Allied Telesis AT-GS950/24 Datasheet

Datasheet | Switches
AT -GS950/24
24 port Gigabit WebSmart Switch
AT -GS950/24-xx
24 port 10/100/1000T WebSmart switch
with 2 SFP combo ports
Performance
Allied Telesis' WebSmart switch integrates the
simplicity of unmanaged switches with the
performance and reliability of managed switches
to provide a cost-effective solution for users
to integrate management at the edge of their
network.This WebSmart switch provides a
network manager some key features using
the simple web-based management function
such as; port-based VLANs, IEEE 802.1p QoS,
port trunking/link aggregation, port mirroring,
priority queues and IEEE 802.1x security
support. With support of up to 8K MAC
addresses and a 2MB packet buffer the
AT-GS950/24 WebSmart switch is an ideal
option for integrating management into your
network solution.
Value
Never thought you could afford managed
switches in your network? Always wanted to
provide management functionality at the edge?
Now's your chance. Allied Telesis' WebSmart
switch truely helps network managers get the
most value for their dollar. With industry
standard protocols, fiber media support via
the SFP's and simple Plug & Play usability
right out of the box how can you go wrong
implementing this cost-effective solution into
your network?
Quality and Reliability
Allied Telesis is a worldwide leader in
unmanaged Ethernet switches. Shipping more
than 250,000 unmanaged switches each year,
Allied Telesis offers proven reliability and
industry recognized quality.
Allied Telesis
Key Features
VLAN
• VLAN ID's available: 4K
• Max VLANs: 200 tagged + 56 port-based
Quality of Service Classification
• IEEE 802.1p tagging
• Port-based priority
• Four priority queues per port
IP Multicast Support (IPv4)
• IGMP snooping (v1/v2)
• Static multicast group
• Spanning-Tree, IEEE 802.1d/w
IEEE 802.3ad Link Aggregation
• Manual
IEEE 802.1x Port-based and MAC-based
Network Access Control
• Local authentication server (MD5 only)
• Remote authentication through RADIUS
• Dynamic VLAN assignment
• RADIUS client for IEEE 802.1x
• DHCP client
• Statistics charts in Web
Others
• IEEE 802.3x flow control or *HOL blocking
Prevention (*when flow control is off)
• Port mirroring
• Destination MAC filtering
• Ingress/egress rate limiting
• Broadcast storming control
• 100FX SFP support
• Switch fabric - non-blocking, full wirespeed
Management Features
• Firmware upgrade by FTP and Web
• Configuration back-up/restore by FTP
• Factory reset
• Password access control and restricted IP
access list
• SNMPv1/v2c
MIBs
• RFC 1213 MIB-II
• RFC 1643 Ethernet MIB
• RFC 1493 Bridge MIB
• Private Enterprise MIB (Allied Telesis provides
the spec)
RMON Groups (1, 2, 3, 9)
• Stats
• History
• Alarms
• Events
www.alliedtelesis.com
