- Page 1 COOKERHOODS CHIMNEY TYPE CONTENTS CANOPY TYPE Chimney Type Wall Mounting Option 1 – Recirculated Air Option 2 – Outside Venting Electrical Installation Controls Operation Caution Canopy Type Cupboard Installation Wall Mounting Optional Rear or Top Venting Installation Operation Maintenance www.defy.co.za...
- Page 2 CHIMNEY TYPE CAUTION The exhaust air from the chimney hood must not be discharged into a flue or chimney which is used for exhausting the fumes from other appliances burning gas or fuels. Please ensure that the regulations concerning the discharge of exhaust air have been fulfilled.
-
Page 3: Wall Mounting
WALL MOUNTING Remove the aluminium grease filters (perforated plates) from the base of the • hood. The hood must be mounted directly over the cooking area. The minimum distance • between the cooking surface and the underside of the hood must be 650 mm. for electric cookers and 750 mm. -
Page 4: Electrical Installation
ELECTRICAL INSTALLATION Connect the appliance to a 15A 230V 50 Hz earthed wall socket. Switch off the power at the mains in the event of a fault or when cleaning the appliance. CONTROLS These at located at the left front corner under the hood. HOB LIGHT OPERATION Switch on the chimney hood prior to cooking. -
Page 5: Canopy Type
CANOPY TYPE CUPBOARD INSTALLATION With this type of installation, (and if the rear vent is not used), the venting hole at the top of the unit must be clear. Remove the perforated plate underneath the unit by loosening the knurled-headed screws on either side. - Page 6 WALL MOUNTING Remove the filters so that the interior of the cooker hood and the keyhole slots are exposed. Hold the cooker hood in position against the wall and with a pencil mark out the location of the keyhole slots on the wall. Using a masonry bit, drill a hole at the top of each marked slot.
-
Page 7: Optional Rear Or Top Venting
All models can re-circulate air or vent it through an outside wall. Select the venting mode before installing the cooker hood. OPTIONAL REAR OR TOP VENTING INSTALLATION When using the external venting mode, ensure that there is adequate ventilation of the room when the Hood is used above a gas or fuel burning appliance. -
Page 8: Maintenance
Aluminium one. • Replacement Carbon, Grease and Aluminium filters are available as spare parts from DEFY SERVICE CENTRES country wide or by mail order. • Filters will have a longer life if they are cleaned regularly. Important: An excessively saturated filter could become a fire hazard if not...
Need help?
Do you have a question about the 600 and is the answer not in the manual?
Questions and answers
How do i put in new filter
To install a new filter in a Defy 600:
1. Grease Filter: Remove the old grease filter by releasing the metal strips. Wash and dry it if still effective; otherwise, replace it with a new one. Secure the new filter in place with the metal strips.
2. Carbon Filter: Remove the old carbon filter by gently turning it anti-clockwise (as seen from the bottom). Install the new carbon filter by turning it clockwise until secure.
3. Fibre Filter (for Gas Hobs): Replace the fibre filter with an aluminium one for better performance.
Replacement filters are available from DEFY service centres.
This answer is automatically generated
