Furuno FM-8800S Specification Sheet

FURUNO DEEPSEA WORLD
Simplex/Semi-duplex/Full-duplex, 25-Watt
MARINE VHF RADIOTELEPHONE
with a built-in Class A DSC and CH70 Watch Receiver
●
Fully meets ITU, IEC, ETSI, IMO for
GMDSS and other national standards
●
Compact all-in-one unit design includes
a 25-Watt radiotelephone, Class A DSC
modem and CH70 watch receiver
●
Superb voice quality by employing
the lower-noise-designed speaker
●
Dual/multiple watch on selected
channels while monitoring CH16
●
Quick access to CH16 key
●
Automatic entry of own
ship position and time
from a GPS navigator
●
Easy channel readout
with large characters
The FURUNO FM-8800S/8800D are high quality, all-in-one
marine VHF radiotelephones designed to comply with the
GMDSS carriage requirements for safety and general
communications. All the necessary functions such as a 25 W
VHF radiotelephone, a Class A DSC modem and a CH 70
Watch Receiver are incorporated into the compact transceiver
unit.
The FM-8800S offers simplex/semi-duplex, the FM-8800D
offers simplex/full-duplex voice communications with superb
voice quality. For easy readout of a selected channel,
the silver-bright LCD on the front panel indicating the channel
numbers with large, easy-to-read characters.
The dedicated rotary control and numeric keys make selecting
channels easy. Other standard features are instant access to
CH 16, telephone call via a PSTN, Dual Watch and Multiple
Watch functions, which allow watch on CH 16 and other
selected channels.
Models
●
ATIS mode available for European inland
waterways
●
Connects to an office or home via an
existing PSTN (Public Switched
Telephone Network)
●
Simple interface with a printer and VDR
(No need for a dedicated Junction Box)
Full Class A DSC functions are provided for distress alert
transmission and reception, as well as the general DSC
communications including Individual Telephone, All Ships,
Group and Area Call. The FM-8800S/8800D maintain a
continual watch on CH 70 even while you are using another
VHF channel. Upon receiving an incoming DSC message,
the FM-8800S/8800D give audible and visual alarms.
ATIS (Automatic Transmitter Identification System) is standard
for use in European inland waterways. It automatically
transmits the ID number when a communication is over or
every 5 min while in communication. The ATIS mode and
DSC mode are selectable through the menu.
Both units have two types of handsets: a compact hand MIC
and a stylish handset. Up to four handsets can be additionally
connected via an optional junction box . Each handset also
functions as an intercom for onboard communication.
The compact transceiver unit allows a flexible and space-
saving installation on a navigation console or the conning
position. Flush mount installation is also available.
R
The future today with FURUNO's electronics technology.
FURUNO ELECTRIC CO., LTD.
9-52 Ashihara-cho, Nishinomiya City, Japan Phone: +81 (0)798 65-2111
Fax: +81 (0)798 65-4200, 66-4622 URL: www.furuno.co.jp
FM-8800S
FM-8800D
R
(Semi-duplex)
(Full-duplex)
Catalogue No. V-031
TRADE MARK REGISTERED
MARCA REGISTRADA
