Class H Fitness Product
Model No. WETL1614.2
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.iconeurope.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo Cadence 65
Summary of Contents for Weslo Cadence 65
- Page 1 Class H Fitness Product USER’S MANUAL Model No. WETL1614.2 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...
-
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no... - Page 4 22. The pulse sensor is not a medical device. scribed in this manual. Never remove the Various factors, including your movement, motor hood unless instructed to do so by an may affect the accuracy of heart rate readings. authorised service representative. Servicing The sensor is intended only as an exercise aid other than the procedures in this manual in determining heart rate trends in general.
-
Page 5: Before You Begin
And when is WETL1614.2. The serial number can be found on a you’re not exercising, the unique CADENCE 65 tread- decal attached to the treadmill (see the front cover of mill can be folded up, requiring less than half the floor this manual for the location of the decal). -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Place a mat under the treadmill to protect the floor during assembly. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until as- sembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 2. Identify the Right Upright (37), which has a large round hole near the lower end, and the Left Upright (32). See drawing 2a. Make sure that there are two U-nuts Hole (93) in the lower end of each Upright (32, 37). 32, 37 See drawing 2b.
- Page 8 5. Identify the Right Handrail (5), which has a large hole in the left side. Feed the Wire Harness (53) into the hole in the bottom of the Right Handrail and out of the large hole in the side. Note: It may be helpful to use needlenose pli- ers to pull the Wire Harness out of the hole.
- Page 9 7. Place the Console Base (45) on the Right Handrail (5) and the Left Handrail (not shown). Attach the Console Base with four 3/4” Screws (77) (only two Screws are shown). Do not tighten the Screws yet. Insert the Wire Harness (53) through the two indicated plastic ties on the Console Base (45).
- Page 10 10. Set the Console (2) on the Console Base (45). Insert the excess Wire Harness (53) into the large hole in the side of Ties the Right Handrail (5). Securely tighten the plastic ties on the bottom of the Console Base to prevent the Wire Harness from slipping.
-
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear. - Page 12 CONSOLE DIAGRAM Displays Note: If there is a thin sheet of Pulse Sensor plastic on the console, remove it. Clip Insert the key fully into the console. After a moment, CAUTION: the displays will light. Test the clip by carefully tak- Before operating the ing a few steps backward until the key is pulled console, read the following precautions.
- Page 13 To stop the walking belt, press the Stop button. Note: The console can The elapsed time will begin to flash in the Time display speed and dis- display. tance in either miles or kilometres. To change the Note: During the first few minutes that the tread- system of measurement, mill is used, inspect the alignment of the walking hold down the Stop but-...
- Page 14 HOW TO CHANGE THE INCLINE OF THE TREADMILL CAUTION: Before using the treadmill, make sure that both incline pins are fully inserted at the same height. Do not use the treadmill with the incline To vary the intensity of your exercise, the incline of the pins removed.
-
Page 15: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right. - Page 16 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
-
Page 17: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a. - Page 18 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
-
Page 19: Conditioning Guidelines
CONDITIONING GUIDELINES Fat Burning WARNING: Before beginning To burn fat effectively, you must exercise at a relatively this or any exercise program, consult your low intensity level for a sustained period of time. physician. This is especially important for in- During the first few minutes of exercise, your body dividuals over the age of 35 or individuals uses easily accessible carbohydrate calories for en-... - Page 20 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
-
Page 21: Part List
PART LIST—Model No. WETL1614.2 R0705A Qty. Description Base 3/4” Tek Screw Hood Belly Pan Console Upright Spacer Motor Belt Motor Tension Washer Left Handrail Left Foot Rail Right Handrail Wheel Nut/Motor Nut Motor Isolator Belt Guide Motor Wire Clip Reed Switch Right Foot Rail Electronics Screw Crossbar... -
Page 22: Exploded Drawing
EXPLODED DRAWING—Model No. WETL1614.2 R0705A... - Page 23 EXPLODED DRAWING—Model No. WETL1614.2 R0705A...
-
Page 24: Ordering Replacement Parts
When ordering parts, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL1614.2) • the NAME of the product (WESLO CADENCE 65 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
