Bounce top and middle pole assembly (4 & 5) onto bottom pole section (6) using a
4.
wood scrap as shown. Bounce until the top and middle pole assembly no longer
moves toward the pole identification mark on the bottom pole.
IMPORTANT!:
Align dimple of middle pole section (5)
into trough of bottom pole section (6)
as shown.
TROUGH
5"
Bottom pole
P/N 21163610 02/05
1-1/2"
Bottom pole
ID
STICKER
DIMPLE
HOLE
WOOD SCRAP
(NOT SUPPLIED)
14
CAUTION!
THE IDENTIFICATION STICKER IS
LOCATED 5" FROM THE END OF
THE POLE. WHEN PROPERLY
POUNDED TOGETHER, THE POLE
SECTIONS SHOULD HAVE A 3-1/2"
MINIMUM OVERLAP, LEAVING 1-
1/2" BETWEEN THE OVERLAPPING
POLE AND THE IDENTIFICATION
STICKER.
4
5
6
NOTE:
POLE SECTIONS
SHOULD HAVE A
3-1/2" (9 CM)
MINIMUM OVERLAP.
RODS SHOWN ARE
FOR VISUAL
REPRESENTATION
OF ALIGNMENT
AND ARE NOT
SUPPLIED WITH
THE HARDWARE
