" content.
High Brightness and Contrast with 2,800 lumens and 2,000:1
contrast ratio.
BrilliantColor DLP Technology and 5-Segment Colour Wheel
for superior colour accuracy and more realistic image reproduction.
Sealed DLP Chip with Filter-Free Design for lower maintenance
and operating costs.
Easy setup and Operation with "Quick-Start" on-screen setup
guide, 1.2x optical zoom lens, and vertical keystone correction
directly accessible from the remote.
Built-in Closed Caption Decoder with black and white text
for easy readability.
Screen Size and Projection Distance
4:3 Signal Input (Normal Mode)
Picture (Screen) Size Projection distance [L]
Diag. [x] Width Height Minimum [L1]
300'' 240'' 180'' 38' 9"
200'' 160'' 120'' 25' 10"
150'' 120'' 90'' 19' 5"
120'' 96'' 72'' 15' 6"
100'' 80'' 60'' 12' 11"
80'' 64'' 48'' 10' 4"
60'' 48'' 36'' 7' 9"
40'' 32'' 24'' 5' 2"
16:9 Signal Input (16:9 Mode)
Picture (Screen) Size Projection distance [L]
Diag. [x] Width Height Minimum [L1]
300'' 261'' 147'' 42' 3"
200'' 174'' 98'' 28' 2"
150'' 131'' 74'' 21' 2"
120'' 105'' 59'' 16' 11"
100'' 87'' 49'' 14' 1"
80'' 70'' 39'' 11' 3"
60'' 52'' 29'' 8' 5"
40'' 35'' 20'' 5' 8"
Note: Allow a margin of error in the values in the diagrams above.
PGLX2000
Distance from the lens center to
the bottom of the image [H]
Maximum [L2]
46' 5" 6 23/32"
30' 11" 4 31/64"
23' 3" 3 23/64"
18' 7" 2 11/16"
15' 6" 2 15/64"
12' 5" 1 51/64"
9' 3" 1 11/32"
6' 2" 0 57/64"
Distance from the lens center to
the bottom of the image [H]
Maximum [L2]
50' 7" 31 53/64"
33' 9" 21 7/32"
25' 3" 15 59/64"
20' 3" 12 47/64"
16' 10" 10 39/64"
13' 6" 8 31/64"
10' 1" 6 23/64"
6' 9" 4 1/4"
PGLX2000
PGLW2000
3D Ready BrilliantColor™ DLP® Data/Video Projectors
Flexible and Lightweight. Weighing just 5.1 lbs., these projectors
are ideal for both portable (table-top) and fixed installation (ceiling
mount) applications.
Wide complement of inputs including HDMI® (available on
PGLX2000 and PGLW2000), RGB/component, composite video
and stereo audio. An RS-232C serial control/communications port
is also provided.
Presentation Assist Functions (by remote control) include 3D Mode
on/off, GUI (Graphic User Interface) Pointer, Spotlight, Image Freeze,
Image Enlarge, Break Timer and AV Mute.
Enhanced Anti-Theft and Security Features include Kensington®
lock compatibility, security bar, key lock and system lock functions, and
optional security cable kit (for use with optional ceiling mount bracket).
Top of Projector Lamp Access (with user replaceable lamp) helps
ensure quick and easy lamp replacement even in ceiling mounted
projector installations.
4:3 Signal Input (Normal Mode)
Picture (Screen) size
Diag. [ ] Width Height
300" 240" 180"
200" 160" 120"
150" 120" 90"
120" 96" 72"
100" 80" 60"
80" 64" 48"
60" 48" 36"
40" 32" 24"
16:10 Signal Input (Normal Mode)
Picture (Screen) size
Diag. [ ] Width Height
300" 254" 159"
200" 170" 106"
150" 127" 79"
120" 102" 64"
100" 85" 53"
80" 68" 42"
60" 51" 32"
40" 34" 21"
(XGA, 2800 Lumens)
(WXGA, 2800 Lumens)
PGLW2000
Projection distance [L] Distance from the lens center
to the bottom of the image [H]
Minimum [L1] Maximum [L2]
37' 1" 44' 9" 2 29/32"
24' 9" 29' 10" 1 15/16"
18' 7" 22' 4" 1 29/64"
14' 10" 17' 11" 1 11/64"
12' 4" 14' 11" 0 31/32"
9' 11" 11' 11" 0 25/32"
7' 5" 8' 11" 0 37/64"
4' 11" 6' 0" 0 25/64"
Projection distance [L] Distance from the lens center
to the bottom of the image [H]
Minimum [L1] Maximum [L2]
32' 9" 39' 6" 2 37/64"
21' 10" 26' 4" 1 23/32"
16' 5" 19' 9" 1 9/32"
13' 1" 15' 10" 1 1/32"
10' 11" 13' 2" 0 55/64"
8' 9" 10' 6" 0 11/16"
6' 7" 7' 11" 0 33/64"
4' 4" 5' 3' 0 11/32"
