EverFocus ED640 Information

IR Cameras
Features
• 1/3" Sony Super HAD II Color CCD with high
resolution of 700TVL for high image clarity
• Full OSD with features like DWDR, HLC/BLC,
DNR, Anti-Color-Roll and more
• 2.8~12mm VF AI lens covers from wide angle of
82° to moderate telephoto field of view
• 3-Axis camera mount for flexible mounting and
positioning
• 24 smart IR LEDs with range of 82 feet for long
distance coverage
• Smart LEDs avoid over exposure of close in
objects
• Digital Day/Night for color in bright light, IR
illuminated B/W in low light
• DC12V only 320mA draw

Ordering Information

ED640: Indoor Color DWDR, 3-Axis
Varifocal 2.8-12mm, 700TVL, IR Dome Camera
Models vary in different countries. Visit www.everfocus.com and select your country for accurate ordering information.
ED640
Indoor Color DWDR 3-Axis Varifocal 700TVL IR Dome Camera
Get superior performance and 700HTVL resolution images in bright light or no light. The
EverFocus ED640 uses a Sony Super HAD II Color CCD to produce high quality color images
with a minimum of 700 horizontal TV lines of resolution; combine this with digital day/night, a
native low light sensitivity of 0.01 lux, and 24 smart IR LEDs with a range of 82 feet that can
control IR output to avoid over exposure of close in objects (max range depends on scene
IR reflectivity), a 3-axis wall or ceiling mount indoor plastic housing plus a full range of OSD
features like DWDR, 2D DNR, Privacy Zones, and Anti-Color-Roll and you have a cost effective
camera that fits a wide variety of indoor applications.
The ED640 comes with a 2.8~12mm VF AI lens that covers a field of view up to 82° wide, or
can magnify images for increased detail. With low 12VDC current draw, this is the camera that
you have been waiting for to create analog CCTV systems that deliver superior image clarity in
a wide range of indoor applications at virtually any light level.
TV System
Image Sensor
Effective Pixels
Resolution
Lens
Scanning System
Scanning Frequency
Auto Shutter Speed
Sync. System
S/N Raito
OSD
OSD Language
Day & Night
Min. Illumination
IR LEDs
IR Range
Smart IR Control
Auto Gain Control
DWDR
BLC
HLC
Gamma Correction
DNR
Lens Shading
Compensation
Mirror
Negative Image
White Balance
Digital Pixel Correction
Motion Detection
Privacy Zones
Video Output
Power Supply
Power Consumption
Operating Temperature
Storage Temperature
Operating Humidity
Dimension
Weight
Certifications
Product specifications are subject to change without notice. Visit www.everfocus.com for the most updated information.
NTSC
1/3" Sony Super HAD II Color CCD
768Hx494V
700 TV Lines
2.8~12mm VF AI
525Lines, 2:1Interlace
15.734KHz(H),59.94Hz
1/60 to 1/100,000sec.
Internal
More than 52dB (AGC off)
5 Button Navigation. Multiple options
English, Spanish, French, Portuguese,
German, Polish, Japanese, Chinese
Auto/Color Black & White;
Digital Day/Night with programmable switch levels
and delays
0.01 lux nominal; 0 lux with IR LEDs on
24 smart LEDs, 850nm
82 feet (depends on scene IR reflectivity)
Off/On with programmable area of interest and gain
Off, Low, Middle, High
Off/On with adjustable weight
Off/On for two areas with programmable area of
interest and gain
Off/Night Only/Always with adjustable level
0.45; Display compensation option for CRT or LCD
with adjustable levels
2D DNR Off/On
Off/On, adjustable for level and image center
Off/On
Off/On
AWB ( 2,100˚k ~ 9,100˚k)
Manual operation; programmable threshold and
area
On screen indication; up to 4 programmable areas
Up to 8areas programmable for location and color
NTSC CVBS, 1Vp-p, 75Ω
DC 12V±10%
160mA Nominal / 320mA IR ON
14ºF ~ 122ºF ; -10°C~50°C
-4ºF ~ 140ºF ; -20°C~60°C
to 90% RH max.
4.41"/112mm diameter, 3.43"/87mm high
7.2oz/205g
CE/FCC
