JVC TK-C700U Specifications

High-sensitivity 1/3" ccd color cctv video camera
Hide thumbs


Advertisement

R
High-Sensitivity 1/3" CCD Color CCTV Video Camera
FEATURES
Integrated Digital Signal Processor for
Low-light Operation (0.75 lx)
1/3-inch IT CCD with 250,000 Effective Pixels
330 Lines of Horizontal Resolution
Automatic Gain Control (AGC)
Auto White Balance
manual Adjustment
S/N Ratio of 50 dB (AGC Off)
Back-light Compensation
Automatic Electronic Shutter
ARCHITECTS' AND ENGINEERS' BID SPECIFICATION
The digital signal processing (DSP) super dynamic color CCD cameras shall be a JVC
Model TK-C700U or equivalent. The TK-C700U camera shall incorporate a 1/3" interline
transfer CCD, 250,000 [510(H) x 492(V)] pixels effective, with a microlens on each pixel,
and achieve high sensitivity 0.2 fc at f/1.2, displaying outstanding 330-line horizontal
resolution and a S/N ratio of 50dB. The TK-C700U camera's super dynamic CCD shall be
charged with long and short charges, creating both standard shutter speeds and fast
shutter speeds simultaneously, on a single image field. The CCD shall automatically apply
each exposure pattern to bright and normal areas. The camera shall feature a 28MHz 10-
bit digital signal processor for image processing of both long and short signals. The super
dynamic CCD shall feature images with a wide dynamic range of up to 32 times. The
camera shall also feature intelligent digital back light compensation, digital wide dynamic
range circuit, and digital noise reduction. For better picture quality, the camera shall feature
digital 2H enhancer, digital aperture correction, knee circuit and digital white detective
ATW. The camera shall be CS-mount/C-mount selectable. The TK-C700U shall offer
ALC/ELC, electronic shutter speed, Auto Gain Control (AGC) plus many other features.
The power source for the TK-C700U shall be 24V AC, 60Hz or 12V DC. All units must be
UL listed.
TK-C700U

Advertisement

Table of Contents
loading

  Related Manuals for JVC TK-C700U

  Summary of Contents for JVC TK-C700U

  • Page 1 ATW. The camera shall be CS-mount/C-mount selectable. The TK-C700U shall offer ALC/ELC, electronic shutter speed, Auto Gain Control (AGC) plus many other features. The power source for the TK-C700U shall be 24V AC, 60Hz or 12V DC. All units must be UL listed.
  • Page 2: Specifications

    TK-C700U Specifications Dimensions Signal system Based on NTSC standard U1-32 Pickup device 1/3" Interline-Transfer CCD (with complementary color filter) Number of effective pixels 250,000 (510 H x 492 V) Video process circuit Built-in DSP (9 bits) BF LOCK Pickup area 4.8 (H) x 3.6 (V) mm...
