Installation/Operator's Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
010496
011899DX/mt
ADS-464
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
For replacement parts, contact the distributor from which the dryer
was purchased or
American Dryer Corporation
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
88 Currant Road
ADC Part No. 112103

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. ADS-464

Summary of Contents for American Dryer Corp. ADS-464

  • Page 1 Do not store or use gasoline or other flammable vapor and liquids in the vicinity of this or any other appliance. 010496 011899DX/mt ADS-464 AVERTISSEMENT: Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort.
  • Page 2 Important For your convenience, log the following information: MODEL NO. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. ADS-464...

  • Page 3: For Your Safety

    YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 4 The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER (SCREEN) IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I IMPORTANT INFORMATION ... 3 A. Receiving and Handling ... 3 B. Safety Precaution ... 4 SECTION II SPECIFICATIONS/DIMENSIONS ... 6 A. Specification ... 6 B. Dimensions ... 7 SECTION III INSTALLATION PROCEDURES ... 8 A. Reassembly of Dryer... 8 B.
  • Page 6 SECTION VIII SERVICE/PARTS INFORMATION ... 41 A. Service ... 41 B. Parts ... 41 SECTION VIII WARRANTY INFORMATION ... 42 A. Returning Warranty Cards ... 42 B. Warranty... 42 C. Returning Warranty Parts ... 42 SECTION IX TROUBLESHOOTING ... 44 Troubleshooting TOC ...

  • Page 7: Section I

    IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden skid should be visually inspected for shipping damage.

  • Page 8: Safety Precaution

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 9 7. This dryer is not to be used in the presence of dry cleaning solvents or fumes. 8. Remove articles from the dryer as soon as the dryer cycle has been completed. WARNING: Articles left in the dryer after the drying and cooling cycles have been completed can create a fire hazard.

  • Page 10: Specifications/Dimensions

    SPECIFICATIONS/DIMENSIONS A. SPECIFICATIONS MAXIMUM CAPACITY (D Total Weight Total Shipping Weight Tilt Height Operating Height Full Tilt Depth Operating Depth Width Tilt Load ( REAR TILT Tilt Unload ( FRO N T T ILT Loading Height from Floor Tumbler ( ) Diameter BA SK ET Tumbler (...

  • Page 11: Dimensions

    B. DIMENSIONS NOTE: ADC reserves the right to make changes in specifications at any time, without notice or obligation.

  • Page 12: Installation Procedures

    INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable NATIONAL ELECTRIC CODE ANSI/ NFPA NO. 70-LATEST EDITION, or in Canada, the CANADIAN ELECTRICAL CODES PARTS 1 & 2 CSA C22.1-1990 or LATEST EDITION.
  • Page 13 2. Reassembly Instructions For Dryers Shipped In Three (3) Pieces When the dryer is shipped in three (3) pieces, the tumbler and the tumbler base sections are shipped as two (2) separate pieces. The heat console section is shipped as the third piece. a.
  • Page 14 c. Reassemble The Tumbler (Basket) Section To The Tumbler (Basket) Base Lift the tumbler (basket) section with a cable through the eye bolts on top of the section. Slowly lower the tumbler (basket) section over the tumbler base. The four (4) large slots located on the bottom of the tumbler (basket) section (one slot at each corner of the tumbler section) must be aligned with the tapped holes in the cylinder cleaves located at the top of the tumbler (basket) section.

  • Page 15: Location Requirements

    B. LOCATION REQUIREMENTS The model ADS-464 dryer requires 36-inches of space on each side of the dryer and 36-inches of space behind the unit for ease of maintenance and tilting. The dryer must be leveled for proper operation. If shimming is required, put 9-1/2”...

  • Page 16: Internal Air, Electrical And Water Connections

    C. INTERNAL AIR, ELECTRICAL and WATER CONNECTIONS 1. Air a. Front Tilt Piston and Sprinkler lines This connection is made at the front of the dryer in the area between the lower heat console section and the tumbler (basket) base section. To connect the sprinkler air line insert the 1/4” aluminum tubing into the 1/4”...
  • Page 17 c. Load Door Piston Air Lines and Cool Down Damper Piston Air Lines The load door cylinder pneumatic connections are made in the lower heat console section, in the area behind the pneumatic panel. To connect the 1/4” poly-flo lines into the corresponding needle valves, match the number on the line with the number on the needle valve.
  • Page 18 2. Electric a. Tumbler (Basket) Motors The disconnects for the two (2) tumbler (basket) motors are located in the lower heat console. The right drum (tumbler/basket) motor disconnect is located in the lower heat console on the upper shelf towards the left.
  • Page 19 c. Annunciator, Pendent, Over-Burner, and RTD (Resistive Temperature Device) Cable Remove the four (4) bolts that hold on the character (464) panel. Open the door to the main electrical enclosure, the female end of the RTD (Resistance Temperature Device) cable will be found there. Loosen the 1-inch lock nut and remove the modified hole seal.
  • Page 20 d. Pendent On the top of the heat console section of the dryer near the pendent, there is a junction box with four (4) cables coming out of it. Two (2) of the cables from the junction box have connectors on the end, a 5-pin connector and an 11-pin connector.
  • Page 21 e. Tumbler Junction Box Disconnect Remove the four (4) bolts that hold on the lower left side panel, then remove the panel. The safety panel is next to be removed. This is done by removing the six (6) bolts on the bottom of the safety panel where the tumbler section and the base meet.

  • Page 22: External Supply Connections

    D. EXTERNAL SUPPLY CONNECTIONS 1. Sprinkler Water Supply A 40 PSI supply of water must be connected into the 1” N.P.T. sprinkler connection located on the left side of the tumbler base. 2. Compressed Air Supply A minimum of 20 cubic feet per hour (cfh) at 80 PSI of dry, clean, and regulated compressed air must be supplied to the dryer.
  • Page 23 3. Steam Supply and Condensate Return Connections The steam supply into the dryer is made into the 2-1/2” F.T.P. pipe fitting located on top of the heat module console. The maximum operating steam supply pressure is 150 psig (10.34 bar). The presence of condensate in the steam supply will cause water hammer and subsequent steam coil (battery) failure.
  • Page 24 4. Exhaust Ducting The dryer’s exhaust air must be vented to the outdoors by the shortest route possible with the number of elbows kept to a minimum. The duct should be designed and installed by qualified technicians. Improperly designed duct work may reduce the airflow through the dryer, causing improper and unsafe drying conditions.
  • Page 25 The duct work must be smooth on the inside with no projections from sheet metal screws or other obstructions which would collect lint. Inspection doors must be installed at strategic points in the duct work for periodic lint removal. Use smooth sweeping elbows instead of sharp 90º elbows. The radius of an elbow should be at least 1-1/2 times the duct diameter.

  • Page 26: Electrical Requirements

    E. ELECTRICAL REQUIREMENTS 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electric connections, materials and workmanship must confirm to the applicable requirements of the National Electrical Code ANSI/NFPA NO.
  • Page 27 2. Electrical Service Specifications ADS-464 (Steam) LECTRICAL IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. NOTES: B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used.
  • Page 28 ADS-464 dryer, this section is located at the bottom left of the main electrical enclosure. The ADS-464 dryer, with sprinkler option, must be supplied with two (2) independent input power lines. One is 3-phase (3ø) electric service that feeds the dryer itself, and the other is single-phase (1ø) electric service that feeds the safety sprinkler system.

  • Page 29: Fresh Air Supply Requirements

    F. FRESH AIR SUPPLY REQUIREMENTS When the dryer is operating, it draws in room air, heats this air through the tumbler (basket), and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If makeup air is inadequate, drying time and efficiency will be adversely affected, and safety will be compromised.

  • Page 30: Steam Information

    IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure which will VOID THE WARRANTY. NOTE: The ADS-464 is manufactured with a pneumatic (piston) damper system which requires an external supply of air (80 psi ± 10 psi).

  • Page 31: Shut Down Instructions

    c. Flexible hoses or couplings must be used. The dryer vibrates slightly when it runs and this will cause the steam coil connections to crack if they are hard piped to the supply and return mains. e. A 3/4” vacuum breaker should be installed for each unit in the piping. This will prevent the condensing steam from causing a vacuum inside the coil and possibly damaging the coil.

  • Page 32: Pre Start-Up

    A. PREPARATION FOR OPERATION 1. The supply voltage must match the dryer voltage as stated on the aluminum dryer data label which is located on the inner right wall of the electrical cabinet. 2. A separate fused power supply must be connected into safety sprinkler circuit power connection. 3.

  • Page 33: Routine Maintenance

    A. CLEANING A program or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of this cleaning can best be determined from experience at each location. Maximum operating efficiency is dependent upon proper air circulation.
  • Page 34 MONTHLY Grease the four (4) tumbler shaft pillow bearings with DC-44 (Dow Corning) grease or equivalent. DC-44 is a lithium grease that conforms to NLGI Grade 2 and has a temperature range of 40º F (4.4º C) to 400º F (204.4º...

  • Page 35: Component System Descriptions

    COMPONENT SYSTEM DESCRIPTIONS A. TUMBLER (BASKET) SUPPORT and DRIVE SYSTEM IMPORTANT: Always keep the tumbler (basket) section of the dryer in an upright position when moving it. 1. Tumbler (Basket) The tumbler is made of five (5)14-gauge stainless steel perforated panels, five (5) stainless steel lifting ribs, and two (2) outer tumbler rings.
  • Page 36 3. Tumbler and Basket Drive System There are two (2) 5 HP tumbler drive motors. Each motor drives one of the 2-inch diameter tumbler drive shafts, and the motors spin simultaneously so that all four (4) sets drive wheels work together to spin the tumbler (basket).
  • Page 37 1) Front Panel Electrical Connections: a) Front Position Switch Disconnect Plug; The front door position switch disconnect plug is located on the left side of the front doors. Disconnect this plug and feed the cable through the right hand side of the tumbler section. b) Intake Temperature Probe Disconnect Plug;...

  • Page 38: Main Air Blower And Heat Reclaimer System

    B. MAIN AIR BLOWER and HEAT RECLAIMER SYSTEM The fan which moves the exhaust air through the ADS-464 dryer is a 22-inch diameter, squirrel cage wheel that is driven at 1,100 rpm by a 25 HP motor. This fan moves a maximum of 13,000 cfm (368 cmm) air...
  • Page 39 The dryer is equipped with a pneumatically operated heat reclaimer damper, which when opened, will recirculate approximately fifteen percent (15%) of the dryer’s exhaust air. The heat reclaimer damper is closed until ignition of flame has been established. Then, the damper piston is actuated, opening the dampers recirculating fifteen percent (15%) of the exhaust air back over the gas burner and into the tumbler (basket).

  • Page 40: Compressed Air System

    NOTE: Current Production models use a Filter Regulator Assembly while Past Production models used a Filter/Regulator/Lubricator (FRL) Assembly. (Refer to the illustrations below.) The compressed air system of the ADS-464 dryer consists of a number of pneumatic pistons located throughout the dryer, a Filter Regulator assembly, and pneumatic control panel.
  • Page 41 3. Pneumatic Control Panel The pneumatic control panel of a 2-Way Tilt dryer has two (2) tilting solenoid valves, one to control the front set of tilting pistons and a second to control the rear set of tilting pistons. A 1-Way Tilt dryer has only one (1) tilting solenoid valve.
  • Page 42 4. Internal and External Pilot Air Supply On two-way tilt dryers, a pneumatic safety circuit is incorporated to prevent both front and rear tilting pistons from extending their rods at the same time. When 120 volts is supplied to the “S5” side of the front tilting piston solenoid valve coil, the round internal spool in the core of the solenoid will move, allowing 80 PSI air to flow into the bottom ports of the front tilting pistons, while the top ports of these pistons are bled to the atmosphere.

  • Page 43: Safety Devices

    D. SAFETY DEVICES The ADS-464 dryer is equipped with numerous safety devices to ensure that the dryer operates safely. The chart on the following page (page 40) lists each device with it’s location, function, computer display message, and result of tripping.
  • Page 44 AFETY EVICES OCATION WITCH NLOAD DOOR IGHT SIDE OF SWITCH WO DOOR UNLOAD DOOR UNIT ONLY OP LEFT SIDE OF ILTING WITCHES BASE MODULE OTATION EFT SIDE OF ENSOR TUMBLER SECTION HAMBER AIR ENTER OF HEAT PRESSURE SWITCH C ONSOLE URNER ENTER OF HEAT WITCH...

  • Page 45: Service/Parts Information

    SERVICE/PARTS INFORMATION A. SERVICE 1. Service must be performed by a qualified trained technician, service agency or gas supplier. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Service Department for a distributor in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so your inquiry is handled in an expeditious manner.

  • Page 46: Warranty Information

    WARRANTY INFORMATION A. RETURNING WARRANTY CARDS 1. Before any dryer leaves the ADC factory test area, a warranty card (ADC Part No. 112254) is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you, if you file a warranty claim.
  • Page 47 d. Date of part failure. e. Specify whether the parts being returned is for a replacement, a credit, or a refund. NOTE: If a part is marked for a credit or a refund, the invoice number covering the purchase of the replacement part must be provided.

  • Page 48: Troubleshooting

    DISPLAYED ON THE DRYER or SPECIFIED IN THIS MANUAL. The following information assumes that the reader has familiarized himself with the introduction to this manual, understands the ADS-464 dryer operation, and has knowledge of the programming features of the dryer. TROUBLESHOOTING TABLE OF CONTENTS A.

  • Page 49: Power Malfunctions

    A. POWER MALFUNCTIONS 1. Main Disconnect Will Not Turn On a. PROBABLE CAUSES; 1a) Sprinkler isolated power source “OFF” or disabled. 2a) OL12 tripped or sprinkler circuit defective. 3a) Sprinkler activated. 4a) Sprinkler will not reset. b. POSSIBLE SOLUTIONS; 1b) Verify “RED” “Sprinkler Power” on main panel to be illuminated. •...
  • Page 50 • If line voltage is not present check fused disconnect and re-test 2b) Attempt to turn the ADS-464 main power handle to the “ON” position • If the switch does not engage, verify that sprinkler power is “ON” (“RED” light on main door) •...
  • Page 51 3. Machine Main Power Shuts Down (“BLUE” Indicator Off) a. PROBABLE CAUSES; 1a) Sprinkler activated. 2a) OL12 (overload #12) tripped. 3a) “UNDER VOLTAGE FEATURE” of main disconnect has tripped. 4a) Sprinkler circuit defective. b. POSSIBLE SOLUTIONS; 1b) Check if the sprinkler is activated, is “SPRINKLER RESET” button lit? Is the sprinkler alarm horn “ON”? Does the sprinkler water valve have its “ON”...
  • Page 52 The following information will first describe the sprinkler circuit components and then provide a circuit description. Please refer to the ADS-464 ladder diagram (which is supplied with the machine) as the following is described. • OL12 (overload #12) is a 1.6-amp magnetic and thermal overload device set 1-amp. Its function is to protect and the line voltage of the sprinkler circuit.
  • Page 53 • UV is the “UNDER VOLTAGE” detection coil of the ADS-464 MAIN DISCONNECT switch, DISC #1. It is this device that controls the automatic POWER DOWN of the dryer when the sprinkler is activated.
  • Page 54 • SHLC alarm relay will toggle, causing the alarm contact to close and activate 2CR’s (control relay’s) coil. This action will; • Open 2CR “B” causing UV, the “under voltage” trip feature of the ADS-464’s main disconnect to shut down the “MAIN POWER” to the dryer.
  • Page 55 4. Front Panel “BLUE” Light and “RED” Light “ON” ADS-464 “ON” button does respond ... a. PROBABLE CAUSES; 1a) EMERGENCY STOP (E-STOP) BUTTONS 1, 2, and 3. b. POSSIBLE SOLUTIONS; 1b) Verify that ALL EMERGENCY STOP (E-Stop) buttons are pushed in.
  • Page 56 3a) Malfunctioning operator interface terminal or communications cable. 4a) Malfunctioning 24 volt DC power supply. 5a) Malfunctioning hi-limit temperature controller. b. POSSIBLE SOLUTIONS; 1b) Verify that fuses 7, 8, 9, and 10 are good. Check that ALL fuse holder L.E.D. (light emitting diode) indicators are not lit •...
  • Page 57 • If their corresponding L.E.D.’s (light emitting diodes) do not cycle, check their respective: • temperature sensors (RTD’s [Resistive Temperature Device]) • power connections • electrical circuits (refer to the ADS-464 main electrical wiring diagram) • If the previous items are “OK,” replace the hi-limit controller. 6. “HI-TEMP FAULT” Message PLC MESSAGE “HI-TEMP FAULT”...
  • Page 58 - Check RTD (Resistive Temperature Device) - Check wiring to the RTD (refer to ADS-464 Main Panel Wiring Diagram) - Check wiring to the HI-LIMIT temperature controller (refer to ADS-464 Main Panel Wiring Diagram.) - If RTD measures in the range of 100 ohms (100...
  • Page 59 Sensor distance from targets is 3/16’. The proximity sensor is located in the same area as the tumbler junction box. - Inductive proximity adjustment Tumbler target - Stop motion detector module - Circiut wiring; refer to ADS-464 main panel wiring diagram ADS-464 tumbler junction box wiring diagram...

  • Page 60: Tumbler (Basket) Electrical Malfunctions

    1. Load Door Switch - DS1 The load door switch is located on the left side of the ADS-464 front doors and compromises of four (4) parts: head, arm, body and cord grip device. The head is a rotating type, with a spring arm attached for switch actuation.
  • Page 61 8. EMERGENCY STOP (E-STOP) “Rear Panel” - PB7 This push button switch is normally closed device and is located on the right rear panel of the ADS-464 its function is to shutdown the control voltage to the dryer in the vent it is pressed.
  • Page 62 - Re-test 3. Wiring back to main electrical enclosure - Shut power off to the ADS-464 dryer (main breaker) - Open “disconnects” on terminal 16 and terminal 17 of TB1; These disconnects are located on the bottom of the main electrical enclosure.
  • Page 63 Drum Forward and Reverse Function c) PROBABLE CAUSES; 2.1 Rear panel disconnect plug 2.2 Defective switches 2.3 Wiring back to the main electrical enclosure d) POSSIBLE SOLUTIONS; 1. If either the Drum forward or reverse functions (rear) do not respond. Verify that the rear panel controls disconnect plug is indeed connected.
  • Page 64 - Refer to blueprints: Main electrical panel diagram Tumbler junction box wiring diagram Rear panel controls wiring diagram Re-test 0 UNLOAD 1 Selection PROBABLE CAUSES; 1. Rear panel disconnect plug 2. Defective switch 3. Wiring back to main electrical enclosure POSSIBLE SOLUTIONS;...
  • Page 65 Check wiring on the MAIN ENCLOSURE PANEL (Refer to the ADS-464 Main Panel Wiring Diagram) Check wiring associated with Solenoid Junction Box. See troubleshooting procedures associated with the Solenoid Junction Box. Input L.E.D. (light emitting doide) not illuminating correctly on the PLC (Programmable Logic Controller) indicates that the signal to the PLC input is missing or the PLC is defective.
  • Page 66 - Open the UNLOAD doors and locate the UNLOAD doors switch actuator. - Cycle the switch by hand and have someone watch PLC (Programmable Logic Controller) input indicator #7. It should go “ON” when the switch is down. Do the associated L.E.D.’s (light emitting diode) come “ON”...
  • Page 67 - The target that is attached to the outside of the basket - Stop motion detector module - Circuit wiring; refer to ADS-464 Main Panel Wiring Diagram, ADS-464 Tumbler Junction Box Wiring Diagram If the L.E.D. (light emitting diode) is constantly “ON”...

  • Page 68: Base Section Electrical Malfunctions

    The “Base Junction Box” is located on the right rear of the base section, and title of its wiring diagram is “ADS-464 Base Electrical Junction Box Wiring Diagram.” The base section of electrical components provide:...
  • Page 69 “B” is used as an electrical interlock to the PLC’s 110 VAC output power Lint Chamber Pressure Switch -- PS3 The “Lint Chamber Pressure Sensing Switch” is located on the left rear side of the ADS-464 base. It is an adjustable pressure switch, which incorporate a single-pole-single-throw (SPST) switch. PS3’s electrical function is to close its switch when the present pressure in the lint chamber is sufficient.
  • Page 70 Refer toblueprints: Main Electrical Panel Diagram, Base Electrical Junction Box Wiring Diagram Re-test; verify that the signal is operational 1b) Place the ADS-464 in the UNLOAD position; TILTED FORWARD Actuate the Rear Down Switch by hand Have someone verify that PLC (Programmable Logic Controller) input L.E.D. #12 lights when the switch actuator is down, and is OFF when the actuator is up Does L.E.D.
  • Page 71 2. WIRING BACK TO THE PLC (Programmable Logic Controller), 0, 8 PROBABLE CAUSES; 1. CLOGGED LINT SCREEN OR LINT BAG 2. AIR PRESSURE SETTING 3. AIR PRESSURE SWITCH - PS3 OR WIRING BACK TO THE PLC (Programmable Logic Controller) POSSIBLE SOLUTIONS; 1.

  • Page 72: Pendent Control Malfunctions

    • If the ADS-464 was configured to Unload from the front: Any time this switch is turned to “UNLOAD”, the dryers front doors will open, and its tumbler will tilt to the front.
  • Page 73 • TUMBLER FORWARD “PENDANT” --- PB1 This push button comprises of one normally open switch, and is mechanically interlock with Tumbler Reverse Push Button. • EMERGENCY STOP (E-STOP) “PENDANT” --- PB6 This push button switch is normally open device and its function is to shut down the control voltage to the dryer in the event it is pressed.
  • Page 74 1. Check fuse blown indicator on fuse 4; replace fuse, if necessary and re-test. 2. Check switches using an OHM meter; replace if necessary, and re-test. 3. Refer to ADS-464 Pendant associated wiring diagrams for detailed assemblyand wiring information. Check ALL circiuts back to PLC (Programmable Logic Controller).

  • Page 75: Temperature Sensing

    E. TEMPERATURE SENSING INTRODUCTION There is one (1)) temperature sensing and controlling device in the ADS-464 located in the intake exhaust. The temperature sensing devices are RTD’s (Resistance Temperature Devices), whose resistance changes with temperature information from each RTD is forwarded to a respective 4 to 20 milliampere (4 to 20 mA) transmitter located on the Main Electrical Enclosure Panel.
  • Page 76 • 24 Volt DC Power Supply The 24 volt power supply used in the ADS-464 is an individual grade switching power supply, rated for 120 volts AC input and 24 volts DC output. Features this device incorporates are: •...
  • Page 77 3a) Defective Analog Input Module For Channel 4a) RTD (Resistive Temperature Device) Wiring To The “EXHAUST” 4 to 20 milliamphere (4 to 20 mA) Transmitter 5a) Circuit Wiring To the Analog Input Module b) POSSIBLE SOLUTIONS; 1b) With the control voltage “OFF.” The exhaust RTD (Resistive Temperature Device) probe can be quickly checked, by locating its labeled disconnect in the right hand wire which is located on the main electrical enclosure panel.

  • Page 78: Motors

    Check ALL wiring and ADS-464 connection from the exhaust RTD (Resistive Temperature Device) probe to the exhaust 4 to 20 milliampere (4 to 20 mA) transmitter. Refer to the ADS-464 EXHAUST Temperature Assembly and Wiring Diagram, ADS-464 Main Panel Wiring Diagram.
  • Page 79 PLC output circuit wiring to associated motor starter coil (“A” terminals). 3b) Re-test 4b) Check associated motor starter circuit wiring to and from motor starters, and to the associated motors themselves. Refer to the ADS-464 Main Panel Wiring Diagram; re-test.

  • Page 80: Plc (Programmable Logic Controller) Messages

    G. PLC (Programmable Logic Controller) ERROR MESSAGES The ADS-464 diagnostics messages have been provides to aid troubleshooters in diagnosing and repairing dryer problems. The message are intended to direct one to a particular fault area for further testing; not to diagnose the machine for you.
  • Page 81 ADC 112103 1- 06/18/96-3 2- 06/24/96-25 3* 11/12/99-20...
