Alpha C Boiler Installation Instructions

Installation Instructions

1. GENERAL

The Anti-Theft Clamp is designed to permanently fix the boiler to the wall. This prevents the boiler from being stolen
or removed from the wall.
The clamp is fitted to the boiler after it has been hung on the wall, but it is recommended that the hole for the security
bolt is drilled into the wall before the boiler is lifted into position on the wall mounting bracket.

2. INSTALLATION

Note: These instructions must be read in conjunction with
the Installation instructions supplied with the boiler.
a. Remove the wall template from the boiler carton and
tape it to the wall in the required position (ensure it is
level and the right way up). Mark the positions of all
the required fixings, flue etc.
Mark the hole for the security bolt in the position
shown in Fig. 1, (this is not marked on the template).
b. Drill a 12 mm hole to a depth of 65 mm in the position
previously marked for the security bolt fixing hole.
Remove the shear nut from the bolt and position the
bolt in the fixing hole.
Alpha CB/C/SY Boiler
Anti-Theft Clamp
(Kit Part No. 6.1000446)
KIT CONTENTS
Fig. 1
