  • Page 1 2025 Canyon/Canyon Denali Owner’s Manual...

  • Page 2: Table Of Contents

    Contents Introduction California Proposition 65 Warning Introduction ............1 Keys, Doors, and Windows .........7 Seats and Restraints ..........26 Storage ..............74 Instruments and Controls ........ 76 Lighting ..............109 Infotainment System ........117 Climate Controls ..........144 Driving and Operating ........150 Vehicle Care ............

  • Page 3: Introduction

    Propriétaires Canadiens limited to, GM, the GM logo, GMC, the Caution On peut obtenir un exemplaire de ce guide GMC Truck Emblem, CANYON, and DENALI en français auprès du concessionnaire ou...
  • Page 4 Introduction Symbols : Under Pressure : ISOFIX/LATCH System Child Restraints : Vehicle Ahead Indicator Some of the vehicle components and labels use : Keep Fuse Block Covers Properly Installed symbols instead of text relating to a specific : Lane Change Alert Additional Instructions or Information feature, control, message, gauge, or indicator.

  • Page 5: Instrument Panel Overview

    Introduction   Instrument Panel Overview 1. Air Vents. See Air Vents 3 148. Windshield Wiper/Washer. See Windshield 3. Instrument Cluster. See Instrument Cluster Wiper/Washer 3 78. 3 83. 2. Turn Signal Lever. See Turn and Lane- Change Signals 3 113.
  • Page 6 Introduction 4. Head-Up Display (HUD). See Head-Up Locking Rear Axle. See Locking Rear Axle 17. Steering Wheel Controls. See Steering Display (HUD) 3 104. 3 194 (If Equipped). Wheel Controls 3 119. Auto Stop Disable Switch. See Stop/Start Driver Information Center (DIC) Controls. 5.
  • Page 7 Introduction 25. Trailer Brake Control Panel (If Equipped). See “Integrated Trailer Brake Control System” under Towing Equipment 3 241.

  • Page 8: Keys, Doors, And Windows

    Keys, Doors, and Windows Keys, Doors, and Windows Keys and Locks Interior Mirrors Interior Rearview Mirrors ......21 Keys Manual Rearview Mirror ........21 Keys and Locks Automatic Dimming Rearview Mirror ..21 Keys ..............7 Windows Warning Remote Key ............8 Windows ............

  • Page 9: Remote Key

    Keys, Doors, and Windows • To remove the mechanical key, press the Check the location. Other vehicles or objects button on the side of the remote key near may be blocking the signal. • the bottom, and pull the mechanical key out. Check the remote key’s battery.
  • Page 10 Keys, Doors, and Windows If the driver door is open when is pressed, all doors will lock and then the driver door will immediately unlock, if enabled. To view available settings from the infotainment screen, touch Settings > Vehicle > Remote Lock, Unlock, Start.
  • Page 11 Keys, Doors, and Windows from the infotainment screen, touch Settings If equipped with memory seats, remote keys If equipped, pressing the lock/unlock button > Vehicle > Remote Lock, Unlock, Start. See 1 and 2 are linked to seating positions of will cause all doors to lock if any of the following occur: Power Windows 3 22.
  • Page 12 Keys, Doors, and Windows Disabling Keyless Unlocking: locking is enabled, the doors may lock with the detected, the Driver Information Center will remote key inside the vehicle. Do not leave the display NO REMOTE DETECTED and the horn will With the vehicle off, press and hold remote key in an unattended vehicle.
  • Page 13 Keys, Doors, and Windows Starting the Vehicle with a Low Remote Replace the remote key battery as soon Caution as possible. Key Battery If the remote key battery is weak or if When replacing the battery, do not touch Battery Replacement there is interference with the signal, the any of the circuitry on the remote key.
  • Page 14 Keys, Doors, and Windows 1. Press the button on the side of the Caution (Continued) remote key near the bottom and pull the mechanical key out. Never pull the prevent damage, always follow the steps mechanical key out without pressing for remote key reassembly in this manual the button.

  • Page 15: Remote Start

    Keys, Doors, and Windows • The ignition is in any mode other than off. The engine will shut off after 15 minutes or after Remote Start • the remainder of the 30 minute total running The hazard warning flashers are on. If equipped with the remote start feature, the time is used, unless you stop the remote start •...

  • Page 16: Door Locks

    Keys, Doors, and Windows Keyless Access Door Locks Warning (Continued) heat and can suffer permanent injuries Warning or even death from heat stroke. Always Unlocked doors can be dangerous. lock the vehicle whenever leaving it. • • Passengers, especially children, can Outsiders can easily enter through an easily open the doors and fall out of unlocked door when you slow down or...

  • Page 17: Power Door Locks

    Keys, Doors, and Windows • lock cylinder click back into place. Remove the Shift the transmission into P (Park). When is pressed on the power door lock key and reinsert fully. Rotate the key to unlock switch with the door open, a chime will sound Automatic door locking cannot be disabled.

  • Page 18: Doors Tailgate

    Keys, Doors, and Windows 2. Move the lever up to unlock. To shut the tailgate, firmly push it upward until it latches. 3. Repeat Steps 1 and 2 on the other door, After closing the tailgate, pull it back to be sure if desired.

  • Page 19: Transporting Items That Can Catch Fire

    Keys, Doors, and Windows 4. Let the tailgate rest on the cables and slowly The board closest to the cab should be cut to Transporting Items That Can Catch lower it as far as it will go. an approximate length of 117 cm (46 in). The Fire board closest to the tailgate should be cut to an Supporting Mid-Position Cargo...

  • Page 20: Vehicle Security

    Keys, Doors, and Windows Vehicle Security Fast Flash: Vehicle is secured during the delay or the door is not unlocked by pressing to arm the system, but a door or the hood the remote key during the 10-second pre-alarm, This vehicle has theft-deterrent features, but is is open.

  • Page 21: Immobilizer

    Keys, Doors, and Windows If the engine does not start and the security Immobilizer Power Mirrors light stays on, there is a problem with the See Radio Frequency Statement 3 357. system. Turn the ignition off and try again. It is possible for the immobilizer system to Immobilizer Operation learn new or replacement keys.

  • Page 22: Folding Mirrors

    Keys, Doors, and Windows Side Blind Zone Alert (SBZA) Automatic Dimming Rearview : Press to heat the outside mirrors. See “Rear Window Defogger” under Dual The vehicle may have Side Blind Zone Alert. See Mirror Automatic Climate Control System 3 146. Side Blind Zone Alert (SBZA) 3 224.

  • Page 23: Power Windows

    Keys, Doors, and Windows Window Lockout Warning (Continued) If equipped, this feature prevents rear seat passengers from opening the rear windows. When there are children in the rear seat, use the window lockout button to prevent To enable or disable this feature from the infotainment home screen, select Controls App operation of the windows.

  • Page 24: Rear Windows

    Keys, Doors, and Windows Window Automatic Reversal System Programming the Power Windows Rear Windows If equipped, the window automatic reversal Programming may be necessary if the vehicle Sliding Rear Window system reverses and stops window movement battery is disconnected or discharged. To if it detects an object in its path.

  • Page 25: Sun Visors

    Keys, Doors, and Windows Roof movement. To express-close the sunroof, fully Sun Visors press and release (1). Press and release Sunroof (1) again to stop the movement. Open/Close (Manual Mode): To open the sunroof, press and hold (1). Release (1) to stop the movement. Press and hold (1) to close the sunroof.
  • Page 26 Keys, Doors, and Windows If an object is in the path while express-closing, the reversal system will detect the object, stop, and open the sunroof slightly. If frost or other conditions prevent closing, override the feature by closing the sunroof in manual mode. To stop movement, release (1).

  • Page 27: Seats And Restraints

    Seats and Restraints Seats and Restraints Head Restraints When Should an Airbag Inflate? ....45 What Makes an Airbag Inflate? ....46 How Does an Airbag Restrain? ....46 Warning Head Restraints What Will You See After an Airbag Inflates? ............47 Head Restraints ..........

  • Page 28: Front Seats Seat Adjustment

    Seats and Restraints Front Seats Rear Head Restraints If you are installing a child restraint in the rear seat, see Lower Anchors and Tethers for Children The vehicle's front seats have adjustable head The vehicle’s rear seats have head restraints in (LATCH System) 3 60.

  • Page 29: Power Seat Adjustment

    Seats and Restraints Seat Height Adjuster To adjust a manual seat position, if equipped: To adjust a power seat, if equipped: • 1. Pull the handle at the front of the seat Move the seat forward or rearward by If equipped, move the lever up or down to raise cushion to unlock it.

  • Page 30: Reclining Seatbacks

    Seats and Restraints Reclining Seatbacks Warning Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the seat belts cannot do their job. The shoulder belt will not be against your body. Instead, it will be in front of you. In a crash, you could go into it, receiving neck or other injuries.

  • Page 31: Lumbar Adjustment

    Seats and Restraints 2. Push and pull on the seatback to make sure Lumbar Adjustment Memory Seats it is locked. Power Lumbar Power Reclining Seatbacks Overview If equipped, press and hold the front or If equipped, the memory seat feature allows To recline a power seatback, if equipped: rear of the control to increase or decrease drivers to save their unique driving positions...
  • Page 32 Seats and Restraints Seat Entry Memory and/or Seat Exit Memory. remote key. Turn the vehicle off and 2, the two beeps will not sound indicating See “Enabling Automatic Recalls” later in this remove the other key or remote key from memory position were not saved.
  • Page 33 Seats and Restraints • Enabling Automatic Recalls Seat Entry Memory is enabled. See Auto Seat Exit Memory Recall • “Enabling Automatic Recalls” previously in Seat Entry Memory moves the driver seat Seat Exit Memory will begin movement to the this section. to the selected 1 or 2 position when the seating position of the button when:...

  • Page 34: Heated And Ventilated Front Seats

    Seats and Restraints • During Manual memory recall: Press to heat the driver or passenger Warning (Continued) seat. Release 1, 2, or memory button • on the seat that insulates against heat, During Auto Seat Entry Memory Recall: Press , if equipped, to ventilate the such as a blanket, cushion, cover, or similar driver or passenger seat.

  • Page 35: Rear Seats

    Seats and Restraints the center stack. Use the manual heated or To enable or disable remote start heated or row doors. There may be an alert even when ventilated seat buttons on the center stack to ventilated seats, select Settings > Vehicle there is nothing in the rear seat;...

  • Page 36: Seat Belts

    Seats and Restraints Seat Belts This vehicle has indicators as a reminder to Warning (Continued) buckle the seat belts. See Seat Belt Reminders This section describes how to use seat belts 3 89. The person wearing the belt could be properly, and some things not to do. seriously injured.

  • Page 37: Buckle To Drive

    Seats and Restraints Questions and Answers About Seat Belts work. To turn the Buckle to Drive feature on or is on the front passenger seat. If this happens, off, select Settings > Vehicle > Buckle to Drive. remove the object from the seat or buckle the Will I be trapped in the vehicle after seat belt to shift out of P (Park).
  • Page 38 Seats and Restraints • It is very important for all occupants to buckle Wear the shoulder belt over the shoulder up. Statistics show that unbelted people are and across the chest. These parts of the hurt more often in crashes than those who are body are best able to take belt restraining wearing seat belts.

  • Page 39: Lap-Shoulder Belt

    Seats and Restraints Warning You can be seriously injured or killed if the shoulder belt is worn behind your back, under your legs, or wrapped around your neck. The shoulder belt can tighten but cannot be loosened if it is locked. The shoulder belt locks when it is pulled all the way out of the retractor.
  • Page 40 Seats and Restraints on the seat, move the seat rearward or recline the seat until the shoulder belt retractor lock releases. 2. Pick up the latch plate and pull the belt 3. Push the latch plate into the buckle until across you.
  • Page 41 Seats and Restraints Before a door is closed, be sure the seat belt is out of the way. If a door is slammed against a seat belt, damage can occur to both the seat belt and the vehicle. Shoulder Belt Height Adjuster The vehicle has a shoulder belt height adjuster for the driver and front outboard passenger seating positions.

  • Page 42: Seat Belt Use During Pregnancy

    Seats and Restraints Push up on the release button and move the Rear Seat Belt Comfort Guides height adjuster to the desired position. Rear seat belt comfort guides may provide After the adjuster is set to the desired position, added seat belt comfort for older children who try to move it down without pushing the have outgrown booster seats and for some release button to make sure it has locked...

  • Page 43: Safety System Check

    Seats and Restraints But if a seat belt is not long enough, your dealer by reversing the latch plate on the webbing. If Warning will order you an extender. Only a GM issued the twist cannot be corrected, ask your dealer extender should be used.

  • Page 44: Airbag System

    Seats and Restraints • may have been stressed or damaged. See A roof-rail airbag for the front Warning your dealer to have the seat belt assemblies outboard passenger and the passenger inspected or replaced. seated directly behind the front You can be severely injured or killed in outboard passenger New parts and repairs may be necessary even if a crash if you are not wearing your seat belt,...

  • Page 45: Where Are The Airbags

    Seats and Restraints The driver frontal airbag is in the center of the Warning (Continued) steering wheel. airbag, as you would be if sitting on the edge of the seat or leaning forward. Seat belts help keep you in position before and during a crash.

  • Page 46: When Should An Airbag Inflate

    Seats and Restraints Warning (Continued) between an occupant and an airbag, and do not attach or put anything on the steering wheel hub or on or near any other airbag covering. Do not use seat accessories that block the inflation path of a seat-mounted side impact airbag.

  • Page 47: What Makes An Airbag Inflate

    Seats and Restraints Frontal airbags are designed to inflate in in some moderate to severe frontal impacts. For airbag locations, see Where Are the Airbags? moderate to severe frontal crashes to help Seat-mounted side impact airbags are not 3 44. reduce the potential for severe injuries, mainly designed to inflate in rollovers or rear impacts.

  • Page 48: What Will You See After An Airbag Inflates

    Seats and Restraints What Will You See After an Airbag Warning (Continued) Warning Inflates? have breathing problems but cannot get A crash severe enough to inflate the After frontal and seat-mounted side impact out of the vehicle after an airbag inflates, airbags may have also damaged important airbags inflate, they quickly deflate, so quickly then get fresh air by opening a window...

  • Page 49: Passenger Sensing System

    Seats and Restraints • The vehicle has a crash sensing Whenever possible, children aged 12 and under and diagnostic module which records should be secured in a rear seating position. information after a crash. See Vehicle Data Never put a rear-facing child seat in the front. Recording and Privacy 3 358 and Event Data This is because the risk to the rear-facing child Recorders 3 358.
  • Page 50 Seats and Restraints The passenger sensing system is designed to If the On Indicator Is Lit for a Child Restraint Warning (Continued) turn on the front outboard passenger frontal The passenger sensing system is designed to airbag anytime the system senses that a person turn off the front outboard passenger frontal the front outboard passenger seat, always of adult size is sitting properly in the front...
  • Page 51 Seats and Restraints 5. If, after reinstalling the child restraint and If the Off Indicator Is Lit for an Adult- 3. Place the seatback in the fully restarting the vehicle, the ON indicator is upright position. Sized Occupant still lit, turn the vehicle off. Then slightly 4.

  • Page 52: Servicing The Airbag-Equipped Vehicle

    Seats and Restraints The ON indicator may be lit if an object, such Warning (Continued) Warning as a briefcase, handbag, grocery bag, laptop, or other electronic device, is put on an unoccupied death. An adult-sized occupant should not For up to 10 seconds after the vehicle is seat.

  • Page 53: Airbag System Check

    Seats and Restraints Adding accessories that change the vehicle's part of the passenger seat. The passenger Airbag System Check frame, bumper system, height, front end, or sensing system may not operate properly if The airbag system does not need regularly side sheet metal may keep the airbag system the original seat trim is replaced with non-GM scheduled maintenance or replacement.

  • Page 54: Child Restraints Older Children

    Seats and Restraints • Child Restraints Buckle the lap-shoulder belt. Does the Warning (Continued) shoulder belt rest on the shoulder? If Older Children yes, continue. If no, try using the rear passenger(s) in a crash, resulting in serious seat belt comfort guide, if available. See injury or even death.
  • Page 55 Seats and Restraints What is the proper way to wear Warning Warning seat belts? An older child should wear a lap- Never allow more than one child to wear Never allow a child to wear the seat shoulder belt and get the additional the same seat belt.

  • Page 56: Infants And Young Children

    Seats and Restraints Warning Warning Warning Children can be seriously injured or killed Children can be seriously injured or killed Never hold an infant or a child while riding if the shoulder belt is worn behind their if the shoulder belt is worn behind their in a vehicle.
  • Page 57 Seats and Restraints Child restraints are devices used to restrain, Warning Warning seat, or position children in the vehicle and are sometimes called child seats or car seats. Children who are up against, or very close To reduce the risk of neck and head injury to, any airbag when it inflates can be in a crash, infants and toddlers should There are three basic types of child restraints:...

  • Page 58: Child Restraint Systems

    Seats and Restraints Child Restraint Systems Forward-Facing Child Restraint Booster Seats Rear-Facing Infant Restraint A forward-facing child restraint provides A belt-positioning booster seat is used for restraint for the child's body with the harness. children who have outgrown their forward- A rear-facing child restraint provides restraint facing child restraint.
  • Page 59 Seats and Restraints Securing an Add-On Child Restraint in When securing an add-on child restraint, see the following: the Vehicle • Instruction labels provided on the child restraint Warning • Instruction manual provided with the A child can be seriously injured or killed child restraint in a crash if the child restraint is not •...

  • Page 60: Where To Put The Restraint

    Seats and Restraints Securing the Child Within the When securing a child restraint with the Warning seat belts in a rear seat position, study the Child Restraint instructions that came with the child restraint A child in a rear-facing child restraint can to make sure it is compatible with this vehicle. Warning be seriously injured or killed if the front Child restraints and booster seats vary...

  • Page 61: Lower Anchors And Tethers For Children (Latch System)

    Seats and Restraints Keep in mind that an unsecured child restraint can be done as long as the booster seat can move around in a collision or sudden can be positioned properly and there is no stop and injure people in the vehicle. Be sure interference with the proper positioning of the to properly secure any child restraint in the lap-shoulder belt on the child.
  • Page 62 Seats and Restraints For a forward-facing 5-pt harness child restraint where the combined weight of the child and restraint are up to 29.5 kg (65 lb), use either the lower LATCH anchorages with the top tether anchorage, or the seat belt with the top tether anchorage. Where the combined weight of the child and restraint are greater than 29.5 kg (65 lb), use the seat belt with the top tether anchorage only.
  • Page 63 Seats and Restraints Restraints (With the Seat Belt in the Rear Seat) Top Tether Anchor Some child restraints with a top tether are designed for use with or without the top tether 3 68 Securing Child Restraints (With the Seat being attached. Others require the top tether Belt in the Front Seat) 3 70.
  • Page 64 Seats and Restraints To assist in locating the lower anchors, each seating position with lower anchors has two labels near the crease between the seatback and the seat cushion. Do not install a child restraint that requires lower anchors in the center rear seating Driver Side Anchor and Loop Passenger Side Loop position.
  • Page 65 Seats and Restraints According to accident statistics, children and Warning (Continued) Warning (Continued) infants are safer when properly restrained in a child restraint system or infant restraint a single anchor could cause the anchor or of the retractor to set the lock, and tighten system secured in a rear seating position.
  • Page 66 Seats and Restraints 1. Attach and tighten the lower attachments For a top tether in the rear driver to the lower anchors. If the child restraint side position: does not have lower attachments or the 2.1.1 Remove the driver side head desired seating position does not have restraint and center headrest.
  • Page 67 Seats and Restraints 2.1.5 Make sure the child restraint 2.2.4 Make sure the child restraint top tether hook is completely top tether hook is completely closed and secured to the top closed and secured to the top tether anchor. tether anchor. Rear Passenger Side Position For a top tether in the rear passenger side position:...
  • Page 68 Seats and Restraints 2.3.4 Make sure the child restraint Head Restraint or Headrest Removal top tether hook is completely and Reinstallation closed and secured to the top The second row outboard head restraints tether anchor. or center headrest can be removed if they 3.

  • Page 69: Replacing Latch System Parts After A Crash

    Seats and Restraints 3. Store the head restraint or headrest in 1. Insert the head restraint or headrest posts If the vehicle has the LATCH system and it was a secure place. into the holes in the top of the seatback. The being used during a crash, new LATCH system notches on the posts must face the driver parts may be needed.
  • Page 70 Seats and Restraints anchored. Refer to the instructions that came it to the top tether anchor. Refer to Position the release pushbutton on the with the child restraint and see Lower Anchors the instructions that came with the child buckle, away from the child restraint, restraint and see Lower Anchors and Tethers so that the seat belt could be quickly and Tethers for Children (LATCH System) 3 60.

  • Page 71: Securing Child Restraints (With The Seat Belt In The Front Seat)

    Seats and Restraints Try to pull the belt out of the retractor to Lower Anchors and Tethers for Children (LATCH make sure the retractor is locked. If the System) 3 60 for additional information on retractor is not locked, repeat Steps 6 and 7. installing the head restraint properly.
  • Page 72 Seats and Restraints 1. Move the seat as far back as it will go before System 3 48 and Passenger Airbag Status Warning (Continued) securing the forward-facing child restraint. Indicator 3 90 for more information, including Move the seat upward or the seatback to important safety information.
  • Page 73 Seats and Restraints 4. Push the latch plate into the buckle until it clicks. Position the release pushbutton on the buckle, away from the child restraint, so that the seat belt could be quickly unbuckled if necessary. Tilt the latch plate to adjust the belt 6.
  • Page 74 Seats and Restraints using the instructions that came with the child restraint. If there is still contact, use another seating position or child restraint. Try to pull the belt out of the retractor to make sure the retractor is locked. If the retractor is not locked, repeat Steps 5 and 6.

  • Page 75: Storage

    Storage Storage Storage Compartments If equipped, lower the armrest to access the rear cupholders. Underseat Storage Warning Storage Compartments Storage Compartments .........74 Do not store heavy or sharp objects in Glove Box ............74 storage compartments. In a crash, these Cupholders ............74 objects may cause the cover to open and Underseat Storage .........

  • Page 76: Center Console Storage

    Storage 4. If wet, dry the lid to prevent water from Tailgate Storage Center Console Storage dripping into the compartment when open. 5. Use the lift tabs to raise the lid. Warning Rain and snow can cause the cargo box to become very slippery.

  • Page 77: Instruments And Controls

    Instruments and Controls Instruments and Controls Malfunction Indicator Lamp (Check Lamps On Reminder ........100 Engine Light) ..........91 Cruise Control Light ........100 Brake System Warning Light ....... 93 Adaptive Cruise Control Light ....100 Controls Electric Parking Brake Light ......93 Door Ajar Light ..........100 Service Electric Parking Brake Light ....93 Steering Wheel Adjustment ......77...

  • Page 78: Controls

    Instruments and Controls Controls Tilt and Telescoping Steering Wheel Heated Steering Wheel Steering Wheel Adjustment To adjust the tilt and telescoping steering : If equipped, press to turn it on or off. A light wheel, if equipped: next to the button displays when the feature To adjust the steering wheel: 1.

  • Page 79: Windshield Wiper/Washer

    Instruments and Controls The windshield wiper/washer lever is on occur depending on how long the windshield Windshield Wiper/Washer the left side of the steering column. With washer has been activated. See Washer Fluid the ignition on or in accessory mode, move 3 271 for information on filling the windshield Warning the windshield wiper knob to select the...

  • Page 80: Compass

    Instruments and Controls If equipped, the vehicle may have accessory Certain power accessory plugs may not be Compass power outlets: compatible with the accessory power outlet The vehicle may have a compass display on the • and could overload vehicle or adapter fuses. If In the center console.

  • Page 81: Wireless Charging

    Instruments and Controls • When the ignition is on, power is supplied Other equipment requiring an to the outlets. A green indicator light on extremely stable power supply, such the DC/AC outlet indicates when the DC/AC as microcomputer-controlled electric operation is active. One power outlet can blankets and touch sensor lamps •...
  • Page 82 Instruments and Controls The operating temperature is −40 °C (−40 °F) 2. Remove all objects from the charging Warning (Continued) to 85 °C (185 °F) for the charging system and pocket. The system may not charge if there 0 °C (32 °F) to 35 °C (95 °F) for the phone. are any objects between the smartphone On the rare occasion that the charging A charging stopped alert may be displayed on...

  • Page 83: Warning Lights, Gauges, And Indicators

    Instruments and Controls If a smartphone is placed on the charger and Some warning lights come on briefly when the engine is started to indicate they are working. a red appears, the charger and/or the When one of the warning lights comes on and smartphone is overheated.

  • Page 84: Instrument Cluster

    Instruments and Controls Reconfigurable Instrument Cluster Instrument Cluster The cluster display layout can be changed. Some of the selectable views may not be available for your particular vehicle. The following are selectable views: Clean: Displays no information zones. Single Gauge: Displays two information zones that are located to the left and right of the display.

  • Page 85: Speedometer

    Instruments and Controls • Voltmeter Trip Odometer • Transmission Temperature The trip odometer shows how far the vehicle has been driven since the trip odometer was Display Settings last reset. The following options can be turned on or off The trip odometer is accessed and reset using the infotainment display.

  • Page 86: Fuel Gauge

    Instruments and Controls The fuel gauge may: Fuel Gauge • Take a little more, or less fuel to fill up than it indicates. For example, the gauge may have indicated the tank is half full, but it actually will take a little more, or less than half the tank's capacity to fill the tank.

  • Page 87: Engine Oil Pressure Gauge

    Instruments and Controls Center (DIC) message indicates oil pressure Engine Oil Pressure Gauge outside the normal operating range, check the engine oil as soon as possible. See Engine Oil 3 263. Caution Lack of proper engine oil maintenance can damage the engine. Driving with the engine oil low can also damage the engine.

  • Page 88: Engine Oil Temperature Gauge

    Instruments and Controls Engine Oil Temperature Gauge Engine Coolant Temperature Gauge English Metric This gauge shows the engine oil temperature. If the gauge pointer moves into the high end, Metric it means that the engine oil has overheated. If the vehicle has been operated under normal driving conditions, pull off the road, stop the vehicle, and turn off the engine as soon as possible.

  • Page 89: Transmission Temperature Gauge

    Instruments and Controls Transmission Temperature Gauge English English Metric This gauge shows the engine The transmission temperature gauge shows coolant temperature. the transmission fluid temperature. If the gauge is reading in the red area and/or If the pointer moves toward the warning area at a message appears in the Driver Information the high end of the gauge, the engine is too hot.

  • Page 90: Seat Belt Reminders

    Instruments and Controls If the driver seat belt is buckled, neither the bag, laptop, or other electronic device. To turn Caution light nor the chime comes on. off the reminder light and/or chime, remove the object from the seat or buckle the seat belt. Do not drive the vehicle while the Front Passenger Seat Belt Reminder Light transmission fluid is overheating, or the...

  • Page 91: Airbag Readiness Light

    Instruments and Controls For information on the front seat belt Passenger Airbag Status Indicator reminder lights, see "Driver Seat Belt The vehicle has a passenger sensing system. Reminder Light" and "Front Passenger Seat See Passenger Sensing System 3 48 for Belt Reminder Light" listed previously in important safety information.

  • Page 92: Charging System Light

    Instruments and Controls ON or OFF, or either the on or off symbol, to Charging System Light Malfunction Indicator Lamp let you know the status of the front outboard (Check Engine Light) passenger frontal airbag. If the word ON or the on symbol is lit on the This light is part of the vehicle’s emission passenger airbag status indicator, it means control on-board diagnostic system.
  • Page 93 Instruments and Controls To help prevent damage, reduce vehicle speed warmed up. If this occurs, change the fuel Caution and avoid hard accelerations and uphill grades. brand. It may require at least one full tank If towing a trailer, reduce the amount of cargo of the proper fuel to turn the light off.

  • Page 94: Brake System Warning Light

    Instruments and Controls • The light does not come on when the Electric Parking Brake Light Warning ignition is on while the engine is off. • Critical emission control systems have The brake system might not be working not been completely diagnosed. If this properly if the brake system warning happens, the vehicle would not be ready light is on.

  • Page 95: Antilock Brake System (Abs) Warning Light

    Instruments and Controls This light may come on briefly when the vehicle Engagement of the 4WD front axle lock will If equipped, the four-wheel-drive light displays is turned on. If it does not come on, have it fixed disable ABS and illuminate the ABS warning what mode the vehicle is in.

  • Page 96: Lane Keep Assist (Lka) Light

    Instruments and Controls a potential crash with a moving vehicle in Lane Keep Assist (LKA) Light Vehicle Ahead Indicator the lane you are entering. See Blind Zone Steering Assist (BZSA) 3 227. LKA will not assist or alert if the turn signal is active in the direction of lane departure, or if LKA detects that you are accelerating, braking, or actively steering.

  • Page 97: Traction Off Light

    Instruments and Controls Trailer Sway Control Light Traction Off Light Traction Control System (TCS)/ Electronic Stability Control Light If equipped, this light will flash when Trailer This light comes on briefly when the vehicle is Sway Control is active. See Trailer Sway Control turned on to show that the light is working.

  • Page 98: Engine Coolant Temperature Warning Light

    Instruments and Controls This light comes on when the Electronic On some vehicles this light comes on briefly This light comes on when Off-Road Mode Stability Control (ESC) system is turned off. while starting the vehicle. If it does not, have is selected.

  • Page 99: Engine Oil Pressure Light

    Instruments and Controls If equipped with the Tire Pressure Monitor Engine Oil Pressure Light System (TPMS), this light comes on briefly when the vehicle is started. It provides Caution information about tire pressures and the TPMS. Driving the vehicle with low engine oil When the Light Is On Steady pressure can damage the engine and the This indicates that one or more of the tires are...

  • Page 100: Auto Stop Indicator

    Instruments and Controls A Low Fuel Warning Light near the fuel gauge The security light should come on briefly as IntelliBeam Light comes on briefly when the ignition is turned on the engine is started. If it does not come on, as a check to show it is working.

  • Page 101: Lamps On Reminder

    Instruments and Controls Information Displays Lamps On Reminder Adaptive Cruise Control Light Driver Information Center (DIC) Driver information is displayed in the instrument cluster. It shows the status of many vehicle systems. Information is broken down into two main zones: This light comes on when the exterior lamps If equipped, this light is white when the Left Zone: Displays on the instrument cluster to...
  • Page 102 Instruments and Controls time this menu item was reset. This number TRAILER OUTPUT shows the power output to : Press to open a menu or select a menu item. reflects only the approximate average fuel the trailer any time a trailer with electric brakes Press and hold to reset certain displays.

  • Page 103: Vehicle Status

    Instruments and Controls Engine Hours: Shows the total number of hours Messages will display based on the engine Off: Allows for no information to be displayed the engine has run. This display also shows the air filter life and the state of the system. When in the cluster info display areas.
  • Page 104 Instruments and Controls Overview When the remaining oil life is low, the CHANGE The Air Filter Life display must be reset after ENGINE OIL SOON message will appear on the the engine air filter replacement. To reset, see Displays an interactive image of your display.

  • Page 105: Head-Up Display (Hud)

    Instruments and Controls Add to Driver Display may be chosen. reflects only the approximate fuel economy The timer shows the time in the current and changes frequently as driving conditions drive cycle. Trip change. Only the best score can be reset. All values in the Drive Summary are Trip Information: Trip 1 or 2 displays the current If the vehicle is equipped with an Active Fuel...

  • Page 106: Vehicle Messages

    Instruments and Controls The HUD information can be displayed in The HUD image can temporarily light up various languages. The speedometer reading depending on the angle and position of and other numerical values can be displayed in sunlight on the HUD image. This is normal. either English or metric units.
  • Page 107 Instruments and Controls Active Safety View: Displays the speed view, Care of the HUD pedestrian advisory, trailer sway, and a driver Clean the inside of the windshield to remove assistance graphic on the left. Driver assistance any dirt or film that could reduce the sharpness graphics show your vehicle, vehicle ahead, gap or clarity of the HUD image.

  • Page 108: Vehicle Messages

    Instruments and Controls Vehicle Messages Follow the instructions given in the messages. Engine Power Messages The system displays messages regarding the REDUCED ACCELERATION DRIVE Messages displayed on the Driver Information following topics: • WITH CARE Center (DIC) indicate the status of the vehicle Service Messages or some action that may be needed to correct •...
  • Page 109 Instruments and Controls propulsion and vehicle systems, such as lubrication; thermal; brake; suspension; tire; or, if equipped, Teen Driver.

  • Page 110: Lighting

    Lighting Lighting Exterior Lighting Headlights can also be activated in the Controls & Safety app. On the infotainment home Exterior Lamp Controls screen, touch > See More Controls > Lights Exterior Lighting > Headlights. The headlight control is located on the Exterior Lamp Controls ........109 infotainment screen.

  • Page 111: High-Beam Systems

    Lighting • Driving with IntelliBeam The vehicle speed drops below 20 km/h High-Beam Systems (12 mph). IntelliBeam System • Warning The outside light is bright enough that If equipped, this system turns the high-beam high-beam headlamps are not required. Using high beams in dense exhaust, smoke, headlamps on and off according to surrounding •...

  • Page 112: Exterior Lamps Off Reminder

    Lighting • The other vehicle's lamps cannot be The DRL are turned on and off by the Automatic detected due to dense exhaust, smoke, Headlamp System. The DRL come on when all of fog, snow, road spray, mist, or other the following conditions are met: •...

  • Page 113: Hazard Warning Flashers

    Lighting To enable the system, set the headlight control cluster may not be as bright as usual. Make sure Hazard Warning Flashers to Auto. the instrument panel brightness control is in • the full bright position. See Instrument Panel If it is dark enough outside, the system turns Illumination Control 3 114.

  • Page 114: Turn And Lane-Change Signals

    Lighting Replace any burned out bulbs. If a bulb is not Using Front Fog Lamps with Headlamps Turn and Lane-Change Signals burned out, check the fuse. See Fuses and Circuit The vehicle and either the parking lamps or Breakers 3 282 . headlamps must be on for the front fog lamps to work.

  • Page 115: Exterior Cargo Lamps

    Lighting Interior Lighting The button on the center stack activates Dome Lamps the accessory. Instrument Panel Illumination When the wiring is connected to Off-Road Control lamps, pressing the button will activate the lamps. For information on installation, contact your dealer. See Add-On Electrical Equipment 3 256.

  • Page 116: Reading Lamps

    Lighting All lamps will eventually turn off Reading Lamps Battery Load Management automatically, and can be turned off manually The vehicle has Electric Power Management by pressing on the remote key or starting the (EPM), which estimates the battery's vehicle. temperature and state of charge.

  • Page 117: Battery Power Protection

    Lighting EPM works to prevent excessive discharge of Exterior Lighting Battery Saver the battery. It does this by balancing the The exterior lights turn off about 10 minutes generator's output and the vehicle's electrical after the vehicle is turned off, if the parking needs.

  • Page 118: Infotainment System

    Infotainment System Infotainment System Introduction Phone Bluetooth (Overview) ........130 Read the following pages to become familiar Bluetooth (Pairing and Using a Phone) ..131 Introduction with the features. Apple CarPlay and Android Auto ....134 Introduction ............ 117 Settings Overview ............118 Warning Settings ............136 Steering Wheel Controls ......119...

  • Page 119: Overview

    Infotainment System Before driving: Home Page Overview • Become familiar with the operation, center The Home Page is where vehicle application Infotainment System stack controls, steering wheel controls, and icons are accessed. Some applications are The infotainment system is controlled by infotainment display.

  • Page 120: Steering Wheel Controls

    Infotainment System Phone Steering Wheel Controls Touch the Phone icon to display the Phone main page. See Bluetooth (Pairing and Using a Phone) 3 131 Bluetooth (Overview) 3 130. Maps If equipped, touch the Maps icon to display the navigation map. See Using the Navigation System 3 125.
  • Page 121 Infotainment System Apple CarPlay Touch/Tap Drag If equipped, touch the Apple CarPlay icon to activate Apple CarPlay after a supported device is connected. See Apple CarPlay and Android Auto 3 134. Android Auto If equipped, touch the Android Auto icon to activate Android Auto after a supported device is connected.

  • Page 122: Software Updates

    Infotainment System Nudge is used to move items a short distance Spread is used to zoom in on a map, certain separately, using mild soap. Do not use bleach on a list or a map. To nudge, hold and move the images, or a web page. Place finger and thumb or fabric softener.

  • Page 123: Satellite Radio

    Infotainment System Tune Sound In addition, RDS features are region and • country of sale specific. This means specific RDS Equalizer Touch on the infotainment display to content may not be available in your listening • enter the Tune screen. Enter a frequency using Fade/Balance area or in the country you operate the vehicle.

  • Page 124: Radio Reception

    Infotainment System When SiriusXM is active, the channel name, Finding a Channel number, song title, and artist appear on From the SiriusXM now playing screen, touch FM signals only reach about 16 to 65 km (10 the display. CH or CH to open the SiriusXM tuner to 40 mi).

  • Page 125: Multi-Band Antenna

    Infotainment System Mobile Devices USB Port Bluetooth Audio Making or receiving calls, charging, or just The vehicle may be equipped with multiple Music may be played from a connected having a mobile device on may cause static USB ports. Music may be played from Bluetooth mobile device.

  • Page 126: Using The Navigation System

    Infotainment System Bluetooth features, visit your brand website. To log into a profile, see Accounts under To recenter the map to the current location, See Online Account and Customer Support touch the location icon. Settings 3 136. 3 351 for details. Maps Voice Assistant See Radio Frequency Statement 3 357.

  • Page 127: Navigation Symbols

    Infotainment System 5. Touch Download. A second pin in the menu is the route overview. 2. Touch the Google Assistant mic icon and say Touch this pin to show more details of the the destination to search by voice. Navigation Symbols destination or to remove the destination.

  • Page 128: Global Positioning System (Gps)

    Infotainment System • 2. Touch the search bar. The vehicle is driving on slippery road Global Positioning System (GPS) surfaces such as sand, gravel, or snow. 3. Touch Categories, then select a category. The current position of the vehicle is • The vehicle is traveling on winding roads or 4.

  • Page 129: Problems With Route Guidance

    Infotainment System • • This is the first navigation use after the map The route prohibits the entry of a vehicle However, not all features within these areas are data is updated. due to a regulation by time or season or any supported by voice commands and requires the •...
  • Page 130 Infotainment System Helpful Hints for Speaking Commands “Play <AM frequency> AM”: Tune to the radio “Call < phone number>”: Initiate a call to station frequency identified in the command a phone number of seven digits or 10 digits. Voice recognition identifies commands that (like “nine fifty”).

  • Page 131: Bluetooth (Overview)

    Infotainment System “Set temperature to <desired number> To minimize driver distraction, before driving, Controls degrees”: Set to a specific temperature inside and with the vehicle parked: Use the controls on the infotainment display • your vehicle. Become familiar with the features of and the steering wheel to operate the the mobile device.

  • Page 132: Bluetooth (Pairing And Using A Phone)

    Infotainment System • The adjusted volume level remains in memory Up to 10 devices can be paired to the Pairing a Phone for later calls. The volume cannot be lowered Bluetooth system. 1. Make sure Bluetooth has been enabled • beyond a certain level. on the phone before starting the The pairing process is disabled when the pairing process.
  • Page 133 Infotainment System The code on the phone and infotainment 11. To pair additional phones, select Settings Using the Settings Icon display need to be acknowledged for > Connections > Phones. 1. Select the Settings icon on the infotainment pairing to be successful. home screen or the Settings icon on the First to Connect Paired Phones application tray near the left of the display.
  • Page 134 Infotainment System • 1. Open the Device List Screen. See “Accessing The mute icon will not be available or Search bar – Select the search icon on the Device List Screen” previously in functional while Handset mode is active. the top right of the Phones window •...

  • Page 135: Apple Carplay And Android Auto

    Infotainment System • Making a Call Using the Keypad Ending a Call Press on the steering wheel controls. • • To make a call by dialing the numbers: Select Answer on the infotainment display. Press on the steering wheel controls. • 1. Select the Phone icon on the infotainment Declining a Call Select on the infotainment display, next...
  • Page 136 Infotainment System 2. Connect your Android phone or Apple For Wireless Phone Projection Wireless CarPlay and/or Wireless Android Auto iPhone by using the factory-provided may experience occasional service disruption Verify your phone is wireless compatible by phone USB cable and plugging into a USB due to outside Wi-Fi interference.

  • Page 137: Settings

    Infotainment System Settings and is subject to Apple’s terms and privacy Android Auto policy. Data plan rates apply. For Android Allows interacting directly with a mobile device Auto support and to see if your phone To access the Settings menus: on the infotainment display.
  • Page 138 Infotainment System Audio Settings Comfort and Convenience Apps Allows adjustment of different audio settings. Allows adjustment of different comfort and Shows app settings and information. convenience settings. Teen Driver Date/Time Lighting See Teen Driver 3 138. Allows setting of the clock. Allows adjustment of different Valet Mode lighting settings.

  • Page 139: Teen Driver

    Infotainment System Assistant and Voice Storage When the vehicle is started with a registered key, the Driver Information Center (DIC) Touch to view storage settings. This menu shows the assistant and displays a message that Teen Driver is active. voice settings. About To access: Security Touch to view the infotainment system...
  • Page 140 Infotainment System 2. For automatic transmissions, the vehicle In vehicles with a pushbutton start system, brake pedal is pressed if the driver, or on must be in P (Park). For manual if a Teen Driver and a non-Teen Driver key some vehicles the detected passenger, has transmissions, the vehicle must be stopped are both present at start up, the vehicle will not buckled their seat belt.
  • Page 141 Infotainment System • • level. The speed warning does not limit the When trying to change a safety feature Distance Driven – the total distance driven. • speed of the vehicle. On some infotainment that is not configurable in Teen Driver, the Maximum Speed –...

  • Page 142: Trademarks And License Agreements

    Infotainment System • Stability Control – the number of events Forgotten PIN which required the use of electronic See your dealer to reset the PIN. stability control. • Trademarks and Antilock Braking System Active – License Agreements the number of Antilock Brake System activations.
  • Page 143 Infotainment System SiriusXM with 360L: Some features, It is prohibited to copy, decompile, TouchSense Technology and TouchSense including streaming content and listening disassemble, reverse engineer, hack, System 1000 Series Licensed from Immersion recommendations, require an active OnStar manipulate, or otherwise make available Corporation.
  • Page 144 Infotainment System COMPLIANCE WITH THE AVC STANDARD (“AVC MPEG4–Visual VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT USE OF THIS PRODUCT IN ANY MANNER WAS ENCODED BY A CONSUMER ENGAGED IN THAT COMPLIES WITH THE MPEG-4 VISUAL A PERSONAL AND NON-COMMERCIAL ACTIVITY STANDARD IS PROHIBITED, EXCEPT FOR USE BY AND/OR WAS OBTAINED FROM A VIDEO A CONSUMER ENGAGING IN PERSONAL AND PROVIDER LICENSED TO PROVIDE AVC VIDEO.

  • Page 145: Climate Controls

    Climate Controls Climate Controls Climate Control Systems The climate control system controls the heating, cooling, and ventilation in the vehicle. Climate Control Systems Climate Control Systems ......144 Dual Automatic Climate Control System ............146 Air Vents Air Vents ............148 Maintenance Passenger Compartment Air Filter ...
  • Page 146 Climate Controls To change the current mode, select one or Avoid using recirculation for long periods If equipped with heated outside mirrors, press more of the following. An indicator light of time in cold or damp conditions. Using to turn them on or off. See Heated Mirrors will illuminate: recirculation in cold or damp conditions can 3 21.

  • Page 147: Dual Automatic Climate Control System

    Climate Controls on the infotainment home screen. A selection Dual Automatic Climate Control System can then be made on the front climate control The heating, cooling, and ventilation in the vehicle can be controlled with this system. page displayed. Choose from available options: •...
  • Page 148 Climate Controls displayed. Functions not manually set will Turn the knob clockwise or counterclockwise : Air is directed to the floor outlets, with continue to be automatically controlled, even to increase or decrease the driver or passenger some air directed to the windshield, outboard if the AUTO indicator is not lit.

  • Page 149: Air Vents

    Climate Controls the air conditioner will not run. The A/C light Remote Start Climate Control Operation: If Do not cover the sensor; otherwise the will stay on even if the outside temperatures equipped with remote start, the climate control automatic climate control system may not are below freezing.

  • Page 150: Maintenance

    Climate Controls Operation Tips Using the climate control system without an air The air conditioning system requires periodic • filter installed is not recommended. Water or maintenance. See Maintenance Schedule Clear away any ice, snow, or leaves from other debris could enter the system and result 3 339.

  • Page 151: Driving And Operating

    Driving and Operating Driving and Operating Shifting out of Park ........175 Cruise Control Parking over Things That Burn ....176 Cruise Control ..........197 Active Fuel Management ......176 Adaptive Cruise Control (Camera) .... 199 Driving Information Extended Parking ..........176 Advanced Driver Assistance Systems Driving for Better Fuel Economy ....

  • Page 152: Driving Information

    Driving and Operating Driving Information Distracted Driving Trailer Towing General Towing Information ......233 Driving for Better Fuel Economy Distraction comes in many forms and can take Driving Characteristics and Towing Tips ..233 your focus from the task of driving. Exercise Trailer Towing ..........

  • Page 153: Defensive Driving

    Driving and Operating • • Wait until the vehicle is parked to retrieve Assume that other road users (pedestrians, Control of a Vehicle items that have fallen to the floor. bicyclists, and other drivers) are going to Braking, steering, and accelerating are •...

  • Page 154: Steering

    Driving and Operating If the engine were to stall or stop while driving, If the vehicle experiences a system malfunction Off-Road Recovery the brake boost system, which is powered by and loses power steering, greater steering the vehicle battery, will maintain the power effort may be required.

  • Page 155: Loss Of Control

    Driving and Operating • Slow down and adjust your driving Four-wheel-drive vehicles can be used for off- Loss of Control according to weather conditions. Stopping road driving. Vehicles without four-wheel drive Skidding distance may be longer and vehicle control and vehicles not equipped with All Terrain may be affected when traction is reduced (AT) or On-Off Road (OOR) tires must not be There are three types of skids that correspond...
  • Page 156 Driving and Operating Jounce Control Dampers the wheel well. If a cap is cracked or worn down Loading the Vehicle for Off-Road Driving so that there is no curve to the tip, replace the cap. Order replacement caps from your dealer. Warning If any of the jounce control damper caps are •...
  • Page 157 Driving and Operating • Environmental Concerns Use headlamps even during the day to Warning make the vehicle more visible. Always use established trails, roads, • and areas that are reserved for public Avoid turns that take the vehicle across Driving to the top of a hill at high speed off-road recreational driving.
  • Page 158 Driving and Operating brakes to slow the vehicle and help keep the If the vehicle stalls on a hill, follow these steps Warning vehicle under control. Use Four-Wheel Drive to stay in control. Low (4 ) to maintain speed down a steep 1.
  • Page 159 Driving and Operating • Stay clear of the path the vehicle Water Fording Before entering any water, determine the would take if it rolled downhill. water depth. Enter the water slowly. As water depth increases, reduce the vehicle speed Warning Driving in Mud, Sand, Snow, or Ice to prevent potential vehicle damage or loss of control.

  • Page 160: Off-Road App

    Driving and Operating After Driving Your Vehicle Off-Road Check the body structure, driveline, steering, Warning suspension, wheels, tires, and exhaust system Be sure to switch out of Off-Road Mode or for damage, and check the fuel lines and cooling Terrain Mode on your Driver Mode Control Taking your eyes off the road for too system for any leakage.

  • Page 161: Driving On Wet Roads

    Driving and Operating • Terrain – For rough terrain at low speeds Pitch and roll: Shows real-time vehicle pitch There is no hard and fast rule about • and roll in a 3D gauge. hydroplaning. The best advice is to slow down Overlanding –...

  • Page 162: Hill And Mountain Roads

    Driving and Operating • Keep windshield wiping equipment in good Winter Driving Warning shape, and keep the windshield washer Driving on Snow or Ice fluid reservoir filled. Using the brakes to slow the vehicle • Ensure the tires are maintained and have on a long downhill slope can cause Caution proper tread depth.

  • Page 163: If The Vehicle Is Stuck

    Driving and Operating • Allow greater following distance and watch To save fuel, run the engine for short periods to Warning for slippery spots. Icy patches can occur warm the vehicle and then shut the engine off on otherwise clear roads in shaded areas. and partially close the window.

  • Page 164: Vehicle Load Limits

    Driving and Operating If equipped, the front and rear axles may be Recovery Hooks Caution locked to improve traction. See Locking Front Axle 3 195 and Locking Rear Axle 3 194. Never use recovery hooks to tow the The Traction Control System (TCS) can often vehicle.
  • Page 165 Driving and Operating Tire and Loading Information Label cold tire inflation pressures (4). For more Warning information on tires and inflation see Tires 3 292 and Tire Pressure 3 298. Do not load the vehicle any heavier than the Gross Vehicle Weight Rating There is also important loading (GVWR), or either the maximum front information on the vehicle Certification/...
  • Page 166 Driving and Operating amount equals 1400 lbs. and there If aftermarket accessories are installed on 3. Remaining available capacity for Cargo Weight = 301.2 kg (665 lb) will be five 150 lb passengers in your the vehicle, for example a rooftop carrier, vehicle, the amount of available cargo be sure to add the weight of all installed and luggage load capacity is 650 lbs.

  • Page 167: Certification/Tire Label

    Driving and Operating Certification/Tire Label (GAWR). To find out the actual loads on the front and rear axles, weigh the vehicle at a weigh station. Your dealer can help with this. Be sure to spread the load equally on both sides of the centerline. Warning In the case of a sudden stop or collision, things carried in the bed of your truck...
  • Page 168 Driving and Operating Two-Tiered Loading Warning (Continued) Warning (Continued) Depending on the model of the pickup, • an upper load platform can be created by handles. This could cause loss of control Put things in the cargo area of positioning three or four 5 cm (2 in) by 15  and a crash.

  • Page 169: Maximum Weight

    Driving and Operating Add-On Equipment Loading Points * Equipment Maximum Weight Caution Ladder Rack and 340 kg (750 lb) Cargo Overloading the vehicle may cause damage. Repairs would not be covered Cross Toolbox and by the vehicle warranty. Do not overload 181 kg (400 lb) Cargo the vehicle.

  • Page 170: Truck-Camper Loading Information

    Driving and Operating the mechanical systems adjust to provide Truck-Camper Loading Caution (Continued) optimal fuel economy and transmission Information shift performance. • Do not drive at any one constant speed, The vehicle was neither designed nor Electrical systems will adapt and calibrate fast or slow, for the first 800 km (500 ...
  • Page 171 Driving and Operating The remote key must be in the vehicle for the 1. Brake using a firm and steady pressure. Do Accessory Mode (Amber Indicator Light): This system to operate. If the pushbutton start is not pump the brakes repeatedly. This may mode allows some electrical accessories to be not working, the vehicle may be near a strong deplete power assist, requiring increased...

  • Page 172: Starting The Engine

    Driving and Operating and audio systems will operate as they do in Starting Procedure Caution ON/RUN, but the vehicle will not be able to 1. With the Keyless Access system, the remote be driven. The engine will not start in Service key must be in the vehicle.

  • Page 173: Stop/Start System

    Driving and Operating • Auto Stops may not occur and/or auto restarts The Auto Stop has reached the maximum Stop/Start System may occur because: allowed time. The Stop/Start system shuts off the engine to • The climate control settings require the help conserve fuel.
  • Page 174 Driving and Operating at or below −18 °C (0 °F). Vehicles with an Warning engine heater should be plugged in at least four  hours before starting. An internal thermostat Improper use of the heater cord or an in the plug-end of the cord may exist, extension cord can damage the cord and which will prevent engine heater operation may result in overheating and fire.

  • Page 175: Retained Accessory Power (Rap)

    Driving and Operating • Sunroof (during RAP this functionality will Warning (Continued) Warning (Continued) be lost when any door is opened) • • Auxiliary Power Outlet Before starting the vehicle, unplug the roll. If you have left the engine running, the •...

  • Page 176: Shifting Out Of Park

    Driving and Operating Leaving the Vehicle with the without pressing the button on the shift lever. Shifting out of Park If you can, it means that the shift lever was not Engine Running This vehicle is equipped with an electronic shift fully locked into P (Park).

  • Page 177: Parking Over Things That Burn

    Driving and Operating Engine Exhaust If equipped, the Buckle to Drive feature may accelerating from a stop, passing, or merging prevent shifting from P (Park). See Buckle To onto a freeway, the system will maintain full-cylinder operation. If the vehicle has an Drive 3 36. Warning Active Fuel Management indicator, see Driver If the shift lever will not move from P ...

  • Page 178: Running The Vehicle While Parked

    Driving and Operating Automatic Transmission Warning (Continued) Warning (Continued) If unusual fumes are detected or if it is gear, Two-Wheel Drive High or Four-Wheel Warning suspected that exhaust is coming into Drive High or Four-Wheel Drive Low — not the vehicle: It is dangerous to get out of the vehicle if in N (Neutral).
  • Page 179 Driving and Operating load, you might notice an increase in the effort Warning (Continued) Caution (Continued) to shift out of P (Park). See “Torque Lock” under Shifting Into Park 3 174. lose control and hit people or objects. Do cool the automatic transmission fluid. This R: Use this gear to back up.

  • Page 180: Manual Mode

    Driving and Operating rapid upshifts and downshifts. This shift warms up. Shifts could be more noticeable with Manual Mode stabilization feature is designed to determine, a cold transmission. This difference in shifting Range Selection Mode before making an upshift, if the engine is is normal.
  • Page 181 Driving and Operating When the shift lever is moved from D (Drive) to L (manual mode), a number displays next to the  L in the Driver Information Center, indicating the current transmission range. This number is the highest gear that the transmission will command while operating in L (manual mode).

  • Page 182: Tow/Haul Mode

    Driving and Operating Selection mode. This will limit torque to Gear before shifting the wheels and help to prevent the tires from D (Drive) to L  from spinning. (manual mode) Tow/Haul Mode Range after shifting from D (Drive) to L  If equipped, Tow/Haul Mode adjusts the (manual mode) –...

  • Page 183: Drive Systems Four-Wheel Drive

    Driving and Operating Automatic Transfer Case See Driver Mode Control Light 3 97 and Hill and Warning Mountain Roads 3 161. Two-Speed Transfer Case Also see “Tow/Haul Mode” under Towing If equipped with four-wheel drive, the vehicle will be free to roll if the transfer case Equipment 3 241.
  • Page 184 Driving and Operating The settings are: Shifting into 4  will turn Traction Control and Shifting Into 4  ESC off. See Traction Control/Electronic N (Neutral): Use only when the vehicle needs 1. The ignition must be on and the vehicle Stability Control 3 188. to be towed.
  • Page 185 Driving and Operating flashing until the shift request has If the transmission is not shifted into Caution completed. A DIC message displays to N (Neutral) or the vehicle has not slowed to indicate the state of the request. 5 km/h (3 mph) within 20 seconds, the transfer Shifting the transmission into gear before case will remain in its original state.
  • Page 186 Driving and Operating the transfer case will remain in its Single Speed Transfer Case The settings are: original state. This will be indicated in the 2  (Two-Wheel Drive High): Use for driving on instrument cluster. most streets and highways. The front axle is not engaged.

  • Page 187: Electric Brake Boost

    Driving and Operating The actual 4x4 shift request is only made Electric Parking Brake after the button is released. The 4x4 graphic will remain flashing until the shift request has completed. A DIC message displays. Once the 4x4 shift has completed, the DIC message disappears, the 4x4 graphic stops flashing, and the current If there is a problem with ABS, this warning setting is indicated.

  • Page 188: Brake Assist

    Driving and Operating Before leaving the vehicle, check the red The vehicle may automatically apply the Caution parking brake status light to ensure that the EPB in some situations when the vehicle is parking brake is applied. not moving. This is normal, and is done to Driving with the parking brake on can periodically check the correct operation of the overheat the brake system and cause...

  • Page 189: Hill Start Assist (Hsa)

    Driving and Operating apply the brake pedal as the driving situation HSA is available when the vehicle is facing braking pressure to one or more of the vehicle dictates. Brake Assist disengages when the uphill in a forward gear, or when facing wheel brakes to assist the driver in keeping the brake pedal is released.
  • Page 190 Driving and Operating 3. Start the vehicle. System is turned back on, the Traction Off light displayed in the instrument cluster will turn 4. Drive the vehicle. off. See Traction Off Light 3 96. If these steps do not remove , see your dealer If the traction system is actively limiting wheel as soon as possible.

  • Page 191: Hill Descent Control (Hdc)

    Driving and Operating and cannot be turned off again until speed is above 80 km/h (50 mph) or above 60 km/h is reduced. The Traction Control System will (37 mph) for at least 30 seconds. must be remain off. pressed again to re-enable HDC. Entering Teen Driver will automatically When enabled, if the vehicle is at a speed enable both the Traction Control System and above 30 km/h (19 mph) and less than 60 km/h...
  • Page 192 Driving and Operating When entering a mode, there is an information time it is started, unless Tow/Haul mode has Terrain mode functions when the vehicle is in icon on the infotainment screen. Select the been activated within the last four hours. See 4 ...
  • Page 193 Driving and Operating When the vehicle comes to a stop on an upward to maximize response at higher vehicle speeds. Tow/Haul Mode: Use this mode when grade, Automatic Vehicle Hold is engaged until If enabled, the rear lockers will remain locked at towing heavy loads to provide increased the accelerator pedal is pressed.
  • Page 194 Driving and Operating Dynamic Performance Mode (DPM): If equipped with Baja mode, DPM allows the transmission to hold the current gear after a quick release of a heavily applied accelerator pedal.  This provides greater engine braking and enhanced vehicle control. DPM recognizes aggressive accelerator pedal rates, heavy braking, and high acceleration to select and hold lower gears longer. When DPM is active,...

  • Page 195: Limited-Slip Differential

    Driving and Operating Mode Selection Attributes MODES Normal Off-Road Tow/Haul Terrain Baja Default Steering Normal Normal Tow/Haul Terrain Normal Transmission (2WD/4WD High) Normal Tow/Haul Tow/Haul Crawl Baja with DPM Locking Rear Axle Up to 40 km/h (25  Unlimited Up to 40 km/h (25  Up to 80 km/h (50 ...

  • Page 196: Locking Front Axle

    Driving and Operating After pressing the switch to unlock the axle, Caution it may remain locked due to torque in the driveline. The axle is more easily unlocked by If the vehicle’s axle is locked while driving turning the steering wheel to the right and to on pavement, the drivetrain could be the left while traveling at a low speed.

  • Page 197: Driving And Operating

    Driving and Operating Before the front axle can be locked, the transfer wheels. Hill Decent Control (HDC) will Caution also be disabled when the front axle lock case must be in 4  is engaged. To lock the front axle, press the front/rear axle If you try to lock the axle while the vehicle If the electronic locking differential locking switch.

  • Page 198: Cruise Control

    Driving and Operating If HDC was enabled prior to axle lock, it will be Cruise control will disengage if: • automatically enabled when the locking front The Traction Control System (TCS) or axle is disengaged. Electronic Stability Control (ESC) system After pressing the switch to unlock the axle, begins to limit wheel spin.
  • Page 199 Driving and Operating • Setting Cruise Control Once the vehicle speed reaches about 40 km/h To decrease the vehicle speed in small (25 mph) or more, briefly press the increments, briefly press the thumbwheel If cruise control is on when not in use, the thumbwheel up to +RES to engage cruise down to −SET and then release it.

  • Page 200: Adaptive Cruise Control (Camera)

    Driving and Operating Ending Cruise Control If a vehicle is detected in your path, ACC Warning (Continued) can apply acceleration or limited, moderate There are four ways to end cruise control: braking to maintain the selected following • lane. Also see “Alerting the Driver” later in Lightly apply the brake pedal.
  • Page 201 Driving and Operating Switching Between ACC and Regular : Press to turn ACC on or off. When ACC is Warning (Continued) Cruise Control on, the ACC indicator light is lit white on the instrument cluster. To switch between ACC and regular cruise additional environmental obstructions, +RES : Press the thumbwheel up briefly to such as road spray.
  • Page 202 Driving and Operating 2. Accelerate to the desired speed. Resuming a Set Speed Warning If the ACC is set at a desired speed and then the 3. Briefly press the thumbwheel down to –SET brakes are applied, ACC is disengaged without and release it.
  • Page 203 Driving and Operating • The vehicle speed is not being limited to +RES, the vehicle speed increases to the Reducing Speed While ACC Is at a Set Speed because of a sharp turn. next 5 km/h (5 mph) mark on the If ACC is already activated, do one of speedometer, then continues to increase the following: Increasing Speed While ACC Is at a Set Speed...
  • Page 204 Driving and Operating The set speed can also be decreased while the vehicle is stopped. If stopped with the brake applied, briefly press and release or press and hold the thumbwheel down to −SET until the desired set speed is displayed. Selecting the Follow Distance Gap When a slower moving vehicle is detected ahead and is within the selected following...
  • Page 205 Driving and Operating when selecting the following gap. The range of Alerting the Driver selectable gaps may not be appropriate for all drivers and driving conditions. Changing the gap setting automatically changes the alert timing sensitivity (Far, Medium, or Near) for the Forward Collision Alert (FCA) feature.
  • Page 206 Driving and Operating five times. To view available settings from lamps will come on. The automatic braking may Stationary or Very Slow-Moving Objects the infotainment home screen, touch Settings feel or sound different than if the brakes were > Vehicle > Collision/Detection Systems. applied manually.
  • Page 207 Driving and Operating • • Non-standard shaped vehicles, such as There is a fault in the system. When the vehicle ahead drives away, ACC • vehicle transport, vehicles with a side car resumes automatically if the stop was brief. If A DIC message displays to indicate that ACC fitted, or horse carriages necessary, press the thumbwheel up to +RES is temporarily unavailable.
  • Page 208 Driving and Operating Curves in the Road ACC automatically slows the vehicle down Warning while navigating the curve and may increase speed out of the curve, but will not exceed the Warning Leaving the vehicle without placing it in set speed. P (Park) can be dangerous.
  • Page 209 Driving and Operating ACC may occasionally provide an alert and/or Driving in Narrow Lanes When ACC is used with vehicles equipped with braking that is considered unnecessary. It aftermarket trailer brake controller, disengage Vehicles in adjacent traffic lanes or roadside could respond to vehicles in different lanes ACC before applying the manual trailer brake.
  • Page 210 Driving and Operating • maintain the set speed. ACC may disengage if droplets from rain or snow that remain on Lighting is poor in the evening or it detects that the brake temperature exceeds the windshield may also limit ACC’s ability to early morning •...

  • Page 211: Advanced Driver Assistance Systems

    Driving and Operating Cleaning the Sensing System Warning (Continued) Warning The camera sensor on the windshield behind • the rearview mirror can become blocked by Do not rely on the Driver Assistance Work if the detection sensor is covered snow, ice, dirt, mud, or debris. This area needs Systems.

  • Page 212: Assistance Systems For Parking Or Backing

    Driving and Operating Cleaning Radio Frequency Depending on vehicle options, keep these This vehicle may be equipped with driver areas of the vehicle clean to ensure the assistance systems that operate using radio best driver assistance feature performance. frequency. See Radio Frequency Statement Driver Information Center (DIC) messages may 3 357.
  • Page 213 Driving and Operating Displayed images may be farther or closer than Warning (Continued) they appear. The area displayed is limited and objects that are close to either corner of the Do not drive or park the vehicle using only bumper or under the bumper do not display. these camera(s).

  • Page 214: Surround Vision System

    Driving and Operating line over the trailer coupler. Continuously 1. Views Displayed by the Surround Warning steer the vehicle to keep the guidance line Vision Cameras centered on the coupler when backing. RVC 2. Area Not Shown The camera(s) do not display children, Park Assist overlays will not display when the pedestrians, bicyclists, crossing traffic, trailer guidance line is active.
  • Page 215 Driving and Operating Camera Views If equipped, the front view camera also 4. Hitch View displays when the Park Assist system Displays a zoomed-in view of the hitch detects an object within 30 cm (12 in). area to assist with aligning the vehicle’s To access this view when in a forward gear hitch ball with the trailer coupler above 12 km/h (8 mph), select CAMERA...
  • Page 216 Driving and Operating • change guidance mode, select the Hitch Guidance Line is available Surround Vision (360 Degrees) appropriate guidance icon. Depending on in Rear Standard View when the If equipped, the Surround Vision system can the guidance mode and view selected, Trailering Guidance mode is selected.

  • Page 217: Park Assist

    Driving and Operating • Guidance Lines off the ground and below bumper level. These • detection distances may be shorter during Hitch Guidance warmer or humid weather. Underbody Camera Blocked sensors will not detect objects and can also cause false detections. Keep the There are two cameras underneath the vehicle sensors clean of mud, dirt, snow, ice, and that show a view of the areas underneath the...

  • Page 218: Rear Pedestrian Alert

    Driving and Operating Turning the Features On or Off Warning (Continued) RPA can be turned on and off. To view available • settings for this feature, touch the Settings The RVC is blocked by dirt, snow, or ice. icon on the infotainment home page. Select •...

  • Page 219: Rear Cross Traffic Alert (Rcta) System

    Driving and Operating Rear Cross Traffic Alert (RCTA) Warning (Continued) System will not work correctly under poor visibility or bad weather conditions, such as rain Warning or snow. To prevent injury, death, or vehicle damage, The Rear Cross Traffic Alert System only Rear Pedestrian Alert Indicator always check the area around the vehicle operates at speeds greater than 8 km/h...

  • Page 220: Assistance Systems For Driving

    Driving and Operating an object is detected, three beeps sounds from Forward Collision Alert (FCA) Warning (Continued) the left or right, depending on the direction of System the detected vehicle. RCTB will bring the vehicle barrels, or other objects. Be ready to take to a full stop if a collision is imminent.
  • Page 221 Driving and Operating The vehicle ahead indicator will display amber Warning when you are following a vehicle ahead much too closely. FCA does not provide a warning to help avoid a crash, unless it detects a vehicle. Selecting the Alert Timing FCA may not detect a vehicle ahead if the FCA sensor is blocked by dirt, snow, or ice, or if the windshield is damaged.

  • Page 222: Automatic Emergency Braking (Aeb)

    Driving and Operating • If your vehicle is equipped with Adaptive Clean the entire front of the vehicle. Warning (Continued) • Cruise Control (ACC), changing the FCA timing Clean the headlamps. setting automatically changes the following Complete attention is always required gap setting (Far, Medium, or Near).

  • Page 223: Front Pedestrian Braking (Fpb) System

    Driving and Operating moderately or hard. Always wear a seat belt IBA may activate when the brake pedal is Front Pedestrian Braking (FPB) and ensure that all passengers are properly applied quickly by providing a boost to braking System restrained. This automatic emergency braking based on the speed of approach and distance to can only occur if a vehicle is detected.
  • Page 224 Driving and Operating to a distance of approximately 40 m (131 ft). FPB can be set to Off, Alert, or Alert and Brake Front Pedestrian Alert During nighttime driving, system performance through vehicle settings. To view available is very limited. settings for this feature, touch the Settings icon on the infotainment home page.

  • Page 225: Side Blind Zone Alert (Sbza)

    Driving and Operating Automatic Braking vehicle is detected in that blind zone. If the Warning (Continued) turn signal is activated and a vehicle is also If FPB detects it is about to crash into detected on the same side, the display will flash a pedestrian or bicyclist directly ahead, and size to pedestrians or bicyclists, including as an extra warning not to change lanes.
  • Page 226 Driving and Operating between 0.5 m (1.5 ft) and 2 m (6 ft) off Warning (Continued) Warning the ground. Drivers are also warned of vehicles rapidly approaching this area up to not provide alerts when changing lanes TSBZA does not alert the driver to vehicles approximately 70 m (230 ft) behind the vehicle.
  • Page 227 Driving and Operating Trailer Side Blind Zone Alert (TSBZA) warning is detected in that blind zone. If the turn bicycle, or object extending out to either side area starts at approximately 3 m (10 ft) to the signal is activated in the same direction as of the vehicle or trailer.

  • Page 228: Blind Zone Steering Assist (Bzsa)

    Driving and Operating When TSBZA is disabled for any reason other LKA and LCA are enabled and able to assist. See Warning (Continued) than the driver turning it off, the Trailer Side Lane Keep Assist (LKA) 3 227. See Lane Change Blind Zone Alert On option will not be available •...
  • Page 229 Driving and Operating may assist by gently turning the steering Warning (Continued) Warning (Continued) wheel if the vehicle approaches a detected lane marking. It may also provide a Lane The LKA and LDW systems may not: repair. Do not use LKA in bad weather Departure Warning (LDW) alert if the vehicle •...

  • Page 230: Top Tier Fuel

    Driving and Operating Steer the vehicle to dismiss. LKA may become LKA assistance and/or LDW alerts may To turn LKA on and off, press on the temporarily unavailable after repeated take occur due to tar marks, shadows, cracks in center stack. If equipped, the indicator light on steering alerts.

  • Page 231: Recommended Fuel

    Driving and Operating Do not use any fuel labeled E85 or FlexFuel. Caution (Continued) Do not use gasoline with ethanol levels greater than 15% by volume. • Fuel with a posted octane rating of less than the recommended fuel. Using Prohibited Fuels this fuel will lower fuel economy and performance, and may decrease the life Caution...

  • Page 232: Filling The Tank

    Driving and Operating Filling the Tank Warning (Continued) Warning An arrow on the fuel gauge indicates which side • Before touching the fill nozzle, touch Overfilling the fuel tank by more than three of the vehicle the fuel door is on. See Fuel Gauge a metallic object to discharge static clicks of a standard fill nozzle may cause: 3 85.

  • Page 233: Filling A Portable Fuel Container

    Driving and Operating The capless system has two internal flapper Warning (Continued) doors. To prevent fuel spray, insert the nozzle fully to ensure both doors are open • Do not fill a container while it is inside before refueling. a vehicle, in a vehicle's trunk, in a pickup Be careful not to spill fuel.

  • Page 234: Trailer Towing

    Driving and Operating • Trailer Towing Install extended side view mirrors on Warning (Continued) your vehicle if your visibility is limited General Towing Information or restricted while towing. State laws also be damaged, and the repairs would may require the use of extended side Only use towing equipment that has been not be covered by the vehicle warranty.
  • Page 235 Driving and Operating • Rear Cross Traffic Alert (RCTA) Towing with a Stability Control System Warning (Continued) • Rear Cross Traffic Braking (RCTB) When towing, the stability control system • might be heard. The system reacts to vehicle For more information about carbon Lane Change Alert (LCA) movement caused by the trailer, which mainly •...
  • Page 236 Driving and Operating the right, move that hand to the right. Always Tow in D (Drive). If the transmission shifts 2. Have someone place chocks under the back up slowly and, if possible, have someone too often under heavy loads and/or hilly trailer wheels.
  • Page 237 Driving and Operating Launching and Retrieving a Boat 'Disconnect the trailer wiring before backing Pulling the Trailer from the Water the trailer into the water to prevent damage To pull the trailer of the water: Backing the Trailer into the Water to the electrical circuits.
  • Page 238 Driving and Operating Maintenance when Trailer Towing See “Trailer Brakes” under Towing Equipment Warning (Continued) 3 241 to determine if brakes are required based A vehicle used to tow trailers requires service on your trailer's weight. more often. See Maintenance Schedule 3 339.It Only tow a trailer if all the steps in this The only way to be sure the weight ratings are is especially important to check the automatic...
  • Page 239 Driving and Operating 6. Add the weight of any accessories vehicle has a driver, a front seat passenger, or aftermarket equipment added to and all required trailering equipment. The the vehicle. maximum trailer weight rating represents the heaviest trailer the vehicle can tow, but it may The resulting weight cannot exceed the Gross be necessary to reduce the trailer weight to Combined Weight Rating value.
  • Page 240 Driving and Operating Use the tow rating chart to determine how much the trailer can weigh, based on the vehicle model, powertrain, and trailering options. Maximum Trailer Weight Gross Combined Mass/ Vehicle Maximum Tongue Weight (Max Towing Capacity) Weight Rating (GCMR/GCWR) 2.7L Engine 1 588 kg (3,500 lb) 4 128 kg (9,100 lb)
  • Page 241 Driving and Operating the maximum trailer tongue weight rating your vehicle. If the trailer weight is too high, while still maintaining the correct trailer it may be possible to transfer some of the load balance. cargo into your vehicle. If the trailer tongue weight is too high or too low, it may be possible to rearrange some of the cargo inside of the trailer.

  • Page 242: Towing Equipment

    Driving and Operating no more than half of the maximum allowable Proper hitch equipment for your vehicle tongue weight for the vehicle or 227 kg (500 lb), helps maintain control of the vehicle-trailer whichever is less. combination. Many trailers can be towed using a weight-carrying hitch with a coupler latched Towing Equipment to the hitch ball, or a tow eye latched to a pintle...
  • Page 243 Driving and Operating Safety Chains Weight-Distributing Trailer Weight Hitch Distribution Hitch Usage Warning Refer to the trailer Up to 2 272 kg (6,000 lb) Optional manufacturer’s Always cross trailer safety chains and never recommendation allow them to drag on the ground. Improper installation can result in damage to the Over 2 272 kg (6,000 lb) Required chains and could lead to loss of control of...
  • Page 244 Driving and Operating Trailer Brakes Trailer Wiring Harness Basic Trailer Wiring Warning Warning Never attempt to tamper with the hydraulic brake system for your trailer brakes. Do not Incorrect trailer wiring may cause blown connect a trailer's hydraulic brake system fuses, damaged wires, trailer brakes directly to your vehicle's hydraulic brake being permanently applied, or trailer system.
  • Page 245 Driving and Operating Center (DIC). However; if the vehicle detects an issue with a trailer connection or lamp, you may see the following DIC message(s): • TRAILER DISCONNECTED CHECK CONNECTION appears when a connected trailer is disconnected. It appears immediately when the vehicle is on, or upon the next start-up if the trailer was disconnected while the vehicle was off.
  • Page 246 Driving and Operating Integrated Trailer Brake Control System amount of vehicle braking. Available output to Trailer Brake Control Panel the trailer brakes can be adjusted to a wide range of trailering situations. Warning The ITBC system is integrated with the vehicle’s Connecting a trailer that has an air brake brake system, antilock brake control system system may result in reduced or complete...
  • Page 247 Driving and Operating control panel and the DIC trailer brake display TRAILER OUTPUT: Trailer Output This displays lever may also be used to request additional page to adjust and display power output to the anytime a trailer with electric brakes is trailer braking at any time.
  • Page 248 Driving and Operating Adjusting Trailer Gain at speeds lower than CHECK TRAILER WIRING: This message will 3. Wait 10 seconds, then turn the vehicle 32–40 km/h (20–25 mph) may result in an display if: back on. • incorrect gain setting. The ITBC system first determines 4.

  • Page 249: Trailer Sway Control (Tsc)

    Driving and Operating A GM dealer may be able to diagnose and To remove the left side kick panel, start at the repair problems with the trailer. However, front of the panel pulling toward the rear of any diagnosis and repair of the trailer is not the vehicle and lift upward to disengage the covered under the vehicle warranty.
  • Page 250 Driving and Operating Aftermarket Electronic Trailer Sway Trailer Tires Warning (Continued) Control Devices Special Trailer (ST) tires differ from vehicle tires. ST tires are designed with stiff sidewalls brake apply lever. Also, check the to help prevent sway and to support heavy Warning trailer brake lamps and other lamps are loads.
  • Page 251 Driving and Operating Always know the maximum speed rating for Light Test Checklist the trailer tires before driving. This may be Select Start to cycle the trailer lamps on and This view shows the recommended steps to significantly lower than the vehicle tire speed off to determine if they are working.
  • Page 252 Driving and Operating • Touch Add To Driver Display to show After a Trailer Profile has been created and After a profile is imported, it can be selected trailer brake gain and output in the Driver the trailer is electrically connected, the trailer from the trailer list.
  • Page 253 Driving and Operating • If no trailer is connected, the Status view If a trailer connection is detected off, a message on the DIC displays the next shows the last trailer profile with a status of without any faults, the view displays No time the vehicle is turned on.
  • Page 254 Driving and Operating • 2. The brake lights turn on for about Touch a reminder to view, reset, delete, or Always follow the maintenance instructions two seconds. edit it. that came with your trailer. 3. The left turn signal light flashes – The progress bar turns yellow Checklist View three times.
  • Page 255 Driving and Operating No Trailer Connected Guest Trailer Status View Guest Trailer If no trailer is connected, the checklist shows If the Guest Trailer Profile is the active Trailer If the Guest Trailer Profile is active, the Status the last selected trailer profile. Profile, trailer detection, lights/connections view shows: •...
  • Page 256 Driving and Operating If a Trailer Profile is already active and the Trailer Name profile will still be associated with the brake gain setting has been set for that Trailer user account. However, if there is not Touch to edit the Trailer Profile name. Profile, the system will recall the brake gain a connected OnStar plan, then the remove value whenever the vehicle is turned on.
  • Page 257 Driving and Operating If Tow/Haul Mode is off and this setting is on for Maintenance Notifications Warning (Continued) a Trailer Profile, each time the vehicle is turned Touch Maintenance Notification to turn on/off on, a reminder appears to turn on Tow/Haul Maintenance Notifications for the selected operation and cause a crash.
  • Page 258 Driving and Operating Your vehicle may be equipped with auxiliary switches that can be used for add-on electrical equipment sold through GM Accessories. See your dealer for more information.

  • Page 259: Vehicle Care

    Vehicle Care Vehicle Care Park Brake and P (Park) Mechanism Tire Pressure Monitor Operation ..... 300 Check ............276 Tire Inspection ..........304 Wiper Blade Replacement ......277 Tire Rotation ..........305 General Information Windshield Replacement ......277 When It Is Time for New Tires ....306 Buying New Tires .........306 General Information ........259 Headlamp Aiming...

  • Page 260: General Information

    Vehicle Care General Information materials. Perchlorate Material – special GM Accessories are designed to complement handling may apply. See www.dtsc.ca.gov/ and function with other systems on the vehicle. For service and parts needs, visit your dealer. hazardouswaste/perchlorate. See your dealer to accessorize the vehicle You will receive genuine GM parts and GM- using genuine GM Accessories installed by Accessories and Modifications...

  • Page 261: Hood

    Vehicle Care To order the proper service manual, see 2. Go to the front of the vehicle and locate Warning the secondary release lever under the front Publication Ordering Information 3 356. center of the hood. Push the secondary This vehicle has an airbag system. Before Components under the hood can get hot hood release lever to the right to release.
  • Page 262 Vehicle Care To close the hood: Warning Do not drive the vehicle if the hood is not latched completely. The hood could open fully, block your vision, and cause a crash. You or others could be injured. Always close the hood completely before driving. 1.

  • Page 263: Engine Compartment Overview

    Vehicle Care   Engine Compartment Overview 2.7L L4 (L3B) Engine...

  • Page 264: Engine Oil

    Vehicle Care 1. Remote Negative (–) Grounding Point. Engine Oil Warning See Jump Starting - North America 3 322. To ensure proper engine performance and long 2. Windshield Washer Fluid Reservoir. See The engine oil dipstick handle may be hot; life, careful attention must be paid to engine it could burn you.
  • Page 265 Vehicle Care When to Add Engine Oil Caution (Continued) the excess oil or limit driving of the vehicle, and seek a service professional to remove the excess oil. See Engine Compartment Overview 3 262 for Caution the location of the engine oil fill cap. If the oil is below the cross-hatched area at the tip of the dipstick and the engine has been off Add enough oil to put the level somewhere in...

  • Page 266: Engine Oil Life System

    Vehicle Care Engine Oil Additives/Engine Oil Flushes If the system is ever reset accidentally, the oil Engine Oil Life System must be changed at 5 000 km (3,000 mi) since Do not add anything to the oil. The When to Change Engine Oil the last oil change.

  • Page 267: Automatic Transmission Fluid

    Vehicle Care 3. Follow the screen prompts and touch RESET Automatic Transmission Fluid Engine Air Filter Life System on the display screen. Then touch RESET How to Check Automatic If equipped, this feature provides the engine again to confirm. The percentage of filter air filter’s remaining life and best timing Transmission Fluid life remaining will change to 100%.

  • Page 268: Cooling System

    Vehicle Care To inspect or replace the engine air Caution Warning cleaner/filter: If part replacement is necessary, the part If the air cleaner/filter is off, dirt can easily must be replaced with one of the same part get into the engine, which could damage it. number or with an equivalent part.
  • Page 269 Vehicle Care What to Use Caution Warning Warning An underhood electric fan can start up Do not use anything other than a mix even when the engine is not running and of DEX-COOL coolant that meets GM Plain water, or other liquids such as alcohol, can cause injury.
  • Page 270 Vehicle Care How to Add Coolant to the Coolant Warning (Continued) Surge Tank them to come out at high speed and you Warning could be burned. Never turn the cap when the cooling system, including the pressure Spilling coolant on hot engine parts can cap, is hot.

  • Page 271: Engine Overheating

    Vehicle Care 1. Turn the pressure cap slowly coolant surge tank until the level reaches The vehicle has an engine coolant temperature counterclockwise. If a hiss is heard, wait the mark pointed to on the front of the gauge on the instrument cluster to warn for that to stop.

  • Page 272: Engine Fan

    Vehicle Care If No Steam Is Coming from the come back on, continue to drive normally and This fan noise may also be heard when starting have the cooling system checked for proper fill the engine. It will go away as the fan clutch Engine Compartment and function.

  • Page 273: Brakes

    Vehicle Care Adding Washer Fluid needed. The sound can come and go or can be Caution (Continued) heard all the time when the vehicle is moving, When washer fluid is low, a message displays except when applying the brake pedal firmly. •...

  • Page 274: Brake Pad Life System

    Vehicle Care Brake pads should be replaced as complete Brake pads should always be replaced as How to Turn Off the Brake Pad Life System axle sets. complete axle sets. The brake pad life system can be turned off. This may be necessary if aftermarket brake pads Brake Pedal Travel How to Reset the Brake Pad Life System...

  • Page 275: Brake Fluid

    Vehicle Care Always clean the brake fluid reservoir cap and What to Add Brake Fluid the area around the cap before removing it. Use only GM approved DOT 4 brake fluid from Do not top off the brake fluid. Adding fluid does a clean, sealed container.

  • Page 276: Four-Wheel Drive

    Vehicle Care The vehicle has an Absorbed Glass Mat (AGM) Vehicle Storage Warning 12-volt battery. Installation of a standard 12- volt battery will result in reduced 12-volt Warning Batteries have acid that can burn you and battery life. gas that can explode. You can be hurt badly Batteries have acid that can burn you and Some 12-volt battery chargers have an AGM if you are not careful.

  • Page 277: Front Axle

    Vehicle Care How to Check Lubricant When to Change Lubricant Rear Axle Refer to Maintenance Schedule 3 339 to Automatic Transfer Case When to Check Lubricant determine how often to change the lubricant. It is not necessary to regularly check the What to Use rear axle fluid unless a leak is suspected or Refer to Recommended Fluids and Lubricants...

  • Page 278: Wiper Blade Replacement

    Vehicle Care Wiper Blade Replacement Warning (Continued) Caution vehicle in case it begins to roll. Be ready to apply the regular brake at once should the Allowing the wiper arm to touch the vehicle begin to move. windshield when no wiper blade is installed could damage the windshield.

  • Page 279: Headlamp Aiming Front Headlamp Aiming

    Vehicle Care according to GM specifications for proper If the vehicle is damaged in a crash, the Taillamps, Turn Signal, Stoplamps, alignment. If it is not, the HUD image may headlamp aim may be affected. If adjustment and Back-Up Lamps look out of focus. to the headlamps is necessary, see your dealer.
  • Page 280 Vehicle Care 2. Remove the two rear lamp 4. Pull the rear lamp assembly straight back 8. Verify the retainer ring is in the proper to remove it from the vehicle. This may position. If the retainer ring is out of assembly screws.

  • Page 281: Center High-Mounted Stoplamp (Chmsl) And Cargo Lamp

    Vehicle Care To replace one of these bulbs: Center High-Mounted Stoplamp License Plate Lamp (CHMSL) and Cargo Lamp 1. Remove the two screws and lift off the 1. The license plate lamp is located on the lamp assembly. rear bumper. 1.

  • Page 282: Electrical System Electrical System Overload

    Vehicle Care 2. Rotate the bulb holder, on the back To check a fuse, look at the band inside the fuse. Replacing a Blown Fuse side of the bumper, counterclockwise If the band is broken or melted, replace the fuse. 1. Turn off the vehicle. to disengage.

  • Page 283: Fuses And Circuit Breakers

    Vehicle Care Headlamp Wiring 9 Danger An electrical overload may cause the lamps to go on and off, or in some cases to remain off. Fuses and circuit breakers are marked with Have the headlamp wiring checked right away their ampere rating. Do not exceed the if the lamps go on and off or remain off.

  • Page 284: Engine Compartment Fuse Block

    Vehicle Care To check or replace a blown fuse, see Electrical A fuse puller is available inside this fuse block. System Overload 3 281. Engine Compartment Fuse Block The engine compartment fuse block is in the engine compartment. See Engine Compartment Overview 3 262 Lift the cover to access the fuse block.
  • Page 285 Vehicle Care Fuses Usage ICCM – Integrated Chassis Control Module FUEL TANK ZONE MDL – Fuel Tank Zone Module – Cooling Fan 2 – – MTAOP – Transmission Auxiliary Oil Pump Motor – – – SECONDARY AXLE MTR – Front Drive Axle Actuator The vehicle may not be equipped with all of the –...
  • Page 286 Vehicle Care Fuses Usage Fuses Usage Fuses Usage – ENG MISC 1 & 2 – Wide TRLR REVERSE LAMPS – Range Air Fuel Oxygen Trailer Reverse Lamps SBZA/CVS – Side Blind Sensor/Canister Purge/ Zone Alert/Canister TIM 1 – Trailer Interface Turbo Bypass/Step Cam Vent Solenoid Module 1 Intake-Exhaust Solenoids...
  • Page 287 Vehicle Care Fuses Usage Fuses Usage Fuses Usage Spare Front Wipers ELM 4 – Exterior Lighting Module 4 – Right Front Spare MISC WINDOWS LEFT Park Lamp/Daytime - Driver Door Panel Running Lamp/Left Spare Switch (Express Up/ Trailer Stop/Turn Lamp/ Down)/Window Motor Spare Left Rear Park Lamp/ Left Front (Express...
  • Page 288 Vehicle Care Fuses Usage Fuses Usage Fuses Usage Aeroshutter ELM 7 – Exterior Lighting MISC WINDOWS RIGHT Module 7 – Left Front – Passenger Door Panel ELM 6 – Exterior Lighting Park Lamp/Daytime Switch (Express Down) Module 6 – Left Low Running Lamp/Left Front Window Motor Right Beam/Right Rear Stop/ Turn Lamp/Center High...
  • Page 289 Vehicle Care Fuse Usage AUX – Center Stack Auxiliary Switch 6 AUX 1– Auxiliary Switch 1 AUX 2– Auxiliary Switch 2 AUX 3– Auxiliary Switch 3 – – Relay Usage AUX – Center Stack Auxiliary Switch 6 AUX 1– Auxiliary Switch 1 AUX 2– Auxiliary Switch 2 AUX 3– Auxiliary Switch 3 – –...

  • Page 290: Instrument Panel Fuse Block

    Vehicle Care Instrument Panel Fuse Block There is a cover on the instrument panel fuse block. Press the clips on the side to remove The instrument panel fuse block is behind a side the cover. trim panel. Unclip the sides of the trim, then pull the cover away from the trim panel to access the fuse block.
  • Page 291 Vehicle Care Fuse Usage FRONT HVAC BLOWER – Front HVAC Module ELM 1 – Exterior Lighting Module 1 TRANS CNTRL MODULE – Transmission Control Module ELM 2 – Exterior Lighting Module 2 DRIVER SEAT MISC – Memory Seat Module/Seat Position Switch (SPS) LIN Switch BODY CNTRL MODULE 1 –...
  • Page 292 Vehicle Care Fuse Usage Fuse Usage Fuse Usage MISCELLANEOUS 1 – MISCELLANEOUS 3 – DISPLAYS/VPM –Video Electric Park Break Exterior Lighting Module/ Processing Module/Display Switch/Automatic Occupant DC-AC Inverter Module/ SUNROOF – Sunroof Sensing Display Vented Module – AUX JACK/TPC – – Auxiliary Audio/Video Jack/ TRLR BRK CNTRL SW –...

  • Page 293: Wheels And Tires Tires

    Vehicle Care Warning (Continued) Fuse Usage Fuse Usage • Overloading the tires can cause VCU MDL/SPARE – Virtual APO CONSOLE – Auxiliary DC overheating as a result of too much Cockpit Unit Module Power Outlet Row 1 flexing. There could be a blowout HTD STR WHL –...

  • Page 294: Winter Tires

    Vehicle Care details regarding winter tire availability and The tread pattern on these tires may wear more Warning (Continued) proper tire selection. Also, see Buying New Tires unevenly than other tires. Consider rotating the tires more frequently than at 12 000 km •...
  • Page 295 Vehicle Care (3) DOT (Department of Transportation) (6) Uniform Tire Quality Grading (UTQG) The Department of Transportation Tire manufacturers are required to grade (DOT) code indicates that the tire tires based on three performance factors: is in compliance with the U.S. treadwear, traction, and temperature Department of Transportation Motor resistance.

  • Page 296: Tire Designations

    Vehicle Care (3) Dual Tire Maximum Load Maximum and plant code, tire size, and date the tire load that can be carried and the maximum was manufactured. The TIN is molded onto pressure needed to support that load both sides of the tire, although only one when used in a dual configuration.
  • Page 297 Vehicle Care (4) Construction Code A letter code is used characters in the tire size mean a light truck to indicate the type of ply construction tire engineered to standards set by the U.S. in the tire. The letter R means radial ply Tire and Rim Association.

  • Page 298: Tire Terminology And Definitions

    Vehicle Care this represents the load index for single Cold Tire Pressure The amount of air Kilopascal (kPa) The metric unit for versus dual wheel usage (single/dual). The pressure in a tire, measured in kPa air pressure. speed rating is the maximum speed a tire (kilopascal) or psi (pounds per square inch) Light Truck (LT-Metric) Tire A tire used on...

  • Page 299: Tire Pressure

    Vehicle Care molding that is higher or deeper than the Tread The portion of a tire that comes into Vehicle Placard A label permanently same moldings on the other sidewall of contact with the road. attached to a vehicle showing the the tire.

  • Page 300: Tire Pressure Monitor System

    Vehicle Care adjustment is necessary. If the inflation 3 163. How the vehicle is loaded affects Warning (Continued) pressure is low, add air until the vehicle handling and ride comfort. Never • recommended pressure is reached. If the load the vehicle with more weight than it Reduced fuel economy for internal inflation pressure is high, press on the was designed to carry.

  • Page 301: Tire Pressure Monitor Operation

    Vehicle Care on the vehicle placard or tire inflation pressure Your vehicle has also been equipped with Tire Pressure Monitor Operation label. (If your vehicle has tires of a different size a TPMS malfunction indicator to indicate when This vehicle may have a Tire Pressure Monitor than the size indicated on the vehicle placard the system is not operating properly.
  • Page 302 Vehicle Care • the DIC warning message come on each time One of the road tires has been replaced with Caution the vehicle is turned on until the tires are the spare tire. The spare tire does not have inflated to the correct inflation pressure. If the a TPMS sensor.
  • Page 303 Vehicle Care • Operating electronic devices or being near Repeat these steps for all underinflated tires The TPMS will not activate the tire fill alert facilities using radio wave frequencies that have illuminated the low tire pressure properly under the following conditions: •...
  • Page 304 Vehicle Care To enable Air Down Mode: the next tire while the turn signal lamp the tire. When the target pressure you selected is still on, the Air Down Mode will not in Step 6 is reached, the horn sounds once and 1.

  • Page 305: Tire Inspection

    Vehicle Care • START was not pressed after selecting will display in the DIC. See Driver Information Warning (Continued) the target tire pressure in the Air Down Center (DIC) 3 100. A warning message displays Mode app. in the DIC if a problem occurs during the Overinflated tires, or tires that have too relearn process.

  • Page 306: Tire Rotation

    Vehicle Care Check that all wheel nuts are properly Tire Rotation tightened. See “Wheel Nut Torque” under Tires should be rotated according to Capacities and Specifications 3 347 and the interval listed in the maintenance “Removing the Flat Tire and Installing the schedule.

  • Page 307: When It Is Time For New Tires

    Vehicle Care Treadwear indicators are one way to tell when Vehicle Storage Warning it is time for new tires. Treadwear indicators Tires age when stored normally mounted on appear when the tires have only 1.6 mm a parked vehicle. Park a vehicle that will be Do not apply grease to the wheel (1/16 in) or less of tread remaining.

  • Page 308: Different Size Tires And Wheels

    Vehicle Care performance, ride and handling, traction Winter tires with the same speed rating Warning (Continued) control, and tire pressure monitoring as the original equipment tires may not performance. GM's TPC Spec number is be available for H, V, W, Y and ZR speed death.

  • Page 309: Uniform Tire Quality Grading

    Vehicle Care only to vehicles sold in the United States. Treadwear Warning (Continued) The grades are molded on the sidewalls The treadwear grade is a comparative of most passenger car tires. The Uniform rating based on the wear rate of the tire systems developed for the vehicle, and Tire Quality Grading (UTQG) system does have them properly installed by a GM...

  • Page 310: Wheel Alignment And Tire Balance

    Vehicle Care traction tests, and does not include excessive loading, either separately or in leaks air, replace it. Some aluminum wheels can be repaired. See your dealer if any of these acceleration, cornering, hydroplaning, or combination, can cause heat buildup and conditions exist.

  • Page 311: Tire Traction Devices

    Vehicle Care In the event of a blowout, follow these tips: Warning (Continued) Warning • A front tire blowout causes the vehicle to pull toward the side of the flat. Take your Replacing a wheel with a used one is cause damage to the brakes, suspension, or foot off the accelerator pedal and grip the dangerous.
  • Page 312 Vehicle Care Warning Warning Lifting a vehicle and getting under it to Changing a tire can be dangerous. The do maintenance or repairs is dangerous vehicle can slip off the jack and roll over without the appropriate safety equipment or fall causing injury or death. Find a level and training.

  • Page 313: Tire Changing

    Vehicle Care Under-Vehicle Mounted Spare Tire Tire Changing Removing the Spare Tire and Tools To access and remove the jack and tools: 1. Assemble the wheel wrench (7) and the two jack handle extensions (6), as shown. 1. Spare Tire 2. Tire/Wheel Retainer 3.
  • Page 314 Vehicle Care 3. Insert the hoist end (open end) (9) of 2. Wheel Mount Handle the extension through the hole (8) in the 3. Bushing rear bumper. 1. Remove wheel mount handle (2) Do not use the chiseled end of the and bushing (3) by turning handle wheel wrench.
  • Page 315 Vehicle Care 1. Jack 2. Wheel Blocks 3. Jack Handle 4. Jack Handle Extensions 5. Wheel Wrench 6. Jack Spacer 1. Do a safety check before proceeding. Make sure all wheels are on level ground. See If a Tire Goes Flat 3 310. Front Position 3.
  • Page 316 Vehicle Care There are two designs for the leaf spring anchor plate. Align the jacking head flange with the slot inside the front edge of the anchor plate as shown if your anchor plate looks like Type 1. Align the curved face of the jacking head with the curvature of the anchor plate as shown if your anchor plate looks like Type 2.
  • Page 317 Vehicle Care 9. Install the spare tire. Warning Warning Warning Raising the vehicle with the jack improperly Rust or dirt on a wheel, or on the parts positioned can damage the vehicle and to which it is fastened, can cause wheel Never use oil or grease on bolts or nuts even make the vehicle fall.
  • Page 318 Vehicle Care Warning (Continued) Warning (Continued) studs on the wheel. If the stud holes in nuts. See Capacities and Specifications a wheel have become larger, the wheel 3 347 for original equipment wheel nut could collapse in operation. Replace any torque specifications. wheel if its stud holes have become larger or distorted in any way.
  • Page 319 Vehicle Care Storing a Flat or Spare Tire and Tools Under-Vehicle Mounted Spare Tire Caution (Continued) Warning wheel with the valve stem pointing down and have the wheel/tire repaired as soon Storing a jack, a tire, or other equipment in as possible. the passenger compartment of the vehicle could cause injury.
  • Page 320 Vehicle Care 2. Pull the cable and spring through the center of the wheel. Tilt the wheel retainer plate down and through the center of the wheel. Make sure the retainer is fully seated across the underside of the wheel. 4.
  • Page 321 Vehicle Care 7. Make sure the tire is stored securely and Bed-Mounted Spare Tire flush in the radius (2) of the spare tire support bracket (1). Push, pull, and then try to turn the tire. If the tire moves, use the wheel wrench to tighten the cable.

  • Page 322: Full-Size Spare Tire

    Vehicle Care The smaller, tapered side of the bushing Have the damaged or flat road tire repaired should be facing the open end of the or replaced and installed back onto the vehicle threaded rod. as soon as possible so the spare tire will be available in case it is needed again.

  • Page 323: Jump Starting Jump Starting - North America

    Vehicle Care If the vehicle has a spare tire that does not Caution Warning match the original road tires and wheels in size and type, do not include the spare in the WARNING: Battery posts, terminals and Ignoring these steps could result in costly tire rotation.
  • Page 324 Vehicle Care The good battery negative (–) terminal and Caution good battery positive (+) terminal are on the battery of the vehicle providing the jump start. If any accessories are left on or plugged in The discharged battery positive (+) terminal is during the jump starting procedure, they could be damaged.

  • Page 325: Towing The Vehicle Transporting A Disabled Vehicle

    Vehicle Care 5. Check that the jumper cables do not have After starting the disabled vehicle and Warning loose or missing insulation. removing the jumper cables, allow it to idle for several minutes. 6. Connect one end of the red positive (+) Using a match near a battery can cause cable to the discharged battery positive ...

  • Page 326: Recreational Vehicle Towing

    Vehicle Care • If the 12-volt battery is dead and/or EPB is Recreational Vehicle Towing Caution not released, the vehicle will not move. Try Recreational vehicle towing means towing to jump start the vehicle with a known good The vehicle may be equipped with the vehicle behind another vehicle, such as 12-volt battery, shift the car into N (Neutral), an Electric Parking Brake (EPB) and/or...
  • Page 327 Vehicle Care • Just as preparing the vehicle for a long trip, Dinghy Towing (Two-Wheel-Drive Dinghy Towing (Vehicles with a Two- ensure the vehicle is prepared to be towed. Vehicles and Vehicles with a Single-Speed Speed Transfer Case) Transfer Case) Follow the tow vehicle manufacturer’s instructions.
  • Page 328 Vehicle Care 7. Turn the vehicle off, wait five seconds, then Warning (Continued) Caution shift to P (Park). 8. Turn on the ignition without starting the injured. Set the parking brake and use If the steering column is locked, vehicle engine. To do this, take your foot off the wheel blocks before shifting the transfer damage may occur.
  • Page 329 Vehicle Care 3. Turn on the ignition without starting the 11. Release the parking brake and remove the engine. To do this, take your foot off the wheel blocks. brake pedal then press and hold ENGINE 12. Reset any lost presets. START/STOP for five seconds until the green The outside temperature display will light on the button is illuminated.

  • Page 330: Appearance Care

    Vehicle Care Appearance Care Cleaning Underhood Components Caution Exterior Care Caution Avoid using high-pressure washers closer Locks than 30 cm (12 in) to the surface of the Do not power wash any component under vehicle. Use of power washers exceeding Locks are lubricated at the factory.
  • Page 331 Vehicle Care • Finish Care Use only approved cleaning solutions for Caution aluminum, chrome or stainless steel. Some Application of aftermarket clearcoat cleaners are highly acidic or contain alkaline sealant/wax materials is not recommended. If Machine compounding or aggressive substances and can damage the moldings. painted surfaces are damaged, see your dealer polishing on a basecoat/clearcoat paint •...
  • Page 332 Vehicle Care • Aftermarket appearance caps or covers Clean rubber blades using a lint-free cloth Caution while the lamps are illuminated, due to or paper towel soaked with windshield excessive heat generated. washer fluid or a mild detergent. Wash the Using silicone-based products may damage windshield thoroughly when cleaning the the bedliner, reduce the slip-resistant Caution...

  • Page 333: Underbody Maintenance

    Vehicle Care Inspect power steering for proper Caution Caution attachment, connections, binding, leaks, cracks, chafing, etc. Using petroleum-based tire dressing To avoid surface damage on wheels and Visually check constant velocity joint boots and products on the vehicle may damage the wheel trim, do not use strong soaps, axle seals for leaks.

  • Page 334: Interior Care

    Vehicle Care Sheet Metal Damage Interior Care Caution If the vehicle is damaged and requires sheet To prevent dirt particle abrasions, regularly metal repair or replacement, make sure To prevent damage: clean the vehicle's interior. Before using the body repair shop applies anti-corrosion •...
  • Page 335 Vehicle Care Cleaning the windshield with water during the Caution (Continued) Warning first three to six months of ownership will reduce tendency to fog. a color transfer to the wipe or change Do not use cleaners that contain silicone, the appearance of the interior surface wax-based products, or cleaners that Speaker Covers when used.
  • Page 336 Vehicle Care To clean: After cleaning, use a paper towel to blot Instrument Panel, Leather, Vinyl, Other excess moisture. Plastic Surfaces, Low Gloss Paint Surfaces, 1. Saturate a clean, lint-free colorfast and Natural Open Pore Wood Surfaces cloth with water. Microfiber cloth is Cleaning High Gloss Surfaces and Vehicle recommended to prevent lint transfer to Information and Radio Displays...

  • Page 337: Floor Mats

    Vehicle Care Care of Seat Belts Use the following guidelines for proper floor Caution (Continued) mat use: Keep belts clean and dry. • The original equipment floor mats are blot immediately and clean with a soft designed for your vehicle. If the floor mats cloth dampened with a mild soap solution.
  • Page 338 Vehicle Care Reinstall by lining up the floor mat retainer openings over the carpet retainers and snapping into position. Make sure the floor mat is properly secured in place. Verify the floor mat does not interfere with the pedals. Cleaning Rubber Floor Mats (All-Weather Mats and Floor Liners) See “Vinyl/Rubber”...

  • Page 339: Service And Maintenance

    Service and Maintenance Service and Maintenance General Information Caution Your vehicle is an important investment. This Damage caused by improper maintenance General Information section describes the required maintenance for can lead to costly repairs and may not the vehicle. Follow this schedule to help protect General Information ........

  • Page 340: Maintenance Schedule

    Service and Maintenance Because of the way people use vehicles, Refer to the information in the Maintenance the rotation, check the wheel alignment. See maintenance needs vary. There may need to Schedule Additional Required Services - When It Is Time for New Tires 3 306 and Wheel be more frequent checks and services.
  • Page 341 Service and Maintenance Additional Required Services — Every 36 000 km (22,500 mi) Every 240 000 km (150,000 mi) • • Normal Service Replace passenger compartment air filter. Drain and fill engine cooling system. Or Or every 24 months, whichever comes first. every six years, whichever comes first.
  • Page 342 Service and Maintenance Multi-Point Vehicle – Any vehicle consistently operated Every 80 500 km (50,000 mi) • in a high sand or dust environment Inspection (MPVI) Change transfer case fluid, if equipped such as those used on oil pipelines with 4WD. Do not directly power wash the and similar applications.

  • Page 343: Special Application Services

    Service and Maintenance • • Exterior Lights Rotation, if applicable Floor mats secured, no interference • • with pedals Visual inspection Alignment check, optional • • Horn Reset tire pressure monitor Windshield and Wipers • • Ignition lock, if equipped •...

  • Page 344: Recommended Fluids, Lubricants, And Parts

    Service and Maintenance Recommended Fluids, Lubricants, and Parts Recommended Fluids and Lubricants Fluids and lubricants identified below by name or specification, including fluids or lubricants not listed here, can be obtained from your dealer. Usage Fluid/Lubricant Automatic Transmission DEXRON-HP Automatic Transmission Fluid. Chassis Lubrication Lubricant meeting requirements of NLGI #2, Category LB or GC-LB.

  • Page 345: Maintenance Records

    Service and Maintenance Usage Fluid/Lubricant Transfer Case (If Equipped With Four-Wheel Drive) DEXRON-VI Automatic Transmission Fluid. Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements. Maintenance Records After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided.
  • Page 346 Service and Maintenance Date Odometer Reading Serviced By Services Performed                              ...

  • Page 347: Technical Data

    Technical Data Technical Data Vehicle Identification Service Parts Identification Vehicle Identification Number There may be a large barcode on the certification label on the center pillar that you Vehicle Identification (VIN) can scan for the following information: Vehicle Identification Number (VIN) ..346 •...

  • Page 348: Vehicle Data

    Technical Data Vehicle Data Capacities and Specifications The following approximate capacities are given in metric and English conversions. See Recommended Fluids and Lubricants 3 343. Capacities Application Metric English For the air conditioning system refrigerant type and charge amount, Air Conditioning Refrigerant see the refrigerant label under the hood.

  • Page 349: Engine Specifications

    Technical Data Engine Specifications Engine VIN Code Spark Plug Gap 2.7L L4 (L3B) 0.65–0.75mm (0.026–0.030 in) Spark plug gaps are preset by the manufacturer. Re-gapping the spark plug is not recommended and can damage the spark plug. Engine Drive Belt Routing 2.7L Engine...

  • Page 350: Customer Information

    OnStar .............359 Customer Satisfaction Procedure Infotainment System ........359 Your satisfaction and goodwill are important to your dealer and to GMC. Normally, any Customer Information concerns with the sales transaction or the Customer Satisfaction Procedure ..... 349 operation of the vehicle will be resolved by Customer Assistance Offices ......

  • Page 351: Customer Information

    Year, Make, Model, mileage of the vehicle vehicle service claims. The program provides When contacting GMC, remember that your and provide a description of the concern. for the review of the facts involved by an concern will likely be resolved at a dealer's...

  • Page 352: Customer Assistance Offices

    Online Account and Customer 1-800-263-3777 (English), 1-800-263-7854 contact 1-800-833-2438 Support (French), or write to: Roadside Assistance: 1-888-881-3302 Create a GMC Account (U.S.) at gmc.com Mediation/Arbitration Program Canada c/o Customer Care Centre Learn more about your vehicle features, shop General Motors of Canada Company...

  • Page 353: Gm Mobility Reimbursement Program (U.s. Only)

    Roadside Assistance program at any time Calling for Assistance without notification. When calling Roadside Assistance, have the GM North America and GMC reserve the right to following information ready: limit services or payment to an owner or driver • if they decide the claims are made too often, or Your name, home address, and home the same type of claim is made too frequently.
  • Page 354 Reimbursement of police mandated tows Emergency Tow from a Public Road or is required. • Highway: Tow to the nearest GMC dealer Mounting, dismounting, or changing of • Trip Interruption Benefits and Assistance: for warranty service, or if the vehicle was in snow tires, chains, or other traction devices Must be over 150 km from where your trip...

  • Page 355: Scheduling Service Appointments

    Customer Information Courtesy Transportation is not a part of Courtesy Rental Vehicle Scheduling Service Appointments the New Vehicle Limited Warranty. See the For an overnight warranty repair, the Be sure to notify your dealer of any “Limited Warranty and Owner Assistance dealer may offer a courtesy rental vehicle safety-related concerns when requesting Information”...

  • Page 356: Collision Damage Repair

    Customer Information of these parts is not known. Such parts are Insuring the Vehicle Collision Damage Repair not covered by the GM New Vehicle Limited Protect your investment in the GM vehicle If the vehicle is involved in a collision and Warranty, and any related failures are not with comprehensive and collision insurance it is damaged, have the damage repaired...

  • Page 357: Publication Ordering Information

    Customer Information If a Crash Occurs Choose a reputable repair facility that uses If another party's insurance company is paying quality replacement parts. See “Collision Parts” for the repairs, you are not obligated to accept If there has been an injury, call emergency earlier in this section.

  • Page 358: Reporting Safety Defects

    Customer Information Current and Past Models Operation is subject to the following and remedy campaign. However, NHTSA two conditions: cannot become involved in individual Service manuals and customer literature are problems between you, your dealer, or 1. The device may not cause available for many GM vehicles. ...

  • Page 359: Reporting Safety Defects To General Motors

    Some modules devices or connect your vehicle to any may also store data about how the vehicle GMC Customer Assistance Center unknown or untrusted networks (such as is operated, such as rate of fuel consumption P.O. Box 33172 Bluetooth, Wi-Fi or similar technology).

  • Page 360: Onstar

    Customer Information hitting a road obstacle, data that will assist the EDR data with the type of personally vehicle’s operation; collisions involving the in understanding how a vehicle’s systems identifying data routinely acquired during vehicle; the use of the vehicle and its features, performed.

  • Page 361: Onstar

    OnStar OnStar OnStar Overview Software Terms for more details including system limitations at www.onstar.com (U.S.) or www.onstar.ca (Canada). OnStar Overview The OnStar system status light is next to the OnStar Overview ..........360 OnStar buttons. If the status light is: • OnStar Services Solid Green: System is ready.

  • Page 362: Onstar Services

    OnStar • OnStar Manage Wi-Fi Settings, if equipped. With Roadside Assistance, Advisors can locate a nearby service provider to help with a flat tire, Additional Information > Press to get a priority connection to an a battery jump, or an empty gas tank. OnStar Advisor available 24/7 to: In-Vehicle Audio Messages •...

  • Page 363: Warranty

    OnStar How OnStar Service Works services may not work if the OnStar equipment TTY Users is not properly installed or it has not been Automatic Crash Response, Emergency OnStar has the ability to communicate to properly maintained. If equipment or software Services, Crisis Assist, Stolen Vehicle deaf, hard-of-hearing, or speech-impaired is added, connected, or modified, OnStar...
  • Page 364 OnStar • Languages In emergency situations, OnStar can use features to function properly. These systems the last stored GPS location to send to may not operate if the battery is discharged The vehicle can be programmed to respond in emergency responders. or disconnected.
  • Page 365 OnStar updates or changes may also cause a system to www.opensourceautomotive.com/an/GM. In automatically communicate with GM servers addition to the source code, all referred license to collect information about vehicle system terms, warranty disclaimers, and copyright status, identify whether updates or changes notices are available for download.

  • Page 366: Connected Services

    Connected Services Connected Services directions. Routes that are sent to the Navigation navigation screen can only be canceled Navigation requires a specific OnStar or through the navigation system. connected service plan. Connected Services See www.onstar.com (U.S.) or Navigation ............. 365 Press to receive Turn-by-Turn directions or www.onstar.ca (Canada).
  • Page 367 1. To retrieve Wi-Fi hotspot information, tap myGMC app to compatible Apple and Android device, factory-installed remote start, and the Wi-Fi Hotspot icon on the infotainment smartphones, if available. GMC users can access power locks are required. Data rates home screen. the following services: apply.

  • Page 368: Index

    INDEX Index How Does an Airbag Restrain?....46 Passenger Sensing System......48 Accessories and Modifications..... 259 What Makes an Airbag Inflate?....46 Accessory Power..........174 What Will You See after an Airbag Active Inflates?............47 Fuel Management........176 When Should an Airbag Inflate?....45 Adaptive Where Are the Airbags?......
  • Page 369 INDEX Assistance Systems AUX Button............113 Automatic Emergency (AEB)....221 Advanced............210 Avoiding Untrusted Media Devices..... 124 Front Pedestrian (FPB) System....222 Automatic Emergency Braking (AEB)..221 Axle Break-In, New Vehicle........169 Blind Zone Alert (SBZA)......224 Front.............. 276 Buckle To Drive..........36 Blind Zone Steering (BZSA).......
  • Page 370 INDEX Center Collision Alert Adaptive............199 High-Mounted Stoplamp (CHMSL) Forward (FCA) System....... 219 Light.............. 100 and Cargo Lamp......... 280 Collision Damage Repair........ 355 Cupholders............74 Center Console Compartments Customer Assistance Storage............75 Storage............74 Offices............351 Charging Compass.............. 79 Text Telephone (TTY) Users...... 351 System Light..........
  • Page 371 INDEX Disabled Vehicle Off-Road............154 Coolant Temperature Gauge..... 87 Transporting..........324 Off-Road Recovery........153 Coolant Temperature Warning Light..97 Distracted Vehicle Load Limits........163 Cooling System........... 267 Driving............151 Wet Roads............ 160 Drive Belt Routing........348 Distracted Driving..........151 Winter............161 Exhaust............
  • Page 372 INDEX Fuel Trip Odometer..........84 Recommended..........230 Warning Lights and Indicators....82 Additives............230 General Information Engine............271 Economy, Driving for Better..... 151 Service and Maintenance......338 Filter Filling a Portable Fuel Container..... 232 Towing............233 Engine Air Cleaner........266 Filling the Tank..........231 Vehicle Care..........
  • Page 373 INDEX Heater Infotainment System........359 High/Low Beam Changer......111 Engine............172 Inspection License Plate..........280 Heating............144, 146 Multi-Point Vehicle........341 Malfunction Indicator (Check Engine)..91 High-Beam On Light......... 99 Instrument Cluster..........83 Off-Road............113 High-Beam Systems........110 Instrument Panel Overview......4 On Reminder..........
  • Page 374 INDEX Electric Parking Brake........93 Loss of Control..........154 Manual Rearview.......... 21 Electronic Stability Control (ESC), Off..96 Lower Anchors and Tethers for Children Power.............. 20 Engine Coolant Temperature (LATCH System)..........60 Mode Warning............97 Low Fuel Warning Light........98 Driver Control..........
  • Page 375 INDEX Older Children, Restraints........ 53 Perchlorate Materials Requirements, Online Account and Customer Support..351 California............259 Radiator............. 267 OnStar..............359 Phone Radio Additional Information......361 Apple CarPlay and Android Auto..... 134 AM-FM Radio..........121 Overview............. 360 Bluetooth..........130, 131 Frequency Statement........ 357 OnStar Emergency..........
  • Page 376 INDEX Key Operation..........8 Safety Defects Reporting OnStar............361 Start..............14 Canadian Government....... 357 Vehicle............. 19 Replacement Parts General Motors........... 358 Vehicle Alarm..........19 Airbags............52 U.S. Government......... 357 Service..............149 Replacing Safety System Check........42 Maintenance Records........ 344 Airbag System..........52 Satellite Radio...........
  • Page 377 INDEX Status Systems Terminology and Definitions....297 Vehicle............102 High-Beam............ 110 Traction Devices.......... 310 Steering.............. 153 Uniform Tire Quality Grading....308 Heated Wheel..........77 Wheel Alignment and Tire Balance..309 Wheel Adjustment........77 Wheel Replacement........309 Tachometer............84 Wheel Controls..........119 When It Is Time for New Tires....
  • Page 378 INDEX Towing............237 Wheels Towing App..........250 Alignment and Tire Balance....309 Vehicle Transfer Case Different Size..........307 Ahead Indicator..........95 Four-Wheel Drive........182 Replacement..........309 Alarm System..........19 Transmission When It Is Time for New Tires..... 306 Canadian Owners........... 2 Automatic.............

  • Page 379: United States And Canada

    Scan to Access • Owner’s Manuals • Warranty Information United States Canada • Connected Services • My GMC Rewards • myGMC Mobile App • How-To Videos • Vehicle Diagnostics • Scheduled Maintenance • Vehicle Features • Many Additional Resources United States...

This manual is also suitable for:

Canyon denali 2025

Table of Contents

Save PDF
