STEP 6 SELECT PCIe OPTION CARD(s)
The standard PCIe card offerings are:
Ethernet
■
Fibre Channel
■
iSCSI
■
Virtual Interface Card (VIC)
■
Select PCIe Option Cards
The available PCIe option cards are listed in
Table 7 Available PCIe Option Cards
Product ID (PID) PID Description
Converged Network Adapters (CNAs)
N2XX-ACPCI01 Cisco UCS P81E Virtual Interface Card/ 2-port 10Gbps
N2XX-AEPCI01 Emulex OneConnect OCe10102-F CNA 2-port 10Gbps
UCSC-PCIE-BSFP
Broadcom 57712 Dual Port 10Gb SFP+ w/TOE iSCSI
Network Interface Cards (NICs)
N2XX-ABPCI02 Broadcom 57711 Dual Port 10GbE NIC w/TOE iSCSI
N2XX-ABPCI03-M3 Broadcom 5709 Quad Port 1Gb w/TOE iSCSI for M3 Servers
N2XX-ABPCI01-M3 Broadcom 5709 Dual Port 1Gb w/TOE iSCSI for M3 Servers
N2XX-AQPCI01 Qlogic QLE 8152-CNA 2port 10Gb SFP+ Copper
N2XX-AIPCI02 Intel Quad port GbE Controller (E1G44ETG1P20)
N2XX-AIPCI01 Intel X520 Dual Port 10Gb SFP+ Adapter
N2XX-AMPCI01 Mellanox ConnectX-2 EN with dual 10GbE SFP+ ports
Host Bus Adapters (HBAs)
N2XX-AEPCI03 Emulex LPe 11002 Dual Port 4Gb Fibre Channel HBA
N2XX-AEPCI05 Emulex LPe 12002 Dual Port 8Gb Fibre Channel HBA
N2XX-AQPCI03 Qlogic QLE2462 Dual Port 4Gb Fibre Channel HBA
N2XX-AQPCI05 Qlogic QLE2562 Dual Port 8Gb Fibre Channel HBA
Cisco UCS C200 M2 High-Density SFF Drive Rack-Mount Server
Table 7.
CONFIGURING the SERVER
Card
Height
Full
Half
Half
Half
Half
Half
Half
Half
Half
Half
Half
Half
Half
Half
