Model No. WETL21020

Serial No.

Serial Number Decal

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts,

please call:

08457 089 009

Or write:

ICON Health & Fitness, Ltd.

Unit 4

Revie Road Industrial Estate

Revie Road, Beeston

Leeds, LS11 8JG

csuk@iconeurope.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

USER'S MANUAL

Visit our website at

www.iconeurope.com

Table of Contents

Need help?

Do you have a question about the Cadence 630 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo Cadence 630

Page 1 USER'S MANUAL Model No. WETL21020 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
Page 3 16. Never leave the treadmill unattended whilst it 21. Never drop or insert any object into any is running. Always remove the key and unplug opening. the power cord when the treadmill is not in DANGER: use. Always unplug the power cord immediately after use, before cleaning 17.
Page 4: Before You Begin
And when serial number can be found on a decal attached to the you’re not exercising, the unique CADENCE 630 can treadmill (see the front cover of this manual for the lo- be folded up, requiring less than half the floor space of cation).
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 6 4. Loosen the two Console Bolts (9) underneath the Console (1), and rotate the Console to the position shown. Push the Right and Left Handrails (6, 7) inward whilst you tighten the two Console Bolts. 5. CAUTION: You must be able to safely lift 20 kg (45 lbs.) in order to do this step.
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPOR- TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 8 DIAGRAM OF THE CONSOLE Monitor Display Water Bottle Holder Speed Control (Water bottle is not included) Note: If there is a thin sheet of clear Clip plastic on the console, remove it. STEP - BY - STEP CONSOLE OPERATION CAUTION: Before operating the Step onto the foot pads on the treadmill.
Page 9 Reset the console and start the walking belt. When you are finished exercising, stop the walking belt and remove the key. Turn the speed control to the RESET Step onto the foot pads, stop the walking belt, and position. Note: Each remove the key from the console.
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) in order to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right.
Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, slide the latch pin to the right. Lock the pin in place by pressing the end of the pin into the slot in the storage latch as shown in the inset drawing.
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- 5–7 cm mance may decrease and the walking belt may be- come damaged.
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be “aerobic.” Aerobic exercise physician. This is especially important for in- is activity that requires large amounts of oxygen for dividuals over the age of 35 or individuals prolonged periods of time.
Page 15 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
Page 16 • the KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and the EXPLODED DRAWING in the centre of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. Part No. 182611 R0302A Printed in USA © 2002 ICON Health & Fitness, Inc.
Page 17: Ordering Replacement Parts
REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL. Save this page for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
Page 18 PART LIST—Model No. WETL21020 R0402A Key No. Qty. Description Key No. Qty. Description Console Reed Switch Clip Speed Control Magnet Key/Clip Belt Console Plate Roller Adj. Bolt Screw Platform Screw Right Handrail Front Roller/Pulley Left Handrail Foot Pad (Right) Battery Cover Frame Console Bolt/Motor Tension Bolt Walking Belt...
Page 19 EXPLODED DRAWING—Model No. WETL21020 R0402A...
