4'' DRY TILE SAW
ASSEMBLY AND OPERATION INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
Visit our website at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND
ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
Copyright
1998, 2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form without
the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
Diamond Blade not included; sold separately.
Distributed Exclusively by Harbor Freight Tools
3491 Mission Oaks Blvd., Camarillo, CA 93011
38941
. All rights reserved. No portion of this
®
REV 09e
Advertisement
Table of Contents
Related Manuals for Chicago Electric 38941
Summary of Contents for Chicago Electric 38941
- Page 1 4’’ DRY TILE SAW Model 38941 ASSEMBLY AND OPERATION INSTRUCTIONS Diamond Blade not included; sold separately. Due to continuing improvements, actual product may differ slightly from the product described herein. Distributed Exclusively by Harbor Freight Tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com...
-
Page 2: Specifications
SAVE THESE INSTRUCTIONS WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite ac- cidents. REV 08/01; 09e For technical questions, please call 1-800-444-3353. SKU 38941 Page 2... -
Page 3: Electrical Safety
Remove adjusting keys or wrenches before turning the power tool on. A wrench or a key that is left attached to a rotating part of the power tool may result in personal injury. For technical questions, please call 1-800-444-3353. SKU 38941 Page 3... - Page 4 “Inspection, Maintenance, And Cleaning” section of this manual. Use of un- authorized parts or failure to follow maintenance instructions may create a risk of electric shock or injury. For technical questions, please call 1-800-444-3353. SKU 38941 Page 4...
-
Page 5: Specific Safety Rules
To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles. (California Health & Safety Code § 25249.5, et seq.) For technical questions, please call 1-800-444-3353. SKU 38941 Page 5... -
Page 6: Double Insulated Tools: Tools With Two Prong Plugs
Make sure your extension cord is properly wired and in good electrical condition. Always replace a damaged extension cord or have it repaired by a qualified electrician before using it. For technical questions, please call 1-800-444-3353. SKU 38941 Page 6... - Page 7 UNPACKING When unpacking your Tile Saw make sure that the item is intact and undamaged. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353. For technical questions, please call 1-800-444-3353. SKU 38941 Page 7...
-
Page 8: Operation
Replace the Carbon Brushes with identical replacement parts from Harbor Freight Tools. Insert the Brushes into the Brush Holder, and insert back into the Enclosure. Screw back in the Brush Cap and tighten. REV 09e For technical questions, please call 1-800-444-3353. SKU 38941 Page 8... -
Page 9: Parts List
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. For technical questions, please call 1-800-444-3353. SKU 38941 Page 9... - Page 10 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available indi- vidually as replacement parts. For technical questions, please call 1-800-444-3353. SKU 38941 Page 10...
-
Page 11: Assembly Instructions
Turn water valve on the Water Plug counterclockwise to open and clockwise to close. Water Plug Thumb Bolt (55) Figure 4 — Attaching the Water Supply Unit (Tile Saw - Rear View) For technical questions, please call 1-800-444-3353. SKU 38941 Page 11... - Page 12 Suck on the other end of the Hose until water can be seen flowing down the hose. Reconnect the hose to the Water Plug. Turn water valve counterclockwise to open and clockwise to close. For technical questions, please call 1-800-444-3353. SKU 38941 Page 12...
- Page 13 This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 For technical questions, please call 1-800-444-3353. SKU 38941 Page 13...
