Sennheiser CEUL 31 Specifications

CEUL 31
This cable is fitted with an Easy
Disconnect (ED) plug at both ends.
This solution is very flexible because
it can be used together with any other
SeCom bottom cable.
CEUL 32
This cable is fitted with an Easy
Disconnect (ED) plug at one end, and
a RJ 9 at the other. The headset can
be connected directly to the phone with
no additional bottom cable required.
CEUL 32 has an 01 wire configuration.
CEUL 31 and CEUL 32
Sennheiser cables for wired call center
& office headsets
The Sennheiser CEUL 31 and CEUL 32 cables are accessories for the following
wired professional headsets from Sennheiser Communications:
• SH series*
• CC series*
The cables make the SH* and CC* wired headsets compliant with the European
Noise at Work Regulations by ensuring that the average incoming audio signal
remains below 85 dB throughout an 8-hour working day. - A true "Comfort calls"
solution.
Benefits and Features
• Low noise exposure during the work day - the average incoming audio signal
remains below 85 dB throughout an 8-hour working day.
• Easy setup – just connect the cable.

Specifications

Product name
Art. No.
EAN No.
UPC No.
General Data
Cable length
Connector
Compatible with
Packaging
Cable weight
Dimension of product packaging
(W x H x D)
Units in distributor master carton
Dimensions of distributor master
carton (W x H x D)
Distributor master carton weight
incl. products
Units in master carton
Dimensions of master carton
(W x H x D)
Master carton weight
incl. products
Warranty
* CEUL 31/32 cables work with wideband headsets too, but please note
that the speaker volume is significantly lower compared to when connected
with narrowband headsets.
CEUL 31 CEUL 32
504186 504187
40 44155 07426 0 40 44155 07427 7
6 15104 22232 8 6 15104 22237 3
37 cm / 14.57 in 70 cm / 27.56 in
ED to ED ED to RJ 9 (CSTD 01)
SH series* SH series*
CC series* CC series*
27.2 g / 0.95 oz 35.4 g / 1.24 oz
200 x 100 x 13.5 mm / 220 x 100 x 13.5 mm /
7.87 x 3.94 x 0.52 in 8.66 x 3.94 x 0.52 in
10 10
210 x 130 x 100 mm / 230 x 130 x 100 mm /
8.27 x 5.12 x 3.94 in 9.06 x 5.12 x 3.94 in
328 g / 11.57 oz 410 g / 14.46 oz
100 100
430 x 320 x 120 mm / 430 x 320 x 120 mm /
16.93 x 12.6 x 4.72 in 16.93 x 12.6 x 4.72 in
4.18 kg / 9.22 lb 5 kg / 11.02 lb
2 years 2 years
