4
INSTALLATION
4.1
INSTALL THE BOILER
Mount the boiler on the wall and connect the pipework as described in the Installation and Servicing instructions supplied with
the boiler.
4.2
CONVERT THE BOILER (see Fig. 5)
Modify the top of the boiler to enable a 2-pipe flue system to be connected using conversion kit 6.1000368 as follows:-
1.
Place the flue duct adaptor in position onto the boiler flue adaptor and secure with the clamp and seal.
2.
Select the required position of the air duct adaptor and remove the three screws securing the cover plate.
3.
Using the same three screws and gasket secure the air duct adaptor in position.
Fig. 5
Fig. 6
Twin Pipe Flue Systems
5
