AV Controller

DRC-R1

Hookup

Step1: Speaker Layout ............................................................3

Step2: Connecting Speakers via a Power Amplifier ................9

Step3: Connect the TV ..........................................................12

Step4: Connect the AV Components .....................................14

Step5: Multi-zone Connection ...............................................18

Basic Manual

Step6: Connect Other Cables ................................................21

Setup

Step7: Power On & Initial Setup ............................................22

HDMI Setup ...........................................................................23

Playback

Basic Playback ......................................................................24

Network Functions .................................................................25

Others ....................................................................................26

Part Names

Front Panel ............................................................................29

Rear Panel ............................................................................30

Remote Controller .................................................................31

Display ...................................................................................31

This manual includes information needed when starting up and also

instructions for frequently used operations. The "Advanced Manual" is

available on the internet with details about the playback features/

listening modes/settings details, specifications, and troubleshooting.

The Advanced Manual is created in a format that makes it easy to read

on a PC or Smartphone.

http://integraworldwide.com/manual/drcr1/adv/en.html

Advanced Manual found here

Table of Contents

Need help?

Do you have a question about the DRC-R1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Integra DRC-R1

Page 1: Table Of Contents
> Before start > Hookup > Setup > Playback > Part Names AV Controller DRC-R1 Hookup Step1: Speaker Layout ............3 Step2: Connecting Speakers via a Power Amplifier ....9 Step3: Connect the TV ............12 Step4: Connect the AV Components ........14 Step5: Multi-zone Connection ..........18 Basic Manual Step6: Connect Other Cables ..........21...
Page 2 > Before start > Hookup > Setup > Playback > Part Names What's in the box 1. Main unit 2. Remote controller (RC-913R) ×1, Batteries (AAA/R03) ×2 3. Indoor FM antenna ×1 4. AM loop antenna ×1 5. Speaker setup microphone ×1 6.
Page 3: Step1: Speaker Layout
> Before start > Hookup > Setup > Playback > Part Names Step1: Speaker Layout 7.1-Channel System Front speakers output front stereo sound and a center speaker outputs center sound such as dialogs and vocals. Surround speakers create back sound field. Powered subwoofer reproduces bass sounds and creates rich sound field.
Page 4 > Before start > Hookup > Setup > Playback > Part Names Height Speakers; Front High Speakers/ Rear High Speakers These are types of height speakers. Furthermore, by 3´ (0.9 m) installing height speakers, you can select the Dolby or more Atmos listening mode, which realizes the most up-to-date 3D sound including overhead sounds, when the input format is Dolby Atmos.
Page 5 > Before start > Hookup > Setup > Playback > Part Names Height Speakers; Ceiling Speakers These are types of height speakers. Furthermore, by installing height speakers, you can select the Dolby Atmos listening mode, which realizes the most up-to-date 3D sound including overhead sounds, when the input format is Dolby Atmos.
Page 6 > Before start > Hookup > Setup > Playback > Part Names Height Speakers; Dolby Enabled Speakers (Dolby Speakers) These are types of height speakers. Dolby enabled speakers are special speakers designed to face the ceiling so that sound is heard after bouncing off the ceiling so that sound appears to be coming from overhead.
Page 7 > Before start > Hookup > Setup > Playback > Part Names Bi-Amping the Speakers It is possible to connect front speakers supporting Bi- Amping to improve quality of the bass and treble. The effects and placements for speakers are the same as for a system that doesn't use Bi-Amping speakers.
Page 8 > Before start > Hookup > Setup > Playback > Part Names Speaker combinations In any of the combinations, up to two powered subwoofers can be connected. SURROUND Speaker Channels FRONT CENTER SURROUND HEIGHT 1 HEIGHT 2 Bi-AMP BACK 2.1 ch 3.1 ch 4.1 ch 5.1 ch...
Page 9: Step2: Connecting Speakers Via A Power Amplifier
> Before start > Hookup > Setup > Playback > Part Names Step2: Connecting Speakers via a Power Amplifier PRE OUT (RCA) Jacks Use an analog audio cable to connect the power amplifier to the PRE OUT (RCA) jacks on this unit. For details on Subwoofer with built-in how to connect the speakers and the power amplifier, amplifier...
Page 10 > Before start > Hookup > Setup > Playback > Part Names PRE OUT (XLR) Jacks Subwoofer with built-in amplifier Use a balanced XLR cable to connect the powered amplifier to the PRE OUT (XLR) jacks on this unit. For details on how to connect the speakers and the amplifier, refer to the instruction manual of the power amplifier.
Page 11 > Before start > Hookup > Setup > Playback > Part Names Connections with Bi- Amping speakers The illustration at left shows an example of connection using the PRE OUT (RCA) jacks. Refer to the illustration at left also when connecting using the PRE OUT (XLR) jacks.
Page 12: Step3: Connect The Tv
> Before start > Hookup > Setup > Playback > Part Names Step3: Connect the TV TV-1 (ARC TV) This describes the connections for a TV that supports the ARC (Audio Return Channel) feature. By connecting with a single HDMI cable, you can not only output the video input to this unit to the TV, but you can also play the sound from the TV through this unit.
Page 13 > Before start > Hookup > Setup > Playback > Part Names TV-2 (Non-ARC TV) This describes the connections for a TV that does not support the ARC (Audio Return Channel) feature. By connecting with both an HDMI cable and a digital optical cable, you can not only output the video input to this unit to the TV, but you can also play the sound from the TV through this unit.
Page 14: Step4: Connect The Av Components
> Before start > Hookup > Setup > Playback > Part Names Step4: Connect the AV Components HDMI AV Components This is an example of connection with an AV component that has an HDMI jack. With connection to an AV component that conforms with the CEC (Consumer Electronics Control) standard, you can use features such as the HDMI CEC feature that links with the input selector,...
Page 15 > Before start > Hookup > Setup > Playback > Part Names Non-HDMI AV Components This is an example of connection with an AV component that does not have an HDMI jack. Make the connections to the AV component to match the jacks it has. When video input connection is to the BD/DVD jack, the audio input connection should also be to the BD/DVD jacks, and so on, so that you connect the video input jacks to the...
Page 16 > Before start > Hookup > Setup > Playback > Part Names Audio Components Example of a connection with an Audio Component. Connect a CD player using a digital optical cable or analog audio cable. You can also connect a turntable that has an MM-type cartridge to the PHONO jack.
Page 17 > Before start > Hookup > Setup > Playback > Part Names Component Video Monitor Use a component video cable to connect a TV or projector that has component video input jacks rather than an HDMI input jack. To output video from the COMPONENT VIDEO OUT jacks, you must connect the external AV components using a component video cable.
Page 18: Step5: Multi-Zone Connection
> Before start > Hookup > Setup > Playback > Part Names Step5: Multi-zone Connection ZONE 2 TV You can enjoy content from a Blu-ray Disc player on a TV equipped with an HDMI input jack in the separate room (ZONE 2) by playing a Blu-ray Disc player in the main room (where this unit is located), or play the content from another AV component.
Page 19 > Before start > Hookup > Setup > Playback > Part Names ZONE 2 PRE/LINE OUT You can enjoy audio in the separate room by, for example, playing a Blu-ray Disc player in the main room (where this unit is located) and listening to internet radio in the separate room (ZONE 2).
Page 20 > Before start > Hookup > Setup > Playback > Part Names ZONE 3 PRE/LINE OUT Along with the main room and ZONE 2, you can also enjoy audio in yet another room (ZONE 3). Connections with an AV component To output the audio of an external AV component to ZONE 3, connect using an analog audio cable.
Page 21: Step6: Connect Other Cables
> Before start > Hookup > Setup > Playback > Part Names Step6: Connect Other Cables Antenna Hookup Move the antenna around while playing the radio to find (North American (Australian models) the position with the best reception. Use a thumb tack or models) similar to attach the indoor FM antenna to a wall.
Page 22: Step7: Power On & Initial Setup
> Before start > Hookup > Setup > Playback > Part Names Step7: Power On & Initial Setup 1. AccuEQ Room Calibration Place the supplied speaker setup microphone in the listening position, measure the test tones emitted by the speakers, then the unit automatically sets the optimum volume level for each speaker, the crossover frequencies, and the distance from the listening position.
Page 23: Hdmi Setup
> Before start > Hookup > Setup > Playback > Part Names HDMI Setup 2. Source Connection 5. Audio Return Channel HDMI CEC Make this setting to enable the control feature for devices complying with the CEC standard. This is set to on Check that each input source is connected correctly.
Page 24: Basic Playback
> Before start > Hookup > Setup > Playback > Part Names Basic Playback AV Component Playback Digital and DTS-HD Master Audio is displayed Game buttons. If content you play is not for DTS-HD Master Audio. The output is Stereo supported by the listening mode you selected for 2-channel input signals.
Page 25: Network Functions
> Before start > Hookup > Setup > Playback > Part Names Network Functions Network Services Player 11 or 12 network servers or NAS that are compatible with home network functionality. You may need to make some 1. Switch the input on the TV to that assigned to ®...
Page 26: Others
NET on this unit. Next, click the AirPlay icon remote controller and then press Clear (e) while the Integra DRC-XX in iTunes, select this unit from the list of devices displayed, preset number is flashing. When deleted, the number on and start play of a music file.
Page 27 > Before start > Hookup > Setup > Playback > Part Names Multi-zone switches. speakers of the TV. 0 DSD and Dolby TrueHD audio signals are not output to ZONE 2/ZONE 3 when Settings Play selected with the "NET" input selector. Settings are required in Initial Setup, "4.
Page 28 > Before start > Hookup > Setup > Playback > Part Names Others When the unit is operating erratically When the subwoofer produces no sound To adjust the sound quality Try restarting the unit If the setting of the front speakers is "Full Band" and during 2ch input such as from the TV or music, the low range It is possible to enhance or moderate the bass and treble Restarting the unit may help it operate more smoothly.
Page 29: Front Panel
> Before start > Hookup > Setup > Playback > Part Names Front Panel 1. Í On/Standby button: Turns the unit on or into standby 7. Listening Mode buttons: Select the listening mode. 16.Zone 2/Zone 3 buttons: Controls the multi-zone function. mode.
Page 30: Rear Panel
> Before start > Hookup > Setup > Playback > Part Names Rear Panel 13 14 1. COMPONENT VIDEO IN/OUT jacks: Transfer the video as a TV or projector. 14.IR IN/OUT port: Allows you to connect a multiroom signals of an AV component with a component video cable. 8.
Page 31: Remote Controller
> Before start > Hookup > Setup > Playback > Part Names Remote Controller Display 1. Í button: Turns the unit on or into standby mode. 2. Input selector buttons: Switches the input to be played. 3. Q (Quick Menu) button: You can perform common settings on the TV screen.
Page 32 License and Trademark Information performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. AccuEQ, Music Optimizer, RIHD and WRAT are trademarks of Onkyo Corporation. Please note that the use of this accessory with iPod, iPhone or iPad may affect wireless performance.
Page 36 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com <Germany> Gutenbergstrasse 3, 82178 Puchheim, Germany Tel: +49-8142-4401-0 Fax: +49-8142-4208-213 http://www.integra.eu <PRC> 302, Building 1, 20 North Chaling Rd., Xuhui District, Shanghai, China 200032, Tel: +86-21-52131366 Fax: +86-21-52130396 http://www.integra.com.cn F1703-1 (C) Copyright 2016 Onkyo &...
