2007 GMC Canyon Owner Manual
Seats and Restraint Systems ....................... 7
.............................................. 9
............................................. 17
............................................ 20
........................................ 76
Features and Controls ................................ 97
....................................................... 99
............................................... 110
..................................... 115
...................................... 43
......................... 94
.................................. 104
....................... 112
.................................................. 138
®
...................................... 150
................................................ 152
Instrument Panel ....................................... 153
Driving Your Vehicle ................................. 241
.............................................. 242
................................................. 292
M
................................... 146
................... 156
................................... 173
.... 177
............ 194
................................... 203
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Canyon and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GMC Canyon

  • Page 1: Table Of Contents

    2007 GMC Canyon Owner Manual Seats and Restraint Systems ....... 7 Mirrors ..........138 ® OnStar System ........146 Front Seats ..........9 Storage Areas ........150 Rear Seats ..........17 Sunroof ..........152 Safety Belts ..........20 Child Restraints ........
  • Page 2 Service and Appearance Care ....313 Vehicle Identification ......424 Electrical System ........425 Service ..........316 Capacities and Specifications ....430 Fuel ............318 Checking Things Under the Hood ..323 Maintenance Schedule ......433 Rear Axle ..........359 Maintenance Schedule ......
  • Page 3: Canadian Owners

    If the GENERAL MOTORS, GM, the GM Emblem, vehicle is sold, leave this manual in the vehicle. GMC, the GMC Emblem, and the name CANYON are registered trademarks of General Motors Corporation.
  • Page 4: How To Use This Manual

    How to Use This Manual CAUTION: Many people read the owner manual from beginning to end when they first receive their new vehicle. If this is done, it can help you learn These mean there is something that could about the features and controls for the vehicle. hurt you or other people.
  • Page 5: Vehicle Symbols

    Vehicle Damage Warnings Vehicle Symbols Also, in this manual you will find these notices: The vehicle has components and labels that use symbols instead of text. Symbols are shown along Notice: These mean there is something with the text describing the operation or that could damage your vehicle.
  • Page 6 These are some examples of symbols that may be found on the vehicle:...
  • Page 7: Seats And Restraint Systems

    Section 1 Seats and Restraint Systems Front Seats ............. 9 Safety Belt Use During Pregnancy ....34 Manual Seats ..........9 Right Front Passenger Position ....34 Power Seats ..........10 Center Front Passenger Position ....35 Manual Lumbar ........... 10 Rear Seat Passengers ........
  • Page 8 Section 1 Seats and Restraint Systems Airbag System ..........76 Servicing Your Airbag-Equipped Vehicle ..92 Where Are the Airbags? ......79 Adding Equipment to Your When Should an Airbag Inflate? ....82 Airbag-Equipped Vehicle ......93 What Makes an Airbag Inflate? ....84 Restraint System Check .......
  • Page 9: Front Seats

    Front Seats Manual Seats CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to.
  • Page 10: Power Seats

    Power Seats • Raise or lower the entire seat by moving the entire horizontal control up or down. If the vehicle has power • Use the vertical control to recline the seatback. seats, the controls used See “Power Reclining Seatbacks” under to operate them are Reclining Seatbacks on page 12 for more located on the outboard...
  • Page 11: Power Lumbar

    Power Lumbar Heated Seats If your vehicle has this If your vehicle has this feature, the controls are feature, the control is located on the outboard located on the outboard side of the front seats. side of the seat(s). Press and hold the front of the control until you This feature will heat the cushion and back of have the desired lumbar support.
  • Page 12: Reclining Seatbacks

    Reclining Seatbacks If your seats have manual reclining seatbacks, the lever used to operate them is located on the Manual Reclining Seatbacks outboard side of the seat(s). CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
  • Page 13 Power Reclining Seatbacks To return the seatback to an upright position, do the following: If the seats have power 1. Lift the lever fully without applying pressure to reclining seatbacks, use the seatback and the seatback will return to the vertical power the upright position.
  • Page 14 CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts cannot do their job when you are reclined like this. The shoulder belt cannot do its job because it will not be against your body.
  • Page 15: Head Restraints

    Head Restraints Pull up on the head restraint to raise it. To Your front seats may have adjustable head lower the head restraint, restraints. If your vehicle has rear seats, they press the button located may have adjustable head restraints. on top of the seatback and push down on the head restraint.
  • Page 16: Seatback Latches

    Seatback Latches CAUTION: Your vehicle may have front seatbacks that fold forward for easy access to the rear seats or the storage area behind the seats. If the seatback is not locked, it could move forward in a sudden stop or crash. To fold the seatback That could cause injury to the person forward, push the lever...
  • Page 17: Rear Seats

    Rear Seats To store the seat, do the following: Notice: Folding a rear seat with the safety Rear Seat Operation (Extended Cab) belts still fastened may cause damage to the seat or the safety belts. Always unbuckle If your vehicle has an the safety belts and return them to their normal extended cab, there may stowed position before folding a rear seat.
  • Page 18: Rear Seat Operation (Crew Cab)

    Rear Seat Operation (Crew Cab) To fold the rear seatback(s) forward, do the following: The rear seatback(s) in the crew cab can be folded forward. Notice: Folding a rear seat with the safety belts still fastened may cause damage to the seat or the safety belts.
  • Page 19 2. Pull the loop, 2. Make sure the seatback(s) is locked by located on the pushing and pulling on it. outboard side of the seatback, forward CAUTION: until you hear a click. A safety belt that is improperly routed, not properly attached, or twisted will not provide the protection needed in a crash.
  • Page 20: Safety Belts

    Safety Belts CAUTION: Safety Belts: They Are for Everyone It is extremely dangerous to ride in a This part of the manual tells you how to use cargo area, inside or outside of a vehicle. safety belts properly. It also tells you some things In a collision, people riding in these areas you should not do with safety belts.
  • Page 21 Why Safety Belts Work In most states and in all Canadian provinces, the law says to wear safety belts. Here is When you ride in or on anything, you go as fast why: They work. as it goes. You never know if you will be in a crash. If you do have a crash, you do not know if it will be a bad one.
  • Page 22 Put someone on it. Get it up to speed. Then stop the vehicle. The rider does not stop.
  • Page 23 The person keeps going until stopped by or the instrument panel... something. In a real vehicle, it could be the windshield...
  • Page 24: Questions And Answers About Safety Belts

    Questions and Answers About Safety Belts Will I be trapped in the vehicle after an accident if I am wearing a safety belt? You could be — whether you are wearing a safety belt or not. But you can unbuckle a safety belt, even if you are upside down.
  • Page 25: How To Wear Safety Belts Properly

    How to Wear Safety Belts Properly If I am a good driver, and I never drive far from home, why should I wear safety belts? This part is only for people of adult size. You may be an excellent driver, but if you are Be aware that there are special things to know in an accident —...
  • Page 26 4. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. If the belt is not long enough, see Safety Belt Extender on page 42. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
  • Page 27 6. To make the lap part tight, pull up on the shoulder belt. It may be necessary to pull stitching on the The lap part of the belt should be worn low and safety belt through the latch plate to fully snug on the hips, just touching the thighs.
  • Page 28 What is wrong with this? CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body. The shoulder belt is too loose. It will not give nearly as much protection this way.
  • Page 29 What is wrong with this? CAUTION: You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force at your abdomen. This could cause serious or even fatal injuries. The lap belt should be worn low and snug on the hips, just touching the thighs.
  • Page 30 What is wrong with this? CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones. This could cause serious internal injuries.
  • Page 31 What is wrong with this? CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which are not as strong as shoulder bones.
  • Page 32 What is wrong with this? CAUTION: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.
  • Page 33: Shoulder Belt Height Adjustment

    Shoulder Belt Height Adjustment Before you begin to drive, move the shoulder belt height adjuster to the height that is right for you. Adjust the height so that the shoulder portion of the belt is centered on your shoulder. The belt should be away from your face and neck, but not falling off your shoulder.
  • Page 34: Safety Belt Use During Pregnancy

    Safety Belt Use During Pregnancy The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, Safety belts work for everyone, including pregnant it is more likely that the fetus will not be hurt women.
  • Page 35: Center Front Passenger Position

    Center Front Passenger Position Lap Belt If your vehicle has a 60/40 split front seat, someone can sit in the center position. To make the belt shorter, pull its free end as shown until the belt is snug. Buckle, position and release it the same way as the lap part of a lap-shoulder belt.
  • Page 36: Rear Seat Passengers

    Rear Seat Passengers Lap-Shoulder Belt All rear seating positions have lap-shoulder belts. It is very important for rear seat passengers to Here is how to wear one properly. buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts.
  • Page 37 2. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. When the shoulder belt is pulled out all the way, it will lock. If it does, let it go back all the way and start again.
  • Page 38 The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The safety belt locks if there is a sudden stop or a crash. CAUTION: You can be seriously hurt if your shoulder belt is too loose.
  • Page 39: Rear Safety Belt Comfort Guides

    Rear Safety Belt Comfort Guides Your vehicle may have rear shoulder belt comfort guides for the rear outside positions. Rear shoulder belt comfort guides may provide added safety belt comfort for older children who have outgrown booster seats and for some adults. When installed on a shoulder belt, the comfort guide positions the belt away from the neck and head.
  • Page 40 2. Slide the guide under and past the belt. The 3. Be sure that the belt is not twisted and it lies elastic cord must be under the belt. Then, flat. The elastic cord must be under the belt place the guide over the belt and insert and the guide on top.
  • Page 41 CAUTION: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.
  • Page 42: Safety Belt Pretensioners

    Safety Belt Pretensioners Safety Belt Extender Your vehicle has safety belt pretensioners for the If the vehicle’s safety belt will fasten around you, driver and right front passenger. Although you you should use it. cannot see them, they are part of the safety belt But if a safety belt is not long enough, your dealer assembly.
  • Page 43: Child Restraints

    Child Restraints What is the proper way to wear safety belts? An older child should wear a lap-shoulder belt Older Children and get the additional restraint a shoulder belt can provide. The shoulder belt should not cross the face or neck. The lap belt should fit snugly below the hips, just touching the top of the thighs.
  • Page 44 What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? If the child is sitting in a seat next to a window, move the child toward the center of the vehicle.
  • Page 45 CAUTION: Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt.
  • Page 46: Infants And Young Children

    Infants and Young Children Every time infants and young children ride in vehicles, they should have the protection provided Everyone in a vehicle needs protection! This by appropriate restraints. Young children should includes infants and all other children. Neither the not use the vehicle’s adult safety belts alone, distance traveled nor the age and size of the unless there is no other choice.
  • Page 47 CAUTION: (Continued) vehicle’s safety belt system nor its airbag system is designed for them. Young children and infants need the protection that a child restraint system can provide. CAUTION: Children who are up against, or very close to, any airbag when it inflates can be seriously injured or killed.
  • Page 48 What are the different types of add-on child restraints? CAUTION: Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic Newborn infants need complete support, types. Selection of a particular restraint should including support for the head and neck. take into consideration not only the child’s This is necessary because a newborn weight, height, and age but also whether or not...
  • Page 49: Child Restraint Systems

    Child Restraint Systems CAUTION: The body structure of a young child is quite unlike that of an adult or older child, for whom the safety belts are designed. A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should.
  • Page 50 A rear-facing infant seat (B) provides restraint with A forward-facing child seat (C-E) provides restraint the seating surface against the back of the for the child’s body with the harness and also infant. The harness system holds the infant in sometimes with surfaces such as T-shaped place and, in a crash, acts to keep the infant or shelf-like shields.
  • Page 51 How Should I Use a Child Restraint? A child restraint system is any device designed for use in a motor vehicle to restrain, seat, or position children. A built-in child restraint system is a permanent part of the motor vehicle. An add-on child restraint system is a portable one, which is purchased by the vehicle’s owner.
  • Page 52 Securing an Add-on Child Restraint To help reduce the chance of injury, the child restraint must be secured in the vehicle. Child in the Vehicle restraint systems must be secured in vehicle seats by lap belts or the lap belt portion of a lap-shoulder belt, or by the LATCH system.
  • Page 53: Where To Put The Restraint

    Securing the Child Within the Child Because there are different systems, it is important to refer to the instructions that come with the Restraint restraint. A child can be endangered in a crash There are several systems for securing the if the child is not properly secured in the child child within the child restraint.
  • Page 54 There is a label on your sun visor that says, “Never put a rear-facing child seat in the front.” CAUTION: (Continued) This is because the risk to the rear-facing child is so great if the airbag deploys. We recommend that rear-facing child restraints be secured in the rear seat, even if the airbag is off.
  • Page 55 CAUTION: (Continued) CAUTION: If you need to secure a forward-facing A child in a rear-facing child restraint child restraint in the right front seat, can be seriously injured or killed if the always move the front passenger seat as right front passenger’s airbag inflates. far back as it will go.
  • Page 56: Lower Anchors And Tethers For Children (Latch)

    Keep in mind that an unsecured child restraint can When installing a child restraint with a top tether, move around in a collision or sudden stop and you must also use either the lower anchors or injure people in the vehicle. Be sure to properly the safety belts to properly secure the child secure any child restraint in your vehicle —...
  • Page 57 Lower Anchors Top Tether Anchor Lower anchors (A) are metal bars built into the A top tether (A, C) anchors the top of the child vehicle. There are two lower anchors for each restraint to the vehicle. A top tether anchor is built LATCH seating position that will accommodate a into the vehicle.
  • Page 58 Lower Anchor and Top Tether Anchor Some child restraints that have a top tether are designed for use with or without the top tether Locations being attached. Others require the top tether (Top Tether Anchor): always to be attached. In Canada, the law requires Seating positions with that forward-facing child restraints have a top top tether anchors.
  • Page 59 For extended cab models with rear seats, there (Top Tether Anchor): are exposed metal lower anchors for each Seating positions with rear seating position, attached to the back wall, top tether anchors. near the seat cushion. To assist you in locating the lower anchors, place your hand in a palm-up position and reach up between the seat cushion and the seatback.
  • Page 60 Crew Cab Extended Cab — Rear Seat The top tether anchors in a crew cab model are The top tether anchors in an extended cab model located on the back wall behind each rear seating are located on the center of the back wall position.
  • Page 61 Do not secure a child restraint in the right front passenger’s position of a vehicle that has rear seats if a national or local law requires that the top tether be attached, or if the instructions that come with the child restraint say that the top tether must be attached.
  • Page 62 Securing a Child Restraint Designed for the LATCH System CAUTION: Each top tether anchor and lower anchor CAUTION: in the vehicle is designed to hold only one child restraint. Attaching more than one If a LATCH-type child restraint is not child restraint to a single anchor could attached to anchors, the restraint will not cause the anchor or attachment to come...
  • Page 63 Notice: Contact between the child restraint or the LATCH attachment parts and the vehicle’s CAUTION: safety belt assembly may cause damage to these parts. Make sure when securing unused Children can be seriously injured or safety belts behind the child restraint that strangled if a shoulder belt is wrapped there is no contact between the child restraint or the LATCH attachment parts and the...
  • Page 64 Crew Cab — Rear Seat 2.2. Route the top tether according to your child restraint instructions and the following instructions: If the position you are using has a fixed head restraint and you are using a single tether, route the tether over the head restraint.
  • Page 65 If the position you are 3. Attach and tighten the lower attachments to using has a fixed or the lower anchors. If the child restraint does adjustable head restraint not have lower attachments or the desired and you are using a seating position does not have lower anchors, dual tether, route secure the child restraint with the top tether...
  • Page 66 Extended Cab — Rear Seat 1.3. Attach the lower attachments on the child restraint to the lower anchors (D) in the vehicle. The child restraint instructions will show you how. 2. If the child restraint manufacturer recommends that the top tether be attached, attach and tighten the top tether to the top tether anchor (C).
  • Page 67 3. Tighten the lower anchor attachments and the 2. If the child restraint manufacturer’s instructions top tether. The child restraint instructions will recommends that the top tether be attached, show you how. attach and tighten the top tether to the top tether anchor.
  • Page 68: Securing A Child Restraint In A Rear Seat Position

    Securing a Child Restraint in a If the position you are using has an adjustable Rear Seat Position head restraint and you are using a single If your child restraint has the LATCH system, see tether, raise the Lower Anchors and Tethers for Children (LATCH) head restraint and route on page 56.
  • Page 69 3. Buckle the belt. Make sure the release button 4. Pull the rest of the shoulder belt all the way is positioned so you would be able to unbuckle out of the retractor to set the lock. the safety belt quickly if you ever had to. 5.
  • Page 70 7. Tighten the top tether to the anchor. See Lower Anchors and Tethers for Children (LATCH) on page 56. 8. Push and pull the child restraint in different directions to be sure it is secure. To remove the child restraint, if the top tether is attached, disconnect it.
  • Page 71: Securing A Child Restraint In The Right Front Seat Position

    Securing a Child Restraint in the Securing a Child Restraint in the Center Front Seat Position Right Front Seat Position Your vehicle has a right front passenger’s airbag. A rear seat is a safer place to secure a CAUTION: forward-facing child restraint. See Where to Put the Restraint on page 53.
  • Page 72 There is a label on your sun visor that says, “Never put a rear-facing child seat in the front.” CAUTION: (Continued) This is because the risk to the rear-facing child is so great, if the airbag deploys. restraint, no system is fail-safe, and no one can guarantee that an airbag will not deploy under some unusual CAUTION:...
  • Page 73 If your vehicle does not have a rear seat that will accommodate a rear-facing child restraint, CAUTION: (Continued) never put a child in a rear-facing child restraint in the right front passenger seat unless the no system is fail-safe, and no one can passenger airbag status indicator shows off and guarantee that an airbag will not deploy the airbag is off.
  • Page 74 Do not secure a child seat in this position if a you turn the ignition to ON or START. See national or local law requires that the top tether be Passenger Airbag Status Indicator on anchored or if the instructions that come with the page 182.
  • Page 75 5. Pull the rest of the shoulder belt all the way 7. To tighten the belt, push down on the child out of the retractor to set the lock. restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt, and 6.
  • Page 76: Airbag System

    9. Push and pull the child restraint in different To remove the child restraint, if the top tether is directions to be sure it is secure. attached, disconnect it. Unbuckle the vehicle’s safety belt and let it go back all the way. The 10.
  • Page 77 Airbags are designed to supplement the protection provided by safety belts. Even though today’s CAUTION: (Continued) airbags are also designed to help reduce the risk of injury from the force of an inflating bag, all Frontal airbags for the driver and right airbags must inflate very quickly to do their job.
  • Page 78 CAUTION: CAUTION: Both frontal and side impact airbags Anyone who is up against, or very inflate with great force, faster than the close to, any airbag when it inflates can blink of an eye. If you are too close to an be seriously injured or killed.
  • Page 79: Where Are The Airbags

    Where Are the Airbags? There is an airbag readiness light on the instrument panel cluster, which shows the airbag symbol. The system checks the airbag electrical system for malfunctions. The light tells you if there is an electrical problem. See Airbag Readiness Light on page 181 for more information.
  • Page 80 The right front passenger’s airbag is in the If your vehicle has a roof-mounted side impact instrument panel on the passenger’s side. airbag for the driver and the person seated directly behind the driver, it is located in the ceiling above the side windows.
  • Page 81 CAUTION: If something is between an occupant and an airbag, the bag might not inflate properly or it might force the object into that person causing severe injury or even death. The path of an inflating airbag must be kept clear. Do not put anything between an occupant and an airbag, and do not attach or put anything on the steering wheel hub or on or near any...
  • Page 82: When Should An Airbag Inflate

    When Should an Airbag Inflate? If the front of your vehicle goes straight into a wall that doesn’t move or deform, the threshold level The driver’s and right front passenger’s frontal for the reduced deployment is about 8 to 16 mph airbags are designed to inflate in moderate (12.9 to 25.7 km/h), and the threshold level for to severe frontal or near-frontal crashes.
  • Page 83 Frontal airbags (driver and right front passenger) In any particular crash, no one can say whether are not intended to inflate during vehicle an airbag should have inflated simply because rollovers, rear impacts, or in many side impacts. of the damage to a vehicle or because of what the repair costs were.
  • Page 84: What Makes An Airbag Inflate

    What Makes an Airbag Inflate? Airbags supplement the protection provided by safety belts. Airbags distribute the force of In an impact of sufficient severity, the airbag the impact more evenly over the occupant’s upper sensing system detects that the vehicle is body, stopping the occupant more gradually.
  • Page 85 What Will You See After an Airbag CAUTION: Inflates? After a frontal airbag inflates, it quickly deflates, so When an airbag inflates, there may be dust quickly that some people may not even realize the in the air. This dust could cause breathing airbag inflated.
  • Page 86: Passenger Sensing System

    Passenger Sensing System In many crashes severe enough to inflate an airbag, windshields are broken by vehicle deformation. Your vehicle has a passenger sensing system. Additional windshield breakage may also occur The passenger airbag status indicator on the from the right front passenger airbag. instrument panel will be visible when you turn your •...
  • Page 87 The passenger sensing system works with sensors that are part of the right front passenger’s CAUTION: (Continued) seat and safety belt. The sensors are designed to detect the presence of a properly seated This is because the back of the occupant and determine if the passenger’s frontal rear-facing child restraint would be very airbag should be enabled (may inflate) or not.
  • Page 88 If your vehicle does not have a rear seat that will accommodate a rear-facing child restraint, CAUTION: (Continued) never put a child in a rear-facing child restraint in the right front passenger seat unless the detects a rear-facing child restraint, passenger airbag status indicator shows off no system is fail-safe, and no one can and the airbag is off.
  • Page 89 The passenger sensing system is designed to turn If a child restraint has been installed and the on off the right front passenger’s frontal airbag if: indicator is lit, turn the vehicle off. Remove the child restraint from the vehicle and reinstall •...
  • Page 90 The passenger sensing system is designed to Restart the vehicle and have the person remain enable (may inflate) the right front passenger’s in this position for about two minutes. This frontal airbag anytime the system senses will allow the system to detect that person and that a person of adult size is sitting properly in then enable the passenger’s airbag.
  • Page 91 Aftermarket equipment, such as seat covers, can affect how well the passenger sensing system CAUTION: operates. You may want to consider not using seat covers or other aftermarket equipment if If the airbag readiness light in the your vehicle has the passenger sensing system. instrument panel cluster ever comes on See Adding Equipment to Your Airbag-Equipped Vehicle on page 93 for more information about...
  • Page 92: Servicing Your Airbag-Equipped Vehicle

    Servicing Your Airbag-Equipped CAUTION: Vehicle Airbags affect how your vehicle should be For up to 10 seconds, after the ignition is serviced. There are parts of the airbag system turned off and the battery is disconnected, in several places around your vehicle. You do not an airbag can still inflate during improper want the system to inflate while someone is service.
  • Page 93 Adding Equipment to Your Because I have a disability, I have to get my vehicle modified. How can I find out Airbag-Equipped Vehicle whether this will affect my airbag system? Changing or moving any parts of the Is there anything I might add to the front front seats, safety belts, the airbag sensing or sides of the vehicle that could keep and diagnostic module, steering wheel,...
  • Page 94: Restraint System Check

    Restraint System Check Notice: If you damage the covering for the driver’s or the right front passenger’s airbag, or the side impact airbag covering (if equipped) Checking the Restraint Systems on the ceiling near the side windows, the airbag may not work properly. You may have to replace Now and then, make sure the safety belt reminder the airbag module in the steering wheel, both light and all your belts, buckles, latch plates,...
  • Page 95: Replacing Restraint System Parts After A Crash

    Replacing Restraint System Parts If belts are cut or damaged, replace them. Collision damage also may mean you will need to After a Crash have LATCH system, safety belt or seat parts repaired or replaced. New parts and repairs may be necessary even if the belt or LATCH system CAUTION: was not being used at the time of the collision.
  • Page 96 NOTES...
  • Page 97: Features And Controls

    Section 2 Features and Controls Keys .............. 99 Starting and Operating Your Vehicle ..115 Remote Keyless Entry (RKE) System ..100 New Vehicle Break-In ........ 115 Remote Keyless Entry (RKE) Ignition Positions ........116 System Operation ........101 Retained Accessory Power (RAP) ..... 117 Starting the Engine ........
  • Page 98 Section 2 Features and Controls ® Mirrors ............138 OnStar System .......... 146 Manual Rearview Mirror ......138 Storage Areas ..........150 ® Manual Rearview Mirror with OnStar ..138 Glove Box ..........150 Automatic Dimming Rearview Mirror Cupholder(s) ..........150 ®...
  • Page 99: Keys

    Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons. They could operate the power windows or other controls or even make the vehicle move. The children or others could be badly injured or even killed. Do not leave the keys in a vehicle with children.
  • Page 100: Remote Keyless Entry (Rke) System

    There is a double-sided If you ever do get locked out of your vehicle call key that can be used for the GM Roadside Assistance Center. See the ignition, all door Roadside Assistance Program on page 462. locks, and the tailgate. Remote Keyless Entry (RKE) System If the vehicle has the Remote Keyless Entry (RKE) system, it operates on a radio frequency subject...
  • Page 101: Remote Keyless Entry (Rke)

    Remote Keyless Entry (RKE) Changes or modifications to this system by other than an authorized service facility could void System Operation authorization to use this equipment. If your vehicle has this feature you can lock At times you may notice a decrease in range. This and unlock your doors and disarm or arm your is normal for any RKE system.
  • Page 102 Matching Transmitter(s) to Your LOCK: Press this button to lock all the doors. The parking lamps may also flash and the Vehicle horn may chirp when this button is pressed. Each remote keyless entry transmitter is coded If a door is open or ajar when the lock button is to prevent another transmitter from unlocking pressed, the horn will chirp several times to let you your vehicle.
  • Page 103 Battery Replacement To replace the battery, do the following: Under normal use, the battery in your remote keyless entry transmitter should last about two years. You can tell the battery is weak if the transmitter will not work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it is probably time to change the battery.
  • Page 104: Doors And Locks

    Doors and Locks CAUTION: (Continued) Door Locks • Young children who get into unlocked vehicles may be unable to get out. A child can be overcome by extreme CAUTION: heat and can suffer permanent injuries or even death from heat stroke. Always lock your vehicle whenever Unlocked doors can be dangerous.
  • Page 105: Power Door Locks

    Power Door Locks If your vehicle has power door locks, the switches are located on the driver’s and the front passenger’s armrests. To lock a door from the inside, push the manual Driver’s Switch Shown, lever on the door forward. To unlock a door Front Passenger’s from the inside, push the lever on the door Switch Similar...
  • Page 106: Programmable Automatic Door Locks

    Programmable Automatic Rear Door Security Locks Door Locks (Crew Cab) If your vehicle has power door locks and the If your vehicle is a crew cab model, it may have remote keyless entry system, it has an automatic rear door security locks. With this feature, you can lock/unlock feature.
  • Page 107: Lockout Protection

    Lockout Protection To engage the security locks, do the following: 1. Open one of the rear doors. If you have power door locks, this feature protects you from locking your key in the vehicle when 2. Using your ignition key, turn the lock to the the key is in the ignition and a door is open.
  • Page 108: Tailgate

    Tailgate Removing the Tailgate Follow these steps if you want to remove the tailgate: 1. With the tailgate fully open, lift up slightly on the entire tailgate assembly. 2. Remove the retaining cables from both sides of the tailgate by pulling the clips away from the bolt heads while pushing the cable...
  • Page 109 Reverse the procedure to reinstall the tailgate. 3. Slide the lower end fitting onto the top bolt. Make sure it is secure. The tailgate will now stay in the partially opened position. To partially lower the tailgate do the following: 4.
  • Page 110: Windows

    Windows CAUTION: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
  • Page 111: Power Windows

    Power Windows Do not hold all four power window switches down for several seconds after the windows have been completely lowered or raised, because the The power window vehicle may blow a fuse. switches for all windows are located on the Express-Down Windows driver’s door armrest.
  • Page 112: Theft-Deterrent Systems

    Sliding Rear Window Sun Visors To block glare, pull the sun visor down. It can also be detached from the center mount and moved to the side to block glare from that direction. Visor Vanity Mirror The passenger’s side sun visor may have a mirror.
  • Page 113 To activate the content theft-deterrent system, You should also remember that you can start your do the following: vehicle with the correct ignition key if the alarm has been set off. 1. Close all the doors. Here is how to avoid setting off the alarm by 2.
  • Page 114: Passlock

    If the alarm does not sound when it should but the If the engine stalls and the security light flashes, lights flash, check to see if the horn works. The wait about 10 minutes until the light stops horn fuse may be blown. To replace the fuse, see flashing before trying to restart the engine.
  • Page 115: Starting And Operating Your Vehicle

    Starting and Operating • Avoid making hard stops for the first 200 miles (322 km) or so. During this Your Vehicle time your new brake linings are not yet broken in. Hard stops with new linings can mean premature wear and earlier New Vehicle Break-In replacement.
  • Page 116: Ignition Positions

    Ignition Positions Notice: Using a tool to force the key from the ignition switch could cause damage or break the key. Use the correct key and turn the key With the key in the only with your hand. Make sure the key is all the ignition switch, you can way in.
  • Page 117: Retained Accessory Power (Rap)

    The battery could be drained if you leave the key in The battery could be drained if you leave the key the ACC or ON position with the engine off. You in the ignition while your vehicle is parked. may not be able to start your vehicle if the battery is You may not be able to start your vehicle after it allowed to drain for an extended period of time.
  • Page 118: Starting The Engine

    Starting the Engine Starting Procedure 1. With your foot off the accelerator pedal, turn Place the transmission in the proper gear. the ignition key to START. When the engine Automatic Transmission starts, let go of the key. The idle speed will go down as the engine gets warm.
  • Page 119: Engine Coolant Heater

    Notice: Cranking the engine for long periods of Notice: Your engine is designed to work with time, by returning the key to the START position the electronics in your vehicle. If you add immediately after cranking has ended, can electrical parts or accessories, you could overheat and damage the cranking motor, and change the way the engine operates.
  • Page 120: Automatic Transmission Operation

    To Use the Engine Coolant Heater How long should you keep the coolant heater plugged in? The answer depends on the outside 1. Turn off the engine. temperature, the kind of oil you have, and 2. Open the hood and unwrap the electrical some other things.
  • Page 121 If you need to leave your key in the ignition but not in LOCK for an extended period, it is recommended CAUTION: (Continued) that you disconnect the battery cable from the battery to prevent discharging your battery. move, even when you are on fairly level There are several different positions for your ground, always set your parking brake shift lever.
  • Page 122 REVERSE (R): Use this gear to back up. CAUTION: Notice: Shifting to REVERSE (R) while your vehicle is moving forward could damage the transmission. The repairs would not Shifting into a drive gear while your be covered by your warranty. Shift to engine is running at high speed is REVERSE (R) only after your vehicle is dangerous.
  • Page 123 DRIVE (D): This position is for normal driving. SECOND (2): This position reduces vehicle speed If provides the best fuel economy for your vehicle. even more than THIRD (3) without using your If you need more power for passing, and you are: brakes.
  • Page 124: Manual Transmission Operation

    Manual Transmission Operation THIRD, FOURTH AND FIFTH (3, 4 and 5): Shift into THIRD (3), FOURTH (4) and FIFTH (5) This is your shift the same way you do for SECOND (2). Slowly pattern. let up on the clutch pedal as you press the accelerator pedal.
  • Page 125 Notice: Shifting to REVERSE (R) while your While you accelerate, it is normal for the light to vehicle is moving forward could damage the go on and off if you quickly change the position of transmission. The repairs would not be covered the accelerator.
  • Page 126: Four-Wheel Drive

    Four-Wheel Drive If your vehicle has four-wheel drive, you can send your engine’s driving power to all four wheels for extra traction. To get the best performance out of four-wheel drive, you must be familiar with its operation. Read the part that follows before using four-wheel drive.
  • Page 127 Use these buttons to shift into and out of four-wheel (Four-Wheel High): This setting engages drive. You can choose from the following: your front axle to help drive your vehicle. Use four-wheel high when you need extra traction, such (Two-Wheel High): This setting is for driving as on snowy or icy roads, or in most off-road in most street and highway situations.
  • Page 128 Shifting from Two-Wheel High to Shifting from Two-Wheel High or Four-Wheel High Four-Wheel High to Four-Wheel Low Press and release the Four-Wheel High button. To shift from Two-Wheel High or Four-Wheel High This can be done at any speed, and the front to Four-Wheel Low, the vehicle must be stopped axle will lock automatically.
  • Page 129 Shifting from Four-Wheel Low to Shifting to NEUTRAL Two-Wheel High or Four-Wheel High Use NEUTRAL when you plan to tow your vehicle. See Recreational Vehicle Towing on page 293 To shift from Four-Wheel Low to Two-Wheel for towing instructions. To shift the transfer case High or Four-Wheel High, your vehicle must be into NEUTRAL do the following: stopped or moving less than 3 mph (5 km/h)
  • Page 130: Parking Brake

    Parking Brake 7. Turn the engine off by turning the key to ACC (Accessory). The parking brake pedal 8. Place the transmission shift lever in is located to the left of PARK (P), or FIRST (1) for vehicles that the regular brake pedal, have a manual transmission.
  • Page 131 If the ignition is on when the parking brake is released, the brake system warning light will go off. Notice: Driving with the parking brake on can overheat the brake system and cause premature wear or damage to brake system parts.
  • Page 132: Shifting Into Park (P)

    Shifting Into Park (P) CAUTION: (Automatic Transmission) If you have four-wheel drive, your vehicle CAUTION: will be free to roll — even if your shift lever is in PARK (P) — if your transfer case is in NEUTRAL. So, be sure the It can be dangerous to get out of your transfer case is in a drive gear, two-wheel vehicle if the shift lever is not fully in...
  • Page 133 Leaving Your Vehicle With the Engine Torque Lock (Automatic Transmission) Running (Automatic Transmission) If you are parking on a hill and you do not shift your transmission into PARK (P) properly, the weight of the vehicle may put too much force CAUTION: on the parking pawl in the transmission.
  • Page 134: Shifting Out Of Park (P)

    Shifting Out of Park (P) Parking Your Vehicle (Automatic Transmission) (Manual Transmission) Your vehicle has an automatic transmission shift Your vehicle has a manual transmission. Before lock control system which locks the shift lever you get out of your vehicle, move the shift in PARK (P) when the ignition is in the LOCK lever into REVERSE (R), and firmly apply the position.
  • Page 135: Parking Over Things That Burn

    Parking Over Things That Burn CAUTION: Things that can burn could touch hot exhaust parts under your vehicle and ignite. Do not park over papers, leaves, dry grass, or other things that can burn.
  • Page 136: Engine Exhaust

    Engine Exhaust CAUTION: (Continued) • CAUTION: Your vehicle was damaged when driving over high points on the road or over road debris. Engine exhaust can kill. It contains the • Repairs were not done correctly. gas carbon monoxide (CO), which you •...
  • Page 137: Running The Engine While Parked

    Running the Engine While Parked CAUTION: It is better not to park with the engine running. But if you ever have to, here are some things to know. It can be dangerous to get out of your vehicle if the automatic transmission shift CAUTION: lever is not fully in PARK (P) with the parking brake firmly set.
  • Page 138: Mirrors

    Mirrors CAUTION: Manual Rearview Mirror Four-wheel drive vehicles with the transfer While sitting in a comfortable driving position, case in NEUTRAL will allow the vehicle to adjust the mirror so you can see clearly behind roll, even if your automatic transmission your vehicle.
  • Page 139: Automatic Dimming Rearview Mirror With Onstar

    ® ® There are also three OnStar buttons located at Control buttons for the OnStar system are at ® the bottom of the mirror. See your dealer for more the bottom of the mirror. See OnStar System information on the system and how to subscribe on page 146 for more information about the ®...
  • Page 140 Compass Calibration If an abnormal temperature reading is displayed for an extended period of time, see your The compass may need calibration if one of the dealer. Under certain circumstances, a delay following occurs: in updating the temperature is normal. •...
  • Page 141 Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if the vehicle is outside of zone eight. Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for compass variance.
  • Page 142: Automatic Dimming Rearview Mirror With Compass And Temperature Display

    Cleaning the Mirror Temperature Display When cleaning the mirror, use a paper towel or The temperature can be displayed by pressing the similar material dampened with glass cleaner. compass/temperature button. Pressing the Do not spray glass cleaner directly on the mirror compass/temperature button once briefly, will as that may cause the liquid cleaner to enter toggle the display reading on and off.
  • Page 143 Automatic Dimming Mirror Operation • The compass does not display the correct heading and the compass zone variance : Press this button to turn the automatic is set correctly. dimming feature on or off. The indicator light to In order to calibrate, CAL must be displayed in the the left of the button will turn on to indicate when mirror compass windows.
  • Page 144 Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if the vehicle is outside zone eight. Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for compass variance.
  • Page 145: Outside Manual Mirrors

    Cleaning the Mirror Outside Power Mirrors Use a paper towel or similar material dampened If your vehicle has this with glass cleaner. Do not spray glass cleaner feature, the controls are directly on the mirror as that may cause the liquid located on the driver’s cleaner to enter the mirror housing.
  • Page 146: Onstar ® System

    ® OnStar System The mirrors can be manually folded inward to prevent damage when going through an automatic car wash. To fold, push the mirror toward the vehicle. To return the mirror to its original position, push outward. Be sure to return both mirrors to the unfolded position before driving.
  • Page 147: Onstar Services

    ® ® OnStar service is provided to you subject to the year, or upgrade to the Directions & Connections ® ® OnStar Terms and Conditions. You may cancel Plan. For more information, press the OnStar ® ® your OnStar service at any time by contacting button to speak with an advisor.
  • Page 148 ® Available Services included with OnStar Virtual Advisor ® Directions & Connections Plan ® ® OnStar Virtual Advisor is a feature of OnStar • All Safe and Sound Plan Services Hands-Free Calling that uses your minutes to access location-based weather, local traffic •...
  • Page 149 ® ® How OnStar Service Works OnStar service that involves location information about your vehicle cannot work unless GPS ® In order to provide you with OnStar services, your satellite signals are unobstructed and available in ® vehicle’s OnStar system has the capability of that place as well.
  • Page 150: Storage Areas

    Storage Areas For vehicles with bucket seats or uplevel packages, your vehicle may have a two-tiered center armrest storage area. Lift up on the upper Glove Box tab located at the front of the armrest to release To open the glove box, pull on the lever. the latch.
  • Page 151: Rear Storage Area

    Rear Storage Area If your vehicle is an extended cab model, it might have storage compartments under the rear seats. To open a storage box, unhook the bottom and lift the two latches on each side of the storage box. To access the storage compartments, lift the cushion on the bottom of the rear seats.
  • Page 152: Sunroof

    Sunroof Your vehicle may have a sunroof. The sunroof control buttons are located on the headliner. Lift the lid from the center area to access the storage box. (Open/Vent): Press and hold this button to vent, and open the sunroof. Release the button when the desired position is reached.
  • Page 153: Instrument Panel

    Section 3 Instrument Panel Instrument Panel Overview ......156 Accessory Power Outlet(s) ......172 Hazard Warning Flashers ......158 Ashtray(s) and Cigarette Lighter ....173 Other Warning Devices ......158 Climate Controls ......... 173 Horn ............158 Climate Control System ......173 Tilt Wheel ..........
  • Page 154 Section 3 Instrument Panel Highbeam On Light ........192 Radio with CD (MP3) ........ 208 Daytime Running Lamps (DRL) Radio with Six-Disc CD ......217 Indicator Light ........193 Using an MP3 ........... 230 Fuel Gage ..........193 XM Radio Messages ......... 236 Theft-Deterrent Feature Driver Information Center (DIC) ....
  • Page 155 NOTES...
  • Page 156: Instrument Panel Overview

    Instrument Panel Overview Manual Transmission shown, Automatic Transmission similar...
  • Page 157 The main components of your vehicle’s instrument panel are the following: A. Air Outlets. See Outlet Adjustment on H. Horn. See Horn on page 158. page 176. I. Traction Control Button or Four-Wheel Drive B. Turn Signal/Multifunction Lever. See Turn Buttons.
  • Page 158: Hazard Warning Flashers

    Hazard Warning Flashers Other Warning Devices The hazard warning flashers let you warn the If you carry reflective triangles, you can set one up police and others that you have a problem. at the side of the road about 300 feet (100 m) The front and rear turn signal lamps will flash behind your vehicle.
  • Page 159: Turn Signal/Multifunction Lever

    Turn Signal/Multifunction Lever The lever on the left side of the steering column includes the following: The tilt lever is located on the left side of the steering column, under the turn signal lever. • Turn and Lane Change Signals. See Turn Signal/Multifunction Lever on page 159.
  • Page 160: Turn And Lane-Change Signals

    An arrow on the • Windshield Wipers. See Windshield Wipers instrument panel cluster on page 161. will flash in the • Windshield Washer. See Windshield direction of the turn or Washer on page 162. lane change. • Cruise Control. See Cruise Control on page 163.
  • Page 161: Headlamp High/Low-Beam Changer

    Turn Signal On Chime Flash-to-Pass If a turn signal is left on for more than 3/4 of This feature lets you use the high-beam a mile (1.2 km), a chime will sound at each flash headlamps to signal a driver in front of you that of the turn signal and the message TURN SIGNAL you want to pass.
  • Page 162: Windshield Washer

    Windshield Washer (Delay): You can set the wiper speed for a long or short delay between wipes. This can be very useful in light rain or snow. Turn the band to choose the delay time. The closer to the top CAUTION: of the lever, the shorter the delay.
  • Page 163: Cruise Control

    Cruise Control Cruise control will not work if the parking brake is set, or if the master cylinder brake fluid level is low. The cruise control If the brakes are applied, the cruise control will set button is located shut off. at the end of the multifunction lever.
  • Page 164 Setting Cruise Control Resuming a Set Speed Suppose you set the cruise control to a desired speed and then you apply the brake. This turns off CAUTION: the cruise control. But it does not need to be reset. Once you are going about 25 mph (40 km/h) or If you leave your cruise control on when more, you can move the cruise control switch you are not using cruise, you might hit a...
  • Page 165 • Using Cruise Control on Hills Move the cruise lever from on to resume/ accelerate. Hold it there until you get up to the How well the cruise control will work on hills speed desired, and then release the lever. depends upon the vehicle speed, load, and the To increase your speed in very small amounts, steepness of the hills.
  • Page 166: Exterior Lamps

    Exterior Lamps AUTO: Turn the knob to this position to automatically turn on the headlamps at normal brightness, together with the following: • Sidemarker Lamps • Taillamps • Parking Lamps • Instrument Panel Lights See Automatic Headlamp System on page 168 for more information.
  • Page 167: Headlamps On Reminder

    Headlamps on Reminder The DRL system will come on when the following conditions are met: If a door is open, a reminder chime will sound when • The ignition is on. the headlamps or parking lamps are manually • The exterior lamps control is in AUTO. turned on and your key is out of the ignition.
  • Page 168: Automatic Headlamp System

    Automatic Headlamp System There is a delay in the transition between the daytime and nighttime operation of the Daytime When it is dark enough outside, the automatic Running Lamps (DRL) and the automatic headlamp system will turn on after the headlamp system so that driving under bridges transmission has been shifted from PARK (P) to or bright overhead street lights does not affect...
  • Page 169: Fog Lamps

    Fog Lamps Exterior Cargo Lamps If your vehicle has fog lamps, you can use them The cargo lamps can be used if more light is for better vision in foggy or misty conditions. needed in the cargo area of the vehicle or in the Your parking lamps and/or low-beam headlamps top-box storage units.
  • Page 170: Interior Lamps

    Interior Lamps Dome Lamp The thumbwheel for the interior lamps is located The dome lamp will come on when a door is next to the exterior lamps control. See Exterior opened. They will shut off several seconds after Lamps on page 166 for additional information on all doors are closed.
  • Page 171: Exit Lighting

    Exit Lighting The battery can be discharged at idle if the electrical loads are very high. This is true for all With exit lighting, the interior lamps will come on vehicles. This is because the generator (alternator) when you remove the key from the ignition. may not be spinning fast enough at idle to The lamps will not come on if the dome override produce all the power that is needed for very high...
  • Page 172: Accessory Power Outlet(S)

    Accessory Power Outlet(s) Notice: Adding any electrical equipment to your vehicle may damage it or keep other Your vehicle may have accessory power outlets. components from working as they should. The repairs would not be covered by your With accessory power outlets you can plug in warranty.
  • Page 173: Climate Controls

    Ashtray(s) and Cigarette Lighter Climate Controls Your vehicle may have an ashtray and cigarette Climate Control System lighter. Your ashtray is located in your center console area. The ashtray can be removed for cleaning. When the ashtray is removed, this area can also be used as a cupholder.
  • Page 174 Fan Knob (Floor): Select this mode to direct air to the floor outlets. Recirculation is disabled in this mode (Fan): The center knob on the control panel because interior window could fog under some is used to control the fan speed. Turn the conditions.
  • Page 175 Defogging and Defrosting (Air Conditioning): Press this button to turn the air conditioning system on or off. An indicator Fog on the inside of windows is a result of high light on the button will come on to let you know humidity (moisture) condensing on the cool the air conditioning is activated.
  • Page 176: Outlet Adjustment

    Outlet Adjustment Turn the mode knob on the climate control panel clockwise to select the defog or defrost modes. Use the thumbwheel on the outlets to change the (Floor/Defog): This mode directs the air to the direction of the air flow. windshield, the side window outlets, and to the floor Lift up or push down on the thumbwheel located in outlets.
  • Page 177: Warning Lights, Gages, And Indicators

    Warning Lights, Gages, and Gages can indicate when there may be or is a problem with one of your vehicle’s functions. Indicators Often gages and warning lights work together to let you know when there is a problem with This part describes the warning lights and gages your vehicle.
  • Page 178: Instrument Panel Cluster

    Instrument Panel Cluster Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You will know how fast you are going, about how much fuel you have used, and many other things you will need to know to drive safely and economically.
  • Page 179: Speedometer And Odometer

    Speedometer and Odometer Trip Odometer Your speedometer lets you see your speed Your vehicle has a trip odometer that can tell you in both miles per hour (mph) and kilometers how far your vehicle has been driven since per hour (km/h). you last set the trip odometer to zero.
  • Page 180: Safety Belt Reminder Light

    Safety Belt Reminder Light Passenger Safety Belt Reminder Light When the key is turned to ON or START, a chime will be provided for several seconds to remind Several seconds after the key is turned to ON or people to buckle their safety belts. The driver START, a chime will sound for several seconds safety belt light will also be provided and stay on to remind the front passenger to buckle their safety...
  • Page 181: Airbag Readiness Light

    Airbag Readiness Light CAUTION: There is an airbag readiness light on the instrument panel, which shows the airbag symbol. The system checks the airbag’s electrical If the airbag readiness light stays on after system for malfunctions. The light tells you if there you start your vehicle, it means the airbag is an electrical problem.
  • Page 182: Passenger Airbag Status Indicator

    Passenger Airbag Status Indicator There is a label on your sun visor that says, “Never put a rear-facing child seat in the front.” Your vehicle has the passenger sensing system. This is because the risk to the rear-facing child is Your instrument panel has a passenger airbag so great if the airbag deploys.
  • Page 183 If your vehicle does not have a rear seat that that the right front passenger’s frontal airbag will accommodate a rear-facing child restraint, is enabled (may inflate). never put a child in a rear-facing child restraint in the right front passenger seat unless the CAUTION: passenger airbag status indicator shows off and the airbag is off.
  • Page 184: Battery Warning Light

    Battery Warning Light If, after several seconds, all status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger This light will come on sensing system. See your dealer for service. briefly when you start the vehicle, as a check to show you it is...
  • Page 185: Up-Shift Light (Manual Transmission)

    Up-Shift Light Brake System Warning Light (Manual Transmission) Your vehicle’s hydraulic brake system is divided into two parts. If one part is not working, the other This light appears when part can still work and stop you. For good you need to shift to the braking, though, you need both parts working well.
  • Page 186: Anti-Lock Brake System Warning Light

    Anti-Lock Brake System When the ignition is on, the brake system warning light will also come on when you set your Warning Light parking brake. See Parking Brake on page 130 for more information. The light will stay on if your With the Anti-Lock Brake parking brake does not release fully.
  • Page 187: Engine Coolant Temperature Gage

    Engine Coolant Temperature Gage Tire Pressure Light This gage shows the This light should come engine coolant on briefly when you turn temperature. the ignition to ON. If the gage pointer is near the top of the gage, This light will also come on when one or more of the engine is too hot.
  • Page 188: Malfunction Indicator Lamp

    Malfunction Indicator Lamp Notice: If you keep driving your vehicle with this light on, after awhile, your emission Check Engine Light controls may not work as well, your fuel economy may not be as good, and your engine may not run as smoothly. This could lead to Your vehicle has a costly repairs that may not be covered by your computer which...
  • Page 189 This light should come on, as a check to show If the light stops flashing and remains on steady, you it is working, when the ignition is on and the see “If the Light Is On Steady” following. engine is not running. If the light does not If the light continues to flash, when it is safe to do come on, have it repaired.
  • Page 190 Emissions Inspection and Maintenance Did you just drive through a deep puddle of water? Programs If so, your electrical system may be wet. The condition will usually be corrected when the Some state/provincial and local governments have electrical system dries out. A few driving trips or may begin programs to inspect the emission should turn the light off.
  • Page 191: Oil Pressure Light

    Oil Pressure Light The light will come on when you turn your key to ON or START. CAUTION: Do not keep driving if the oil pressure is low. If you do, your engine can become so It goes off once you start your engine. That is a hot that it catches fire.
  • Page 192: Security Light

    Security Light Cruise Control Light This light will come on This light comes on briefly when you turn whenever you set the the key to START. The cruise control. light will stay on until the engine starts. If the ignition is turned on, and the light flashes, The light goes out when the cruise control is ®...
  • Page 193: Daytime Running Lamps (Drl) Indicator Light

    Daytime Running Lamps (DRL) Here are four things that some owners ask about. None of these indicate a problem with your Indicator Light fuel gage: • At the gas station, the gas pump shuts off This light turns on before the gage reads full. whenever the Daytime •...
  • Page 194: Driver Information Center (Dic)

    Driver Information Center (DIC) Trip Information Odometer The Driver Information Center (DIC) displays The odometer is automatically displayed on the information such as the trip odometer, DIC when you start the vehicle. The odometer personalization features, and warning messages. shows the total distance the vehicle has The DIC display is located on the instrument been driven in either miles for the United States panel cluster.
  • Page 195 Engine Oil Life System Language With the engine off, turn the key to ON and then This feature allows you to choose the language in press the reset stem until OIL LIFE RESET which the DIC display will show information. appears —...
  • Page 196 Automatic Door Locks On vehicles with a manual transmission, this mode locks all of the doors when the vehicle This feature allows you to program your door speed is greater than 15 mph (24 km/h) and locks to a preferred setting. unlocks all of the doors when the key is removed from the ignition.
  • Page 197 Remote Keyless Entry (RKE) Feedback The following are the available modes: RFA 1 (default): This mode flashes the parking This feature allows you to program your Remote lamps when you press the lock or unlock Keyless Entry (RKE) feedback to a preferred buttons on the RKE transmitter.
  • Page 198: Dic Warnings And Messages

    DIC Warnings and Messages AC (Air Conditioning) OFF This message displays when the engine coolant Messages are displayed on the DIC to notify the temperature is too high and the air conditioning in driver that the status of the vehicle has changed your vehicle needs to be turned off.
  • Page 199 BRAKES ENG (Engine) HOT This message displays if there is a problem with This message displays when the engine coolant the brakes. Check the brakes as soon as possible temperature is hot. Check the engine coolant and have your vehicle serviced by your dealer. temperature gage.
  • Page 200 FUEL CAP The message appears at each ignition cycle until the tires are inflated to the correct This message displays if the vehicle’s fuel cap is inflation pressure. See Tires on page 369 and either off or loose. Pull over as soon as possible Inflation - Tire Pressure on page 377 for and check to see if the fuel cap is secure.
  • Page 201 PARK BRK (Brake) SERV (Service) 4WD (Four-Wheel Drive) This message displays when the parking brake This message displays when there is a problem is set. See Parking Brake on page 130 and with the transfer case control system. Check the Brake System Warning Light on page 185 for transfer case on your vehicle and have it serviced more information.
  • Page 202 SERV (Service) VEH (Vehicle) TRACTION FAULT This message displays if your vehicle needs If your vehicle has the Traction Control service. Have your vehicle serviced by your dealer System (TCS), this message may display if as soon as possible. there is a problem with the TCS. Check the TCS as soon as possible and have your vehicle SERVICE CHARG (Charge) serviced by your dealer.
  • Page 203: Audio System(S)

    Audio System(s) CAUTION: Determine which radio your vehicle has and then read the pages following to familiarize yourself This system provides you with a far with its features. greater access to audio stations and Driving without distraction is a necessity for a song listings.
  • Page 204: Setting The Time For Radios Without Radio Data Systems (Rds)

    Here are some ways in which you can help avoid Notice: The chime signals related to safety distraction while driving. belts, parking brake, and other functions of your vehicle operate through the While your vehicle is parked: radio/entertainment system. If that equipment •...
  • Page 205: Setting The Time For Radios With Radio Data Systems (Rds)

    Setting the Time for Radios with AM-FM Radio Radio Data Systems (RDS) The radio may have a button marked with an H or HR to represent hours and an M or MN to represent minutes. Press and hold the hour button until the correct hour appears on the display.
  • Page 206 Finding a Station Setting Preset Stations Up to 18 stations (six FM1, six FM2, and six AM) AM FM: Press this button to switch between FM1, can be programmed on the six numbered FM2, or AM. The selection displays. pushbuttons, by performing the following steps: TUNE: Turn this knob to select radio stations.
  • Page 207 To adjust both tone controls and both speaker To adjust both tone controls and both speaker controls to the middle position, first exit out of audio controls to the middle position, first exit out of audio mode by pressing another button, causing the radio mode by pressing another button, causing the radio to perform that function or wait five seconds for the to perform that function or wait five seconds for the...
  • Page 208: Radio With Cd (Mp3)

    Radio with CD (MP3) With RDS, the radio can do the following: • Seek to stations broadcasting the selected type of programming • Receive announcements concerning local and national emergencies • Display messages from radio stations • Seek to stations with traffic announcements This system relies upon receiving specific information from these stations and only works when the information is available.
  • Page 209 XM™ Satellite Radio Service DISPL (Display): When the ignition is turned off, press this knob to display the time. XM™ is a satellite radio service that is based in For RDS, press the DISPL knob to change what the 48 contiguous United States and Canada. appears on the display while using RDS.
  • Page 210 Set the volume at the desired level. Press this The radio only seeks stations with a strong signal button to select LOW, MEDIUM, or HIGH. AVOL that are in the selected band. appears on the display. Each higher setting allows SCAN : Press and hold either arrow for for more volume compensation at faster vehicle...
  • Page 211 Setting Preset Stations Setting the Tone (Bass/Treble) Up to 30 stations (six FM1, six FM2, and six AM, AUDIO: Push and release the AUDIO knob until six XM1 and six XM2 (if equipped)), can be BASS or TREB appears on the display. Turn the programmed on the six numbered pushbuttons, by knob to increase or to decrease.
  • Page 212 Adjusting the Speakers (Balance/Fade) Finding a Program Type (PTY) Station (RDS and XM™) AUDIO: To adjust the balance between the right and the left speakers, push and release the To select and find a desired PTY perform the AUDIO knob until BAL (balance) appears on following: the display.
  • Page 213 BAND (AF– Alternate Frequency): Alternate INFO (Information): If the current station has a frequency lets the radio switch to a stronger station message, the information symbol appears on with the same program type. To turn alternate the display. Press this button to see the message. frequency on, press and hold BAND for The message may display the artist, song title, two seconds.
  • Page 214 Radio Messages for XM™ Only When a station that broadcasts traffic announcements is found, the radio stops seeking See XM Radio Messages on page 236 later in this and TRAF appears on the display. If no station section for further detail. is found that broadcasts traffic announcements, NO TRAF appears on the display.
  • Page 215 There may be an increase in skipping, difficulty in 1 FLD (Previous): This button is inactive finding tracks, and/or difficulty in loading and when playing a CD. ejecting. If these problems occur, check the bottom 2 FLD (Next): This button is inactive when surface of the CD.
  • Page 216 6 RDM (Random): Press this pushbutton to hear BAND: Press this button to listen to the radio the tracks in random, rather than sequential, order. when a CD is playing. The inactive CD remains RDM ON appears on the display. RDM and the safely inside the radio for future listening.
  • Page 217: Radio With Six-Disc Cd

    CD Messages Radio with Six-Disc CD CHECK CD: If this message appears on the display and/or the CD comes out, it could be for one of the following reasons: • It is very hot. When the temperature returns to normal, the CD should play. •...
  • Page 218 Radio Data System (RDS) XM™ Satellite Radio Service The audio system has a Radio Data System (RDS). XM™ is a satellite radio service that is based in RDS features are available for use only on FM the 48 contiguous United States and Canada. stations that broadcast RDS information.
  • Page 219 Finding a Station Press the INFO button to display additional text information related to the current FM-RDS or XM™ BAND: Press this button to switch between FM1, station. A choice of additional information such FM2, AM, or XM1 or XM2 (if equipped). The as: Channel, Song, Artist, and PTY (program type) display shows the selection.
  • Page 220 To scan preset stations, press and hold either the To store an equalization setting to a preset station SCAN or the TYPE arrows for more than four perform the following: seconds. PSC appears on the display and you will 1. Tune to the preset station. hear a double beep.
  • Page 221 ALL CENTERED appears on the display and you To adjust the balance or fade to the middle will hear a beep. position, push and hold the AUDIO knob while BAL or FAD is displayed. The radio produces one beep AUTO EQ (Automatic Equalization): Press this and adjusts the display level to the middle position.
  • Page 222 Setting Preset PTYs (RDS Only) SCAN: Scan the stations within a PTY by performing the following: These pushbuttons have factory PTY presets. 1. Press the TYPE button to activate program Up to 12 PTYs (six FM1 and six FM2), can type select mode.
  • Page 223 RDS Messages Radio Messages INFO (Information): If the current station has a CAL ERR (Calibration Error): The audio system message, INFO appears on the display. Press this has been calibrated for your vehicle from the button to see the message. The message may factory.
  • Page 224 Playing a CD If there is no apparent damage, try a known good CD. If the ignition or radio is turned off, with a CD in the Do not add any label to a CD, it could get caught player, it stays in the player. When the ignition or in the CD player.
  • Page 225 To insert one CD, do the following: To load more than one CD but less than six, complete Steps 1 through 3. When finished loading 1. Turn the ignition on. CDs, press the LOAD button to cancel the 2. Press and release the LOAD button. loading function.
  • Page 226 To eject multiple CDs, do the following: REV (Reverse): Press and hold this button to reverse quickly within a track. You will hear 1. Press and hold the CD eject button for sound at a reduced volume. The elapsed time of five seconds.
  • Page 227 © ¨ RDM (Random): With random, you can listen to SCAN : To scan one CD, press and hold the tracks in random, rather than sequential, either SCAN arrow for more than two seconds until order, on one CD or on all of the CDs. To use SCAN appears on the display and you hear a random, do one of the following: beep.
  • Page 228 Using Song List Mode 4. Press and hold the SONG LIST button to save the track into memory. When SONG The six-disc CD changer has a feature called LIST is pressed, one beep will sound. song list. This feature is capable of saving 20 track After two seconds of continuously pressing selections.
  • Page 229 To delete tracks from the song list, perform the To delete the entire song list, perform the following steps: following steps: 1. Turn the CD player on. 1. Turn the CD player on. 2. Press the SONG LIST button to turn song list 2.
  • Page 230: Using An Mp3

    CD Messages Using an MP3 CHECK CD: If this message appears on the MP3 CD-R Disc display and/or the CD comes out, it could be for MP3 Format one of the following reasons: • It is very hot. When the temperature returns to If you burn your own MP3 disc on a personal normal, the CD should play.
  • Page 231 Empty Directory or Folder The player is able to read and play a maximum of 50 folders, 50 playlists, 10 sessions, and 255 files. If a root directory or a folder exists somewhere Long file names, folder names, or playlist names in the file structure that contains only folders/ may use more disc memory space than necessary.
  • Page 232 Order of Play File System and Naming Tracks are played in the following order: The song name that displays is the song name that is contained in the ID3 tag. If the song name is not • Play begins from the first track in the first present in the ID3 tag, then the radio displays the playlist and continues sequentially through file name without the extension (such as .mp3) as...
  • Page 233 If the ignition or radio is turned off with a CD in the Do not add any label to a CD, it could get caught player it stays in the player. When the ignition or in the CD player. If a CD is recorded on a radio is turned on, the CD starts to play where it personal computer and a description label is stopped, if it was the last selected audio source.
  • Page 234 6 RDM (Random): To play the tracks in random 2 FLD (Next Folder): Press this pushbutton to order in the current folder or playlist, press and go to the first track in the next folder. Pressing release this pushbutton. FLDR RDM (folder this button while in folder random mode takes the random) appears on the display.
  • Page 235 To change the default on the display, press the TUNE : Turning the TUNE knob will fast DISPL knob until you see the desired display, then track reverse or advance through the tracks in all press and hold this knob for two seconds. The folders or playlists.
  • Page 236: Xm Radio Messages

    XM Radio Messages Radio Display Message Condition Action Required XL (Explicit Language XL on the radio display, These channels, or any others, can be blocked at a Channels) after the channel name, customer’s request, by calling 1-800-852-XMXM (9696). indicates content with explicit language.
  • Page 237: Theft-Deterrent Feature (Non-Rds Radios)

    Radio Display Message Condition Action Required No Info No Text/Informational No text or informational messages are available at this time message available on this channel. The system is working properly. Not Found No channel available for There are no channels available for the selected category. the chosen category The system is working properly.
  • Page 238: Theft-Deterrent Feature (Rds Radios)

    Theft-Deterrent Feature (RDS Radios) The range for most AM stations is greater than for FM, especially at night. The longer range can ® THEFTLOCK is designed to discourage theft cause station frequencies to interfere with each of your vehicle’s radio. The feature works other.
  • Page 239: Care Of Your Cds

    XM™ Satellite Radio Service Do not touch the bottom side of a CD while handling it; this could damage the surface. XM™ Satellite Radio Service gives digital radio Pick up CDs by grasping the outer edges or reception from coast-to-coast in the 48 contiguous the edge of the hole and the outer edge.
  • Page 240: Xm™ Satellite Radio Antenna System

    XM™ Satellite Radio Antenna Chime Level Adjustment System The radio is used to adjust the vehicle’s chime level. To change the volume level of the chime, The XM™ Satellite Radio antenna is located on press and hold pushbutton 6 with the ignition the roof of your vehicle.
  • Page 241: Driving Your Vehicle

    Section 4 Driving Your Vehicle Your Driving, the Road, and Your Vehicle ..242 Freeway Driving ........275 Defensive Driving ........242 Before Leaving on a Long Trip ....276 Drunken Driving ........243 Highway Hypnosis ........277 Control of a Vehicle ........246 Hill and Mountain Roads ......
  • Page 242: Your Driving, The Road, And Your Vehicle

    Your Driving, the Road, and CAUTION: Your Vehicle Defensive driving really means “Be ready Defensive Driving for anything.” On city streets, rural roads, The best advice anyone can give about driving is: or expressways, it means “Always expect Drive defensively. the unexpected.”...
  • Page 243: Drunken Driving

    Drunken Driving Many adults — by some estimates, nearly half the adult population — choose never to drink Death and injury associated with drinking and alcohol, so they never drive after drinking. driving is a national tragedy. It is the number For persons under 21, it is against the law in one contributor to the highway death toll, every U.S.
  • Page 244 According to the American Medical Association, It is the amount of alcohol that counts. For example, a 180 lb (82 kg) person who drinks three 12 ounce if the same person drank three double martinis (355 ml) bottles of beer in an hour will end up (3 ounces or 90 ml of liquor each) within an hour, with a BAC of about 0.06 percent.
  • Page 245 But the ability to drive is affected well below a There is something else about drinking and driving BAC of 0.10 percent. Research shows that that many people do not know. Medical research the driving skills of many people are impaired at shows that alcohol in a person’s system can make a BAC approaching 0.05 percent, and that crash injuries worse, especially injuries to the...
  • Page 246: Control Of A Vehicle

    Control of a Vehicle Braking You have three systems that make your See Brake System Warning Light on page 185. vehicle go where you want it to go. They are Braking action involves perception time and the brakes, the steering, and the accelerator. reaction time.
  • Page 247: Anti-Lock Brake System (Abs)

    Anti-Lock Brake System (ABS) Avoid needless heavy braking. Some people drive in spurts — heavy acceleration followed by heavy Your vehicle has the Anti-Lock Brake System braking — rather than keeping pace with traffic. (ABS), an advanced electronic braking system This is a mistake.
  • Page 248 ABS can change the brake pressure faster than any driver could. The computer is programmed to make the most of available tire and road conditions. This can help you steer around the obstacle while braking hard. Let us say the road is wet and you are driving safely.
  • Page 249: Braking In Emergencies

    Traction Control System (TCS) Remember: ABS does not change the time you need to get your foot up to the brake pedal or Your vehicle may have a Traction Control always decrease stopping distance. If you get too System (TCS) that limits wheel spin. This is close to the vehicle in front of you, you will not have especially useful in slippery road conditions.
  • Page 250: Limited-Slip Rear Axle

    When road conditions allow you to safely use it See Rocking Your Vehicle to Get It Out on again, you may re-engage the cruise control. page 284 and If Your Vehicle is Stuck in Sand, See Cruise Control on page 163. Mud, Ice, or Snow on page 284 for more information.
  • Page 251 Steering Tips What should you do if this ever happens? Ease up on the accelerator pedal, steer the vehicle the It is important to take curves at a reasonable way you want it to go, and slow down. speed. Speed limit signs near curves warn that you A lot of the “driver lost control”...
  • Page 252 Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and find a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
  • Page 253: Off-Road Recovery

    Off-Road Recovery Passing You may find that your right wheels have dropped The driver of a vehicle about to pass another on a off the edge of a road onto the shoulder while two-lane highway waits for just the right moment, you are driving.
  • Page 254 • • Watch for traffic signs, pavement markings, and If other vehicles are lined up to pass a slow lines. If you can see a sign up ahead that might vehicle, wait your turn. But take care that indicate a turn or an intersection, delay your someone is not trying to pass you as you pull pass.
  • Page 255: Loss Of Control

    Loss of Control If your vehicle starts to slide, ease your foot off the accelerator pedal and quickly steer the Let us review what driving experts say about what way you want the vehicle to go. If you start happens when the three control systems — brakes, steering quickly enough, your vehicle may steering, and acceleration —...
  • Page 256: Off-Road Driving

    Off-Road Driving Before You Go Off-Roading There are some things to do before you go out. This off-road guide is for vehicles that have For example, be sure to have all necessary four-wheel drive. Also, see Braking on page 246 maintenance and service work done.
  • Page 257 Loading Your Vehicle for Off-Road CAUTION: (Continued) Driving • Heavy loads on the roof raise the CAUTION: vehicle’s center of gravity, making it more likely to roll over. You can be seriously or fatally injured if the • Cargo on the load floor piled higher vehicle rolls over.
  • Page 258 Environmental Concerns Traveling to Remote Areas Off-road driving can provide wholesome and It makes sense to plan your trip, especially when satisfying recreation. However, it also raises going to a remote area. Know the terrain and plan environmental concerns. We recognize these your route.
  • Page 259 Scanning the Terrain Controlling your vehicle is the key to successful off-road driving. One of the best ways to control Off-road driving can take you over many different your vehicle is to control your speed. Here are kinds of terrain. You need to be familiar with some things to keep in mind.
  • Page 260 Surface Obstacles: Unseen or hidden obstacles In a way, off-road driving requires a different kind can be hazardous. A rock, log, hole, rut, or of alertness from driving on paved roads and bump can startle you if you are not prepared highways.
  • Page 261 Here are some other things to consider as you approach a hill. CAUTION: • Is there a constant incline, or does the hill get sharply steeper in places? Many hills are simply too steep for any • Is there good traction on the hillside, or will vehicle.
  • Page 262 Driving Uphill • Ease up on your speed as you approach the top of the hill. Once you decide you can safely drive up the hill, • Attach a flag to the vehicle to make you more you need to take some special steps. visible to approaching traffic on trails or hills.
  • Page 263 the wheels are straight and maneuver as What should I do if my vehicle stalls, you back down. It is best that you back down or is about to stall, and I cannot make it the hill with the wheels straight rather than in up the hill? the left or right direction.
  • Page 264 If you decide you can go down a hill safely, then Suppose, after stalling, I try to back down try to keep your vehicle headed straight down, and the hill and decide I just cannot do it. use a low gear. This way, engine drag can help What should I do? the brakes and they will not have to do all Set the parking brake, put the automatic...
  • Page 265 3. Shift back to a low gear, release the parking Are there some things I should not do brake, and drive straight down. when driving down a hill? 4. If the engine will not start, get out and Yes! These are important because if you get help.
  • Page 266 • Surface conditions can be a problem when you drive across a hill. Loose gravel, muddy CAUTION: spots, or even wet grass can cause your tires to slip sideways, downhill. If the vehicle Driving across an incline that is too slips sideways, it can hit something that will steep will make your vehicle roll over.
  • Page 267 Stalling on an Incline If your vehicle stalls when you are crossing an incline, be sure you, and any passengers, get out on the uphill side, even if the door there is harder to open. If you get out on the downhill side and the vehicle starts to roll over, you will be right in its path.
  • Page 268 Driving in Mud, Sand, Snow, or Ice CAUTION: When you drive in mud, snow, or sand, your wheels will not get good traction. You cannot accelerate as quickly, turning is more difficult, and you will need Driving on frozen lakes, ponds, or rivers longer braking distances.
  • Page 269 After Off-Road Driving If the water is not too deep, drive slowly through it. At faster speeds, water splashes on the ignition Remove any brush or debris that has collected system and your vehicle can stall. Stalling can also on the underbody, chassis, or under the hood. occur if you get the tailpipe under water.
  • Page 270: Driving At Night

    Driving at Night No one can see as well at night as in the daytime. But as we get older these differences increase. Night driving is more dangerous than day driving. A 50-year-old driver may require at least twice as One reason is that some drivers are likely to much light to see the same thing at night as a be impaired —...
  • Page 271: Driving In Rain And On Wet Roads

    Driving in Rain and on Wet Roads Keep the windshield and all the glass on your vehicle clean — inside and out. Glare at night is made much worse by dirt on the glass. Even the inside of the glass can build up a film caused by dust.
  • Page 272 The heavier the rain, the harder it is to see. Driving too fast through large water puddles or Even if your windshield wiper blades are in good even going through some car washes can cause shape, a heavy rain can make it harder to see problems, too.
  • Page 273 Driving Through Deep Standing Water Some Other Rainy Weather Tips • Turn on your low-beam headlamps — not just Notice: If you drive too quickly through deep your parking lamps — to help make you more puddles or standing water, water can come in visible to others.
  • Page 274: City Driving

    City Driving Here are ways to increase your safety in city driving: • Know the best way to get to where you are going. Get a city map and plan your trip into an unknown part of the city just as you would for a cross-country trip.
  • Page 275: Freeway Driving

    Freeway Driving The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving. Too-fast or too-slow driving breaks a smooth traffic flow. Treat the left lane on a freeway as a passing lane.
  • Page 276: Before Leaving On A Long Trip

    Before Leaving on a Long Trip Just before you leave the lane, glance quickly over your shoulder to make sure there is not Make sure you are ready. Try to be well rested. another vehicle in your blind spot. If you must start when you are not fresh — such Once you are moving on the freeway, make as after a day’s work —...
  • Page 277: Highway Hypnosis

    Highway Hypnosis Here are some things you can check before a trip: • Windshield Washer Fluid: Is the reservoir Is there actually such a condition as highway full? Are all windows clean inside and outside? hypnosis? Or is it just plain falling asleep at the •...
  • Page 278: Hill And Mountain Roads

    Hill and Mountain Roads If you drive regularly in steep country, or if you are planning to visit there, here are some tips that can make your trips safer and more enjoyable. See Off-Road Driving on page 256 for information about driving off-road.
  • Page 279 • Stay in your own lane when driving on two-lane roads in hills or mountains. Do not swing wide CAUTION: or cut across the center of the road. Drive at speeds that let you stay in your own lane. Coasting downhill in NEUTRAL (N) or with •...
  • Page 280: Winter Driving

    Winter Driving Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth, and a couple of reflective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet, or a couple of burlap bags to help provide traction.
  • Page 281 Accelerate gently. Try not to break the fragile traction. If you accelerate too fast, the drive wheels will spin and polish the surface under the tires even more. The Anti-Lock Brake System (ABS) improves your vehicle’s stability when you make a hard stop on a slippery road.
  • Page 282 If You Are Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow.
  • Page 283 Run your engine only as long as you must. This saves fuel. When you run the engine, make CAUTION: it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for Snow can trap exhaust gases under your the heat that you get and it keeps the battery vehicle.
  • Page 284: If Your Vehicle Is Stuck In Sand

    If Your Vehicle is Stuck in Sand, Notice: Spinning the wheels can destroy parts of your vehicle as well as the tires. If you Mud, Ice, or Snow spin the wheels too fast while shifting the transmission back and forth, you can destroy In order to free your vehicle when it is stuck, the transmission.
  • Page 285: Recovery Hooks

    If that does not get your vehicle out after a few tries, it may need to be towed out. Or, you can use the recovery hooks if your vehicle has them. If your vehicle does need to be towed out, see Towing Your Vehicle on page 292.
  • Page 286: Loading Your Vehicle

    Loading Your Vehicle Tire and Loading Information Label It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo, and all nonfactory-installed options.
  • Page 287 The Tire and Loading Information label shows the 3. Subtract the combined weight of the driver number of occupant seating positions (A), and the and passengers from XXX kg or XXX lbs. maximum vehicle capacity weight (B) in kilograms 4. The resulting figure equals the available and pounds.
  • Page 288 Example 1 Example 2 Item Description Total Item Description Total Vehicle Capacity Vehicle Capacity 1,000 lbs (453 kg) 1,000 lbs (453 kg) Weight for Example 1 Weight for Example 2 Subtract Subtract Occupant Weight 300 lbs (136 kg) Occupant Weight 750 lbs (340 kg) 150 lbs (68 kg) x 2 150 lbs (68 kg) x 5 =...
  • Page 289 Certification/Tire Label Example 3 Item Description Total Label Example Vehicle Capacity 1,000 lbs (453 kg) A vehicle specific Certification/Tire label is attached Weight for Example 3 to the bottom section of the center pillar, on the Subtract driver’s side of the vehicle. Vehicles without a Occupant Weight 1,000 lbs (453 kg) 200 lbs (91 kg) x 5 =...
  • Page 290 The Certification/Tire label also tells you the maximum weights for the front and rear axles, CAUTION: called Gross Axle Weight Rating (GAWR). To find out the actual loads on your front and Do not load your vehicle any heavier than rear axles, you need to go to a weigh station and the Gross Vehicle Weight Rating (GVWR), weigh your vehicle.
  • Page 291 Two-Tiered Loading CAUTION: By positioning four 2” X 6” wooden planks across the width of the pickup box, you can create an upper load platform. The planks must be inserted Things you put inside your vehicle can in the pickup box depressions. The length of strike and injure people in a sudden stop the planks must allow for at least a 3/4 inch (2 cm) or turn, or in a crash.
  • Page 292: Towing

    Add-On Equipment Pickup Conversion to Chassis Cab When you carry removable items, you may need General Motors is aware that some vehicle to put a limit on how many people you carry owners may consider having the pickup box inside your vehicle. Be sure to weigh your vehicle removed and a commercial or recreational before you buy and install the new equipment.
  • Page 293: Recreational Vehicle Towing

    Recreational Vehicle Towing Here are some important things to consider before you do recreational vehicle towing: Recreational vehicle towing means towing your • What’s the towing capacity of the towing vehicle behind another vehicle — such as behind vehicle? Be sure you read the tow vehicle a motorhome.
  • Page 294 Dinghy Towing Four-Wheel Drive Vehicles Two-Wheel Drive Vehicles Notice: If you tow your vehicle with all four wheels on the ground, the drivetrain components could be damaged. The repairs would not be covered by your warranty. Do not tow your vehicle with all four wheels on the ground.
  • Page 295 3. Put an automatic transmission in PARK (P) 5. Shift the transfer case to NEUTRAL. or a manual transmission in FIRST (1). See Four-Wheel Drive on page 126 for more information. 4. Securely attach the vehicle being towed to the tow vehicle.
  • Page 296 Dolly Towing Four-Wheel-Drive Vehicles Front Towing (Front Wheels Off the Ground) Two-Wheel-Drive Vehicles Notice: If you tow a two-wheel-drive vehicle with the rear wheels on the ground, the transmission could be damaged. The repairs would not be covered by your warranty. Never tow your vehicle with the rear wheels on the ground.
  • Page 297 3. Put an automatic transmission in PARK (P) 5. Shift the transfer case to NEUTRAL. See or a manual transmission in FIRST (1). Four-Wheel Drive on page 126 for more information. 4. Follow the dolly manufacturer’s instructions to attach and secure the vehicle being towed 6.
  • Page 298 Rear Towing 3. Put an automatic transmission in PARK (P) or a manual transmission in FIRST (1). (Rear Wheels Off the Ground) 4. Follow the dolly manufacturer’s instructions to Two-Wheel-Drive Vehicles attach and secure the vehicle being towed to the dolly and then the loaded dolly to the tow vehicle.
  • Page 299 Four-Wheel-Drive Vehicles For manual transmission vehicles, make sure the wheels are straight before proceeding to the next steps. On automatic transmission vehicles, use an adequate clamping device to ensure that the front wheels are locked into the straight position. CAUTION: Shifting a four-wheel-drive vehicle’s transfer case into NEUTRAL can cause your vehicle to roll even if the...
  • Page 300: Towing A Trailer

    7. Turn the ignition to LOCK. Notice: Pulling a trailer improperly can damage your vehicle and result in costly If the tow vehicle will not be started or driven repairs that would not be covered by your for six weeks or more, remove the battery warranty.
  • Page 301: If You Do Decide To Pull A Trailer

    If You Do Decide To Pull A Trailer Three important considerations have to do with weight: If you do, here are some important points: • the weight of the trailer, • There are many different laws, including speed • the weight of the trailer tongue limit restrictions, having to do with trailering.
  • Page 302 The following charts show how much your trailer can weigh, based upon your vehicle model and options. 2WD Regular Cab Axle Ratio Maximum Trailer Weight GCWR* Automatic Transmission, 2.9L Engine 3.73 3,300 lbs (1 497 kg) 7,000 lbs (3 175 kg) Automatic Transmission, 3.7L Engine 3.73 4,000 lbs (1 814 kg)
  • Page 303 4WD Regular Cab Axle Ratio Maximum Trailer Weight GCWR* Automatic Transmission, 2.9L Engine 3.73 3,000 lbs (1 361 kg) 7,000 lbs (3 175 kg) Automatic Transmission, 2.9L Engine 4.10 3,000 lbs (1 361 kg) 7,000 lbs (3 175 kg) Automatic Transmission, 3.7L Engine 3.73 4,000 lbs (1 814 kg) 9,000 lbs (4 082 kg)
  • Page 304 You can ask your dealer for our trailering information or advice, or you can write us at our Customer Assistance Offices. See Customer Assistance Offices on page 460 for more information. Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total or gross weight of your vehicle.
  • Page 305 After you’ve loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they aren’t you may be able to get them right simply by moving some of the items around in the trailer. Trailering may be limited by the vehicle’s ability to carry tongue weight.
  • Page 306 But let’s say your specific vehicle is equipped with But, you must still consider the effect on the rear some of the latest options and you have a front axle. Because your rear axle now weighs seat passenger and two rear seat passengers with 3,100 lbs (1 406 kg), you can only put 900 lbs some luggage and gear in the vehicle as well.
  • Page 307 Total Weight on Your Vehicle’s Tires Safety Chains Be sure your vehicle’s tires are inflated to the upper You should always attach chains between your limit for cold tires. You’ll find these numbers on the vehicle and your trailer. Cross the safety Certification/Tire label located at the bottom of the chains under the tongue of the trailer to help center pillar on the driver’s side of the vehicle, or...
  • Page 308 Your trailer’s brake system can tap into the Before you start, check all trailer hitch parts and vehicle’s hydraulic brake system only if: attachments, safety chains, electrical connector, lamps, tires and mirror adjustment. If the trailer has • The trailer parts can withstand 3,000 psi electric brakes, start your vehicle and trailer (20 650 kPa) of pressure.
  • Page 309 Backing Up When towing a trailer, the arrows on your instrument panel will flash for turns even if the bulbs Hold the bottom of the steering wheel with on the trailer are burned out. Thus, you may think one hand. Then, to move the trailer to the left, just drivers behind you are seeing your signal when move that hand to the left.
  • Page 310 Parking on Hills 4. Reapply the regular brakes. Then apply your parking brake, and then shift into PARK (P), or REVERSE (R) for a manual transmission. CAUTION: See Parking Brake on page 130 for more information. 5. If you have a four-wheel-drive vehicle, be sure You really should not park your the transfer case is in a drive gear and not in vehicle, with a trailer attached, on a hill.
  • Page 311: Trailer Recommendations

    Maintenance When Trailer Towing Trailer Recommendations Your vehicle will need service more often You must subtract your hitch load from the when you’re pulling a trailer. See Scheduled CWR for your vehicle. Weigh your vehicle with Maintenance on page 437 for more on this. Things your trailer attached, so that you won’t go over that are especially important in trailer operation the GVWR or the GAWR.
  • Page 312 NOTES...
  • Page 313: Service And Appearance Care

    Section 5 Service and Appearance Care Service ............316 Engine Oil Life System ......328 Accessories and Modifications ....316 Engine Air Cleaner/Filter ......330 California Proposition 65 Warning ....317 Automatic Transmission Fluid ....331 Doing Your Own Service Work ....317 Manual Transmission Fluid ......
  • Page 314 Section 5 Service and Appearance Care Bulb Replacement ........361 Tire Chains ..........392 Halogen Bulbs ........... 361 If a Tire Goes Flat ........393 Headlamps ..........362 Changing a Flat Tire ......... 394 Front Turn Signal, Parking and Removing the Spare Tire and Tools ..395 Daytime Running Lamps (DRL) ....
  • Page 315 Section 5 Service and Appearance Care Sheet Metal Damage ......... 422 Electrical System ........425 Finish Damage .......... 422 Add-On Electrical Equipment ..... 425 Underbody Maintenance ......423 Windshield Wiper Fuses ......425 Chemical Paint Spotting ......423 Fuses and Circuit Breakers ....... 426 Vehicle Care/Appearance Materials ....
  • Page 316: Service

    Service Accessories and Modifications When you add non-GM accessories to your vehicle Your dealer knows your vehicle best and wants they can affect your vehicle’s performance and you to be happy with it. We hope you will go safety, including such things as, airbags, braking, to your dealer for all your service needs.
  • Page 317: California Proposition 65 Warning

    California Proposition 65 Warning CAUTION: (Continued) Most motor vehicles, including this one, contain and/or emit chemicals known to the State of • Be sure to use the proper nuts, bolts, California to cause cancer and birth defects or other and other fasteners. English and metric reproductive harm.
  • Page 318: Adding Equipment To The Outside Of

    Adding Equipment to the Outside Gasoline Specifications of Your Vehicle At a minimum, gasoline should meet ASTM specification D 4814 in the United States or Things you might add to the outside of your CAN/CGSB-3.5 in Canada. Some gasolines may vehicle can affect the airflow around it.
  • Page 319: Additives

    Additives Notice: Your vehicle was not designed for fuel that contains methanol. Do not use To provide cleaner air, all gasolines in the United fuel containing methanol. It can corrode metal States are now required to contain additives parts in your fuel system and also damage that will help prevent engine and fuel system the plastic and rubber parts.
  • Page 320: Fuels In Foreign Countries

    Fuels in Foreign Countries Filling the Tank If you plan on driving in another country outside the United States or Canada, the proper fuel may CAUTION: be hard to find. Never use leaded gasoline or any other fuel not recommended in the previous Fuel vapor burns violently and a fuel fire text on fuel.
  • Page 321 CAUTION: If you spill fuel and then something ignites it, you could be badly burned. Fuel can spray out on you if you open the fuel cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather.
  • Page 322: Filling A Portable Fuel Container

    Filling a Portable Fuel Container This would allow fuel to evaporate into the atmosphere. If the fuel cap is not properly installed, the FUEL CAP message will appear on the Driver Information Center (DIC) and the check CAUTION: engine light will be lit on the instrument panel cluster.
  • Page 323: Checking Things Under The Hood

    Checking Things Under Hood Release To open the hood, do the following: the Hood 1. Pull the handle with this symbol on it. It is located inside CAUTION: the vehicle on the lower left side of Things that burn can get on hot engine the instrument parts and start a fire.
  • Page 324: Engine Compartment Overview

    Engine Compartment Overview When you open the hood on the 2.9L engine (3.7L engine similar), you will see the following:...
  • Page 325: Engine Oil

    A. Windshield Washer Fluid. See “Adding Washer K. Brake Fluid Reservoir. See “Brake Fluid” under Fluid” under Windshield Washer Fluid on Brakes on page 350. page 349. L. Engine Compartment Fuse Block. See Engine B. Engine Coolant Recovery Tank. See Engine Compartment Fuse Block on page 426.
  • Page 326 2. Pull out the dipstick and clean it with a paper Notice: Do not add too much oil. If the engine towel or cloth, then push it back in all the has so much oil that the oil level gets above way.
  • Page 327 What Kind of Engine Oil to Use These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils such as SAE 20W-50. Oils meeting these requirements should also have the starburst symbol on the container.
  • Page 328: Engine Oil Life System

    If you are in an area of extreme cold, where the When the system has calculated that oil life has temperature falls below 20°F ( 29°C), it is been diminished, it will indicate that an oil change is recommended that you use either an SAE 5W-30 necessary.
  • Page 329 How to Reset the Engine Oil Life What to Do with Used Oil System Used engine oil contains certain elements that may be unhealthy for your skin and could The Engine Oil Life System calculates when to even cause cancer. Do not let used oil stay on change your engine oil and filter based on vehicle your skin for very long.
  • Page 330: Engine Air Cleaner/Filter

    Engine Air Cleaner/Filter When to Inspect the Engine Air Cleaner/Filter Inspect the air cleaner/filter at the Maintenance II intervals and replace it at the first oil change after each 50,000 mile (83 000 km) interval. See Scheduled Maintenance on page 437 for more information.
  • Page 331: Automatic Transmission Fluid

    Automatic Transmission Fluid CAUTION: When to Check and Change Automatic Transmission Fluid Operating the engine with the air A good time to check your automatic transmission cleaner/filter off can cause you or others fluid level is when the engine oil is changed. to be burned.
  • Page 332 How to Check Automatic Transmission To get the right reading, the fluid should be at normal operating temperature, which is 180°F to Fluid 200°F (82°C to 93°C). Because this operation can be a little difficult, you Get the vehicle warmed up by driving about may choose to have this done at the dealership 15 miles (24 km) when outside temperatures are service department.
  • Page 333 3. With your foot on the brake pedal, move the shift lever through each gear range, pausing for about three seconds in each range. Then, position the shift lever in PARK (P). 4. Let the engine run at idle for three minutes or more.
  • Page 334: Manual Transmission Fluid

    How to Add Automatic Transmission Manual Transmission Fluid Fluid When to Check Refer to the Maintenance Schedule to determine A good time to have it checked is when the what kind of transmission fluid to use. See engine oil is changed. However, the fluid in your Recommended Fluids and Lubricants on page 447.
  • Page 335 How to Add Fluid Then, follow these steps: Here is how to add fluid. Refer to the Maintenance Schedule to determine what kind of fluid to use. See Recommended Fluids and Lubricants on page 447. 1. Remove the filler plug. 2.
  • Page 336: Hydraulic Clutch

    Hydraulic Clutch When to Check and What to Use The hydraulic clutch linkage in your vehicle is self-adjusting. The clutch master cylinder reservoir is filled with hydraulic clutch fluid. The hydraulic clutch fluid reservoir cap has this symbol on it. See Engine Compartment Overview on page 324 for...
  • Page 337: Engine Coolant

    How to Check and Add Fluid A 50/50 mixture of clean, drinkable water and ® DEX-COOL coolant will: The proper fluid should be added if the level does • Give freezing protection down to not reach the bottom of the diaphragm when it 34°F ( 37°C).
  • Page 338 What to Use Notice: If you use an improper coolant mixture, your engine could overheat and be Use a mixture of one-half clean, drinkable water badly damaged. The repair cost would not be ® and one-half DEX-COOL coolant which will covered by your warranty.
  • Page 339 It is located toward the rear of the engine compartment on the passenger’s side of the CAUTION: (Continued) vehicle. See Engine Compartment Overview on page 324 for more information on location. Never turn the radiator pressure The vehicle must be on a level surface. When cap —...
  • Page 340: Radiator Pressure Cap

    Radiator Pressure Cap If Steam Is Coming From Your Engine Notice: If the pressure cap is not tightly installed, coolant loss and possible engine CAUTION: damage may occur. Be sure the cap is properly and tightly secured. Steam from an overheated engine can See Engine Compartment Overview on page 324 burn you badly, even if you just open the for more information on location.
  • Page 341: If No Steam Is Coming From Your Engine

    If No Steam Is Coming From Your If you no longer have the overheat warning, you can drive. Just to be safe, drive slower for about Engine 10 minutes. If the warning does not come back on, If you get an engine overheat warning but see or you can drive normally.
  • Page 342: Cooling System

    Cooling System When you decide it is safe to lift the hood, here is what you will see: When the engine is cold, the coolant level should be at least up to the FULL COLD mark. If it is not, you may have a leak at the pressure cap or in the radiator hoses, heater hoses, radiator, water pump or somewhere else in the cooling system.
  • Page 343 Notice: Engine damage from running your engine without coolant is not covered by CAUTION: your warranty. ® Notice: Using coolant other than DEX-COOL Heater and radiator hoses, and other may cause premature engine, heater core, engine parts, can be very hot. Do not or radiator corrosion.
  • Page 344 How to Add Coolant to the Coolant Recovery Tank CAUTION: If you have not found a problem yet, but the Adding only plain water to your cooling coolant level is not at the FULL COLD mark, add a 50/50 mixture of clean, drinkable water and system can be dangerous.
  • Page 345 Notice: In cold weather, water can freeze and crack the engine, radiator, heater core and CAUTION: other parts. Use the recommended coolant and the proper coolant mixture. Steam and scalding liquids from a hot cooling system can blow out and burn CAUTION: you badly.
  • Page 346 ® How to Add Coolant to the Radiator 3. Fill the radiator with the proper DEX-COOL coolant mixture, up to the base of the filler neck. See Engine Coolant on page 337 for more information about the proper coolant mixture. 1.
  • Page 347: Engine Fan Noise

    Engine Fan Noise This vehicle has a clutched engine cooling fan. When the clutch is engaged, the fan spins faster to provide more air to cool the engine. In most everyday driving conditions, the clutch is not engaged. This improves fuel economy and reduces fan noise.
  • Page 348: Power Steering Fluid

    Power Steering Fluid How to Check Power Steering Fluid 1. Turn the key off and let the engine The power steering fluid compartment cool down. reservoir is located near 2. Wipe the cap and the top of the reservoir clean. the front of the engine compartment, behind 3.
  • Page 349: Windshield Washer Fluid

    Windshield Washer Fluid Notice: • When using concentrated washer fluid, What to Use follow the manufacturer’s instructions for adding water. When you need windshield washer fluid, be sure • to read the manufacturer’s instructions before Do not mix water with ready-to-use washer use.
  • Page 350: Brakes

    Brakes So, it is not a good idea to top off the brake fluid. Adding brake fluid will not correct a leak. If Brake Fluid you add fluid when your linings are worn, then you will have too much fluid when you get new brake linings.
  • Page 351 Checking Brake Fluid CAUTION: You can check the brake fluid without taking off the cap. With the wrong kind of fluid in the brake Look at the brake fluid system, the brakes may not work well, or reservoir. The fluid level they may not even work at all.
  • Page 352 Brake Wear Properly torqued wheel nuts are necessary to help prevent brake pulsation. When tires are rotated, Your vehicle has front disc brakes and rear inspect brake pads for wear and evenly tighten drum brakes. wheel nuts in the proper sequence to GM torque Disc brake pads have built-in wear indicators that specifications.
  • Page 353: Battery

    Replacing Brake System Parts Warning: Battery posts, terminals, and related accessories contain lead and lead compounds, The braking system on a vehicle is complex. Its chemicals known to the State of California many parts have to be of top quality and work well to cause cancer and reproductive harm.
  • Page 354: Jump Starting

    Jump Starting Notice: Ignoring these steps could result in costly damage to your vehicle that would If your vehicle’s battery has run down, you may not be covered by your warranty. want to use another vehicle and some jumper Trying to start your vehicle by pushing or cables to start your vehicle.
  • Page 355 Put an automatic transmission in PARK (P) or a manual transmission in NEUTRAL before CAUTION: setting the parking brake. If you have a four-wheel-drive vehicle, be sure the transfer Using a match near a battery can cause case is not in NEUTRAL. battery gas to explode.
  • Page 356 CAUTION: Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running. 5. Check that the jumper cables do not have loose or missing insulation. If they do, you could get a shock.
  • Page 357 7. Do not let the other end touch metal. Connect 9. Connect the other end of the negative ( ) cable it to the positive (+) terminal of the good at least 18 inches (45 cm) away from the dead battery.
  • Page 358 Notice: If the jumper cables are connected or To disconnect the jumper cables from both removed in the wrong order, electrical shorting vehicles, do the following: may occur and damage the vehicle. The repairs 1. Disconnect the black negative ( ) cable from would not be covered by your warranty.
  • Page 359: Rear Axle

    Rear Axle The proper level is from 0 to 3/8 inch (0 mm to 10 mm) below the bottom of the filler plug hole, located on the rear axle. When to Check and Change Lubricant What to Use It is not necessary to regularly check rear axle fluid unless you suspect there is a leak or you hear See Recommended Fluids and Lubricants on an unusual noise.
  • Page 360: Front Axle

    Front Axle When to Check and Change Lubricant It is not necessary to regularly check your front axle fluid unless you suspect there is a leak or you hear an unusual noise. A fluid loss could indicate a problem. Have it inspected and repaired. How to Check Lubricant A.
  • Page 361: Bulb Replacement

    Bulb Replacement If the level is below the bottom of the filler plug hole, located on the front axle, you may need For the proper type of replacement bulbs, see to add some lubricant. Replacement Bulbs on page 366. When the differential is cold, add enough lubricant For any bulb changing procedure not listed in this to raise the level to 1/2 inch (12 mm) below the section, contact your dealer.
  • Page 362: Headlamps

    Headlamps 3. Turn the bulb socket counterclockwise to remove it from the headlamp assembly A. Low-Beam Headlamp/Daytime Running and pull it straight out. Lamps (DRL) 4. Unplug the electrical connector from the old B. High-Beam Headlamp bulb by releasing the clips on the bulb socket.
  • Page 363: Front Turn Signal, Parking And Daytime Running Lamps (Drl)

    Front Turn Signal, Parking and 3. Turn the bulb socket counterclockwise and remove it from the lamp assembly. Daytime Running Lamps (DRL) 4. Holding the socket, pull the old bulb to To replace one of these bulbs, do the following: release it from the bulb socket.
  • Page 364: Center High-Mounted Stoplamp (Chmsl)

    Center High-Mounted Stoplamp Taillamps, Turn Signal, Stoplamps (CHMSL) and Back-up Lamps A. Stoplamp/Taillamp To replace the CHMSL bulb, do the following: B. Turn Signal/Taillamp 1. Remove the two screws and lift off the lamp assembly from the vehicle. C. Back-up Lamp 2.
  • Page 365 To replace one of these bulbs, do the following: 3. Pull the lamp assembly away from the vehicle. 1. Open the tailgate. See Tailgate on page 108 4. Turn the bulb socket counterclockwise to for more information. remove it from the taillamp assembly. 2.
  • Page 366: License Plate Lamp

    License Plate Lamp Replacement Bulbs Exterior Lamp Bulb Number To replace one of these bulbs, do the following: Center High-Mounted Stoplamp (CHMSL) License Plate Bulb Headlamps High-beam 9005 Low-beam/Daytime Running 9006 Lamp (DRL) Parking/Front Turn Signal 3757KA 1. Reach under the rear bumper for the bulb Parking Lamp (Inboard) 3157A socket.
  • Page 367: Windshield Wiper Blade Replacement

    Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear and cracking. See Scheduled Maintenance on page 437 for more information. Replacement blades come in different types and are removed in different ways. For proper type and length, see Normal Maintenance Replacement Parts on page 449.
  • Page 368 4. To install the new wiper insert, slide the insert (D), notched end last, into the end with two blade claws (A). Slide the insert all A. Claw in Notch the way through the blade claws at the B. Correct Installation opposite end (B).
  • Page 369: Tires

    Tires CAUTION: (Continued) Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever • Underinflated tires pose the same have questions about your tire warranty and where danger as overloaded tires. The to obtain service, see your GM Warranty booklet resulting accident could cause serious for details.
  • Page 370: Tire Sidewall Labeling

    Tire Sidewall Labeling (A) Tire Size: The tire size is a combination of letters and numbers used to define a particular Useful information about a tire is molded into its tire’s width, height, aspect ratio, construction type sidewall. The examples below show a typical and service description.
  • Page 371 (E) Tire Ply Material: The type of cord and number of plies in the sidewall and under the tread. (F) Uniform Tire Quality Grading (UTQG): Tire manufacturers are required to grade tires based on three performance factors: treadwear, traction and temperature resistance. For more information see Uniform Tire Quality Grading on page 389.
  • Page 372 (B) Tire Ply Material: The type of cord and (E) Tire Inflation: The temporary use tire or number of plies in the sidewall and under compact spare tire should be inflated to 60 psi the tread. (420 kPa). For more information on tire pressure and inflation see Inflation - Tire Pressure on (C) Tire Identification Number (TIN): The Tire page 377.
  • Page 373 Tire Size (C) Aspect Ratio: A two-digit number that indicates the tire height-to-width measurements. The following illustration shows an example of a For example, if the tire size aspect ratio is 70, as typical passenger vehicle tire size. shown in item C of the illustration, it would mean that the tire’s sidewall is 70 percent as high as it is wide.
  • Page 374: Tire Terminology And Definitions

    Tire Terminology and Definitions Cold Tire Pressure: The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has built up heat Air Pressure: The amount of air inside the tire from driving.
  • Page 375 GAWR RR: Gross Axle Weight Rating for the rear Normal Occupant Weight: The number of axle. See Loading Your Vehicle on page 286. occupants a vehicle is designed to seat multiplied by 150 lbs (68 kg). See Loading Your Vehicle Intended Outboard Sidewall: The side of on page 286.
  • Page 376 Radial Ply Tire: A pneumatic tire in which the UTQGS (Uniform Tire Quality Grading ply cords that extend to the beads are laid at Standards): A tire information system that 90 degrees to the centerline of the tread. provides consumers with ratings for a tire’s traction, temperature, and treadwear.
  • Page 377: Inflation - Tire Pressure

    Inflation - Tire Pressure A Tire and Loading Information label is attached to the vehicle’s center pillar (B-pillar), below the Tires need the correct amount of air pressure to driver’s door latch. This label shows your vehicle’s operate effectively. original equipment tires and the correct inflation pressures for your tires when they are cold.
  • Page 378: Tire Pressure Monitor System

    How to Check Tire Pressure Monitor System Use a good quality pocket-type gage to check tire Your vehicle has a Tire Pressure Monitor System pressure. You cannot tell if your tires are (TPMS). This system uses radio and sensor properly inflated simply by looking at them. Radial technology to check tire pressure levels.
  • Page 379 For additional information and details about the As an added safety DIC operation and displays see DIC Controls and feature, your vehicle Displays on page 194 and DIC Warnings and has been equipped with Messages on page 198. a tire pressure monitoring system You may notice, during cooler weather conditions, (TPMS) that illuminates...
  • Page 380 Your vehicle has also been equipped with a TPMS A Tire and Loading Information label, attached to malfunction indicator to indicate when the your vehicle, shows the size of your vehicle’s system is not operating properly. The TPMS original equipment tires and the correct inflation malfunction indicator is combined with the low tire pressure for your vehicle’s tires when they are cold.
  • Page 381 TPMS Sensor Identification Codes If it takes longer than one minute, to match the first tire and wheel, or more than five minutes Each TPMS sensor has a unique identification to match all four tire and wheel positions code. Any time you replace one or more of the matching process stops and you will need to the TPMS sensors or rotate your vehicle’s tires, start over.
  • Page 382 5. Remove the valve cap from the valve cap 8. Proceed to the driver’s side rear tire, and stem. Activate the TPMS sensor by repeat the procedure in Step 5. increasing or decreasing the tire’s air pressure 9. After hearing the confirming horn chirp for the for 10 seconds, then stop and listen for a driver side rear tire, check to see if the TPMS single horn chirp.
  • Page 383: Tire Inspection And Rotation

    Federal Communications Commission Tire Inspection and Rotation (FCC) and Industry and Science Canada Tires should be rotated every 5,000 to 8,000 miles (8 000 to 13 000 km). The Tire Pressure Monitor System (TPMS) operates on a radio frequency and complies with Any time you notice unusual wear, rotate your Part 15 of the FCC Rules.
  • Page 384 CAUTION: Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When you change a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle.
  • Page 385: When It Is Time For New Tires

    When It Is Time for New Tires You need a new tire if any of the following statements are true: One way to tell when it • You can see the indicators at three or more is time for new tires is places around the tire.
  • Page 386: Buying New Tires

    Buying New Tires CAUTION: GM has developed and matched specific tires for your vehicle. The original equipment tires installed on your vehicle, when it was new, were Mixing tires could cause you to lose designed to meet General Motors Tire control of your vehicle while driving.
  • Page 387 If you must replace your vehicle’s tires with those CAUTION: (Continued) that do not have a TPC Spec number, make sure they are the same size, load range, speed rating, and construction type (radial and Because they were designed and bias-belted tires) as your vehicle’s original tires.
  • Page 388: Different Size Tires And Wheels

    Different Size Tires and Wheels CAUTION: If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, If you add different sized wheels, your including its braking, ride and handling vehicle may not provide an acceptable characteristics, stability, and resistance to rollover.
  • Page 389: Uniform Tire Quality Grading

    Uniform Tire Quality Grading Treadwear The treadwear grade is a comparative rating Quality grades can be found where applicable on based on the wear rate of the tire when tested the tire sidewall between tread shoulder and under controlled conditions on a specified maximum section width.
  • Page 390: Wheel Alignment And Tire Balance

    Temperature – A, B, C Wheel Alignment and Tire Balance The temperature grades are A (the highest), B, The tires and wheels on your vehicle were aligned and C, representing the tire’s resistance to and balanced carefully at the factory to give you the generation of heat and its ability to dissipate the longest tire life and best overall performance.
  • Page 391 Your dealer will know the kind of wheel you need. Notice: The wrong wheel can also cause problems with bearing life, brake cooling, Each new wheel should have the same speedometer or odometer calibration, load-carrying capacity, diameter, width, offset and headlamp aim, bumper height, vehicle ground be mounted the same way as the one it clearance, and tire or tire chain clearance...
  • Page 392: Tire Chains

    Tire Chains CAUTION: (Continued) CAUTION: Follow that manufacturer’s instructions. To help avoid damage to your vehicle, drive slowly, readjust, or remove the If your vehicle has P225/75R15, device if it is contacting your vehicle. P265/75R15, P235/75R15, or P235/50R18 Do not spin the vehicle’s wheels. size tires, do not use tire chains.
  • Page 393: If A Tire Goes Flat

    If a Tire Goes Flat CAUTION: It is unusual for a tire to blowout while you are driving, especially if you maintain your vehicle’s tires properly. If air goes out of a tire, it is Lifting a vehicle and getting under it to do much more likely to leak out slowly.
  • Page 394: Changing A Flat Tire

    Changing a Flat Tire CAUTION: (Continued) If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on 3. If you have a four-wheel-drive vehicle, your hazard warning flashers. See Hazard be sure the transfer case is in a drive Warning Flashers on page 158 for more gear –...
  • Page 395: Removing The Spare Tire And Tools

    Removing the Spare Tire and Tools When your vehicle has a flat tire, use the following example as a guide to assist you in the placement The tools you will need are located under the of the wheel blocks. passenger’s seat. Crew Cab For crew cab models, the jack and wheel blocks are located under the driver’s side rear seat.
  • Page 396 For regular and 2. Turn the wing nut on the cover extended cab vehicles, counterclockwise to remove it. the jack and wheel For crew cab models, reach under the rear blocks are located under seat to access the jack and wheel blocks. To the cover at the reinstall the jack and wheel block assembly center of the vehicle...
  • Page 397 A. Jack Handle Extensions 2. Insert the hoist end (chiseled end) of the extension tool (C) through the hole in the B. Jack rear bumper and into the funnel-shaped guide. C. Extension Tool The chiseled end of the extension is used D.
  • Page 398: Removing The Flat Tire And Installing The Spare Tire

    Removing the Flat Tire and 3. Turn the wheel wrench (D) counterclockwise to lower the spare tire to the ground. Continue Installing the Spare Tire to turn the wheel wrench until the spare tire Use the following pictures and instructions to can be pulled out from under the vehicle.
  • Page 399 1. Remove the center cap by placing the chisel 2. Use the wheel wrench to loosen all the wheel end of the wheel wrench (E) into one of the nuts by turning it counterclockwise. Do not slots on the wheel and gently prying the remove the wheel nuts yet.
  • Page 400 CAUTION: Getting under a vehicle when it is jacked up is dangerous. If the vehicle slips off the jack you could be badly injured or killed. Never get under a vehicle when it is supported only by a jack. CAUTION: Front Position Raising your vehicle with the jack 3.
  • Page 401 Front Position Rear Position If the flat tire is on the front of the vehicle, If the flat tire is on the rear, position the jack position the jack to the rear of the front tire in under the rear axle and get as close as the pocket off of the frame.
  • Page 402 6. Remove all the wheel nuts and take CAUTION: (Continued) off the flat tire. The wheel could come off and cause an accident. When you change a wheel, remove any rust or dirt from the places where the wheel attaches to the vehicle. In an emergency, you can use a cloth or a paper towel to do this;...
  • Page 403 8. Install the spare tire. CAUTION: Never use oil or grease on studs or nuts. If you do, the nuts might come loose. Your wheel could fall off, causing a serious accident. 9. Put the wheel nuts back on with the rounded end of the Front Position nuts toward the...
  • Page 404 CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to come loose and even come off. This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts.
  • Page 405 Notice: Improperly tightened wheel nuts can When you reinstall the regular wheel and tire, you lead to brake pulsation and rotor damage. must also reinstall the center cap. Place the To avoid expensive brake repairs, evenly cap on the wheel and tap it into place until it seats tighten the wheel nuts in the proper sequence flush with the wheel.
  • Page 406: Secondary Latch System

    Secondary Latch System To release the spare tire from the secondary latch, do the following: Your vehicle has an underbody-mounted tire hoist 1. Check under the assembly that has a secondary latch system. It vehicle to see if the is designed to stop the spare tire from suddenly cable end fitting falling off your vehicle.
  • Page 407 4. Repeat this procedure at least two times. If the spare tire lowers to the ground, continue with Step 5 under Removing the Spare Tire and Tools on page 395. 5. Turn the wrench counterclockwise until approximately 6 inches (15 cm) of cable is exposed.
  • Page 408 12. Reinsert the jack handle into the jack. Lower the jack by turning the wheel wrench counterclockwise. Keep lowering the jack until the spare tire slides off the jack or is hanging by the cable. CAUTION: Someone standing too close during the procedure could be injured by the jack.
  • Page 409 13. Disconnect the jack handle from the jack and carefully remove the jack. Use one hand to push against the spare while firmly pulling the jack out from under the spare tire with the other hand. If the spare tire is hanging from the cable, insert the hoist end of the extension into the hoist shaft hole in the bumper and turn the wheel wrench counterclockwise to lower the spare the...
  • Page 410: Storing A Flat Or Spare Tire And Tools

    Storing a Flat or Spare Tire Store the tire under the rear of the vehicle in the spare tire carrier. Use the following art and and Tools text to help you. 1. Put the tire on the ground at the rear of the vehicle with the valve stem pointed down.
  • Page 411 3. Attach the wheel wrench and extensions 4. Insert the hoist end of the extension through together as shown. the hole in the rear bumper and into the funnel-shaped guide. 5. Turn the wheel wrench clockwise to raise the tire part way up. Make sure the retainer is seated in the wheel opening and the valve stem is pointed down.
  • Page 412 To store the tools, do the following: 1. Return the wheel wrench, jack extensions and the storage bag to the locations described under Removing the Spare Tire and Tools on page 395. 2. Install the wheel blocks first. Then install the jack.
  • Page 413: Spare Tire

    A. Jack replaced. You could damage your vehicle, and the repair costs would not be covered by your B. Wheel Blocks warranty. Never use four-wheel drive when the C. Wing Nut compact spare tire is installed on your vehicle. After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your vehicle’s spare tire is correctly inflated.
  • Page 414 And do not mix your compact spare tire or wheel Your vehicle may have a different size spare tire with other wheels or tires. They will not fit. than the road tires originally installed on your Keep your spare tire and its wheel together. vehicle.
  • Page 415: Appearance Care

    For heavy payloads or towing, and for low traction Lighter colored interiors may require more or four-wheel-drive conditions, repair or replace the frequent cleaning. Use care because newspapers full-size tire. Have the damaged or flat road tire and garments that transfer color to your home repaired or replaced as soon as you can and furnishings may also transfer color to your installed back onto your vehicle.
  • Page 416: Fabric/Carpet

    • Dust may be removed from small buttons and Do not heavily saturate your upholstery while knobs using a small brush with soft bristles. cleaning. • Your GM dealer has a product for cleaning your Damage to your vehicle’s interior may result vehicle’s glass.
  • Page 417: Leather

    Leather To clean, use the following instructions: 1. Saturate a lint-free, clean white cloth with A soft cloth dampened with water may be used to water or club soda. remove dust. If a more thorough cleaning is 2. Wring the cloth to remove excess moisture. necessary, a soft cloth dampened with a mild soap solution can be used.
  • Page 418: Instrument Panel, Vinyl, And Other Plastic Surfaces

    Instrument Panel, Vinyl, and Other Care of Safety Belts Plastic Surfaces Keep belts clean and dry. A soft cloth dampened with water may be used to remove dust. If a more thorough cleaning is CAUTION: necessary, a clean soft cloth dampened with a mild soap solution can be used to gently remove Do not bleach or dye safety belts.
  • Page 419: Washing Your Vehicle

    Washing Your Vehicle Cleaning Exterior Lamps/Lenses The paint finish on the vehicle provides beauty, Use only lukewarm or cold water, a soft cloth and depth of color, gloss retention, and durability. a car washing soap to clean exterior lamps and lenses. Follow instructions under Washing The best way to preserve the vehicle’s finish is to Your Vehicle on page 419.
  • Page 420: Windshield And Wiper Blades

    Protecting Exterior Bright Metal Parts If your vehicle has a basecoat/clearcoat paint finish, the clearcoat gives more depth and gloss to Bright metal parts should be cleaned regularly to the colored basecoat. Always use waxes and keep their luster. Washing with water is all that is polishes that are non-abrasive and made for a usually needed.
  • Page 421: Aluminum Or Chrome-Plated Wheels

    Grime from the windshield will stick to the wiper The surface of these wheels is similar to the blades and affect their performance. Clean painted surface of your vehicle. Do not use strong the blade by wiping vigorously with a cloth soaked soaps, chemicals, abrasive polishes, abrasive in full-strength windshield washer solvent.
  • Page 422: Tires

    Sheet Metal Damage Notice: If you drive your vehicle through an automatic car wash that has silicone carbide If the vehicle is damaged and requires sheet metal tire cleaning brushes, you could damage repair or replacement, make sure the body the aluminum or chrome-plated wheels.
  • Page 423: Underbody Maintenance

    Underbody Maintenance Vehicle Care/Appearance Materials Chemicals used for ice and snow removal and dust Description Usage control can collect on the underbody. If these are Polishing Cloth Interior and exterior not removed, corrosion and rust can develop on the Wax-Treated polishing cloth.
  • Page 424: Vehicle Identification

    Vehicle Identification Description Usage Removes swirl marks, fine Swirl Remover Polish scratches, and other light Vehicle Identification Number (VIN) surface contamination. Removes light scratches Cleaner Wax and protects finish. Cleans, shines, and Foaming Tire Shine protects in one step. No Low Gloss wiping necessary.
  • Page 425: Service Parts Identification Label

    Engine Identification Electrical System The eighth character in the VIN is the engine code. This code will help you identify your vehicle’s Add-On Electrical Equipment engine, specifications, and replacement parts. Notice: Do not add anything electrical to your Service Parts Identification Label vehicle unless you check with your dealer first.
  • Page 426: Fuses And Circuit Breakers

    Fuses and Circuit Breakers Engine Compartment Fuse Block The wiring circuits in your vehicle are protected from short circuits by a combination of fuses and circuit breakers. This greatly reduces the chance of fires caused by electrical problems. Look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse.
  • Page 427 Fuses Usage Fuses Usage Daylight Running Lamps S/ROOF Sunroof (If Equipped) AUX PWR 1 Accessory Power 1 Air Conditioning Control Head, Power Seats STOP Brake Switch, Stoplamps Power Seat Circuit Breaker BLWR Climate Control Fan PWR/SEAT (If Equipped)
  • Page 428 Fuses Usage Fuses Usage RT HDLP Passenger’s Side Headlamp Anti-lock Brake System (ABS), ABS module, Four-Wheel Drive, LT HDLP Driver’s Side Headlamp Gravity Sensor AUX PWR 2 Accessory Power 2 BCK/UP Back-up Lights FOG/LAMP Fog Lamps (If Equipped) FRT/AXLE Front Axle Actuator A/C CMPRSR Air Conditioning Compressor TRN/HAZRD...
  • Page 429 Fuses Usage Relays Usage Driver’s Side Rear Taillamp, Front Parking Lamp Fuse, Rear PRK/LAMP REAR PRK Passenger Side Airbag Indicator Parking Lamps LAMP2 Lighting, Instrument Panel Dimming HDLP Headlamps Power (2WD/4WD switch lighting) FOG/LAMP Fog Lamps (If Equipped) CLSTR Cluster FUEL/PUMP Fuel Pump, Fuel Pump Fuse TRN/HAZRD...
  • Page 430: Capacities And Specifications

    Capacities and Specifications The following approximate conversion capacities are given in English and metric conversions. See Recommended Fluids and Lubricants on page 447 for more information. Capacities and Specifications Capacities Application English Metric For the air conditioning system refrigerant charge amount, see the refrigerant caution label located Air Conditioning Refrigerant R134a under the hood.
  • Page 431 Capacities and Specifications (cont’d) Capacities Application English Metric Transmission (Drain and Refill) Automatic 5.0 qt 4.7 L Manual – Two - Wheel Drive 2.3 qt 2.2 L Manual – Four - Wheel Drive 2.4 qt 2.3 L Wheel Nut Torque 100 lb ft 140 Y All capacities are approximate.
  • Page 432 NOTES...
  • Page 433: Maintenance Schedule

    Section 6 Maintenance Schedule Maintenance Schedule ........ 434 Owner Checks and Services ..... 442 Introduction ..........434 At Each Fuel Fill ........443 Maintenance Requirements ......434 At Least Once a Month ......443 Your Vehicle and the Environment .... 434 At Least Once a Year .......
  • Page 434: Maintenance Schedule

    Maintenance Schedule Maintenance Requirements Notice: Maintenance intervals, checks, Introduction inspections, replacement parts, and recommended fluids and lubricants as Important: Keep engine oil at the proper level prescribed in this manual are necessary to and change as recommended. keep your vehicle in good working condition. Any damage caused by failure to follow scheduled maintenance may not be covered by warranty.
  • Page 435: Using The Maintenance Schedule

    Using the Maintenance Schedule This schedule is for vehicles that: • carry passengers and cargo within We at General Motors want to help you keep your recommended limits. You will find these limits vehicle in good working condition. But we do on the Tire and Loading Information label.
  • Page 436 ® The services in Scheduled Maintenance on When you go to your GM Goodwrench dealer for page 437 should be performed when indicated. your service needs, you will know that GM-trained See Additional Required Services on page 440 and and supported service technicians will perform Maintenance Footnotes on page 441 for further the work using genuine GM parts.
  • Page 437: Scheduled Maintenance

    Scheduled Maintenance If the engine oil life system is ever reset accidentally, you must service your vehicle within When the CHANGE OIL message comes on, it 3,000 miles (5 000 km) since your last service. means that service is required for your vehicle. Remember to reset the oil life system whenever See DIC Warnings and Messages on page 198.
  • Page 438 Maintenance I — Use Maintenance I if the Maintenance II — Use Maintenance II if the CHANGE OIL message comes on within previous service performed was Maintenance I. 10 months since the vehicle was purchased or Always use Maintenance II whenever the message Maintenance II was performed.
  • Page 439 Scheduled Maintenance (cont’d) Service Maintenance I Maintenance II Check engine coolant and windshield washer fluid levels and add fluid as needed. Perform any needed additional services. See “Additional Required Services” in this section. Inspect suspension and steering components. See footnote (b). Inspect engine cooling system.
  • Page 440: Additional Required Services

    Additional Required Services The following services should be performed at the first maintenance service (I or II) after the indicated miles (kilometers) shown for each item. Additional Required Services 25,000 50,000 75,000 100,000 125,000 150,000 Service and Miles (Kilometers) (40 000) (80 000) (120 000) (160 000)
  • Page 441: Maintenance Footnotes

    Maintenance Footnotes (d) Visually inspect wiper blades for wear or cracking. Replace wiper blades that appear worn (a) Visually inspect brake lines and hoses for or damaged or that streak or miss areas of proper hook-up, binding, leaks, cracks, chafing, etc. the windshield.
  • Page 442: Owner Checks And Services

    (g) A fluid loss in any vehicle system could (j) If you drive regularly under dusty conditions, indicate a problem. Have the system inspected inspect the filter at each engine oil change. and repaired and the fluid level checked. (k) Visually inspect belt for fraying, excessive Add fluid if needed.
  • Page 443: At Each Fuel Fill

    At Each Fuel Fill At Least Once a Month It is important to perform these underhood Tire Inflation Check checks at each fuel fill. Visually inspect your vehicle’s tires and make Engine Oil Level Check sure they are inflated to the correct pressures. Do not forget to check the spare tire.
  • Page 444: At Least Once A Year

    At Least Once a Year 3. On automatic transmission vehicles, try to start the engine in each gear. The Starter Switch Check vehicle should start only in PARK (P) or NEUTRAL (N). If the vehicle starts in any ® other position, contact your GM Goodwrench CAUTION: dealer for service.
  • Page 445 Automatic Transmission Shift Lock Ignition Transmission Lock Check Control System Check While parked, and with the parking brake set, try to turn the ignition to LOCK in each shift lever position. CAUTION: • With an automatic transmission, the ignition should turn to LOCK only when the shift When you are doing this inspection, the lever is in PARK (P).
  • Page 446 Parking Brake and Automatic Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot on the regular Transmission Park (P) Mechanism Check brake, set the parking brake. • To check the parking brake’s holding ability: CAUTION: With the engine running and transmission in NEUTRAL (N), slowly remove foot pressure from the regular brake pedal.
  • Page 447: Recommended Fluids And Lubricants

    Recommended Fluids and Usage Fluid/Lubricant Lubricants Chassis Lubricant (GM Part No. U.S. 12377985, Parking Brake Fluids and lubricants identified below by name, in Canada 88901242) or lubricant Cable Guides meeting requirements of NLGI #2, part number, or specification may be obtained Category LB or GC-LB.
  • Page 448 Usage Fluid/Lubricant Usage Fluid/Lubricant SAE 75W-90 Synthetic Hood and Door Axle Lubricant Hinges, Body Front and (GM Part No. U.S. 12378261, Door Hinge Rear Axle in Canada 10953455) meeting Pins, Liftgate Multi-Purpose Lubricant, Superlube GM Specification 9986115. Hinge and (GM Part No. U.S. 12346241, Linkage, in Canada 10953474).
  • Page 449: Normal Maintenance Replacement Parts

    Normal Maintenance Replacement Parts Replacement parts identified below by name, part number, or specification can be obtained from your GM dealer. ® Part GM Part Number ACDelco Part Number Engine Air Cleaner/Filter 15202408 A1624C Engine Oil Filter 2.9L Engine 88984215 PF46 3.7L Engine 89017342...
  • Page 450: Engine Drive Belt Routing

    Engine Drive Belt Routing 2.9L and 3.7L Engine without air 2.9L and 3.7L Engines with air...
  • Page 451: Maintenance Record

    Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. See Maintenance Requirements on page 434. Any additional information from Owner Checks and Services on page 442 can be added on the following record pages.
  • Page 452 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
  • Page 453 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
  • Page 454 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
  • Page 455: Customer Assistance Information

    Section 7 Customer Assistance Information Customer Assistance and Information ..456 Reporting Safety Defects ......474 Customer Satisfaction Procedure ....456 Reporting Safety Defects to the Online Owner Center ......... 459 United States Government ..... 474 Customer Assistance for Reporting Safety Defects to the Text Telephone (TTY) Users ....
  • Page 456: Customer Assistance And Information

    STEP TWO: If after contacting a member of dealership management, it appears your concern Information cannot be resolved by the dealership without further help, in the U.S., contact the GMC Consumer Relations Manager by calling Customer Satisfaction Procedure 1-800-GMC-8782 (1-800-462-8782, Customer Assistance prompt).
  • Page 457 STEP THREE — U.S. Owners: Both General You may contact the BBB Auto Line Program using Motors and your dealer are committed to making the toll-free telephone number or write them at the sure you are completely satisfied with your following address: new vehicle.
  • Page 458 STEP THREE — Canadian Owners: In the event For further information concerning eligibility in that you do not feel your concerns have been the Canadian Motor Vehicle Arbitration Plan addressed after following the procedure outlined in (CAMVAP), call toll-free 1-800-207-0685. steps 1 and 2, General Motors of Canada Limited Alternatively, you may call the General Motors wants you to be aware of its participation in a...
  • Page 459: Online Owner Center

    Online Owner Center My GM Canada (Canada only) My GM Canada is a password-protected section Online Owner Center of gmcanada.com where you can save information (United States only) on GM vehicles, get personalized offers, and use handy tools and forms with greater ease. The Owner Center is a resource for your GM ownership needs.
  • Page 460: Customer Assistance For

    General Motors of Canada Limited GMC encourages customers to call the toll-free Customer Communication number for assistance. However, if a customer Centre, CA1-163-005 wishes to write or e-mail GMC, the letter should be 1908 Colonel Sam Drive addressed to: Oshawa, Ontario L1H 8P7 www.gmcanada.com...
  • Page 461: Gm Mobility Reimbursement Program

    All Overseas Locations GM Mobility Reimbursement Program Please contact the local General Motors Business Unit. Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center This program, available to qualified applicants, Paseo de la Reforma # 2740 can reimburse you up to $1,000 of the cost...
  • Page 462: Roadside Assistance Program

    Service available 24 hours a day, 365 days a year customer to get to the nearest service station As the owner of a new GMC vehicle, you are (approximately $5 in the U.S. and 10 litres automatically enrolled in the GMC Roadside in Canada).
  • Page 463 • Additional Services for Canadian Emergency Tow From a Public Roadway or Highway: Tow to the nearest dealership for Customers warranty service or in the event of a • Trip Routing Service: Upon Request, vehicle-disabling accident. Winch-out Roadside Assistance will send you detailed, assistance when the vehicle is mired in sand, computer-personalized maps, highlighting your mud, or snow.
  • Page 464 • In many instances, mechanical failures are covered Trip Interruption Benefits and Assistance: under GMC’s Bumper-to-Bumper warranty. In the event of a warranty related vehicle However, when other services are utilized, our disablement, while en route and over Roadside Assistance Representatives will explain 250 kilometres from original point of departure, any payment obligations you might incur.
  • Page 465: Courtesy Transportation

    Courtesy Transportation GMC and General Motors of Canada Limited reserve the right to limit services or reimbursement To enhance your ownership experience, we and to an owner or driver when, in their sole our participating dealers are proud to offer...
  • Page 466 Scheduling Service Appointments Transportation Options When your vehicle requires warranty service, Warranty service can generally be completed you should contact your dealer and request an while you wait. However, if you are unable to wait, appointment. By scheduling a service appointment GM helps to minimize your inconvenience by and advising your service consultant of your providing several transportation options.
  • Page 467 Additional Program Information In addition, for U.S. customers, should you arrange transportation through a friend or relative, All program options, such as shuttle service, may limited reimbursement for reasonable fuel not be available at every dealer. Please contact expenses may be available. Claim amounts should your dealer for specific information about reflect actual costs and be supported by original availability.
  • Page 468: Vehicle Data Collection And Event Data Recorders

    Vehicle Data Collection and Event This information has been used to improve vehicle crash performance and may be used to improve Data Recorders crash performance of future vehicles and driving safety. Unlike the data recorders on many Your vehicle, like other modern motor vehicles, airplanes, these on-board systems do not has a number of sophisticated computer systems record sounds, such as conversation of vehicle...
  • Page 469: Collision Damage Repair

    Collision Damage Repair In addition, once GM collects or receives data, GM may: If your vehicle is involved in a collision and it is • use the data for GM research needs, damaged, have the damage repaired by a qualified •...
  • Page 470 Repair Facility Recycled original equipment parts may also be used for repair. These parts are typically removed GM also recommends that you choose a collision from vehicles that were total losses in prior repair facility that meets your needs before you accidents.
  • Page 471 • If your vehicle is leased, the leasing company Give only the necessary and requested may require you to have insurance that assures information to police and other parties involved repairs with Genuine GM Original Equipment in the accident. Do not discuss your personal Manufacturer (OEM) parts or Genuine condition, mental frame of mind, or anything Manufacturer replacement parts.
  • Page 472 • • Gather the important information you will Choose a reputable collision repair facility for need from the other driver. Things like name, your vehicle. Whether you select a GM dealer address, phone number, driver’s license or a private collision repair facility to fix the number, vehicle license plate, vehicle make, damage, make sure you are comfortable with model and model year, Vehicle Identification...
  • Page 473 Managing the Vehicle Damage Remember if your vehicle is leased you may be obligated to have the vehicle repaired with Repair Process Genuine GM parts, even if your insurance In the event that your vehicle requires damage coverage does not pay the full cost. repairs, GM recommends that you take an active If another party’s insurance company is paying for role in its repair.
  • Page 474: Reporting Safety Defects

    Canada) in a situation like this, we certainly hope To contact NHTSA, you may call the Vehicle you will notify us. Please call us at Safety Hotline toll-free at 1-888-327-4236 1-800-GMC-8782 (1-800-462-8782), or write: (TTY: 1-800-424-9153); go to http://www.safercar.gov; or write to: GMC Customer Assistance Center Administrator, NHTSA P.O.
  • Page 475: Service Publications Ordering Information

    Service Bulletins In Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French). Or, write: Service Bulletins give technical service information General Motors of Canada Limited needed to knowledgeably service General Customer Communication Centre, CA1-163-005 Motors cars and trucks. Each bulletin contains 1908 Colonel Sam Drive instructions to assist in the diagnosis and service Oshawa, Ontario L1H 8P7...
  • Page 476 Owner Information ORDER TOLL FREE: 1-800-551-4123 Monday-Friday 8:00 AM - 6:00 PM Owner publications are written specifically for Eastern Time owners and intended to provide basic operational information about the vehicle. The owner manual For Credit Card Orders Only will include the Maintenance Schedule for all (VISA-MasterCard-Discover), visit Helm, Inc.
  • Page 477 Airbag System (cont.) When Should an Airbag Inflate? ....82 Accessories and Modifications ..... 316 Where Are the Airbags? ......79 Accessory Power Outlet(s) ......172 AM-FM Radio ..........205 Adding Equipment to Your Airbag- Antenna, Fixed Mast ........239 Equipped Vehicle ........
  • Page 478 Appearance Care (cont.) Automatic Headlamp System ....... 168 Vehicle Care/Appearance Materials ..423 Automatic Transmission Washing Your Vehicle ......419 Fluid ............331 Weatherstrips ........... 418 Operation ..........120 Windshield and Wiper Blades ....420 Ashtray(s) ............ 173 Assist Handles ..........150 Audio System(s) ..........
  • Page 479 Bulb Replacement ........361 CD, MP3 ............. 230 Center High-Mounted Stoplamp Center Front Passenger Position, Safety (CHMSL) ..........364 Belts ............35 Front Turn Signal, Parking and Daytime Center High-Mounted Stoplamp (CHMSL) ..364 Running Lamps ........363 Chains, Tire ..........392 Halogen Bulbs .........
  • Page 480 Cleaning Coolant Aluminum or Chrome-Plated Wheels ..421 Engine Temperature Gage ......187 Exterior Lamps/Lenses ......419 Heater, Engine ......... 119 Fabric/Carpet ........... 416 Cooling System ........... 342 Finish Care ..........419 Cruise Control ..........163 Inside of Your Vehicle ......415 Cruise Control Light ........
  • Page 481 Driving (cont.) Defensive ..........242 Daytime Running Lamps ......167 Drunken ........... 243 Daytime Running Lamps Indicator Light ..193 Freeway ........... 275 Defensive Driving ........242 Hill and Mountain Roads ......278 Disc, MP3 ........... 230 In Rain and on Wet Roads ...... 271 Doing Your Own Service Work ....
  • Page 482 Engine (cont.) Flashers, Hazard Warning ......158 Check and Service Engine Soon Light ..188 Flash-to-Pass ..........161 Coolant ............ 337 Flat Tire ............393 Coolant Heater ......... 119 Flat Tire, Changing ........394 Coolant Temperature Gage ...... 187 Flat Tire, Storing ......... 410 Drive Belt Routing ........
  • Page 483 Fuses Headlamps (cont.) Engine Compartment Fuse Block ..... 426 Daytime Running Lamps ......167 Fuses and Circuit Breakers ...... 426 Flash-to-Pass ........... 161 Windshield Wiper ........425 Halogen Bulbs ......... 361 High/Low Beam Changer ......161 On Reminder ........... 167 Heated Seats ..........
  • Page 484 Instrument Panel Lamps (cont.) Overview ..........156 Exterior ............ 166 Instrument Panel (I/P) Exterior Cargo .......... 169 Brightness ..........170 Fog ............169 Cluster ............. 178 Interior ............. 170 Interior Lamps ..........170 LATCH System Child Restraints ......... 56 Latches, Seatback ......... 16 License Plate Lamps ........
  • Page 485 Lighting Maintenance Schedule (cont.) Exit ............171 At Least Once a Year ......444 Limited-Slip Rear Axle ......... 250 Introduction ..........434 Loading Your Vehicle ........286 Maintenance Footnotes ......441 Lockout Protection ........107 Maintenance Record ........ 451 Locks Maintenance Requirements ......
  • Page 486 Mirrors Off-Road Recovery ........253 Automatic Dimming Rearview with Compass and Temperature Display ..142 Engine ............. 325 Automatic Dimming Rearview with Pressure Light .......... 191 ® OnStar , Compass and Temperature Oil, Engine Oil Life System ......328 Display ..........139 Older Children, Restraints ......
  • Page 487 Parking Brake ............130 Radiator Pressure Cap ........ 340 Over Things That Burn ......135 Radios ............203 Parking Your Vehicle ........134 AM-FM Radio .......... 205 Passenger Airbag Status Indicator ....182 Care of Your CD Player ......239 Passenger Sensing System ......
  • Page 488 Rearview Mirror, Automatic Dimming with Restraint System Check Compass and Temperature Display ..142 Checking the Restraint Systems ....94 Rearview Mirror, Automatic Dimming with Replacing Restraint System Parts After ® OnStar , Compass and Temperature a Crash ..........95 Display .............
  • Page 489 Safety Belts (cont.) Secondary Latch System ......406 Driver Position ........... 25 Securing a Child Restraint How to Wear Safety Belts Properly .... 25 Center Front Seat Position ......71 Questions and Answers About Safety Rear Seat Position ........68 Belts ............
  • Page 490 Spare Tire ........... 413 Theft-Deterrent, Radio ......237, 238 Installing ..........398 Theft-Deterrent Systems ......112 Removing ..........395 Content Theft-Deterrent ......112 ® Storing ............. 410 Passlock ..........114 Specifications, Capacities ......430 Tilt Wheel ............ 158 Speedometer ..........179 Tire Starting Your Engine ........
  • Page 491 Tires (cont.) Turn and Lane-Change Signals ....160 Tire Sidewall Labeling ......370 Turn Signal/Multifunction Lever ....159 Tire Terminology and Definitions ....374 Uniform Tire Quality Grading ....389 Wheel Alignment and Tire Balance ... 390 Wheel Replacement ......... 390 Understanding Radio Reception ....
  • Page 492 Windshield Washer ............ 162 Warning Lights, Gages and Indicators ..177 Washer Fluid ........... 349 Warnings Wiper Blade Replacement ......367 DIC Warnings and Messages ....198 Wiper Blades, Cleaning ......420 Hazard Warning Flashers ......158 Wiper Fuses ..........425 Other Warning Devices ......

This manual is also suitable for:

2007 canyon

Table of Contents

Save PDF
