Huffy 600 Owner's Manual page 17

Assemble lanyard (25) to locking pin (24) as shown (FIG A). Attach covers (22) onto
.
10
pole mount bracket (15) with carriage bolt (23) and nut (14) as shown.
FIG. A
25
24
.
11
Insert handle assembly through pole
mount assembly as shown. Lock pole
assembly in place at the 10' (3.05 m)
mark with pin (24).
14
IMPORTANT!:
23 Loop end of pin
lanyard (25) over
carriage bolt (23)
25
as it passes
through the pole
mount bracket
(15) during this
24
assembly.
17
22
15
25
22
23
24
24
02/05 P/N 21163610
