AV Controller
DHC-40.2
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHC-40.2 and is the answer not in the manual?

Questions and answers

Related Manuals for Integra DHC-40.2

Summary of Contents for Integra DHC-40.2

  • Page 1 AV Controller DHC-40.2 Instruction Manual...

  • Page 2: Important Safety Instructions

    AVIS WARNING: WARNING RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR ELECTRIC DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO The lightning flash with arrowhead symbol, within an RAIN OR MOISTURE.

  • Page 3: Precautions

    Precautions 1. Recording Copyright—Unless it’s for personal use For U.S. models only, recording copyrighted material is illegal without FCC Information for User the permission of the copyright holder. CAUTION: 2. AC Fuse—The AC fuse inside the unit is not user-ser- The user changes or modifications not expressly approved viceable.

  • Page 4: Supplied Accessories

    Supplied Accessories Thank you for purchasing an Integra AV controller. Please read this manual thoroughly before making con- nections and plugging in the unit. Make sure you have the following accessories: Following the instructions in this manual will enable you...

  • Page 5: Table Of Contents

    Using the Sleep Timer..........25 Entering Remote Control Codes........85 Using the Home Menu..........25 Remote Control Codes for Changing the Input Display .......... 26 Integra/Onkyo Components Connected via ..85 Using Headphones............26 Resetting Remote Mode Buttons........86 Using Easy Macros ............26 Resetting the Remote Controller ........

  • Page 6: Features

    Features Processing • THX Ultra2 Plus Certified • HDMI Video Upscaling (to 1080p Compatible) with THX and the THX logo are trademarks of THX Ltd. which Faroudja DCDi Cinema Enhancement may be registered in some jurisdictions. All rights reserved. • HDMI (Ver.1.4a with Audio Return Channel, 3D), Deep- Color, x.v.Color , Lip Sync, DTS -HD Master Audio,...
  • Page 7 Rhapsody and the Rhapsody logo are registered trademarks of RealNetworks, Inc. THX Ultra2 Plus Before any home theater component can be THX Ultra2 Plus certified, it must pass a rigorous series of quality and performance tests. Only then can a product feature the THX Ultra2 Plus logo, which is your guarantee that the Home Theater products you purchase will give you superb performance for many years to come.

  • Page 8: Front & Rear Panels

    Front & Rear Panels Front Panel The actual front panel has various logos printed on it. They are not shown here for clarity. The page numbers in parentheses show where you can find the main explanation for each item. On/Standby button Tuning, Preset 30), arrow and Enter buttons (➔...

  • Page 9: Display

    Display For detailed information, see the pages in parentheses. Speaker/channel indicators Headphone indicator (➔ Listening mode and format indicators (➔ 38, 62) Audyssey indicator (➔ 27, 50) Dynamic EQ indicator (➔ NETWORK indicator (➔ 65, 66, 70) Dynamic Vol indicator (➔...

  • Page 10: Rear Panel

    Rear Panel GND screw DIGITAL IN COAXIAL and OPTICAL jacks RS232 terminal SIRIUS antenna jack Terminal for control. Composite, S-Video and analog audio jacks REMOTE CONTROL jack (BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT IN, GAME IN, PC IN, TV/CD IN and PHONO IN) ETHERNET port Multichannel input jacks UNIVERSAL PORT jack...

  • Page 11: Remote Controller

    Remote Controller Controlling the AV Controller To control the AV controller, press Receiver to select Receiver mode. You can also use the remote controller to control Onkyo Blu-ray Disc/DVD player, CD player and other components. See “Entering Remote Control Codes” for more 85).

  • Page 12: About Home Theater

    About Home Theater Enjoying Home Theater Thanks to the AV controller’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. With Blu-ray Discs or DVDs, you can enjoy DTS and Dolby Digital.

  • Page 13: Connecting The Av Controller

    Connecting the AV Controller Number of speakers Connecting Your Speakers ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ Front speakers ✔ ✔ ✔ ✔ ✔ ✔ The AV controller is designed to be used with a separate Center speaker ✔ ✔ ✔ ✔ ✔ ✔ multichannel power amplifier.
  • Page 14 Using Dipole Speakers Normal speakers Dipole speakers You can use dipole speakers for the surround and surround back speakers. Dipole speakers output the same sound in two directions. TV/screen TV/screen Dipole speakers typically have an arrow printed on them to indicate how they should be positioned.

  • Page 15: Bi-Amping The Front Speakers

    Bi-amping the Front Speakers The FRONT L/R and SURR BACK L/R outputs can be used with front speakers and surround back speakers, respec- tively, or bi-amped to provide separate tweeter and woofer feeds for a pair of front speakers that support bi-amping, pro- viding improved bass and treble performance.

  • Page 16: About Av Connections

    About AV Connections Connected image with AV components HDMI cable Other cables : Video & Audio : Video : Audio AV controller AV controller Blu-ray Disc/ Blu-ray Disc/ DVD player DVD player Game console Game console TV, projector, etc. TV, projector, etc. •...

  • Page 17: Connecting Your Components With Hdmi

    Connecting Your Components with HDMI VCR or DVD recorder/Digital Video Recorder Game console TV, projector, etc. Personal computer Blu-ray Disc/DVD player Camcorder Satellite, cable, set-top box, etc. Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed 46).

  • Page 18: Connecting Your Components

    Connecting Your Components Front Rear Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed (➔ 47). Jack Signal Components Assignable AUX Input Video Composite video Camcorder, etc Audio L/R Analog audio ✔...

  • Page 19: Connecting Integra/Onkyo Components

    (➔ 37). Connecting Integra/Onkyo Components Note Step 1: Make sure that each Integra/Onkyo component is con- • Use only cables for connections. cables are supplied with Integra/Onkyo players (DVD, CD, etc.). nected with an analog audio cable (connection...

  • Page 20: Connecting Antenna

    Connecting Antenna This section explains how to connect the supplied indoor FM antenna and AM loop antenna. The AV controller won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner. Caution •...

  • Page 21: Which Connections Should I Use

    Which Connections Should I Use? The AV controller supports several connection formats for compatibility with a wide range of AV equipment. The format you choose will depend on the formats supported by your components. Use the following sections as a guide. Video Connection Formats Video component can be connected by using any one of the following video connection formats: composite video, S-Video, PC IN (Analog RGB), component video or HDMI, the latter offering the best picture quality.
  • Page 22 ■ “Monitor Out” setting set to “Analog” Video input signals flow through the AV controller as shown, Video Signal Flow Chart with composite video, S-Video and PC IN (Analog RGB) Blu-ray Disc/DVD player, etc. sources being upconverted for the component video output. Use this setting if you connect the AV controller’s COM- PONENT VIDEO MONITOR OUT to your TV.

  • Page 23: Turning On/Off The Av Controller

    Turning On/Off the AV Controller On/Standby Standby indicator Standby Receiver Front panel Remote controller Turning On Press On/Standby on the front panel. Press Receiver followed by On on the remote controller. The AV controller comes on, the display lights, and the Standby indicator goes off. Pressing the remote controller’s On again will turn on any components connected via Turning Off Press On/Standby on the front panel.

  • Page 24: Basic Operations

    Basic Operations Displaying Source Information This manual describes the procedure using the remote controller unless otherwise specified. You can display various information about the current input source as follows. (Components connected to the Selecting the Language Used for the UNIVERSAL PORT jack are excluded.) Onscreen Setup Menus Press Receiver followed by Display repeatedly to You can determine the language used for the onscreen...

  • Page 25: Muting The Av Controller

    Muting the AV Controller Use / / / to make the desired selection. ■ Audio You can temporarily mute the output of the AV controller.  You can change the following settings: “Bass”, “Treble”, “Subwoofer Level”, “Center Level”, Press Receiver followed by Muting. “Dynamic EQ”, “Dynamic Volume”, “Late The output is muted and the MUTING indicator Night”, “Music Optimizer”, “Re-EQ”, “Re-...

  • Page 26: Changing The Input Display

    Changing the Input Display Using Easy Macros Using the Easy macro command in the Easy macro mode, When you connect an -capable Onkyo component, you you can sequentially operate Onkyo components with sim- must configure the input display so that can work ple commands by simply pressing one button.

  • Page 27: Audyssey Multeq ® Room Correction And Speaker Setup

    Changing Source Component Using Audyssey MultEQ When you want to operate the component that is not Using Audyssey MultEQ to create a listening environment assigned as the source component, you can assign it as the in your home theater that all listeners will enjoy, source component.
  • Page 28 Turn on the AV controller and the connected TV. Press Enter. On the TV, select the input to which the AV control- Audyssey MultEQ Room Correction and Speaker ® ler is connected. Setup starts. Set the speaker setup microphone at the Main Lis- Test tones are played through each speaker as Audyssey MultEQ Room Correction and Speaker , and connect it to the Setup...
  • Page 29 Error Messages Changing the Speaker Settings Manually While Audyssey MultEQ ® Room Correction and Speaker You can manually make changes to the settings found dur- Setup is in progress, one of the error messages below may ing Audyssey MultEQ Room Correction and Speaker appear.

  • Page 30: Listening To The Radio

    Listening to the Radio ■ Manual tuning mode This section describes the procedure using the but- tons on the front panel unless otherwise specified. Press Tuning Mode so that the AUTO indicator goes off on the display. Using the Tuner Press and hold Tuning / .

  • Page 31: Presetting Fm/Am Stations

    Presetting FM/AM Stations Listening to SIRIUS Satellite Radio ® You can store a combination of up to 40 of your favorite To listen to Satellite Radio, you’ll need to connect a SIR- FM/AM radio stations as presets. IUS Satellite Radio tuner (sold separately) to your Sirius- Ready receiver.
  • Page 32 Setting Up the SiriusConnect™ Home Tuner The optional SiriusConnect Home tuner kit includes Display everything for easy home installation, including the Sirius- Connect receiver, indoor/outdoor antenna with 21-foot cable, 8-pin mini DIN connector cable, and an AC power Tuner adapter. See the SiriusConnect Home tuner’s instructions for more information.
  • Page 33 Selecting Channels using the Remote Use / to select “SAT Radio Mode”, and Controller select “SIRIUS”. Pressing cycles through the following options: There are three ways to select SIRIUS Satellite Radio None: channels: Select if you’re not using Satellite Radio. 1.
  • Page 34 ■ Selecting the previously selected channel SIRIUS Parental Lock With SIRIUS Parental Lock, you can lock out channels Press Return to select the previously selected that you do not want to receive and use a 4-digit PIN num- channel. ber to prevent others from unlocking them. Selecting Channels on the AV Controller Press Receiver followed by Setup.
  • Page 35 Use / to select “Parental Lock”, and then press to select a number on the screen, and Enter. then press Enter. The channel number, channel name, and the current Repeat this for each of the four digits in the PIN status are displayed.
  • Page 36 Displaying SIRIUS Satellite Radio Position the SiriusConnect Home antenna so that Information as many bars as possible (up to 3) appear on the Satellite signal strength meter. Press Display repeatedly to cycle through the available information. Antenna Aiming SIRIUS Satellite Terrestrial The following information can be displayed: Channel name and Channel number...

  • Page 37: Recording

    Recording This section explains how to record the selected input source to a component with recording capability, and how to record audio and video from different sources. Connecting a Recording Component Recording Separate AV Sources Here you can record audio and video from completely separate sources, allowing you to overdub audio onto your video recordings.

  • Page 38: Using The Listening Modes

    Using the Listening Modes Selecting Listening Modes 39). See “About Listening Modes” for detailed information about the listening modes (➔ Listening Mode Buttons Press Receiver first. Movie/TV, Music, Game Music Game Movie/TV Movie/TV button Game button This button selects the listening modes intended for use This button selects the listening modes intended for use with movies and TV.

  • Page 39: About Listening Modes

    About Listening Modes The AV controller’s listening modes can transform your listening room into a movie theater or concert hall, with high fidelity and stunning surround sound. Explanatory Notes Front speakers Center speaker Listening Surround speakers Mode Subwoofer(s) Surround back speakers Front high speakers Front wide speakers ■...

  • Page 40: Listening Modes

    Listening Modes Listening Mode Description Input Speaker Source Layout Direct In this mode, audio from the input source is output without surround-sound processing. The “Speaker Configuration” (presence of speakers), D i r e c t “Sp Distance” and “A/V Sync” settings are enabled, but much of the pro- cessing set via Home is disabled.
  • Page 41 Listening Mode Description Input Speaker Source Layout DTS-HD High (Continued from the previous page ) Resolution Audio D T S H D H R DTS-HD Master Audio D T S H D M S T R DTS Express D T S E x p r e s s D S D DTS 96/24...
  • Page 42 Listening Mode Description Input Speaker Source Layout Founded by George Lucas, THX develops stringent standards that ensure movies are reproduced in movie theaters and home theaters just as the direc- T H X C i n e m a tor intended. THX Modes carefully optimize the tonal and spatial character- istics of the soundtrack for reproduction in the home-theater environment.
  • Page 43 Onkyo-Original DSP Listening Modes Listening Mode Description Input Speaker Source Layout Orchestra Suitable for classical or operatic music, this mode emphasizes the surround channels in order to widen the stereo image, and simulates the natural rever- O r c h e s t r a beration of a large hall.

  • Page 44: Advanced Setup

    Advanced Setup On-screen Setup Menus Common Procedures in Setup Menu This manual describes the procedure using the remote controller unless otherwise specified. Receiver MENU Enter 1. Input/Output Assign / / / 2. Speaker Setup 3. Audio Adjust 4. Source Setup Setup Return 5.

  • Page 45: Input/Output Assign

    ■ Explanatory Notes Monitor Out Analog: Select this if your TV is connected to the COMPO- Main Menu Speaker Setup NENT VIDEO MONITOR OUT, MONITOR OUT ■ Subwoofer S, or MONITOR OUT V. Yes: HDMI Main: Select if a subwoofer is connected. Select this if your TV is connected to the HDMI No: OUT MAIN.

  • Page 46: Hdmi Input

    ■ 1080p BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TV/CD, PHONO, PORT Select this for 1080p output and video conversion as HDMI1, HDMI2, HDMI3, HDMI4, HDMI5, necessary. Source: HDMI6: Output will be according to the resolution level Select the HDMI IN to which the video component has been connected.
  • Page 47 Component Video Input Digital Audio Input If you connect a video component to a component video If you connect a component to a digital audio input, you input, you must assign that input to an input selector. For must assign that input to an input selector. For example, if example, if you connect your Blu-ray Disc/DVD player to you connect your CD player to the OPTICAL IN 1, you COMPONENT VIDEO IN 2, you must assign “IN2”...

  • Page 48: Speaker Setup

    Speaker Configuration Speaker Setup Main menu Speaker Setup This setting is set automatically by Audyssey MultEQ 27). Room Correction and Speaker Setup function (➔ Some of the settings in this section are set automatically by Audyssey MultEQ ® Room Correction and Speaker With these settings, you can specify which speakers are Setup function (➔...
  • Page 49 ■ Surr Back Ch Speaker Distance  1ch: Select if only one surround back speaker is con- This setting is set automatically by Audyssey MultEQ nected. Room Correction and Speaker Setup function (➔ 27).  2ch: Select if two (left and right) surround back speakers Here you can specify the distance from each speaker to the are connected.
  • Page 50 Equalizer Settings THX Audio Setup With the “Surr Back Speaker Spacing” setting, you can This setting is set automatically by Audyssey MultEQ ® specify the distance between your surround back speakers. Room Correction and Speaker Setup function (➔ 27). If you’re using a THX-certified subwoofer, set the “THX Ultra2/Select2 Subwoofer”...

  • Page 51: Audio Adjust

    ■ Preserve THX Settings Audio Adjust  Yes: ® Audyssey Dynamic EQ Main menu Audio Adjust Audyssey Dynamic Volume ® will not be active in With the Audio Adjust functions and settings, you can THX listening mode. adjust the sound and listening modes as you like. ...
  • Page 52 Dolby back speakers are connected. This setting is effective with Dolby Digital, Dolby Digital Plus and Dolby ■ TrueHD only. PLIIx Music (2ch Input) Auto: These settings apply to only 2-channel stereo sources. If the source signal contains a Dolby EX flag, the If you’re not using any surround back speakers, these Dolby EX or THX Surround EX listening mode is settings apply to Dolby Pro Logic II, not Dolby Pro...

  • Page 53: Source Setup

    ■ LFE Level Reference Level Audyssey Dynamic EQ Reference Level Offset ■ 0dB: Dolby Digital , DTS , Multich PCM, Dolby TrueHD, DTS-HD Master Audio, DSD It should be used when listening to movies. 5dB:  – dB, –20dB, –10dB, or 0dB Select this setting for content that has a very wide With these settings, you can set the level of the LFE (Low dynamic range, such as classical music.
  • Page 54 • When “Dynamic Volume” is set to effective, “Equalizer” is set IntelliVolume 50) and “Dynamic EQ” is set to “On”. to “Audyssey” (➔ When “Dynamic EQ” is set to “Off”, “Dynamic Volume” ■ IntelliVolume becomes “Off” automatically. –12dB to 0dB to +12dB in 1 dB steps. •...

  • Page 55: Picture Adjust

    Picture Adjust Name input area Using “Picture Adjust”, you can adjust the picture qual- 4-4. Name Edit BD/DVD ity and reduce any noise appearing on the screen. Name To view the TV picture while setting, press Enter. To return to the previous screen, press Return. –...
  • Page 56 ■ ■ Picture Mode Film Mode *2*3 Through: Video: The following settings are set to the default values: Does not process in either “3:2” or “2:2”. Auto: “Film Mode”, “Edge Enhancement”, “Noise Reduction”, “Brightness”, “Contrast”, “Hue”, Adjusts to the picture source, automatically selecting “Saturation”, “Gamma”, “Red Brightness”, “Red “Film Mode”.
  • Page 57 ■ ■ Resolution *2*3 Red Contrast *2*3  –50 to 0 to +50 Through: Select this to pass video through the AV controller at With this setting you can adjust red contrast. “–50” is the same resolution and with no conversion. the least.

  • Page 58: Listening Mode Preset

    ■ DTS/DTS-ES/DTS-HD Listening Mode Preset With this setting, you can specify the listening mode to be used when a DTS or DTS-HD High Resolution You can assign a default listening mode to each input Audio format digital audio signal is played (DVD, LD, source that will be selected automatically when you select CD, etc.).

  • Page 59: Hardware Setup

     1, 2, or 3 The audio is not output from the HDMI output. When several Integra/Onkyo components are used in On: the same room, their remote ID codes may overlap. To The audio is output from the HDMI output.
  • Page 60 ■ ■ Lip Sync Audio Return Channel Disable: Off: HDMI lip sync disabled. Select “Off” if you don’t want to use audio return Enable: channel (ARC) function. Auto: HDMI lip sync enabled. The audio signal from your TV tuner can be sent to The AV controller can be set to automatically correct any the HDMI OUT MAIN of the AV controller.

  • Page 61: Lock Setup

    – the “Audio TV Out” setting is set to “On” (➔ 59) and an Note input selector other than HDMI is selected. • Perform the firmware update only when an announcement is posted on the Integra web site. • It takes about 30 minutes to complete the firmware update.
  • Page 62 Tone Control Settings Late Night You can adjust the bass and treble for the front speakers, With the Late Night function, you can reduce the dynamic except when the Direct or THX listening mode is selected. range of Dolby Digital material so that you can still hear quiet parts even when listening at low volume levels—...
  • Page 63 Multich: Re-EQ The AV controller always outputs analog signals With the Re-EQ function, you can compensate a from multichannel analog input. soundtrack whose high-frequency content is too harsh, Analog: making it more suitable for home theater viewing. The AV controller always outputs analog signals. ■...

  • Page 64: Net/Usb

    NET/USB About NET Connecting the AV Controller The AV controller is network-ready, which means you can To connect the AV controller to your home network, plug hook it up to your home network with a standard Ethernet one end of a shielded CAT5 Ethernet cable into the AV cable and enjoy the music files stored on your computer or controller’s ETHERNET port, and plug the other end into media server.

  • Page 65: Listening To Internet Radio

    Listening to Internet Radio Note • When the NETWORK indicator flashes, confirm that the To receive Internet radio, you must connect the AV con- Ethernet cable is firmly connected to the AV controller. 64). troller to a network with Internet access (➔...

  • Page 66: Playing Music Files On A Server

    Enter the preset name and Internet address Playing Music Files on a Server (URL). This section explains how to play music files on a com- puter or media server through the AV controller. See WEB Setup Menu “Supported Audio File Formats” to “About DLNA” for Unit Information Preset Internet Radio Network set ing...
  • Page 67 Random Playback Use / to select a server, and then press Enter. The Random function can only be set while the PLAY A list of items on the server appears. screen is displayed. To play songs in random order, during playback (or while Server1 playback is paused or stopped), press Random.
  • Page 68 ■ Supported Audio File Formats AAC stands for MPEG-2/MPEG-4 Audio. For server playback, the AV controller supports the fol- • Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, lowing music file formats: MP3, WMA, WAV, FLAC, Ogg 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz, Vorbis, AAC and LPCM.

  • Page 69: Remote Playback From Media Server/Personal Computer

    Server Requirements Remote Playback from Media Server/ Personal Computer The AV controller can play digital music files stored on a computer or media server and supports the following tech- Remote Playback means you can play the music files nologies: stored on the DLNA-certified device such as media server •...

  • Page 70: Network Settings

    Using Remote Playback Network Settings Start Windows Media ® Player 12. Note Before remote playback, setup on Windows Media • When modifying network settings, after modifying it is neces- Player 12 is required. sary to execute “Save”. On the product, press NET/USB to select the This section explains how to configure the AV controller’s server screen.
  • Page 71 ■ Proxy Port When you’ve finished, press Return. If you’re using a Web proxy, enter a proxy port number The save confirmation screen appears. here. 7-6. Network ■ Control Save Cancel This setting enables or disables control over the network. Enable: Use / to select “Save”, and then press Enter.

  • Page 72: About Usb

    Plug your USB mass storage device into the AV About USB controller’s USB port. USB can be used to play music files stored on USB mass Press NET/USB repeatedly to select the “USB” storage devices (e.g., USB flash drives and MP3 players), input.
  • Page 73 Random Playback The Random function can only be set while the PLAY screen is displayed. To play songs in random order, while the list of songs is displayed, press Random. All of the songs in the current folder will be played in random order. When all of the songs in the folder have been played once, they’ll all be played again in a different random order.

  • Page 74: Multi Zone

    Multi Zone In addition to your main listening room, you can also enjoy playback in the other room, or as we call Multi Zone. And, you can select a different source for each room. Zone 2 Video Output Connecting Zone 2 The AV controller features a composite video output for Connecting Your Zone 2 Speakers connection to a TV in Zone 2, so you can enjoy both audio...

  • Page 75: Setting The Multi Zone

    Setting the Multi Zone Using Zone 2 This section explains how to turn Zone 2 on and off, how Press Receiver followed by Setup. to select an input source for Zone 2, and how to adjust the The main menu appears onscreen. volume for Zone 2.
  • Page 76 Controlling Zone 2 with the Remote Adjusting the Volume for Zone 2 Controller On the remote controller, press Zone2, and then Standby use VOL / . Zone2 On the AV controller, press Zone 2 Level Up / Down . Input Selector Muting Zone 2 On the remote controller, press Zone2, and then...

  • Page 77: Using The 12V Triggers

    Using the 12V Triggers Use / to select “Delay”, and use to select: 0sec, 1sec, 2sec, or 3sec. The 12V triggers A, B, and C can be used to turn on 12V When 0 sec is selected, the trigger signal is output as trigger-capable components automatically when they are soon as the input source is changed.

  • Page 78: Using The Remote Controller In

    Using a Multiroom Kit with a Cabinet Using the Remote Controller in Zone 2 and Multiroom Control Kits In this setup, the IR receiver picks up the infrared signals from the remote controller and feeds them to the AV con- To control the AV controller with the remote controller troller located in the cabinet via the connecting block.

  • Page 79: Controlling Ipod

    Controlling iPod Press NET/USB repeatedly to select the USB Connecting the iPod Directly to the input. USB Port Connect the USB cable that comes with the iPod/ USB can be used to play music files stored on iPod/ iPhone to the USB port at the front of the AV con- iPhone, which can be plugged into the AV controller’s troller.

  • Page 80: Connecting An Onkyo Dock

    Extended Mode control • Genres • Songs The content information is displayed (lists are displayed) • Composers on the on-screen, and you can select and manipulate the • Shuffle Songs content while looking at the screen. • Now Playing Top screen list: Displays a list.

  • Page 81: Using The Onkyo Dock

    ■ Using Your iPod models Alarm Clock Using the Onkyo Dock You can use your iPod models Alarm Clock function to automatically turn on your iPod and the AV controller at a Dock is sold separately. specified time. The AV controller’s input source will auto- For the latest information on the Onkyo Dock compo- matically be set to the Port selector.

  • Page 82: Controlling Your Ipod

    ■ System Function Controlling Your iPod System On When you turn on the AV controller, RI Dock and iPod By pressing Remote Mode that’s been programmed with turn on automatically. In addition, when the RI Dock and the remote control code for your Dock, you can control iPod are on, the AV controller can be turned on by press- your iPod in the Dock.
  • Page 83 ✔: Available buttons Press the appropriate Remote Mode first. Onkyo Dock Buttons ✔ On, Standby ✔ Top Menu ✔ ✔ / / / Enter ✔ ✔ Playlist ✔ ✔ ✔ ✔ Repeat ✔ ✔ Random ✔ ✔ Play Mode ✔ ✔...

  • Page 84: Controlling Other Components

    For details on controlling these components, see the pages indicated. Use / / / to select a character, and then press Enter. BD/DVD Integra/Onkyo Blu-ray Disc player (➔ Repeat this step from the 1st character to the 3rd TV/CD Integra/Onkyo CD player (➔...

  • Page 85: Entering Remote Control Codes

    For example, if you connect your CD player to the CD input, choose TV/CD when entering its remote control If you want to control an Integra/Onkyo component by code. pointing the remote controller directly at it, or you want to Within 30 seconds, use the number buttons to control an Integra/Onkyo component that’s not connected...

  • Page 86: Resetting Remote Mode Buttons

    If you want to control an Integra/Onkyo component by Controlling Other Components pointing the remote controller directly at it, use the follow- ing remote control codes: By pressing Remote Mode that’s been programmed with 32900: the remote control code for your component, you can con- Integra/Onkyo Blu-ray Disc player trol your component as below.
  • Page 87 ✔: Available buttons Press the appropriate Remote Mode first. Components Buttons ✔ ✔ ✔ ✔ ✔ ✔ On, Standby ✔ , Input, TV VOL / ✔ ✔ ✔ Guide ✔ Top Menu ✔ ✔ ✔ ✔ ✔ / / / Enter ✔...

  • Page 88: Learning Commands

    Learning Commands Note • The following buttons cannot learn new commands: Remote The AV controller’s remote controller can learn the com- Mode, All Off, My Movie, My TV, My Music, Mode. mands of other remote controllers. By transmitting, for • The remote controller can learn approximately 70 to 90 com- example, the Play command from your CD player’s mands, although this will be less if commands that use a lot of remote controller, the remote controller can learn it, and...

  • Page 89: Using Normal Macros

    Running Macros Using Normal Macros You can program the remote controller’s Activities to Press My Movie, My TV or My Music. perform a sequence of remote control actions. The commands in the macro are transmitted in the Example: order in which they were programmed. Keep the To play a CD you typically need to perform the following remote controller pointed at the AV controller until actions:...

  • Page 90: Troubleshooting

    Troubleshooting If you have any trouble using the AV controller, look for a Audio solution in this section. If you can’t resolve the issue your- ■ self, contact the dealer from whom you purchased this There’s no sound, or it’s very quiet unit.
  • Page 91 ■ ■ Only the center speaker produces sound The speaker volume cannot be set as required (The volume cannot be set to Max(100)) If you use the Dolby Pro Logic IIx Movie, Dolby Pro — Logic IIx Music, or Dolby Pro Logic IIx Game lis- Check to see if a maximum volume has been set.
  • Page 92 On your TV, make sure that the video input to which — the AV controller is connected is selected. If it’s an Integra/Onkyo component, make sure that cable and analog audio cable are connected If your TV is connected to the analog outputs, set the properly.
  • Page 93 ■ Can’t connect to the AV controller from a Web To control an Integra/Onkyo component that’s con- browser nected via , point the remote controller at the AV controller. Be sure to enter the appropriate remote If you’re using DHCP, your router may not always —...
  • Page 94 ■ When performing “Audyssey MultEQ ® Room Important Note Regarding Video Playback Correction and Speaker Setup”, the measurement fails showing the message The AV controller can upconvert component video, S- “Ambient noise is too high.”. Video, and composite video sources for display on a TV connected to the HDMI output.

  • Page 95: Specifications

    Specifications ■ Amplifier Section Video Inputs Component IN 1, IN 2, IN3 Input Sensitivity and Impedance S-Video BD/DVD, VCR/DVR, CBL/SAT, GAME 200 mV/47 k (LINE) Composite BD/DVD, VCR/DVR, CBL/SAT, GAME, 2.5 mV/47 k (PHONO MM) Rated RCA Output Level and Impedance Analog RGB input PC IN 200 mV/470 ...

  • Page 96: About Hdmi

    About HDMI Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, Blu-ray Disc/DVD players, set-top boxes, and other video compo- nents. Until now, several separate video and audio cables have been required to connect AV components. With HDMI, a single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichan- nel digital audio, and multichannel PCM).

  • Page 97: Using An Rihd-Compatible Tv, Player, Or Recorder

    Using an RIHD-compatible TV, Player, or Recorder , which stands for Remote Interactive over HDMI, is the name of the system control function found on Integra/ Onkyo components. The AV controller can be used with CEC (Consumer Electronics Control), which allows system con- trol over HDMI and is part of the HDMI standard.
  • Page 98 ■ How to connect and setup Confirm the settings. 1. Turn on the power for all connected components. Confirm the connecting and setting. 2. Turn off the power of the TV, and confirm that 1. Connect the HDMI OUT MAIN jack to the the power of the connected components is turned HDMI input jack of the TV.

  • Page 99: Video Resolution Chart

    Video Resolution Chart The following tables show how video signals at different resolutions are output by the AV controller. NTSC ✔: Output Output HDMI Component S-Video Composite Input 1080p 1080i 720p 480p 480i 1080p 1080i 720p 480p 480i 480i ✔ HDMI 1080p ✔...
  • Page 100 Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Y1005-1 Tel: 072-831-8023 Fax: 072-831-8163 SN 29400363 (C) Copyright 2010 ONKYO CORPORATION Japan.
