Model No. WLTL49806.0
Serial No.
USER'S MANUAL
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.wesloservice.com
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.weslo.com
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cadence 60 Se Treadmill and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo Cadence 60 Se Treadmill

Summary of Contents for Weslo Cadence 60 Se Treadmill

  • Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST ON THE WEB: www.wesloservice.com CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. .Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual. WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    1. It is the responsibility of the owner to ensure page 12. To purchase a surge suppressor, see that all users of this treadmill are adequately your local WESLO dealer or call the toll-free informed of all warnings and precautions. telephone number on the front cover of this manual and order part number 146148, or see 2.
  • Page 4 20. Do not attempt to raise, lower, or move the DANGER: Always unplug the power treadmill until it is properly assembled. (See cord immediately after use, before cleaning ASSEMBLY on page 6, and HOW TO FOLD the treadmill, and before performing the AND MOVE THE TREADMILL on page 20.) maintenance and adjustment procedures de- You must be able to safely lift 45 pounds (20...

  • Page 5: Before You Begin

    (see the front cover of this manual for the location). nience of your home. And when you’re not exercising, the CADENCE 60 SE treadmill can be folded up, requir- To avoid a registration fee for any service needed under warranty, you must register the treadmill at ing less than half the floor space of other treadmills.

  • Page 6: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 2. Have a second person orient the Base (48) as shown. Identify the Left Upright (31), which has a large hole near the bend as shown. Bend Orient the Left Upright (31) as shown, and attach it to the Base (48) with two Upright Bolts (27) and two Upright Star Washers (39);...
  • Page 8 5. See the left inset drawing. Identify the two Frame Spacers (34). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer. Next, hold a Frame Spacer (34) between the Right Upright (36) and the Lift Frame (59), with the outer side of the Frame Spacer facing the Right Upright.
  • Page 9 7. Set the console assembly face down on a soft surface to avoid scratching it. Hold a Handrail (18) near the console assembly. Console Next, insert the console wire into the hole in the Wire bottom of the Handrail (18) and out of the indi- cated square hole.
  • Page 10 10. Lower the Uprights (31, 36). Side View See the inset drawing. Position the Uprights (31, 36) so that the treadmill Frame (74) is centered between the Uprights. See steps 2–6. Firmly tighten the Upright Bolts (27) and the Frame Bolts (32) on each side of 31, 36 the treadmill.
  • Page 11 12. Attach the ground wire on the Upright Wire (28) to the indicated hole in the Base (48) with a Grommet Silver Ground Screw (11). Then, press the indicated grommet into the Right Upright (36). Attach the Right Base Cover (91) to the Base (48) with two 3/4"...

  • Page 12: Operation And Adjustment

    Grounded Outlet Box the right). To purchase a surge suppressor, see Adapter your local WESLO dealer or call the toll-free tele- Surge Suppressor phone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 13 CONSOLE DIAGRAM Note: If there are sheets of clear plastic Clip on the console, remove the plastic. FEATURES OF THE CONSOLE Calorie Goal Programs The console also features four calorie goal programs. The treadmill console offers a selection of features Each program controls the speed and incline of the designed to make your workouts more effective.
  • Page 14 To stop the walking belt, press the Stop button. HOW TO USE THE MANUAL MODE The time will begin to flash in the display. To restart the walking belt, press the Start button, the Insert the key into the console. Speed increase button, or one of the numbered speed buttons.
  • Page 15 Note: For the treadmill to count your steps accu- Turn on the fan if desired. rately, correct walking form is important. As you walk, try to maintain a steady pace, a uniform To turn on the fan at low speed, press the Fan stride length, and a consistent position on the button;...
  • Page 16 Note: To change the speed of the walking belt or HOW TO USE A DISTANCE PROGRAM the incline of the treadmill at any time during the program, press the Speed or Incline buttons. Insert the key into the console. The left side of the display will show the number of kilometers still to be run every few seconds.
  • Page 17 Press the Start button or the Speed increase HOW TO USE A STEP PROGRAM button to start the program. Insert the key into the console. A moment after the button is pressed, the walking belt will begin to move at 2 mph. Hold the See HOW TO TURN ON THE POWER on page handrails and begin walking.
  • Page 18 When only three seconds remain in the first seg- HOW TO USE A CALORIE GOAL PROGRAM ment of the program, both the Current Segment column and the column to the right will flash and a series of tones will sound. If the speed and/or in- Insert the key into the console.
  • Page 19 THE INFORMATION MODE Follow your progress with the display. The console features an information mode that keeps See step 6 on pages 14 and 15. track of treadmill usage information. The information mode also allows you to select miles or kilometers as Measure your heart rate if desired.

  • Page 20: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 22 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 12. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.

  • Page 23: Conditioning Guidelines

    CONDITIONING GUIDELINES is to burn fat, adjust the speed and incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed and incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle...
  • Page 24 PART LIST—Model No. WLTL49806.0 R1006A Key No. Qty. Description Key No. Qty. Description Hood Lift Frame Bolt 3/4" Screw 3/8" Nut Left Foot Rail Lift Motor Foot Rail Screw Stop Bracket Motor Tension Bolt Incline Motor Bolt, Top Motor Tension Washer Incline Motor Bolt, Bottom Wire Tie Lift Frame...
  • Page 25 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.

  • Page 27: How To Order Replacement Parts

    • the MODEL NUMBER of the product (WLTL49806.0) • the NAME of the product (WESLO CADENCE 60 SE treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the EXPLODED DRAWING and PART LIST...
