Tr-069 Client - D-Link Wireless ADSL2/2+ 4-port Ethernet Router DSL-2640U User Manual

To configure the system log settings, click on the Configure System Log button to
view the following screen.
If the log is enabled, the system will log selected events including Emergency, Alert,
Critical, Error, Warning, Notice, Informational, and Debugging. All events above or
equal to the selected log level will be logged and displayed.
If the selected mode is "Remote" or "Both", events will be sent to the specified IP
address and UDP port of a remote system log server. If the selected mode is "Local"
or "Both", events will be recorded in the local memory. Select the desired values
and click on Apply to configure the system log options.

TR-069 Client

The router includes a TR-069 client, a WAN management protocol. All the values
are already filled in. If you wish to enable this protocol, then select enable. You
must click on the Apply button for the setting to take place.
66
