Page 1: Portable Dvd Player
GDVD67LCD Portable DVD Player User Manual Goodmans Product Information Helpline: 0870 873 0080 82-154-00230... -
Page 2: Table Of Contents
Table of Contents Remote Control Location of buttons................ 4 Front View Location of controls................5 Side View Location of controls................6 Chapter 1. DVD 1-1 DVD Playback....................8 Basic Playback........................... 8 Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The DVD).........8 Stopping Playback........................9 Rapid Advance (Rapid Reverse)......................9 Skipping Ahead or Back to Previous Chapters............ - Page 3 Table of Contents -continued Chapter 4. Setup 4-1 Language Setup..................22 On Screen Display (OSD) Language Setting..................22 DVD MENU Language Setting......................23 AUDIO Soundtrack Language Selection [DVD]..................24 SUBTITLE Language Selection [DVD]....................25 4-2 Screen Setup....................26 TV Type Setting.........................26 Screen Saver Setting........................
-
Page 4: Remote Control Location Of Buttons
Remote Control Location of buttons SETUP button INFO. button PAUSE/UP button MENU button F.BWD/LEFT button PLAY/SEL. button PREVIOUS button STOP/DOWN button NUMERICAL buttons SUBTITLE button LCD button ANGLE button TITLE button AUDIO button F.FWD/RIGHT button NEXT button A-B REPEAT button REPEAT(1-ALL) button MUTE button... -
Page 5: Front View Location Of Controls
Front View Location of controls 10 9 1314 LCD screen LCD button SETUP button INFO. button MENU button PAUSE/UP button F.FWD/RIGHT button PLAY/SEL. button STOP/DOWN button NEXT button PREVIOUS button SPEAKERS F.BWD/LEFT button OPEN button... -
Page 6: Side View Location Of Controls
Side View Location of controls LEFT SIDE DC IN Socket POWER button FRONT SIDE Remote Sensor POWER indicator... - Page 7 Side View Location of controls -continued RIGHT SIDE Volume control Phones 1 socket Phones 2 socket Coaxial output socket (Digital Audio) AV out/AV in switch Audio output/input socket Video output/input socket...
-
Page 8: Chapter 1. Dvd
DVD Playback Preparation Please connect the portable DVD player to Power (using the supplied battery or the mains adapter) and connect the earphones/headphones or connect it to external equipment. If connecting the player to external equipment: Turn on the TV set, and select “Video” or “Aux” as the TV’s source. Turn on the stereo system if the player has been connected to a stereo system. -
Page 9: Stopping Playback
DVD Playback -continued Stopping Playback Press <STOP> once to stop the disc at its present position (PRESTOP). When the play button is pressed). The disc will start from the playback position. Press <STOP> twice to stop the disc when the play button is pressed, playback will resume from the beginning. -
Page 10: Repeat Viewing
DVD Playback -continued Repeat Viewing Press <1/ALL REPEAT> during playback. Press once: CHAPTER (The current chapter will be repeated.) Press twice: TITLE (The current title will be repeated.) Press three times: DISC (The whole disc will be repeated.) Press four times: off (Repeat cancelled) To return to normal playback <1/ALL REPEAT>... -
Page 11: Convenient Functions
Convenient functions Scene Information Press <INFO.> during playback. <INFO.> button repeatedly and the title number, chapter number, and other information will be shown Press on the screen. Stop Displaying the Scene Information Press <INFO.> repeatedly until the information disappears. Changing Audio Soundtrack Language The audio language can be changed from the one selected at the initial settings to a different language, if available. -
Page 12: Viewing From Another Angle
Convenient functions -continued Viewing From Another Angle Some DVD discs contain scenes which have been filmed simultaneously from a number of different angles. These <ANGLE> button. (The recorded angles scenes can be viewed from each of these different angles using the vary depending on the disc.) Press <ANGLE>... -
Page 13: To Mute The Dvd Player
Convenient functions -continued To Mute the DVD Player Press <MUTE> button during playback. “MUTE” will be shown on the screen, and the audio output will be muted. To unmute the sound, press the mute button and “MUTE OFF” will be shown on the screen. DVD Menu Some DVD discs have unique menu structures called DVD menus. -
Page 14: Chapter 2. Audio Cd
Audio CD Playback Preparation Please connect the portable DVD player to Power and connect the earphones/headphones or connect it to external equipment. If connecting to external equipment: Press on the power button of the TV set, and select “Video” or “Aux” as the TV input. Press on the power button of the stereo system if the player has been connected to a stereo system. -
Page 15: Skip To Previous Or Subsequent Tracks
Audio CD Playback -continued Skip to Previous or Subsequent Tracks Skip Ahead Press <NEXT> during playback. The next track will be played. Press the button repeatedly to select subsequent tracks. Skip Back Press <PREVIOUS> during playback. The previous track will be played. Press the button repeatedly to select eariler tracks. Pause Playback Press <PAUSE>... -
Page 16: Playing Kodak Picture Cds
Playing Kodak Picture CDs Basic Playback Insert a kodak picture CD into the player. After few seconds, the portable DVD player will start to playback the pictures in slide show automatically. Enter the number of the picture to be shown using the numerical keys, then press <PLAY/SEL.>... -
Page 17: During Slide Show
Playing Kodak Picture CDs -continued During a Slide Show Press <NEXT> to view the next picture or <PREVIOUS> to view the previous picture. Press <RIGHT> button or <LEFT> button to rotate the picture. <RIGHT> button to rotate right by 90 degree. Press <LEFT>... -
Page 18: Playing Jpeg Picture Cds
Playing JPEG picture CDs Basic Playback JPEG pictures on a CD can be played back as a slide show. Load a JPEG picture CD. After few seconds, the portable DVD player will start to playback the pictures as a slide show automatically. Enter the number of the picture to be shown using the numerical keys, then press <PLAY/SEL.>. -
Page 19: File Manager
Playing JPEG picture CDs -continued File Manager Press < > to choose the required picture, then press <PLAY/SEL.> to show the picture. Press <NEXT> to skip seven pictures or <PREVIOUS> jump back seven pictures. Playback Press <NEXT> to view the next picture or <PREVIOUS>... -
Page 20: Playing Mp3 Music Discs
Playing MP3 Music Discs Basic Playback Turn the DVD player on using the power ON/OFF switch. Press <OPEN> to open the DVD door. Hold the edge of a MP3 disc and push the disc gently until it clicks into place with the printed side up. -
Page 21: Playing A Cd Containing Jpeg Pictures And Mp3 Music
Playing a CD containing JPEG pictures and MP3 music Basic Playback Load a disc containing JPEG pictures and MP3 music. After few seconds, the File Manager will be displayed and the portable DVD player starts to play back the files in order automatically. To pause playback Press <PAUSE>. -
Page 22: Language Setup
Language Setup On Screen Display (OSD) Language Setting Allows the default languages for the on screen display (OSD) to be set. (Default: English) Press <SETUP> when the disc is stopped. Press <UP> button / <DOWN> button to select “Language Setup”, and then press <PLAY/SEL.>. -
Page 23: Dvd Menu Language Setting
Language Setup -continued DVD Menu Language Setting Set the default language for the menu on the DVD. (Default: English) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Language Setup”, and then press <PLAY/SEL.>. Press <UP>... -
Page 24: Audio Soundtrack Language Selection [Dvd]
Language Setup -continued AUDIO Soundtrack Language Selection [DVD] Set the preferred audio language for playback. (Default: English) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Language Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN>... -
Page 25: Subtitle Language Selection [Dvd]
Language Setup -continued SUBTITLE Language Selection [DVD] Set the preferred language for the subtitles. (Default: Off) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Language Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN>... -
Page 26: Screen Setup
Screen Setup TV Type Setting Set the TV picture type that should be displayed on the LCD screen or the connected TV. (Default: 16:9) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Screen Setup”, and then press <PLAY/SEL.>. -
Page 27: Screen Saver Setting
Screen Setup -continued Screen Saver Setting Set the screen saver to come on when a disc is stopped and no button is pressed after 10 minutes. (Default : On) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Screen Setup”, and then press <PLAY/SEL.>. -
Page 28: Tv System Setting
Screen Setup -continued TV System Setting The player provides “PAL”, “NTSC” and “AUTO” settings for your selection. When connecting the portable DVD player to your TV, set the “TV SYSTEM” from the on-screen display to the format that is compatible with your TV’s system. -
Page 29: Audio Setup
Audio Setup Digital Out Setting Set the digital output depending on the amplifier connected. (Default: SPDIF/RAW) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Audio Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN>... -
Page 30: Analog Out Setting
Audio Setup -continued Analog Out Setting (Default: 2 Channel) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Audio Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN> button to select “Analog Out”, and then press <PLAY/SEL.>. -
Page 31: Custom Setup
Custom Setup Parental Control Setting [DVD] A built-in viewer rating setting enables you to lock the videos that you do not want children to view. For example, if you set it to PG-13, then the portable DVD player will not play the videos rated R, NC-17 or X unless the correct password is entered. -
Page 32: Password Setting [Dvd]
Custom Setup -continued Password Setting [DVD] You can change the password that protects the parental settings. (Default: 0000) Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Custom Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN>... -
Page 33: Angle Mark Setting [Dvd]
Custom Setup -continued Angle Mark Setting [DVD] You can choose to display or hide the angle mark “ ” on the screen which will appear if there are multiple angle shot for the current scene. Press <SETUP> in the stop mode. Press <UP>... -
Page 34: Default Setting
Custom Setup -continued Default Setting Returns settings to factory set defaults. Press <SETUP> in the stop mode. Press <UP> button / <DOWN> button to select “Custom Setup”, and then press <PLAY/SEL.>. Press <UP> button / <DOWN> button to select “Default”, and then press <PLAY/SEL.>. -
Page 35: Lcd Setup
LCD Setup Panel Setting The portable DVD player provides three options about the panel adjustment: “Normal”, “16:9” or “4:3”. Press <LCD> repeatedly until “Panel” is shown. Press <LEFT> button or <RIGHT> button to choose the preferred panel setting. P P P P P anel: anel: anel: anel:... -
Page 36: Bright Setting
LCD Setup -continued Bright Setting Increase or decrease the brightness. Press <LCD> repeatedly until “Bright” is shown. Press <LEFT> button or <RIGHT> button to choose the preferred bright setting. Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright: Bright:... -
Page 37: Important Safety Information
As the laser beam used in the DVD Player is harmful to eyes, and to avoid electrical hazards, do not attempt to disassemble the housing. Refer servicing to qualified personnel. Cleaning Unplug the unit and turn power off before cleaning this unit. Goodmans Product Information Helpline: 0870 873 0080... - Page 38 Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. Goodmans Product Information Helpline: 0870 873 0080...
-
Page 39: Disc Use And Care
Use of the in car power lead This lead is specially designed for the unit. DO NOT use it for other in car products as this may result in damage to lead or the other equipment. Goodmans Product Information Helpline: 0870 873 0080... -
Page 40: Precautions
Precautions Please read these precautions before operating this player. Power cord protection To avoid any malfunctioning of the player, and to protect against electric shock, fire or personal injury, please observe the following. Hold the plug firmly when connecting or disconnecting the AC power cord. Keep the AC power cord away from heating appliances. -
Page 41: Troubleshooting
Troubleshooting Before requesting service for the portable DVD player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation. SYMPTOM (COMMON) REMEDY No power. -
Page 42: Disc Handling And Maintenance
Disc Handling and Maintenance Handling Precautions Hold the disc by the edges so the surface will not be soiled with fingerprints. (A) Fingerprints, dirt and scratches can cause skipping and distortion. Do not write on the label side with a ball-point pen or other writing utensils. Do not use record cleaning sprays, benzene, thinner, static electricity prevention liquids or any other solvent. -
Page 43: Specifications
Specifications DVD VIDEO PLAYER/OUTPUTS/SUPPLIED ACCESSORIES DVD VIDEO PLAYER Power supply ~120v 60Hz Power consumption Weight 850 g External dimensions 212 x 158 x 29.8 mm (W/H/D) Signal system Laser semiconductor laser, wavelength 650 nm OUTPUTS Video output 1.0 V (p-p), 75 ohms, negative sync Audio output (digital audio) 0.5 V (p-p), 75ohms Audio output (analog audio)
