3M™ MicroTouch™ Controller EX USB Reference Guide
Sensor Connection
The sensor cable has a 12-pin (2 x 6) dual row female connector that plugs into the
EX121 controller. Table 2 describes the pins on this connector. The sensor connector
always exits towards the USB cable.
Table 2. Sensor Cable Connector for EX121 Controllers
Pin
1
2
3
4
5
6
7
8
9
10
11
12
The sensor flex tail has a 5-pin single row female connector that plugs into the EX111
controller with a right side tail exit. The following table describes the pins on this
connector.
Table 3. Sensor Flex Tail Connector for EX111 Controllers
Pin
1
2
3
4
5
Mounting the Controller
The cased controller is mounted externally. The uncased controller is mounted internally.
Choose a convenient spot away from high-voltage, high power cables and electronics.
Use 4-40 plastic screws to mount the cased controller to eliminate possible ESD input
path. Metal or plastic screws can be used on the 2x3 board if the green ground wire is
used. Metal screws are required on the 1x2 board if a separate ground wire is not used.
The controller should be mounted in line with the sensor flex tail exit point to minimize
flexing. Refer to Figure 1 for more details on controller mounting.
Wire Color
Description
———
NOVRAM interface
———
NOVRAM interface
———
NOVRAM interface
———
+5 VDC
Gray
Not used
Green
Chassis (earth) ground
Orange
Not used
Brown Cable
Connects to the flex tail shield, which must not be grounded
shield/drain
because the EX121 drives the flex tail shield with an AC
wire
waveform.
White
Upper right (UR) corner
Red
Lower right (LR) corner
Black
Upper left (UL) corner
Blue
Lower left (LL) corner
Description
Upper left (UL) corner
Upper right (UR) corner
Connects to the flex tail shield, which must not be grounded because the
EX111 drives the flex tail shield with an AC waveform.
Lower right (LR) corner
Lower left (LL) corner
3M Touch Systems, Inc. Proprietary Information -- 29489v05
11
