Connecting the Router to Your Computer

Power
Input
On / Off
Button
*
Console—for use by D-Link repair service personnel only.

Connect the Telephone Cable

•
Connect one end of the telephone cable to the
the other end of the cable into the wall socket.

Connect the Ethernet Cable

•
Connect one end of the Ethernet cable to one of the 4
back of the router and attach the other end to an Ethernet Adapter or
available Ethernet port on your computer. Or, you can attach it to a switch /
hub first and connect your computer to the switch / hub.

Connect the Power Adapter

•
Complete the process by connecting the power adapter to the
on the back of the router and then plug the other end of power adapter into a
wall outlet or power strip. Then turn on the router and boot up your PC and
any LAN devices, such as hubs or switches, and any computers connected to
them.
Reset
*
Console
Button
DSL
LAN
Port
1-4
DSL port on the router and
LAN ports
6
on the
Power input
