AV Controller
DHC-80.2
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHC-80.2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Integra DHC-80.2

  • Page 1 AV Controller DHC-80.2 Instruction Manual...
  • Page 2: Introduction

    Introduction WARNING: WARNING AVIS RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR ELECTRIC DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO The lightning flash with arrowhead symbol, within an RAIN OR MOISTURE.
  • Page 3: Precautions

    Precautions 1. Recording Copyright—Unless it’s for personal use For U.S. models only, recording copyrighted material is illegal without FCC Information for User the permission of the copyright holder. CAUTION: 2. AC Fuse—The AC fuse inside the unit is not user-ser- The user changes or modifications not expressly approved viceable.
  • Page 4: Supplied Accessories

    Supplied Accessories Thank you for purchasing an Integra AV controller. Please read this manual thoroughly before making con- nections and plugging in the unit. Make sure you have the following accessories: Following the instructions in this manual will enable you...
  • Page 5: Table Of Contents

    Changing the Input Display .......... 28 Entering Remote Control Codes........94 Using Headphones............28 Remote Control Codes for Using Activities to Start Easy Macros......28 Integra/Onkyo Components Connected via ..94 Audyssey MultEQ ® XT32 Resetting Remote Mode Buttons........95 Room Correction and Speaker Setup......
  • Page 6: Features

    Features Processing Miscellaneous • THX Ultra2 Plus Certified • (North American models) 40 SIRIUS /FM/AM Pre- sets • HQV-Reon-VX Video Processing with 1080p Video Upscaling of All Video Sources via HDMI • (Australian models) 40 FM/AM Presets • HDMI (Ver.1.4a with Audio Return Channel, 3D), Deep •...
  • Page 7 “HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.” iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
  • Page 8: Front & Rear Panels

    Front & Rear Panels Front Panel North American models Australian models The actual front panel has various logos printed on it. They are not shown here for clarity. The page numbers in parentheses show where you can find the main explanation for each item. On/Standby button Tuning Mode button (➔...
  • Page 9: Display

    Input selector buttons (BD/DVD, VCR/DVR, AUX Input jacks (Video, Audio L/R and Digital) CBL/SAT, Game, PC, AUX, Tape, Tuner, (➔ TV/CD, Phono, Port and NET/USB) (➔ RT/PTY/TP button (Australian models) (➔ USB port (➔ 79, 87) AUX Input HDMI jack (➔...
  • Page 10: Rear Panel

    Rear Panel North American models UNIVERSAL PORT jack 12V TRIGGER OUT (A/B/C) jacks IR IN (A/B) and OUT jacks Composite video, S-Video and analog audio jacks (BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT IN, DIGITAL IN COAXIAL and OPTICAL jacks GAME IN, PC IN, TAPE IN and OUT, TV/CD IN USB port and PHONO IN)
  • Page 11: Remote Controller

    Controlling the AV Controller To control the AV controller, press Receiver to select Receiver mode. You can also use the remote controller to control Integra/Onkyo Blu-ray Disc/DVD player, CD player and other components. See “Entering Remote Control Codes” for more details (➔...
  • Page 12: About Home Theater

    About Home Theater Enjoying Home Theater Thanks to the AV controller’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. With Blu-ray Discs or DVDs, you can enjoy DTS and Dolby Digital.
  • Page 13: Connections

    Connections Connecting the AV Controller Connecting Your Speakers The AV controller is designed to be used with a separate multichannel power amplifier. You connect the AV controller’s PRE OUT jacks to the amplifier’s inputs, and connect your speakers to the amplifier’s speakers terminals. Speaker set- tings such as crossover frequency and distance are set on the AV controller.
  • Page 14 Note Specify crossover frequency for the channel that you want to output in “Speaker Configuration” (➔ 54). If you use the front high and wide speakers at the same time, you need to set the “Front High + Front Wide” setting to “Yes” (➔...
  • Page 15 Using Dipole Speakers Normal speakers Dipole speakers You can use dipole speakers for the surround and surround back speakers. Dipole speakers output the same sound in two directions. TV/screen TV/screen Dipole speakers typically have an arrow printed on them to indicate how they should be positioned.
  • Page 16 Bi-amping the Front Speakers The FRONT L/R and SURR BACK L/R outputs can be used with front speakers and surround back speakers, respec- tively, or bi-amped to provide separate tweeter and woofer feeds for a pair of front speakers that support bi-amping, pro- viding improved bass and treble performance.
  • Page 17 Connecting a Balanced Audio Source You can connect a balanced audio source to the AV controller’s BALANCE L/R INPUT jacks by using two XLR audio 53). If you connect a mono source, use the cables. To use the balanced input, you must assign it to an input selector (➔...
  • Page 18: About Av Connections

    About AV Connections Connected image with AV components HDMI cable Other cables : Video : Audio : Video & Audio AV controller AV controller Blu-ray Blu-ray Disc/DVD player Disc/DVD player Game console Game console TV, projector, etc. TV, projector, etc. •...
  • Page 19: Connecting Your Components With Hdmi

    Note • The AV controller does not support SCART plugs. • The AV controller’s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it’s removed. Push plugs in all the way. Caution •...
  • Page 20: Connecting Your Components

    Connecting Your Components Front Rear Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed (➔ 52, 53). Jack Signal Components Assignable AUX Input Video Composite video Camcorder, etc Audio L/R Analog audio Digital Digital audio...
  • Page 21: Connecting Integra/Onkyo Components

    (➔ 41). Connecting Integra/Onkyo Components Note Step 1: Make sure that each Integra/Onkyo component is con- • Use only cables for connections. cables are supplied nected with an analog audio cable (connection in the with Integra/Onkyo players (DVD, CD, etc.).
  • Page 22: Connecting Antenna

    Connecting Antenna This section explains how to connect the supplied indoor FM antenna and AM loop antenna. The AV controller won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner. Caution (North American (Australian models)
  • Page 23: Which Connections Should I Use

    Which Connections Should I Use? The AV controller supports several connection formats for compatibility with a wide range of AV equipment. The format you choose will depend on the formats supported by your components. Use the following sections as a guide. Video Connection Formats Video component can be connected by using any one of the following video connection formats: composite video, S-Video, PC IN (Analog RGB), component video or HDMI, the latter offering the best picture quality.
  • Page 24 ■ “Monitor Out” setting set to “Analog” Video input signals flow through the AV controller as Video Signal Flow Chart shown, with composite video, S-Video and PC IN (Analog Blu-ray Disc/DVD player, etc. RGB) sources being upconverted for the component video output.
  • Page 25: Turning On & Basic Operations

    Turning On & Basic Operations Turning On/Off the AV Controller On/Standby Standby indicator Standby Receiver Turning On Press On/Standby on the front panel. Press Receiver followed by On on the remote controller. The AV controller comes on, the display lights, and the Standby indicator goes off. Pressing the remote controller’s On again will turn on any components connected via Turning Off Press On/Standby on the front panel.
  • Page 26: Basic Operations

    Basic Operations Displaying Source Information This manual describes the procedure using the remote controller unless otherwise specified. You can display various information about the current input source as follows. (Components connected to the Selecting the Language Used for the UNIVERSAL PORT jack are excluded.) Onscreen Setup Menus Press Receiver followed by Display repeatedly to You can determine the language used for the onscreen...
  • Page 27: Muting The Av Controller

    Muting the AV Controller Use / / / to make the desired selection. ■ Audio You can temporarily mute the output of the AV controller. Performs audio settings. For details, refer to “Using the Audio Settings” (➔ 68). Press Receiver followed by Muting. The output is muted and the MUTING indicator ■...
  • Page 28: Changing The Input Display

    Changing the Input Display Using Activities to Start Easy Macros You can use Activities to execute a number of remote When you connect an -capable Onkyo component, you control operations with a single button. must configure the input display so that can work This button has the following two modes.
  • Page 29: Audyssey Multeq ® Xt32 Room Correction And Speaker Setup

    Turning Off the Components Audyssey MultEQ ® XT32 Room Correction and Speaker Setup Press All Off. With the supplied calibrated microphone, The playback component assigned to the Audyssey MultEQ XT32 automatically determines the last-pressed Activities, the AV controller, and the number of speakers connected, their size for purposes of TV turn off.
  • Page 30 If you use a powered subwoofer(s), adjust the sub- woofer volume level to 75dB. Test tones are played through the subwoofer. Use the volume control on the subwoofer. Caution • When the “Subwoofer” setting is set to “1ch”, the left-hand subwoofer (SW1) alone will be measured. When the “Subwoofer”...
  • Page 31 Changing the Speaker Settings Manually Disconnect the speaker setup microphone. You can manually make changes to the settings found dur- ing Audyssey MultEQ XT32 Room Correction and Note Speaker Setup. • When Audyssey MultEQ ® XT32 Room Correction and Speaker See also: Setup is complete, the “Equalizer”...
  • Page 32: Listening To The Radio

    Listening to the Radio ■ Manual tuning mode This section describes the procedure using the but- tons on the front panel unless otherwise specified. Press Tuning Mode so that the AUTO indicator goes off on the display. Using the Tuner Press and hold Tuning / .
  • Page 33: Presetting Fm/Am Stations

    Presetting FM/AM Stations Listening to SIRIUS Satellite Radio ® (North American models) You can store a combination of up to 40 of your favorite FM/AM radio stations as presets. To listen to Satellite Radio, you’ll need to connect a SIR- IUS Satellite Radio tuner (sold separately) to your Sir- Tune into the FM/AM station that you want to ius-Ready receiver.
  • Page 34 Setting Up the SiriusConnect™ Home Tuner The optional SiriusConnect Home tuner kit includes Display everything for easy home installation, including the Sirius- Connect receiver, indoor/outdoor antenna with 21-foot cable, 8-pin mini DIN connector cable, and an AC power Tuner adapter. See the SiriusConnect Home tuner’s instructions for more information.
  • Page 35 Selecting Channels using the Remote Use / to select “SAT Radio Mode”, and Controller select “SIRIUS”. Pressing cycles through the following options: There are three ways to select SIRIUS Satellite Radio None: channels: Select if you’re not using Satellite Radio. 1.
  • Page 36 ■ Selecting the previously selected channel SIRIUS Parental Lock With SIRIUS Parental Lock, you can lock out channels Press Return to select the previously selected that you do not want to receive and use a 4-digit PIN num- channel. ber to prevent others from unlocking them. Selecting Channels on the AV Controller Press Receiver followed by Setup.
  • Page 37 Use / to select “Parental Lock”, and then press to select a number on the screen, and Enter. then press Enter. The channel number, channel name, and the current Repeat this for each of the four digits in the PIN status are displayed.
  • Page 38 Displaying SIRIUS Satellite Radio Position the SiriusConnect Home antenna so that Information as many bars as possible (up to 3) appear on the Satellite signal strength meter. Press Display repeatedly to cycle through the available information. Antenna Aiming SIRIUS Satellite Terrestrial The following information can be displayed: Channel name and Channel number...
  • Page 39: Using Rds (Australian Models)

    Finding Stations by Type (PTY) Using RDS (Australian models) You can search for radio stations by type. RDS works only in areas where RDS broadcasts are available. Press RT/PTY/TP twice. The current program type appears on the display. When tuned into an RDS station, the RDS indicator lights. Use Preset to select the type of program you want.
  • Page 40 ■ RDS program types (PTY) Type Display None None News reports News Current affairs Affairs Information Info Sport Sport Education Educate Drama Drama Culture Culture Science and technology Science Varied Varied Pop music Pop M Rock music Rock M Middle of the road music Easy M Light classics Light M...
  • Page 41: Recording

    Recording This section explains how to record the selected input source to a component with recording capability, and how to record audio and video from different sources. Connecting a Recording Component Recording Separate AV Sources Here you can record audio and video from completely separate sources, allowing you to overdub audio onto your video recordings.
  • Page 42: Using The Listening Modes

    Using the Listening Modes Selecting Listening Modes See “About Listening Modes” for detailed information about the listening modes (➔ 43). Listening Mode Buttons Press Receiver first. Movie/TV, Music, Game Music Game Movie/TV Movie/TV button This button selects the listening modes intended for use with movies and TV.
  • Page 43: About Listening Modes

    About Listening Modes The AV controller’s listening modes can transform your listening room into a movie theater or concert hall, with high fidelity and stunning surround sound. Explanatory Notes Front speakers Center speaker Surround speakers Listening Mode Subwoofer(s) Surround back speakers Front high speakers Front wide speakers ■...
  • Page 44: Listening Modes

    Listening Modes Listening Mode Description Input Speaker Source Layout Direct In this mode, audio from the input source is output without surround-sound processing. The speaker configuration (presence of speakers), speaker dis- D i r e c t d i o P P o P P tances and A/V Sync settings are enabled, but much of the processing set via Home is disabled.
  • Page 45 Listening Mode Description Input Speaker Source Layout DTS-HD High (Continued from the previous page.) Resolution Audio D T S – H D H R DTS-HD Master Audio D T S – H D M S T R DTS Express D T S E x p r e s s D S D DTS 96/24...
  • Page 46 Listening Mode Description Input Speaker Source Layout Founded by George Lucas, THX develops stringent standards that ensure movies are reproduced in movie theaters and home theaters just as the direc- T H X C i n e m a tor intended. THX Modes carefully optimize the tonal and spatial character- istics of the soundtrack for reproduction in the home-theater environment.
  • Page 47 Listening Mode Description Input Speaker Source Layout Neural Surround This mode employs psychoacoustic frequency domain processing, which allows delivery of a more detailed sound stage, with superior channel separa- N R L S u r r o u n d tion and localization of audio elements.
  • Page 48 Onkyo-Original DSP Listening Modes Listening Mode Description Input Speaker Source Layout Orchestra Suitable for classical or operatic music, this mode emphasizes the surround channels in order to widen the stereo image, and simulates the natural rever- O r c h e s t r a beration of a large hall.
  • Page 49: Advanced Operations

    Advanced Operations Advanced Setup On-screen Setup Menus Common Procedures in Setup Menu This manual describes the procedure using the remote controller unless otherwise specified. Receiver MENU Enter 1. Input/Output Assign / / / 2. Speaker Setup 3. Audio Adjust 4. Source Setup Setup Return 5.
  • Page 50: Input/Output Assign

    Explanatory Notes Note • See “Video Connection Formats” (➔ 23) for charts showing Main Menu Speaker Setup how the “Monitor Out” and “Resolution” settings (➔ affect the video signal flow through the AV controller. ■ Subwoofer ■ Monitor Out 1ch: Analog: Audio signal is outputted from SW1 jack Select this if your TV is connected to the COMPO-...
  • Page 51: Hdmi Input

    ■ Resolution HDMI Input You can specify the output resolution for the HDMI output If you connect a video component to an HDMI input, you and COMPONENT VIDEO MONITOR OUT and have must assign that input to an input selector. For example, if the AV controller upconvert the picture resolution as nec- you connect your Blu-ray Disc/DVD player to HDMI essary to match the resolution supported by your TV.
  • Page 52: Component Video Input

    Component Video Input Note • For composite video, S-Video, and component video upconver- If you connect a video component to a component video sion for the HDMI output, the “Monitor Out” setting must be input, you must assign that input to an input selector. For set to other than “Analog”...
  • Page 53: Digital Audio Input

    Digital Audio Input Analog Audio Input If you connect a component to the AV controller’s analog If you connect a component to a digital audio input, you multichannel input, you must assign that input to an input must assign that input to an input selector. For example, if selector.
  • Page 54: Speaker Setup

    Speaker Setup Note • When you have selected “Yes”, – the “Surround Back” setting is set to “None”. Main menu Speaker Setup – the “Front High” or “Front Wide” setting is set to Some of the settings in this section are set automatically “80Hz(THX)”...
  • Page 55: Level Calibration

    ■ Unit Note feet: “Full Band” can be selected only when “Full Band” is Distances can be set in feet. Range: “0.2ft” to selected in the “Front” setting. “30.0ft” in 0.2 foot steps. If the “Surround” setting is set to “None”, this setting cannot meters: be selected.
  • Page 56 Equalizer Settings THX Audio Setup With the “Surr Back Speaker Spacing” setting, you can This setting is set automatically by specify the distance between your surround back speakers. ® Audyssey MultEQ XT32 Room Correction and If you’re using a THX-certified subwoofer, set the “THX Speaker Setup function (➔...
  • Page 57: Audio Adjust

    ■ Preserve THX Settings Input Channel Yes: Left + Right: Audyssey Dynamic EQ ® Both the left and right channels are output. ® Audyssey Dynamic Volume / Dolby Volume will Left: not be active in THX listening mode. Only the left channel is output. Right: Audyssey Dynamic EQ / Only the right channel is output.
  • Page 58 ■ ■ PLIIz Height Gain Volume Leveler The Height Gain Control in Dolby Pro Logic IIz Off: enables the listener to select how much gain is applied Volume Leveler off. to the front high speakers. There are three settings, Low: “Low”, “Mid”...
  • Page 59: Source Setup

    Audyssey DSX™ Note • If the “Subwoofer” setting is set to “No” (➔ 54), this setting ■ Soundstage cannot be selected. –3dB to Reference to +3dB ■ With this setting, you can adjust the soundstage when using DAC Direct Audyssey DSX™. Off: Note DSD signals are processed by the DSP.
  • Page 60 ■ Reference Level • When “Dynamic Volume” is set to effective, “Equalizer” is set to “Audyssey” (➔ 56) and “Dynamic EQ” is set to “On”. ® Audyssey Dynamic EQ Reference Level Offset When “Dynamic EQ” is set to “Off”, “Dynamic Volume” 0dB: becomes “Off”...
  • Page 61: A/V Sync

    IntelliVolume Name input area ■ IntelliVolume 4-4. Name Edit BD/DVD Name –12dB to 0dB to +12dB in 1 dB steps. D/DVD With IntelliVolume, you can set the input level for each input selector individually. This is useful if one of your –...
  • Page 62: Picture Adjust

    ■ Picture Adjust Picture Mode Custom: Using “Picture Adjust”, you can adjust the picture qual- All settings can be performed manually. ity and reduce any noise appearing on the screen. ISF Day: To view the TV picture while setting, press Enter. To Setting when a room is bright.
  • Page 63 ■ Mosquito NR *2*3*4*6 1080p/24: Select this for 1080p output at 24 frames per second Off: and video conversion as necessary. When the “Mon- Mosquito noise reduction off. itor Out” is set to “Analog”, this setting will be Low: changed to “1080i”. Low mosquito noise reduction.
  • Page 64: Listening Mode Preset

    ■ ■ Blue Contrast *2*4 Analog/PCM With this setting, you can specify the listening mode to –50 to 0 to +50 With this setting you can adjust blue contrast. “–50” be used when an analog (CD, TV, LD, VHS, MD, turn- is the least.
  • Page 65: Hardware Setup

    1, 2, or 3 Last, – dB, –81dB to +18dB (Relative display) When several Integra/Onkyo components are used in With this preference, you can specify the volume set- the same room, their remote ID codes may overlap. To ting to be used each time the AV controller is turned differentiate the AV controller from the other compo- nents, you can change its remote ID from “1”, to “2”...
  • Page 66 ■ HDMI HDMI Control(RIHD) Off: ■ Audio TV Out disabled. Off: The audio is not output from the HDMI output. enabled. This function allows -compatible components The audio is output from the HDMI output. connected via HDMI to be controlled with the AV control- This preference determines whether the incoming audio (➔...
  • Page 67 Off: • Perform the firmware update only when an announcement is TV Control disabled. posted on the Integra web site. See the Integra web site for latest information. • It takes about 60 minutes to complete the firmware update. TV Control enabled.
  • Page 68: Lock Setup

    Speaker Levels Lock Setup You can adjust the volume of each speaker while listening With this preference, you can protect your settings by to an input source. locking the setup menus. These temporary adjustments are cancelled when the AV Main menu Lock Setup controller is set to Standby.
  • Page 69 Late Night Screen Centered Dialog With the Late Night function, you can reduce the dynamic “Screen Ctr Dialog” is a function for moving the Center range of Dolby Digital material so that you can still hear image of dialog etc. upwards through use of the front high quiet parts even when listening at low volume lev- speaker to fix the image to the display height.
  • Page 70 Audio Selector Setting the Incoming Digital Signal (Fixed Mode) You can set priorities of audio output when there are both digital and analog inputs. By pressing Enter while selecting “HDMI”, “COAX”, “OPT” in the “Audio Selector”, you can specify the input ■...
  • Page 71: Net/Usb

    NET/USB About NET Connecting the AV Controller The AV controller is network-ready, which means you can To connect the AV controller to your home network, plug hook it up to your home network with a standard Ethernet one end of a shielded CAT5 Ethernet cable into the AV cable and enjoy the music files stored on your computer or controller’s ETHERNET port, and plug the other end into media server.
  • Page 72: Listening To Internet Radio

    Listening to Internet Radio Note • When the NETWORK indicator flashes, confirm that the To receive Internet radio, you must connect the AV con- Ethernet cable is firmly connected to the AV controller. troller to a network with Internet access (➔...
  • Page 73: Playing Music Files On A Server

    Enter the preset name and Internet address (URL). Display WEB Setup Menu Unit Information Preset Internet Radio Network setting Customer Setting Save Refresh Internet Radio Information Name NET/USB Tuner Internet Radio Delete Delete Delete Click “Save” to save the Internet radio station. Enter / / / Registering Presets...
  • Page 74 Random Playback Use / to select an item, and then press Enter. The Random function can only be set while the PLAY A list of music files appears. screen is displayed. To play songs in random order, during playback (or while All Music playback is paused or stopped), press Random.
  • Page 75 ■ Supported Audio File Formats AAC stands for MPEG-2/MPEG-4 Audio. For server playback, the AV controller supports the fol- • Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, lowing music file formats: MP3, WMA, WAV, FLAC, Ogg 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz, Vorbis, AAC and LPCM.
  • Page 76: Remote Playback From Media Server/Personal Computer

    Server Requirements Remote Playback from Media Server/Personal Computer The AV controller can play digital music files stored on a computer or media server and supports the following tech- Remote Playback means you can play the music files nologies: stored on the DLNA-certified device such as media server •...
  • Page 77: Network Settings

    Using Remote Playback Adjusting the Volume You can adjust the volume of your AV controller by adjusting the volume bar in the “Remote playback” Start Windows Media Player 12. window. The default maximum volume for the AV Before remote playback, setup on Windows Media controller is 82 (0dB).
  • Page 78 ■ IP Address Use / to select “Hardware Setup”, and then If you set the “DHCP” setting to “Disable”, you must press Enter. specify an IP address. Enter a static IP address provided The “Hardware Setup” menu appears. by your ISP. The IP address must be within the following ranges.
  • Page 79: About Usb

    About USB Display USB can be used to play music files stored on USB mass storage devices (e.g., USB flash drives and MP3 players), which can be plugged into the AV controller’s USB port. NET/USB See “Controlling iPod” for iPod connection (➔...
  • Page 80 Random Playback Use / to select a music file, and press Enter or The Random function can only be set while the PLAY to start playback. screen is displayed. Playback starts and the following screen appears. To play songs in random order, while the list of songs is displayed, press Random.
  • Page 81: Multi Zone

    Multi Zone In addition to your main listening room, you can also enjoy playback in the other room, or as we call Multi Zone. And, you can select a different source for each room. Zone 2 Video Output Connecting Zone 2 The AV controller features a composite video output for Zone 2 speakers must be connected to an amp in Zone 2.
  • Page 82: Connecting Zone 3

    Connecting Zone 3 Setting the Multi Zone Zone 3 speakers must be connected to an amp in Zone 3. Press Receiver followed by Setup. The main menu appears onscreen. Connecting Your Zone 3 Speakers You can enjoy 2-channel stereo playback in Zone 3 and a •...
  • Page 83: Using Zone 2/3

    ■ Zone 2 Power On Volume, Using Zone 2/3 Zone 3 Power On Volume Last, Min, 1 to 99 or Max (Absolute display) This section explains how to turn Zone 2/3 on and off, how to select an input source for Zone 2/3, and how to Last, –...
  • Page 84 Controlling Zone 2/3 with the Remote Adjusting the Volume for Zones Controller On the remote controller, press Zone repeatedly, Standby and then use VOL / . Zone On the AV controller, press Zone 2 or Zone 3 (the Zone 2/3 indicator and Zone 2/3 selector on Input the display flashes) and press Zone Level / Selector...
  • Page 85: Using The 12V Triggers

    Using the 12V Triggers Use / to select “12V Trigger A, B, or C Setup” and then press Enter. The 12V triggers A, B, and C can be used to turn on 12V The “12V Trigger A, B, or C Setup” screen trigger-capable components automatically when they are appears.
  • Page 86: Using The Remote Controller In Zone 2/3 And Multiroom Control Kits

    Using a Multiroom Kit with a Cabinet Using the Remote Controller in Zone 2/3 and Multiroom Control Kits In this setup, the IR receiver picks up the infrared signals from the remote controller and feeds them to the AV con- To control the AV controller with the remote controller troller located in the cabinet via the connecting block.
  • Page 87: Controlling Ipod & Other Components

    Controlling iPod & Other Components Controlling iPod Press NET/USB repeatedly to select the USB Connecting the iPod Directly to the input. USB Port Connect the USB cable that comes with the USB can be used to play music files stored on iPod/iPhone to the USB port at the front of the AV iPod/iPhone, which can be plugged into the AV control- controller.
  • Page 88: Connecting An Onkyo Dock

    Extended Mode control The content information is displayed (lists are displayed) • Songs • Composers on the on-screen, and you can select and manipulate the • Shuffle Songs content while looking at the screen. • Now Playing Top screen list: Displays a list.
  • Page 89: Using The Onkyo Dock

    ■ Using Your iPod models Alarm Clock Using the Onkyo Dock You can use your iPod models Alarm Clock function to automatically turn on your iPod and the AV controller at a Dock is sold separately. specified time. The AV controller’s input source will auto- For the latest information on the Onkyo Dock compo- matically be set to the Port selector.
  • Page 90: Controlling Your Ipod

    ■ System Function ■ Operating Notes Auto Power On • Use the AV controller’s volume control to adjust the playback If you press the remote controller’s while the AV con- volume. troller is on Standby, the AV controller will automatically •...
  • Page 91 ✔: Available buttons Press the appropriate Remote Mode first. Onkyo Dock Buttons ✔ On, Standby ✔ Top Menu ✔ ✔ / / / Enter ✔ ✔ Playlist ✔ ✔ ✔ ✔ Repeat ✔ ✔ Random ✔ ✔ Play Mode ✔ ✔...
  • Page 92: Controlling Other Components

    For details on controlling these components, see the pages indicated. Use / / / to select a character, and then press Enter. BD/DVD Integra/Onkyo Blu-ray Disc player (➔ Repeat this step from the 1st character to the 3rd Tape Integra/Onkyo cassette tape deck with character of the brand name.
  • Page 93 When you searched for the model, a message “Successful” will appear. Now the transfer is • If you cannot access the database, a message “Cannot successful! connect to database.” will appear. Press Enter to Go to step 15. return to the previous step. •...
  • Page 94: Entering Remote Control Codes

    • The remote control codes provided are correct at the time of printing, but are subject to change. If you want to control an Integra/Onkyo component by pointing the remote controller directly at it, or you want to control an Integra/Onkyo component that’s not connected , use the following remote control codes: •...
  • Page 95: Resetting Remote Mode Buttons

    Resetting Remote Mode Buttons Controlling Other Components You can reset a Remote Mode to its default remote con- By pressing Remote Mode that’s been programmed with trol code. the remote control code for your component, you can con- trol your component as below. While holding down Remote Mode that you want For details on entering a remote control code for other to reset, press and hold down Home until Remote...
  • Page 96 ✔: Available buttons Press the appropriate Remote Mode first. Components Buttons ✔ ✔ ✔ ✔ ✔ ✔ On, Standby ✔ , Input, TV VOL / ✔ ✔ ✔ Guide ✔ Top Menu ✔ ✔ ✔ ✔ ✔ / / / Enter ✔...
  • Page 97: Activities Setup

    ■ Source Power On Activities Setup Enable: Via onscreen menu, you can specify what actions will be Source component will turn on. taken by the Easy macro command in the Easy macro Disable: mode (➔ 28). Source component will not turn on. This option enables the source component to turn Press Receiver followed by Setup.
  • Page 98: Learning Commands

    Press Enter. Learning Commands A message for transfer will appear. The AV controller’s remote controller can learn the com- 8–2. Activities Setup My Movie mands of other remote controllers. By transmitting, for example, the Play command from your CD player’s remote controller, the remote controller can learn it, and Now we are ready to transfer data to the remote.
  • Page 99: Using Normal Macros

    Press the buttons whose actions you want to pro- are preprogrammed with commands for controlling gram into the macro in the order you want them Integra/Onkyo CD players, cassette decks, and DVD players. performed. However, they can learn new commands, and you can restore the For the CD example above, you’d press the following...
  • Page 100: Others

    Others Troubleshooting If you have any trouble using the AV controller, look for a Audio solution in this section. If you can’t resolve the issue your- ■ self, contact the dealer from whom you purchased this There’s no sound, or it’s very quiet unit.
  • Page 101 ■ ■ Only the center speaker produces sound The speaker volume cannot be set as required (The volume cannot be set to Max(100.0)) If you use the Dolby Pro Logic IIx Movie, Dolby Pro — Logic IIx Music, or Dolby Pro Logic IIx Game lis- Check to see if a maximum volume has been set.
  • Page 102 On your TV, make sure that the video input to which — the AV controller is connected is selected. If it’s an Integra/Onkyo component, make sure that If your TV is connected to the analog outputs, set the cable and analog audio cable are connected “Monitor Out”...
  • Page 103 Reduce the number of playback devices on the network, upgrade your network, or use a switch To control an Integra/Onkyo component that’s con- instead of a hub. nected via , point the remote controller at the AV controller.
  • Page 104 ■ functions don’t work Important Note Regarding Video Playback To use , you must make an connection and an The AV controller can upconvert component video, analog audio connection (RCA) between the compo- S-Video, and composite video sources for display on a TV nent and AV controller, even if they are connected digitally.
  • Page 105: Specifications

    Specifications ■ Amplifier Section HDMI Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7, Input Sensitivity and Impedance AUX INPUT 200 mV/47 kΩ (LINE) Output OUT MAIN, OUT SUB 2.5 mV/47 kΩ (PHONO MM) Video Resolution 1080p Rated RCA Output Level and Impedance...
  • Page 106: About Hdmi

    About HDMI Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, Blu-ray Disc/DVD players, set-top boxes, and other video compo- nents. Until now, several separate video and audio cables have been required to connect AV components. With HDMI, a single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichan- nel digital audio, and multichannel PCM).
  • Page 107: Using An Rihd-Compatible Tv, Player, Or Recorder

    , which stands for Remote Interactive over HDMI, is the name of the system control function found on Integra/Onkyo components. The AV controller can be used with CEC (Consumer Electronics Control), which allows sys- tem control over HDMI and is part of the HDMI standard. CEC provides interoperability between various components, however, operation with components other than -compatible components cannot be guaranteed.
  • Page 108 ■ How to connect and setup Confirm the settings. 1. Turn on the power for all connected components. Confirm the connecting and setting. 2. Turn off the power of the TV, and confirm that 1. Connect the HDMI OUT MAIN jack to the the power of the connected components is turned HDMI input jack of the TV.
  • Page 109: Firmware Update

    Note that the Firmware Update option will be grayed prospective profits, loss of data, or for any other reason out about 50 seconds after the AV controller is whatsoever. turned on. Please wait. Select “via NET” and press Enter. See the Integra web site for latest information.
  • Page 110 Case6: If you do not have a wired connection to the network, Troubleshooting 112). please contact Integra Support (➔ Case1: If “No Update” is displayed on the front display of the AV controller, the firmware has already been updated. You do not need to do anything further.
  • Page 111: Updating The Firmware Via Usb

    USB storage device, Press On/Standby to turn on the AV controller. remove it. Congratulations!! Now you have the latest firm- Download the firmware file from the Integra ware on the AV controller. web site. The file name is as follows: ONKAVR0001_*******.zip Unzip the downloaded file.
  • Page 112 USB storage device, or the firm- ware file is for other model. Retry download following instructions at the support website. If the error persists, please contact Integra Support and provide the error code. Others Retry the update procedure from the begin- ning.
  • Page 113: Video Resolution Chart

    Video Resolution Chart The following tables show how video signals at different resolutions are output by the AV controller. NTSC/PAL ✔: Output Output HDMI 1080p/24 1080p 1080i 720p 480p/ 480i/ SXGA XGA SVGA Input 576p 576i ✔ ✔ ✔ ✔ ✔...
  • Page 114 Memo...
  • Page 115 Memo...
  • Page 116 Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Y1007-1 Tel: 072-831-8023 Fax: 072-831-8163 SN 29400447 (C) Copyright 2010 ONKYO CORPORATION Japan.
