Table of Contents Chapter 1 Introduction.......................1 Overview ..........................2 About This Guide........................3 User’s Guide Organization..................... 3 Definitions of Terms ......................4 Sharpdesk Online Help ......................4 Chapter 2 Installing Sharpdesk ..................5 Installation Procedure......................5 Software Location......................5 User File Location ......................5 Sharpdesk CD Installation....................
Page 4
Chapter 4 Working with Sharpdesk ................17 Introduction .......................... 17 Viewing Images and Documents..................17 Working within a Folder ....................18 Working with Images ...................... 19 Combine ........................19 Split..........................19 Rotate........................... 19 Controlling the Desktop Display..................20 Changing the Thumbnail Size ..................20 Adding/Removing an Application on the Output Zone ..........
Page 5
Setup Required......................... 30 Index Databases ......................30 Ignored Words......................31 Restrictions........................31 Searching ..........................32 To run a search......................... 32 Search Query Syntax ....................... 32 Phrases......................... 33 Wildcards (* and ?)..................... 33 Examining the Results..................... 35 Sorting the Results List....................36 Moving Files........................
Page 6
Chapter 6 Composing with Sharpdesk .................48 Introduction .......................... 48 Starting Composer........................ 50 Menu Bar ......................... 50 Toolbar..........................50 Work Area........................50 Reference Area ........................ 51 Menu Options ........................51 Toolbar Options....................... 52 Working with Composer...................... 53 Loading Pages into Composer ..................53 Adding Pages into Composer ..................
Page 8
Chapter 8 Converting Images to Text................73 Introduction .......................... 73 Setting Convert by OCR Options ..................74 Setting the Output File format..................75 Setting the Original Document Layout................76 Setting Languages in Document ..................76 Selecting a User Dictionary..................... 77 Selecting an existing dictionary.................. 77 Modifying a user dictionary ..................
This User’s Guide describes the standard features of Sharpdesk. Sharpdesk also works with other Sharp products that might add new capabilities to Sharpdesk that are not included in this Guide. The details of these new capabilities are described in the literature that comes with the Sharp product that “links in”...
• documents into your PC using all of the scanning controls and options provided with your TWAIN scanner or Sharp multi-functional peripheral (MFP) with the Network Scanner Tool option. Sharpdesk provides you with both “simple” scanning options as well as “advanced”...
About This Guide This User’s Guide assumes you have a basic understanding of Windows operation and are familiar with Windows terms. This includes how to start your system and navigate within a Windows environment, and perform such basic Windows functions as copying, printing and moving documents.
Definitions of Terms As you work with Sharpdesk, keep in mind how the following terms are used: Images In Sharpdesk, the term Image refers to items that can be loaded into Imaging. Devices A device is a piece of hardware such as a scanner, printer, fax machine, digital camera or copier. Optical Character Recognition (OCR).
Software Location By default, the Sharpdesk software is installed on your default boot drive (usually C:\) in a folder named Sharpdesk (the full path is C:\Program Files\Sharp\Sharpdesk\), unless you specify another drive and/or folder during installation. The installation process also changes some of your system files to allow all the Sharpdesk components to work properly.
Sharpdesk CD Installation To install Sharpdesk from a CD: 1. If any Windows applications are open, close them to ensure that the software installs properly. In particular, anti-virus programs such as “Norton AntiVirus” may report false warnings if they are not disabled prior to installation. 2.
Uninstalling Sharpdesk If you need to uninstall Sharpdesk, you can do so using the following standard Windows procedure for uninstalling software. 1. Click the Windows Start button, then Settings and Control Panel. 2. Double-click Add/Remove Programs. Add/Remove Programs Properties Dialog Box 3.
Chapter 3 Sharpdesk Overview Introduction Sharpdesk is a Windows application that provides integrated organization for all your paper and electronic documents and images. With Sharpdesk, you can: • Scan and view documents • Convert images into text documents • Organize documents and images among Windows folders •...
Starting Sharpdesk You can start Sharpdesk from the Windows Start menu by clicking Start, pointing to Programs, then to Sharpdesk, and finally clicking Sharpdesk. You can also start Sharpdesk from the Windows desktop by double-clicking the Sharpdesk shortcut icon. Menu Bar Toolbar Folder Window...
Work Area The work area displays the contents of a selected folder in a thumbnail view. From the work area, you can select a file to work with, and then view it, convert it to text, or print it. Output Zone The Sharpdesk Output Zone displays icons for various destinations you can send files to.
Navigating in Sharpdesk Working with Sharpdesk is very easy. It is designed to let you find your images and documents quickly using the Folder Window, the Menu Bar, and the Toolbar. Working with the Folder Window By default, the Folder Window appears at the left on the Sharpdesk screen. The Folder Window can be used much like Windows Explorer to locate and display information from Sharpdesk, your hard disk, or any connected network drives.
Page 20
• Sharpdesk Folders — add a folder shortcut to the Sharpdesk Folder window, reorder folders in the Folder Window, or remove folder shortcuts from the Folder Window. • Copy — copy the contents of the selected folder into the Clipboard. •...
The Sharpdesk Menu The Sharpdesk menu provides you with the following options: FILE MENU DESCRIPTION New Folder Create a new folder at the current location. Open… Open the currently selected file or folder. If a readable image is selected, it opens in Imaging.
Page 22
Launch Composer component of Sharpdesk. INTERNET MENU DESCRIPTION Sharp Product Information Display the Internet page connected to Sharp Product Information. OUTPUT ZONE MENU DESCRIPTION Print Prints a single copy of the image to your default printer. To print to another printer, click on the Down Arrow and select the desired printer.
The Sharpdesk Toolbar The Sharpdesk toolbar allows you quick access to key commands and additional Sharpdesk applications such as Composer and Imaging. To display a popup tip for a command, move the mouse slowly over its icon. Sharpdesk Toolbar The toolbar lets you perform the following functions: TOOL BUTTON DESCRIPTION Acquire...
The Sharpdesk Output Zone The Sharpdesk Output Zone lets you perform functions by simply dragging and dropping a selected file to the appropriate Output Zone button. You can also highlight a file and click the desired Output Zone button. To change the destination of an Output Zone button, click the “down arrow”...
Chapter 4 Working with Sharpdesk Introduction Sharpdesk makes it easy to identify, locate, and organize your files. This chapter reviews how to work with each of the options Sharpdesk provides. Viewing Images and Documents When you open a folder in Sharpdesk, you view the documents contained in the folder as a thumbnail of the document.
Working within a Folder On the Folder Window, click on the desired folder. The documents contained in the folder are displayed in the work area. Each of your documents appears as a thumbnail image, showing the file’s name and type. Note that it takes longer to generate thumbnails the first time a folder is selected.
If the document cannot be displayed as a thumbnail, it will be shown in the work area in the following manner: If the thumbnails do not appear as expected, select the Refresh command from the View menu to correct the problem. Working with Images Combine You can combine .TIF image documents in the work area by clicking on an image, then dragging...
Controlling the Desktop Display Sharpdesk lets you customize the Desktop according to your preferences: • Choose the Preferences command from the Tools menu, and click on the Desktop tab, if not already displayed. Desktop Display Options Changing the Thumbnail Size To change the thumbnail size, click on your preference: Small, Medium, or Large.
Viewing Image Files Sharpdesk lets you choose the various image file types you can view with Sharpdesk Imaging. To do so, choose the Preferences command from the Tools menu and click on the Imaging Files tab: Imaging Files Handling Options Setting the File Types to be Viewed by Sharpdesk Imaging The file types that can be viewed with Imaging are listed.
Setting Export Options Both Sharpdesk and Sharpdesk Composer allow you to attach and send files via email. In addition, Sharpdesk Composer allows you to export Composer files as Adobe Acrobat (.PDF) format files. (Refer to Chapter 6: Composing with Sharpdesk for details.) If you have Adobe’s PDFWriter software installed (version 5 or later), Sharpdesk will use that driver to create the PDF file.
information: 1. Click the mouse on the document for which you want to view details in the work area, and choose Properties from the File menu. 2. To close the Properties dialog, click OK. Properties Dialog Organizing Files With Sharpdesk, organizing your files could not be easier. This section reviews the overall procedures for such tasks as selecting files, opening them, moving them, and deleting them.
• Right-click on the document and choose Open, or, • Choose the Open command from the File menu, or, • Double-click the image/document in the work area. To open an image using Imaging, click the image in the work area and then click the Imaging button on the toolbar.
Copying a File A file can be copied from one folder to a different folder. To copy a file from one folder to another: 1. Open the folder with the file you want to copy. 2. Drag the file, while holding down the Ctrl key, to the desired folder. Renaming a File You can change the name of a file to something else.
To scan an image from a scanner using the WIA driver: [This option is only available on Windows XP platforms.] 1. Place the image you want to scan in your scanner. 2. In Sharpdesk, choose the From scanner or camera command from the File menu. 3.
Page 35
Image View in Imaging For more information about viewing an image, refer to “Chapter 7, Sharpdesk Imaging.” Sharpdesk User’s Guide...
Changing Scanning Options You can change the default naming convention used for new scans as follows: 1. Choose the Preferences command from the Tools Menu. 2. Click the Acquire tab. Acquire Tab 3. To use a Date as the name for new scans, click the Current Date Formats option, and then select a date format from the drop-down list.
Chapter 5 Searching with Sharpdesk Introduction Sharpdesk’s advanced searching capabilities allow you to easily retrieve image and text files using a single word, a phrase, or a list of words. Additionally, you can search for particular files using a wide range of criteria, including: •...
Setup Required The Search capability is based on an index of all the words found in all of the files in the target folders identified when the index is created. These indexes need to be created in advance of any attempt to use the Search feature.
Since all Index Databases are common to all users of the local PC, if a user indexes a private directory, either local or networked, some information regarding this data will be available to any other user of the PC, even if they logon under a different username. Information such as file name and number of hits is shown in the Search Results table, although the private entries are grayed out and a non-privileged user will not be able to access the files.
Searching You can search for text files using a single word, a phrase, or a list of words. You can also perform an advanced search using a: • Document name and/or path • File type • Modified date • File size •...
To Search for this Sharp and copier Documents that contain both “sharp” and “copier”. Sharp copier Documents that contain both “sharp” and “copier”. Note that and is implied between words. “sharp copier” Documents that contain the phrase “sharp copier”. apple or pear Documents that contain either “apple”...
Page 42
ap*ed would match applied, approved, etc. Exact Match vs. “Stemming” Stemming extends a match to cover grammatical variations of a word. For example, fish would match “fish”, “fishes” and “fishing”. applied would match “applied”, “applying”, “applies”, and “apply”. To enable stemming, check ‘Variation of word endings’ in the Find Matches section of the Search Preferences page.
Examining the Results The search results list shows you each file that contains the word or phase you entered to search. It displays the name of the file and a hyperlink to its location: • Clicking the Location link opens the file in the application that originally created it. •...
Sorting the Results List You can re-sort the search results list by choosing a sort option from the Sorted by drop-down. The results list can be sorted by: • Match Score (qualitative measure based on number of ‘hits’ on search terms within an individual index) •...
2. Select the favorite search query from the list provided. It will fill the Search For box when you select it. 3. Click Find. Advanced Searching Techniques To run a more advanced search of your files, click the Advanced button. The Advanced Search tabs display.
• Size (at least or at most) Note that you cannot use the Boolean operators (“and”, “or”, “not”, or “near”) on the fields in the File Attributes Tab. Document Properties Tab The Document Properties tab allows you to search for a Microsoft Office file (e.g. generated by Word, Excel, PowerPoint) by: •...
1. Select the search term you want to remove in the Favorite Search Terms box 2. Click the Remove button. When the Favorites list is the way you want it, click OK and exit. If you change your mind, click Cancel to put the Favorites list back the way it was and exit. Customizing Search Preferences You can customize your search options –...
Display Favorites box on this page is unchecked, the Favorites button will not be present on the Advanced page. 5. Indexes to be searched are displayed in the Search Area of the Search Home page. If you do not what them displayed, uncheck this checkbox. 6.
Page 49
2. Click the Create button. The Index Database Creation Wizard begins. 3. Click Next. The Index Name and Location window displays. 4. Enter an Index Name using up to 39 characters. To select an index location, click Browse, navigate to the desired location and click OK. After entering the information, click Next.
Page 50
5. Click the checkbox next to the folder(s) you want to include in the index (any sub- folders are automatically selected). To clear all your selections, click Clear. After making your selections, click Next. The File Extensions to Index prompt displays. 6.
7. To create the index later, select Skip building Index Database for now and click Next. To create the index database now, select Build Index Database now and click Next. The Ready to Build Index Database screen appears. Click Index Now to begin the index process. The Index is created and displayed in the Currently Available Databases list box.
3. Make the desired changes to the folders or sub-folders you want searched, or the file extensions you want to include. 4. Click Save. Your changes are saved and the Index Databases page is redisplayed. Note that you must rerun the index step for the changes to take effect in your searches. Deleting an Index Database If you want to delete an index database: 1.
Page 53
To set up or modify the Index Schedule: 1. Choose Indexing Schedule from the Search option in the Tools menu. This can also be selected from the Search drop-down on the toolbar, the Search Home page, or the Index Database page. The Indexing Schedule page displays. 2.
6. If you are running on Windows NT, 2000, or XP, you may be asked to provide your login name and password before the Index schedule can be saved. Typically, this occurs the first time that you attempt to use the Windows scheduling service. If this is necessary, the following dialog will be presented: Enter your Domain Name\Username in the appropriate box and your password in each of the password boxes.
Show Progress Select the Show Progress item to display the current file being indexed. A display similar to the following will appear: Show Last Indexing Select the Show Last Indexing item to display the summary of the last indexing operation. A display similar to the following will appear: The Last Indexing Performed dialog displays detailed information about the last instance of indexing performed for the local PC, regardless of which user performed indexing the last...
Chapter 6 Composing with Sharpdesk Introduction Using Sharpdesk Composer, you can combine files of different types into a single production- ready document. For example, you could combine a Word file with an Excel file, and then even add in a Lotus file. Composer lets you reorder pages, add a cover page or inserts, and then print, copy, or e-mail the entire document.
Starting Composer To start the Composer from Sharpdesk: Click the Composer icon on the Sharpdesk toolbar, or choose the Composer command from the Tools menu. The Composer work area and reference area appears. Menu Bar Toolbar Composer Reference Composer Work Area Area Sharpdesk Composer Composer is comprised of the following elements:...
Reference Area The Reference section lists all source documents displayed in the Work Area. The Reference area shows the document name, the number of pages, and the created date. Menu Options The Menu Bar provides you with the following options: MENU DESCRIPTION File...
MENU DESCRIPTION View References Toggle the reference documents list on and off. Toolbars Toggle the toolbar on and off. Tools Reinstall Printer Driver Reinstall the Sharpdesk Composer printer driver. Help Contents and Index Display the Composer help information. About Composer Display Composer copyright and version information.
Working with Composer Pages are loaded into Composer by printing to the Sharpdesk Composer driver from third-party applications (for example, MS Word, MS Excel, and so on). Or, you can drag and drop a file from Sharpdesk or Microsoft Explorer directly into either the Composer’s work area or the Composer icon on the Output Zone.
2. Click OK to save your settings and close the Properties screen. 3. Click OK or Print (depending on the application you’re running) to start the print operation. If Sharpdesk is not running, it automatically starts and the new pages are added to an Untitled1.sdf document in the Composer work area.
• To view the Work Area only, uncheck the References option in the View menu. You can also enlarge the Work Area (or the Reference Area) by grabbing and dragging the separator bar between the Work Area and Reference Area. •...
File.Page Setup menu option. If specific pages were not selected prior to entering the Header/Footer dialog, only the “Entire document” selection will be available. 3. Select the “This page forward” item from the drop-down list in the Apply to: section if you want the Header/Footer to be applied the page you selected prior to selecting the File.Page Setup menu option.
saved. If this is the first time you are saving the document, a Save As dialog box displays allowing you to name it and save it with a .SDF extension. Opening a Composer Document You can open a Composer document as follows: 1.
Chapter 7 Sharpdesk Imaging Introduction Using Sharpdesk Imaging, you can view images, manipulate them, annotate them, and print them. Basic Imaging Concepts This section discusses some basic concepts and terminology to help you better understand Sharpdesk Imaging. What is Imaging? Imaging can be described as using computer software to create, modify, and process electronic images.
Types of Images An image is an electronic representation of a text document, a photograph, a line drawing, or other graphical entity. You can create an image by scanning a printed page, a photograph, a drawing, by saving a fax, or by creating an image with a drawing or graphic-design program. After a page of text is scanned and saved, it takes on the properties of an image file, and can no longer be opened with a word processor or text editor.
Simple Image Document Another image document could be a collection of faxes, memos, and photographs that are scanned to a multi-page image file. Multi-Page Image File Sharpdesk Imaging With Sharpdesk Imaging, you can perform a variety of imaging operations by making selections from menus or by clicking on tool buttons.
IMAGE FILE TYPE EXTENSION JPEG File .JPG, .JPE, .JPEG PCX/DCX Document .PCX, .DCX WIFF Document .WIF XIF Document .XIF You can display a single image in the window, display thumbnail views of the images contained in a multi-page image document, or display an image page and thumbnails together. Imaging Window Dialog Convert Image Files Using Sharpdesk Imaging, you can save a displayed image in one of the following formats:...
In some cases, converting from one format to another causes the source image to permanently lose certain attributes. For example, if you save a color .BMP file to .AWD format (which is black and white only), the saved image is converted to black and white. If you convert the .AWD image back to .BMP, the color information that was lost in the first conversion cannot be recovered.
When the annotation icon appears next to a thumbnail's page number, it means the page contains one or more annotations. Annotating an Image Dialog Create a Contact Sheet You can create a contact sheet that contains a thumbnail rendition of each page of an image document, similar to a photographic contact sheet that displays images of each negative on a roll of film.
To start Sharpdesk Imaging: 1. Click the Start button. 2. Point to Programs, then Sharpdesk, and then choose Sharp Imaging. NOTE: If you use the sample image files installed with Sharpdesk to practice working with Imaging options, you can access the original versions of these files on your installation CD.
The Summary tab allows you to specify property values for your image documents. You may want to standardize the values you use so your documents are organized in a more useful way. For example, descriptive Keyword entries might be Invoices, Deposits, Inventory, and so on. 7.
4. Select the drive or folder you want to search from the Look in drop-down. To navigate to a particular folder, use the Browse button. 5. Click the Include Subfolders checkbox. 6. Click Find Now. The lower pane of the dialog displays the names of documents containing the specified property value.
4. Position the pointer over the vertical bar separating the Thumbnail and Page windows and picture. When the pointer changes shape, hold down the left mouse button and then drag the bar left or right to resize each window. Sizing Windows Dialog 5.
3. Place the pointer over the handle in the lower right corner of the thumbnail, hold down the left mouse button, and then drag the handle diagonally to increase or decrease the size of the thumbnail. 4. Click OK to apply the new size to the displayed thumbnails. Creating a Contact Sheet To create a contact sheet: 1.
Page 77
2. Navigate to the image document you want to annotate, and click Open. The image document appears. 3. Choose the One Page command from the View menu. 4. Choose the Rubber Stamps command from the Annotation menu. The Rubber Stamp Properties dialog appears. You can also click on the Rubber Stamp...
The Rubber Stamp Font Properties dialog appears. Rubber Stamp Font Properties Dialog 6. Choose the desired font attributes and color, and click OK. 7. Click OK to close the Edit Text Rubber Stamp Properties dialog. 8. Click OK to close the Rubber Stamp Properties dialog. The pointer changes to a rubber stamp icon.
Highlighter Properties Dialog 3. Choose a color, such as light blue, that allows the text to show through. 4. Click OK to apply the new color. Document Enhancement This section shows how to enhance a document page by despeckling and straightening it. Removing Speckles From a Document To remove speckles from a displayed document: 1.
Page 80
Straighten Page Dialog 4. Click OK in the Straighten Page dialog. The page rotates until the reference line you drew is parallel with the top and bottom edges of the window. Sharpdesk User’s Guide...
Chapter 8 Converting Images to Text Introduction Sharpdesk lets you convert a non-editable, graphical image containing text into a file that can be edited with your favorite word processor. You can convert an image at anytime while working in Sharpdesk by simply dragging the image onto the Convert by OCR option on the Output Zone bar.
Setting Convert by OCR Options Sharpdesk lets you set the various options that control the OCR process. To do so, choose the Preferences command from the Sharpdesk Tools menu and click the Convert by OCR tab: Convert By OCR Options Sharpdesk User’s Guide...
Setting the Output File format You may select one of the following output file formats for the OCR process: Save File As format Adobe PDF (*.pdf) Adobe PDF with image on text (*.pdf) Excel 97, 2000 (*.xls) RTF Word 2000 (*.rtf) Text –...
Setting the Original Document Layout The Original Document Layout setting tells the OCR engine what to expect in the image(s) it is about to process. You may choose from the following layout selections: Layout Setting Description Automatic Let the OCR engine make its own decisions regarding the layout.
Selecting a User Dictionary You may improve the recognition of words that you find in documents you scan often by creating a User Dictionary. The currently selected dictionary is displayed in the Custom Dictionary box. To change the selected dictionary or create a new one, click on the Browse button. This will display the User Dictionary Files dialog: Selecting an existing dictionary All known User Dictionaries will be displayed in the File Name section.
Page 86
Deleting words from the user dictionary Select the words currently in the dictionary you want to remove by clicking on it in the list; this will highlight the word to show it has been selected. To select more than one word, hold down the Ctrl key as you click on each word to select it.
Creating a new User Dictionary To create a new User Dictionary, click on the New button in the User Dictionary Files dialog. This will display the following dialog: Give the new user dictionary a name and click on the OK button. This will create the user dictionary file (“Contract Terms”) and display the dialog for adding, importing, or deleting words.
Page 88
completes, the dialog automatically closes and the finished text document appears in the appropriate application. If you click Cancel, the ongoing conversion process is canceled. Sharpdesk User’s Guide...
Chapter 9 Glossary Introduction The following terms and definitions can assist you when working with Sharpdesk. ASCII Acronym for American Standard Code for Information Interchange. A set of definitions for the bit composition of characters and symbols. ASCII defines 128 symbols using 7 binary bits and 1 parity bit.
Page 90
Graphic A written, printed, or electronically displayed symbol or drawing. Also, characters or text that have been generated by a computer graphics application program. Grayscale An image in black and white created from a color image using different intensities of black. Image In Sharpdesk, an image is used interchangeably with Document.
Page 91
TWAIN Both a protocol and an application programmer’s interface (API) that lets you input image data directly from any source (for example: desktop and hand-held scanners, video capture boards, digital cameras, and other imaging equipment) without requiring you to switch out of the application.
