GAS GRILL
Built-In LP Gas Grill Owner's Guide
™
S-660
- LP
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#43261
#00000
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting
Instructions" section of this manual.
43261 US 08/06/08
LP
US ENGLISH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weber S-660 - LP
Summary of Contents for Weber S-660 - LP
- Page 1 GAS GRILL Built-In LP Gas Grill Owner’s Guide ™ S-660 - LP #43261 #00000 YOU MUST READ THIS OWNER’S GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL procedures carefully in this manual prior to barbecue operation. Do this even if the barbecue was dealer-assembled.
- Page 2 Do not use a flame to check for gas leaks. Combustible materials should never be within 24 inches (61 cm) of the back or sides of your Weber ® gas barbecue.
- Page 3 All remaining parts, 2-years Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no When assembled and operated in accordance with the printed instructions accompanying it.
- Page 4 EXPLODED VIEW S-660 S660_LP_US WWW.WEBER.COM ®...
- Page 5 Small Knob Bezel IR Burner Igniter Wire Right Frame Panel Small Knob Thermocouple Matchstick Holder Large Knob IR Burner Hose Bottom Panel Large Knob Bezel Rotisserie Spit Assembly Right Vent Bracket Sear Station Knob Cooking Grate Battery Housing Smoker Box WWW.WEBER.COM ®...
-
Page 6: Storage And/Or Nonuse
® Liquid Propane (LP) gas supply is easy to use and gives you more cooking control than • The gas must be turned off at the liquid propane cylinder when the Weber charcoal fuel. barbecue is not in use. •... -
Page 7: Important Lp Cylinder Information
Proceed to the next step. If they do turn continue turning them clockwise until they stop, then they are off. Proceed to the next step. Your Weber ® gas grill is equipped for a cylinder supply system designed for vapor withdrawal. - Page 8 One series of tanks mount with the valve facing front (a). The other tanks mount with the valve facing away from the fuel scale (b). Weber recommends the use of cylinder manufacturer’s Manchester and Worthington, with a 47.6 lb water capacity.
-
Page 9: Check For Gas Leaks
Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber ® Gas Barbecue. Shipping and handling may loosen or damage a gas fitting. -
Page 10: Reinstall Control Panel
If a leak persists after re-tightening the fitting, turn off the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® Hose to regulator connection. -
Page 11: Gas Instructions
Be sure the regulator is mounted with the small vent hole pointed downward so that it will not collect water. This vent should be free of dirt, grease, bugs etc. CYLINDERS • The gas connections supplied with your Weber ® gas barbecue have been •... -
Page 12: Snap Ignition Operation
WARNING: If the burner still does not light, turn the burner control knob to “OFF” and wait 5 minutes to let the gas clear before you try again or try to light with a match. WWW.WEBER.COM ®... - Page 13 If the hose is found to be damaged in any way, do not use the barbecue. Replace ® using only Weber authorized replacement hose. Contact the Customer Service Representative in your area using the * The grill illustrated may have slight differences than the contact information on our web site.
-
Page 14: Grilling Methods
YOU control the flames. Because of the special design of the Flavorizer ® bars and burners, excess fats are directed through the funnel-shaped bottom tray into the grease catch pan. WWW.WEBER.COM ®... -
Page 15: Indirect Cooking
Do not line the funnel-shaped bottom tray with foil. This could prevent the grease from flowing into the grease catch pan. • Using a timer will help to alert you when “well-done” is about to become “over- done.” WWW.WEBER.COM ®... -
Page 16: Using The Sear Station
WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. - Page 17 ENCENDIDO Note: See Maintenance for burner removal and cleaning procedure. TO EXTINGUISH Push in and turn each burner control knob clockwise to “OFF” position. Turn gas supply off at the source. WWW.WEBER.COM ®...
- Page 18 “smoke” residue will accumulate on the inside of your gas grill. This residue need not DANGER be removed and will not adversely affect the function of your gas grill. Do not use any flammable fluid in the smoker to ignite the wood. This will cause serious bodily injury. WWW.WEBER.COM ®...
-
Page 19: Lighting The Smoker Burner
® authorized replacement hose. Contact the Customer Service Representative in your area using the contact ® information on our web site. Log onto www.weber.com Open the grill lid. Open smoker box lid. * The grill illustrated may have slight Fill smoker with water soaked wood chunks or chips. -
Page 20: Manually Lighting The Smoker Burner
Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® Open the lid. DANGER Failure to open the lid while igniting the grill, or not waiting... -
Page 21: Using The Rotisserie
Contact the Customer Service Representative in your area using the contact information on • Read all instructions before using your rotisserie. our web site. Log onto www.weber.com ® • This rotisserie is for outdoor use only. - Page 22 WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only a Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.
- Page 23 Turn off the rotisserie burner once the food has browned to the desired color. Finish cooking on indirect heat. TO EXTINGUISH Push in and turn each burner control knob clockwise to “OFF” position. Turn gas supply off at the source. WWW.WEBER.COM ®...
-
Page 24: Manually Lighting The Rotisserie Burner
WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only a Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. -
Page 25: Troubleshooting
OPERATING THE HANDLE LIGHT The Weber Grill Out™ Handle Light has a built-in “Tilt Sensor.” With the power button (a) activated, the light will come on when the grill lid is open. The light will turn off when the lid is closed. - Page 26 Reconnect the regulator to the cylinder. Turn cylinder valve on slowly. Refer to “Lighting Instructions”. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® MAINTENANCE WEBER ®...
-
Page 27: Main Burner Cleaning Procedure
REMOVE CONTROL PANEL Part required: Phillips Screwdriver. Remove the burner control knobs. Remove the two screws that secure the control panel to the frame. Remove the control panel. Tilt panel forward and lift up and away from grill. WWW.WEBER.COM ®... - Page 28 Check proper assembly before fastening manifold in place. WARNING: After reinstalling the gas lines, they should be leak checked with a soap and water solution before using the grill. (See, “Check for gas leaks.”) WWW.WEBER.COM ®...
-
Page 29: Inspection And Cleaning Of The Spider/Insect Screens
Insect screens and burners are clean replace the burners. If the Spider/Insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® BURNER FLAME PATTERN The Weber ®... - Page 30 ® ©2008 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria; Kettle Silhouette , Smokey Joe, Weber, Benelux; Kettle Silhouette , Smokey Joe, Weber, Compact Grill Configura- tion, Botswana;...
- Page 31 (If you register online, you do not need to send in this registration card.) ® ® Para registrar el producto, llene y envíe por correo este formulario o REGÍSTRESE EN LÍNEA en www.weber.com Para registrar el producto, llene y envíe por correo este formulario o REGÍSTRESE EN LÍNEA en www.weber.com (Si se registra en linea, no necesita enviar esta tarjeta de registro).
- Page 32 14. Which activities or interests do you have that keep you (or your partner) up with new cutting edge Weber products. Please fill in the answers you feel busy? / ¿Qué actividades o intereses tiene que lo mantienen a usted (o a comfortable sharing with us, and pass by any question you prefer to leave su compañero/a) ocupado? / Quelles sont les activités ou centres d’intérêt...
