Short Parts List - Alpha CD24C Installation And Servicing Instructions

11 SHORT PARTS LIST

Reference
Description
Fig. 27
Burner - CD24
Fig. 27
Burner - CD32
Fig. 2, item 30
Main injector 5.0 mm - CD24
Fig. 2, item 30
Main injector 6.6 mm - CD32
Fig. 32
Primary heat exchanger - CD24
Fig. 32
Primary heat exchanger - CD32
Fig. 34
DHW heat exchanger - CD24C
Fig. 34
DHW heat exchanger - CD32C
Fig. 24
Gas valve - Honeywell VK4115V
Fig. 33
Pump
Fig. 28
Fan assembly - CD24
Fig. 28
Fan assembly - CD32
Fig. 33
Primary pressure switch
Fig. 2, item 1
DHW flow regulator - CD24C
Fig. 2, item 1
DHW flow regulator - CD32C
Fig. 31
DHW flow switch
Fig. 30
PCB
Fig. 28
Flue thermostat 100°C
Fig. 28
Ignition generator
Fig. 28
Transformer
Figs. 34 and 28
Temperature sensor
Fig. 20
Fuse F2A
Fig. 30
PCB fuse F315mA
Fig. 28
Overheat thermostat 100°C
Fig. 2, item 14
Expansion vessel 8 Litre
Fig. 33
Pressure relief valve 3 bar
Fig. 33
Automatic air vent
Fig. 33
Pressure gauge
Fig. 28
Ignition electrode and lead
Fig. 28
Ignition electrode
Fig. 28
Flame sensing electrode and lead - CD24
Fig. 28
Flame sensing electrode and lead - CD32
Fig. 31 and 35
Diverter valve assembly
Fig. 2, item 27
By-pass assembly
Fig. 27
Combustion chamber insulation panel front
Fig. 2, item 29
Condensate trap
Qty. Alpha Pt. No.
1 1.013172
1 1.018956
1 1.011848
1 1.019247
1 1.018030
1 1.018593
1 1.015957
1 1.018597
1 1.011846
1 1.015610
1 1.010659
1 1.021206
1 1.018320
1 1.011128
1 1.019465
1 3.013211
1 1.017788
1 1.012067
1 1.018162
1 1.012477
2 1.021762
1 1.6098
1 1.013931
1 1.012067
1 1.015394
1 1.011126
1 1.010771
1 1.016151
1 3.013626
1 1.016779
1 1.018163
1 1.019293
1 3.012752
1 3.012801
1 1.014732
1 1.018192
Alpha CD24C/32C - Short Parts List
British Gas GC No.
E94-407
E96-565
E94-409
E96-566
E94-408
E96-567
E57-739
E96-568
E94-410
E57-666
E94-411
E96-569
E76-320
E65-154
E96-570
E57-751
E94-412
E94-413
E94-414
E94-415
E76-317
E76-378
E96-571
E94-416
E57-702
E57-703
E57-709
E57-710
E94-417
E94-418
E94-419
E96-572
E57-773
E65-498
E94-420
37
