SL20/CG20 Parts Manual
Phase 7
COIN & NON-COIN (OPL)
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail:
techsupport@amdry.com
www.amdry.com
ADC Part No. 450222

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG20 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Dryer Corp. CG20

  • Page 1 SL20/CG20 Parts Manual Phase 7 COIN & NON-COIN (OPL) American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450222...
  • Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. ONLY qualified technicians should service this equipment.
  • Page 3: Table Of Contents

    Table of Contents Phase 7 OPL Top Panel Assembly For Top Control Models ... 2 Phase 7 Coin Top Panel Assembly For Top Control Models ... 3 Phase 7 Top Panel Assembly For Bottom Control Models ... 4 Front Bottom Panel Assembly ... 5 Main Door Assemblies ...
  • Page 4: Phase 7 Opl Top Panel Assembly

    Illus. No. Part No. Qty. Description 112579 Phase 7 Keyboard 137250 Phase 7 Ribbon Cable 137270 16” x 1” Large Character Display 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 153010 #6 Star Washer 883434 Phase 7 Board with Sensor Activated Fire Extinguishing (S.A.F.E.) System 818173 SL-20 Black Control Panel 818196...
  • Page 5: Phase 7 Coin Top Panel Assembly

    Phase 7 Coin Top Panel Assembly For Top Control Models Illus. No. Part No. Qty. Description 137270 16” x 1” Large Character Display 152015 8-32 Hex Nut 153010 #6 Internal and External Star Washer Zinc 150005 6-32 x 1/4” Phillips Round Head Machine Screw 112579 Phase 7 Keypad 137250...
  • Page 6: Phase 7 Top Panel Assembly

    Illus. No. Part No. Qty. Description 818431 SL-20 Black Control Panel 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 153010 #6 Star Washer 887009 Phase 7 Board with Sensor Activated Fire Extinguishing (S.A.F.E.) System 153603 Snap Top Standoff 818206 Magnetic Switch Assembly -------* Logo ONLY...
  • Page 7: Front Bottom Panel Assembly

    Front Bottom Panel Assembly Illus. No. Part No. Qty. Description 818165* Front Bottom Panel Assembly Specify color when ordering.
  • Page 8: Main Door Assemblies

    Illus. No. Part No. Qty. Description 883824 Door Pan with Glass 883823 Door (left hinge) (includes illus. nos. 2, 13 and 14) 883825 Door (right hinge) (includes illus. nos. 2, 13 and 14) 102313 Door Gasket (fiberglass) 151016 #8-32 Acorn Nut 150322 #6 x 1/2”...
  • Page 9: Middle Front Panel Assembly

    Middle Front Panel Assembly Illus. No. Part No. Qty. Description 150322 #6 x 1/2” Self-Drilling Screw 318146 Door Catch Holder 818104 Middle Front Panel Assembly Complete (specify left or right hinged) (includes illus. nos. 1 through 9) 318249 Door Catch Cover 150531 #6 x 1-1/4”...
  • Page 10: Lint Drawer Assembly

    Illus. No. Part No. Qty. Description 883751 Lint Drawer Handle (includes illus. nos. 1 through 5) 151010 #10-32 Hex Acorn Lock Nut 153420 #10 Split Lock Washer 318541 Offset Washer 117605 Gasket (sold by the foot) 883752 Lint Drawer Assembly (includes illus.
  • Page 11: Basket (Tumbler) Assembly

    Basket (Tumbler) Assembly Illus. No. Part No. Qty. Description 884359 Open Back Tumbler Assembly 884363 Solid Back Tumbler Assembly (as of May 2004) (includes illus. nos. 1 through 8) 318242 5” Tapered Rib 150313 #10-16 x 1/2” TORX Screw 154217 1/8”...
  • Page 12: Front Basket (Tumbler)/Support Panel Assembly

    Illus. No. Part No. Qty. Description 883820 Front Basket (tumbler) Support Panel Complete 818110 Front Right Wheel Assembly (refer to Basket [Tumbler] Roller Wheel Assemblies on page 12) 818109 Front Left Wheel Assembly (refer to Basket [Tumbler] Roller Wheel Assemblies on page 12) 121400 Universal Bushing Front Basket (Tumbler)/Support Panel Assembly...
  • Page 13: Rear Support Panel Assembly

    Rear Support Panel Assembly Illus. No. Part No. Qty. Description 818207 Temperature Sensor Probe Assembly (refer to Temperature Sensor Assemblies on page 14) 318252 Rear Temperature Probe Mount 318234 Rotational Sensor Switch Bracket 152015 #8-32 Hex Nut 153000 #8 Flat Washer 153012 #8 Star Washer 153009...
  • Page 14: Basket (Tumbler) Roller Wheel Assemblies

    Illus. No. Part No. Qty. Description 150510 1/4-20 x 3/4” Hex Head Machine Bolt 154267 M10 x 25mm Shoulder Screw 153007 1/4” Split Lock Washer 153002 5/16” Split Lock Washer 154013 M8 Hex Nut 154284 Basket (tumbler) Wheel Spacer 318232 Rear Left/Front Right Roller Wheel Bracket 818110 Rear Left/Front Right Wheel Assembly Complete...
  • Page 15: System Piping Assembly

    S.A.F.E. System Piping Assembly Illus. No. Part No. Qty. Description 143581 3 GPM 3/8” N.P.T. Spray Nozzle 318167 Nozzle Bracket 143220 3/8” F.P.T. Brass Tee 143242 3/8” x 2-1/2” Brass Nipple 143208 3/8” Comp x 3/8” M.P.T. Brass Connector 143155 3/4”...
  • Page 16: Temperature Sensor Assemblies

    Illus. No. Part No. Qty. Description 818207 Basket (tumbler) Temperature Sensor Probe (includes illus. nos. 1 through 3) 122646 2-Pin Plug 122706 Socket Terminal ONLY 883821 Sensor Activated Fire Extinguishing (S.A.F.E.) System Temperature Sensor Probe Assembly Complete (includes illus. nos. 4 through 8) 122646 2-Pin Plug 122706...
  • Page 17: Motor Drive Assembly

    Motor Drive Assembly Illus. No. Part No. Qty. Description 154279 5/16-18 x 3/4” Carriage Bolt (for motor bases without studs) 153002 5/16” Split Lock Washer 154321 5/16” x 3/8” Allen Setscrew 152004 5/16-18 Hex Nut 153001 5/16” Flat Washer 181120 4-Pole Motor (for earlier models without studs) 318247 4-Pole Motor Sheave (60 Hz models)
  • Page 18: Direct Spark Ignition (Dsi) Burner Assembly

    Direct Spark Ignition (DSI) Burner Assembly...
  • Page 19 Direct Spark Ignition (DSI) Burner Assembly Illus. No. Part No. Qty. Description 143226 1/2” Brass Street Elbow 141317 1/2” Bronze Union Elbow 882451 Ignitor Probe Assembly with High Voltage (HV) Wire (includes illus. nos. 3 and 16) 128927 1/2” 24 VAC Redundant (natural gas) Gas Valve 880960 1/2”...
  • Page 20: Electric Oven Assembly

    Illus. No. Part No. Qty. Description 318543 Electric Oven Housing 318294 Electric Oven Mounting Bracket 120086 3-Phase (3ø) Oven (5.4 kW at 240 volt or 8.1 kW at 416 volt) 818155 Electric Oven Assembly Complete (includes illus. nos. 1 through 9) 150300 #10-16 x 1/2”...
  • Page 21: Lint Box/Blower Motor Assembly

    Lint Box/Blower Motor Assembly Illus. No. Part No. Qty. Description 818207 Temperature Sensor Probe Assembly (refer to Temperature Sensor Assemblies on page 14) 100623 25 M.F.D. 440 VAC Capacitor (for use with 120 volt blower) 100633 6 M.F.D. 440 VAC Capacitor (for use with 220 volt blower) 318230 Capacitor Bracket (for use with 25 M.F.D.
  • Page 22: Blower Assembly

    Illus. No. Part No. Qty. Description 883826 Motorized Impellor 120V ONLY (refer to Blower Motor Assembly on page 21) 883827 Motorized Impellor 240V ONLY (refer to Blower Motor Assembly on page 21) 318204 Blower Housing Mount 150300 #10-16 x 1/2” Hex Washer Screw 154338 M4 x 6mm Phillips Head Slotted Machine Screw 152008...
  • Page 23: Blower Motor Assembly

    Blower Motor Assembly Illus. No. Part No. Qty. Description 883826 120V Motorized Impellor with Plug (includes illus. nos. 1 through 4) 883827 240V Motorized Impellor with Plug (includes illus. nos. 1 through 4) 100624 Motorized Impellor 240V (50 Hz) 100621 Motorized Impellor 120V (60 Hz) 121000 1/4”...
  • Page 24: Rear Electrical Panel Assembly

    Illus. No. Part No. Qty. Description 818189 Electrical Panel Assembly 818229 Rear Electrical Panel Complete 120V (60 Hz) (includes illus. nos. 1 through 15) 818227 Rear Electrical Panel Complete 240V (50 Hz) (includes illus. nos. 1 through 15) 131932 24V SPST Relay 120730 30-Position Terminal Block 818212...
  • Page 25: For Electric Models Only

    Rear Electrical Panel Assembly For Electric Models ONLY Illus. No. Part No. Qty. Description 818190 Electrical Panel Assembly 818332 Rear Panel Assembly Complete 240V 1ø to 416V 3ø (includes illus. nos. 1 through 14) 131932 24V SPST Relay 131368 25-Amp Contactor 818224 Transformer Assembly 120728...
  • Page 26: Heat Duct Assembly

    Illus. No. Part No. Qty. Description 130403 330º F Thermostat (for gas models Only) 318289 Heat Duct Cover Commercial Electric 150300 #10-16 x 1/2” Hex Washer TEK Screw 153012 #8 Star Washer 152015 #8 Hex Nut 153000 #8 Flat Washer 818154 Heat Duct 818114...
  • Page 27: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 154002 1/8” Push On Fastener 332689 Sail Switch Damper (flat) 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 122200 Sail Switch ONLY 154004 Twin Speed Nut 150303 #4 x 3/4” Pan Head “A” Machine Screw 318237 Sail Switch Box 105500...
  • Page 28: Base/Top/Sides/Back Guard Assemblies

    Illus. No. Part No. Qty. Description 318398 SL-20 Back Guard 318222 CG-20 Back Guard 818168 SL-20 Back Guard Assembly Complete (includes illus. nos. 1 through 4) 818179 CG-20 Back Guard Assembly Complete (includes illus. nos. 1 through 4) 318397 Gas Pipe Pocket 150300 #10-16 x 1/2”...
  • Page 29: Pedestal Box Option

    Pedestal Box Option Illus. No. Part No. Qty. Description 818313 Dryer Pedestal...
  • Page 30: Additional Parts Available

    Part No. Description 112280 “Clean Lint Screen” Label 114006 “WARNING - Fire Hazards” Label 114548 Phase 7 Program Location Summary Label 404519 Black Touch-Up Paint 120903 Crimp-On Wire Nut 121499 5-1/2” Harness Tie 122804 Manometer (hydro gauge) for Measuring Gas Pressure 114094 Warning Arc Label 112017...
  • Page 31 Notes _________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________...
  • Page 32 ADC 450222 4 - 05/04/06-0...
