Sharp PG-LX2000 Specifications

3d ready brilliantcolor dlp data/video projectors.
Hide thumbs


Advertisement

Model Shown: pG-lX2000
Portable and aff ordable, these 3D Ready BrilliantColor™ DLP® projectors deliver high image quality and superb reliability
for classroom, meeting room and small offi ce use. With 2,800 lumens and 2,000:1 contrast ratio, these models provide
exceptionally vibrant and realistic image reproduction. The sealed DLP chip with fi lter-free design helps ensure low
maintenance and operating costs. Built in an ISO 14001 certifi ed factory with standby power consumption as low as
0.5W and estimated lamp life of up to 5,000 hours (in eco mode), these lightweight RoHS compatible projectors are
an environmentally conscious choice.
3D Ready. Incorporating DLP Link™ technology, when used with
compatible 3D field sequential content and active shutter 3D glasses
(not included) that support the DLP Link system, these projectors
captivate audiences with breathtaking 3D imagery. (Please refer
to product operation manual for more specific 3D compatibility
information.) When not being used for 3D projection, these models
offer full compatibility with traditional "2D" content.
High Brightness and Contrast with 2,800 lumens and 2,000:1
contrast ratio.
Screen Size and Projection Distance
4:3 Signal Input (Normal Mode)
Picture (Screen) Size
Projection distance [L]
Diag. [x] Width
Height
Minimum [L1]
300''
240''
180''
38' 9"
200''
160''
120''
25' 10"
150''
120''
90''
19' 5"
120''
96''
72''
15' 6"
100''
80''
60''
12' 11"
80''
64''
48''
10' 4"
60''
48''
36''
7' 9"
40''
32''
24''
5' 2"
16:9 Signal Input (16:9 Mode)
Picture (Screen) Size
Projection distance [L]
Diag. [x] Width
Height
Minimum [L1]
300''
261''
147''
42' 3"
200''
174''
98''
28' 2"
150''
131''
74''
21' 2"
120''
105''
59''
16' 11"
100''
87''
49''
14' 1"
80''
70''
39''
11' 3"
60''
52''
29''
8' 5"
40''
35''
20''
5' 8"
Note: Allow a margin of error in the values in the diagrams above.
PG-LX2000 Terminal Inputs
Distance from the lens center to
the bottom of the image [H]
Maximum [L2]
46' 5"
6 23/32"
30' 11"
4 31/64"
23' 3"
3 23/64"
18' 7"
2 11/16"
15' 6"
2 15/64"
12' 5"
1 51/64"
9' 3"
1 11/32"
6' 2"
0 57/64"
Distance from the lens center to
the bottom of the image [H]
Maximum [L2]
50' 7"
31 53/64"
33' 9"
21 7/32"
25' 3"
15 59/64"
20' 3"
12 47/64"
16' 10"
10 39/64"
13' 6"
8 31/64"
10' 1"
6 23/64"
6' 9"
4 1/4"
PG-LX2000
PG-LS2000
3D Ready BrilliantColor™ DLP® Data/Video Projectors
BrilliantColor DLP Technology and 5-Segment Color Wheel
for superior color accuracy and more realistic image reproduction.
Sealed DLP Chip with Filter-Free Design for lower maintenance
and operating costs.
Easy setup and Operation with "Quick-Start" on-screen setup
guide, 1.2x optical zoom lens, and vertical keystone correction
directly accessible from the remote.
Built-in Closed Caption Decoder with black and white text
for easy readability.
Flexible and Lightweight. Weighing just 5.1 lbs., these projectors
are ideal for both portable (table-top) and fixed installation (ceiling
mount) applications.
Wide complement of inputs including HDMI® (available on
PG-LX2000), RGB/component, composite video and stereo audio.
An RS-232C serial control/communications port is also provided.
Presentation Assist Functions (by remote control) include 3D Mode
on/off, GUI (Graphic User Interface) Pointer, Spotlight, Image Freeze,
Image Enlarge, Break Timer and AV Mute.
Enhanced Anti-Theft and Security Features include Kensington®
lock compatibility, security bar, key lock and system lock functions, and
optional security cable kit (for use with optional ceiling mount bracket).
Top of Projector Lamp Access (with user replaceable lamp) helps
ensure quick and easy lamp replacement even in ceiling mounted
projector installations.
PG-LS2000 Terminal Inputs
(XGA, 2800 Lumens)
(SVGA, 2800 Lumens)
