DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER
DVD-3930
OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
ISTRUZIONI PER L'USO
INSTRUCCIONES DE FUNCIONAMIENTO
GEBRUIKSAANWIJZING
BRUKSANVISNING

Advertisement

Table of Contents
loading

Related Manuals for Denon DVD-3930

Summary of Contents for Denon DVD-3930

  • Page 1 DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER DVD-3930 OPERATING INSTRUCTIONS BEDIENUNGSANLEITUNG MODE D’EMPLOI ISTRUZIONI PER L’USO INSTRUCCIONES DE FUNCIONAMIENTO GEBRUIKSAANWIJZING BRUKSANVISNING...
  • Page 2 ENGLISH DEUTSCH FRANCAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA ¢ NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / CAUTION NOTE SULL’USO / NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 3 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANCAIS DEUTSCH ENGLISH A NOTE ABOUT RECYCLING: CAUTION: This product’s packaging materials are recyclable and can be reused. Please dispose of any To completely disconnect this product from the mains, disconnect the plug from the wall socket outlet. materials in accordance with the local recycling regulations.

  • Page 4: Table Of Contents

    Making the settings for the picture output from the HDMI terminal Thank you for purchasing this DENON DVD Audio-Video / Super Audio CD player. Please read the operation instructions thoroughly in order to Changing the signal format ··························································29 acquaint yourself with the DVD Audio-Video / Super Audio CD player and achieve maximum satisfaction from it.
  • Page 5 Marking scenes you want to see again later·····························46 Adding marks ···············································································46 Calling out marked scenes···························································46 Zoomed play ·················································································47 Setting the video format ·····························································47 Adjusting the brightness of the display·····································47 Others About the DENON LINK function················································48 Advanced AL24 Processing··························································48 Copyright protection technology················································48 Resetting························································································48 Registered trademarks·································································48 Troubleshooting············································································49 Specifications ················································································50...

  • Page 6: Accessories

    Discs usable on this set operation button to the standby position before connecting and unit: disconnecting connection cables. The discs playable on the DVD-3930 are the discs shown on the table Operating instructions .............1 • Sufficiently ventilate the place of installation. at the right.

  • Page 7: Holding Discs

    ENGLISH Getting Started Getting Started *1 : Some DVD-Audio discs, DVD-Video discs and video CDs may be Playable discs Mark (logo) Signal content Disc size Loading discs designed to by the software producer to operate in ways other DVD-Audio than described in this manual. •...

  • Page 8: Cautions On Handling

    ENGLISH Getting Started Getting Started Cautions on handling About the remote control unit Operating range of the remote control unit • Do not get fingerprints, oil or dirt on discs. • Point the remote control unit at the remote sensor when operating Inserting the batteries •...

  • Page 9: Part Names And Functions

    ¢ £ OFF).....(15, 34) These indicate the type of the currently playing STOP button ( )........(34) LFE : Subwoofer DENON LINK indicator ......(48) disc. PLAY button ( )........(34) SL : Surround left Advanced AL24 indicator ......(48) STILL/PAUSE button ........(35) : Surround monaural...

  • Page 10: Rear Panel

    AV-1 output terminal ........(9) RANDOM button........(39) VIDEO OUT terminal........(9) HDMI OUT terminal ........(11) MARKER button ........(46) S-VIDEO OUT terminal .......(9) DENON LINK output terminal ....(11) SETUP button..........(15) COMPONENT VIDEO OUT terminals ..(9) DIGITAL OUT COAXIAL/ PICTURE ADJUST button......(32) OPTICAL terminals........(9, 12) ROOM TO ROOM IN/OUT jacks OPEN/CLOSE button ........(34)

  • Page 11: Connections

    Signal direction DENON LINK connections Audio signal Component video cable DENON LINK cable (Included) Video signal NOTE: • Do not plug in the power supply cord until all connections have been completed. • When making connections, also refer to the operating instructions of the other components.

  • Page 12: Connection To A Tv

    NOTE: ¢ For a TV equipped with component video input terminals • Connect the DVD-3930’s video output either directly to the TV or indirectly via an AV amplifier. Do not connect it via a VCR (video cassette recorder). Some discs include copy prohibit signals. If such discs are played via a VCR, the copy guard system Monitor may disturb the picture.

  • Page 13: Connection To A Device With 2-Channels Of Analog Audio Inputs

    ENGLISH Connections Connections ¢ Audio signals output from the DVD-3930’s digital audio output terminals Connection to a device with 2-channels of analog audio inputs Bitstream output With “DIGITAL OUTPUT” as initial setting Disc type Audio recording format Stereo component NORMAL...

  • Page 14: Denon Link Connections

    • Digital transfer is possible up to 24 bit/2ch for 192/176.4 kHz, 24 bit/6ch for 96 kHz or less. HDMI audio • When making DENON LINK connections, be sure to check the version of the AV amplifier to be Disc type...

  • Page 15: Digital Connection To A Recording Device (Md Recorder, Etc.)

    • The audio signals from the HDMI terminal (sampling frequency, bit length, etc.) may be restricted by the connected device. • Set the DVD-3930’s resolution according to the resolutions with which the connected TV or monitor MD recorder are compatible.

  • Page 16: Making The Initial Settings

    WIDE (16:9)* TV TYPE Set this according to the video format of the connected TV. NTSC MULTI* COMPONENT Use this procedure to set the DVD-3930’s component video output PROGRESSIVE* INTERLACED VIDEO OUT format. AUDIO / VIDEO Set the video output to synchronize the audio signal.
  • Page 17 ENGLISH Making the initial settings Making the initial settings Audio settings Description Item you want to set (* indicates the setting upon purchase) Page Set the audio output. MULTI CHANNEL* 2CH (VSS OFF) 2CH (VSS1 ON) 2CH (VSS2 ON) The properties and components of the FRONT SP CENTER SP SUBWOOFER...

  • Page 18: Operations For Making The Initial Settings

    Before starting playback, make the initial settings according to your usage conditions. Icon Check that all the connections are proper. Turn on the TV’s power and switch its video input so that the DVD-3930’s image can be seen. <POWER> < POWER > Press Item you want to change ¢...

  • Page 19: Language Setting

    ENGLISH Making the initial settings Making the initial settings ¢ Language code list Language setting ( Code Language Code Language Code Language Code Language [F F G G ] to select “ ”. 4747 Afar 5271 Frisian 5868 Latvian; Lettish 6558 Slovenian 4748...

  • Page 20: Digital Interface Settings

    ENGLISH Making the initial settings Making the initial settings Setting the HDMI audio Setting the HDMI speaker settings Digital interface settings ( Use this procedure to set the audio signals output from the HDMI At “HDMI AUDIO SETUP”, select “MULTI (LPCM)”. The “HDMI SPEAKER [F F G G ] to select “...
  • Page 21 ENGLISH Making the initial settings Making the initial settings ¢ Channel level Set the volume of the different speakers so that the test tones output from them sound to have the same volume. [D D H H ] At the HDMI speaker setting screen, use [ENTER] select “CHANNEL LEVEL”, then press [D D H H ]...

  • Page 22: Setting The Hdmi Auto Format

    HDMI output resolution is selected automatically. • The DENON LINK setting with respect to the DENON LINK version of the connected AV amplifier is as shown below. AV amplifier’s DENON LINK version DENON LINK setting 2nd Edition “2nd”...

  • Page 23: Video Setting

    Setting the TV type Setting the component video output Video setting ( Set this according to the video format of the connected TV. Use this procedure to set the DVD-3930’s component video output [F F G G ] to select “ ”.

  • Page 24: Setting The Av Synchronized

    ENGLISH Making the initial settings Making the initial settings Setting the AV Synchronized Setting the squeeze mode Setting the progressive mode Set the video output to synchronize the audio signal. Use this procedure to set the output picture when “WIDE (16:9)” is Sets the optimum progressive mode for the image material.

  • Page 25: Setting The Horizontal Display Range

    ENGLISH Making the initial settings Making the initial settings Setting the horizontal display range VIDEO (Upon purchase): 2CH (VSS OFF): Composite video signals will be output from the AV-1 terminal. Select this when using 2 speakers and a Dolby Pro Logic decoder Set the horizontal display range with respect to the interlaced output.

  • Page 26: Setting The Digital Output

    • When playing linear PCM or packed PCM DVDs with copyright protection, due to considerations for the copyright holder, digital output is not possible for sources of 48 kHz/16 bit or more. To play such sources, either set to “ON”, use DENON LINK or analog connections ( page 9, 10).

  • Page 27: Setting The Bass Enhancer

    ENGLISH Making the initial settings Making the initial settings Setting the bass enhancer Setting the dynamic range compression • When set to “50kHz” or “100kHz”, you can enjoy the DTS Sets the subwoofer output for when playing 2-channel or other Use this procedure to set the dynamic range of the output signals recommended full range all-channel sound.

  • Page 28: Viewing Restriction Setting

    ENGLISH Making the initial settings Making the initial settings Setting the password Viewing restriction setting ( Use this procedure to change the password for the “RATING LEVEL”. [F F G G ] to select “ ”. [D D H H ] [G G ] to select “PASSWORD”, use to select...

  • Page 29: Setting The Displaying The Registration Code

    ENGLISH Making the initial settings Making the initial settings Setting the displaying the registration code Special settings ( Use this procedure to display the registration code for leasing or [F F G G ] to select “ ”. ® ® purchasing DivX VOD format video files using the DivX VOD (Video...

  • Page 30: Setting The Screensaver

    ENGLISH Making the initial settings Making the initial settings Setting the screensaver Setting the display The screensaver functions protects the TV screen from imprinting. If the display is turned off with the pure direct or dimmer function, a description of operations can be displayed for about 2 seconds. [D D H H ] to select “SCREEN SAVER”, then press [D D H H ]...

  • Page 31: Other Settings

    • ON (Upon purchase), OFF: Select whether or not to output video signals. DISPLAY: • ON (Upon purchase), OFF: Select whether or not to light the DVD-3930’s display. About the button names in this explanation < > : Buttons on the main unit...

  • Page 32: Making The Settings For The Picture Output

    ENGLISH Other settings Other settings NOTE: • The normal display reappears if no operation is performed for 3 • The “HDMI MODE VIDEO” indicator on the front panel lights when seconds while making the selection using < VIDEO MODE > . “YCbCr”...

  • Page 33: Performing Keystone Correction

    ENGLISH Other settings Other settings ¢ When the signal format is set to “PC RES.”: Performing keystone correction Performing keystone correction in the vertical direction Keystone distortion occurs when the connected projector or screen is When operating from the remote control unit: at an angle.

  • Page 34: Audio Synchronization Adjustment Procedure

    ENGLISH Other settings Other settings Audio synchronization adjustment procedure Use this procedure to set so that the video signal output method’s video signal set at “AV Sync” ( page 21) under “Making the initial settings” and the audio signal are synchronized. <...
  • Page 35 ENGLISH Other settings Other settings ¢ Picture quality adjustment setting memory list Item Description STANDARD Upon purchase (initial value) MEMORY1 MEMORY2 Picture quality settings can be stored MEMORY3 at “Adjust 1” to “Adjust 4”. MEMORY4 MEMORY5 ¢ List of picture quality adjustment modes Adjustment range Item Description...

  • Page 36: Gamma Correction

    Horizontal axis: Brightness level of pictures recorded on disc Make these adjustments using numerical tables or graphs. Vertical axis: Brightness level of pictures upon output from the DVD-3930 To adjust using the numerical tables: [H H ] At “Adjust 4”, press...

  • Page 37: Basic Operation

    ENGLISH Basic Operation Basic Operation Turning the power on Playing discs <ON/STANDBY> < POWER > Press Press • “0h00m00s” is displayed if no disc is loaded. • The “ ” indicator lights and playback starts. The power indicator lights green. ¢...

  • Page 38: To Pause Playback

    ENGLISH Basic Operation Basic Operation To pause playback TOP MENU < STILL/PAUSE > Apple Banana Press Orange • The “ ” indicator lights and the pause mode is set. Orange Strawberry Peach Pineapple ¢ To resume playback: Press Example: When “Orange” is selected <STILL/PAUSE>...

  • Page 39: Using The Top Menu And Dvd Menu

    ENGLISH Basic Operation Basic Operation Using the top menu and DVD menu Switching the audio language Switching the angle (Multiple-Angle Function) (Multiple-Audio Function) For DVDs containing multiple titles, the desired title can be selected The angle can be switched when playing DVDs containing multiple and played from the top menu.

  • Page 40: Switching Between Groups And Tracks

    ENGLISH Basic Operation Basic Operation Switching between groups and tracks Selecting still pictures For DVD-Audio discs containing still pictures, the desired still picture [SEARCH MODE] In the stop or play mode, press can be selected. select the search mode. • The mode switches each time the button is pressed and is [PAGE +] [PAGE –] Press...

  • Page 41: Setting The Super Audio Cd Playback Area/Layer

    Track 3 Track 4 Track 5 Example: WMA screen ¢ Listening to CD-ROM, CD-R or CD-RW discs containing WMA files The DVD-3930 can play music files stored on CD-ROM/CD–R/CD–RW Playback Control (Video CDs): ® discs in WMA (Windows Media Audio) format.
  • Page 42 ¢ Playing in repeat order: frequencies (fs) of 32, 44.1 or 48 kHz. Press [REPEAT]. • The DVD-3930 is compatible with MP3 files with bit rates of 32 to 320 kbps, WMA files with bit rates of 64 to 160 kbps. FILE REPEAT FOLDER REPEAT •...

  • Page 43: About Discs Containing Divx ® Format Files

    Remaining time per track (SINGLE ELAPSED) (SINGLE REMAIN) • The DVD-3930 can play [discs containing] up to 255 folders and 1000 files. • Note that depending on the software used for burning and other conditions, some files may not play or display correctly.

  • Page 44: Playing Picture Cds And Fujicolor Cds

    Playing Picture CDs and Fujicolor CDs In the pause mode, press [ZOOM]. (“ZOOM” is displayed on the TV The DVD-3930 can play Kodak Picture CDs and Fujifilm Fujicolor CDs, screen.) so you can view the photographs recorded on them on your TV.

  • Page 45: Repeat And Random Play Of Mp3, Wma, Jpeg And Divx ® Files

    ENGLISH Basic Operation Repeat and random play of MP3, WMA, JPEG Convenient operations and DivX ® files Fast-forwarding/Fast-reversing FILE REPEAT: The selected file is played repeatedly. During playback, press FOLDER REPEAT: • The fast-forward/fast-backward speed increases each time one of Playback starts from the selected file, and all the files in that folder these buttons is pressed.

  • Page 46: Frame-By-Frame Playback (For Dvd-Video Discs And Video Cds Only)

    ENGLISH Convenient operations Convenient operations Frame-by-frame playback For DVD-Video discs: (for DVD-Video discs and Video CDs only) Indication on Normal playback display In the pause mode, press • The picture advances one frame each time the button is pressed. Chapter played repeatedly ¢...

  • Page 47: Repeating A Section Between Two Specific Points (A-B Repeat Playback)

    • The repeat play and A-B repeat functions may not work for discs on • The last track set in the program is deleted each time the button is which the elapsed playing time is not indicated on the DVD-3930’s pressed.

  • Page 48: Operating Using The On-Screen Display

    Button name only : discs on which the elapsed playing time is not indicated on the Buttons on the main unit and remote control unit DVD-3930’s display during playback. For DVD-Audio discs: [D D H H F F G G ] to select the item you want to change.

  • Page 49: Marking Scenes You Want To See Again Later

    ENGLISH Convenient operations Convenient operations ¢ Specifying the elapsed time Marking scenes you want to see again later Calling out marked scenes Scenes you want to see again later can be marked so you can play [F F G G ] [NUMBER] 0 ~ 9, +10 ) to input the time, then press...

  • Page 50: Zoomed Play

    [D D H H F F G G ] Press • The zoomed picture moves. Adjusting the brightness of the display Use this procedure to adjust the brightness of the DVD-3930’s display. NTSC/PAL The brightness can be switched in 3 steps. The display can also be turned off.

  • Page 51: Others

    About the DENON LINK function Copyright protection technology Registered trademarks DENON LINK is a balanced transfer type digital link using high speed This product incorporates copyright protection technology that is The DVD-3930 is manufactured using the technologies listed below transfer elements. Connecting the DENON LINK terminal to a DENON protected by U.S.

  • Page 52: Troubleshooting

    23, 24 Picture does not appear with • Check the HDMI connections. (Check the lighting conditions of HDMI- 11, 12 • Digital signals are not output for Super Audio CDs. Use analog or DENON 10, 11 HDMI connections. related indicators.) LINK 3rd connections.

  • Page 53: Specifications

    (3) Harmonic distortion : 0.0008 % (4) Dynamic range : 110 dB Digital audio output: Output terminal: Optical, 1 set / Coaxial, 1 set / DENON LINK, 1 set ¢ General Power supply: AC 230 V, 50 Hz Power consumption: 70 W (In the standby mode : Approx.
  • Page 54 TOKYO, JAPAN www.denon.com Denon Brand Company, D&M Holdings Inc. Printed in China 00D 511 4531 004...
