Kenwood Double DIN Kit Installation Manual

© 07/2009 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Opel Antara 2007->
Opel Astra 2004->
Opel Zafira 2005->
colour standard Rubber-Touch
black CAW 2230-04 CAW 2230-04-RT
anthracite CAW 2230-05 CAW 2230-05-RT
metallic
silver CAW 2230-06 CAW 2230-06-RT
champagne CAW 2230-14 CAW 2230-14-RT
glossy black CAW 2230-15 -
Compatible with these Kenwood double DIN devices
Kenwood Navigation
1
2
Double DIN Kit contents
• (1) Metal Frame • (2) Installation Kit · (3) Facia Plate · (4) Trim Frame
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.

Installation Manual

Double DIN Kit
colour standard Rubber-Touch
chrome silver CAW 2230-16 CAW 2230-16-RT
champagne CAW 2230-17 CAW 2230-17-RT
light silver CAW 2230-18 CAW 2230-18-RT
anthracite CAW 2230-19 CAW 2230-19-RT
dark silver CAW 2230-20 CAW 2230-20-RT
dark grey CAW 2230-21 CAW 2230-21-RT
3
4
