4. CAMERA
Focus and Zoom Adjustments
Loosen and tilt back the camera's top cover to
access the lens for adjustment.
Step 3.1 -
Step 3.2 -
Step 3.3 -
Step 3.4 -
The LED Array brightness has been set at the
factory before shipment.
For photocell brightness adjustment refer to
Figure 3-2 on page 11.
LED ARRAY ADJUSTMENTS
/
Loosen the lens setscrews
for focus/zoom adjustments.
See Figure 4-1 on page 13.
The setscrew for N ←→
is used for image focus.
The setscrew for T←→ W
is used for telephoto or wide-
angle settings.
Re-tighten the setscrews after
focus adjustments have been
completed.
12
