American Dryer Corp. AD-81 II Installation Manual

Gas/steam models
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use
any phone in your building.
* Clear the room, building or area of all
occupants.
* Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
* If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
010301DX/rar
AD-81 II
(Gas/Steam Models)
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimumle risque
d'incendie ou d'explosion pour ou éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinagede cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
* Ne pas tenter d'allumer d'appareil.
* Ne touchez à aucun interrupteur. Ne pas
* Évacuez la pièce le bâtiment ou la zone.
* Appelez immédiatement votre fournisseur de
* Si vous ne pouvez rejoindre le fournisseur
Línstallation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualiifié ou par le fournisseur de gaz.
For replacement parts, contact the reseller from which the dryer
American Dryer Corporation
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez.
gaz depuis un voisin. Suivez les instructions
du fournisseur.
de gaz appelez le service des incendies.
was purchased or
88 Currant Road
www.amdry.com
ADC Part No. 113311
