Front Panel View

LED Mode
Solid Green
Power No light
Red
Flashing
Status
Green
Solid Green
No Light
DSL
Slow Flashing
Fast Flashing
Solid Green
WLAN
Flashing
No Light
Solid Green
Flashing
LAN 1-4
Green
No Light
Solid Green
Internet
No Light
Red
Indication
The router is powered on. (READY)
The power is off.
Failure or device malfunction. (NOT READY)
Traffic is passing through the device. (INTERNET
TRAFFIC)
DSL is synchronized.
No carrier signal.
DSL attempting synch. Trying to detect carrier signal.
Carrier has been detected and router is trying to train.
Wireless is up.
Wireless traffic is passing through.
Wireless is down.
Powered device connected to associated port
LAN activity present (traffic in either direction).
No activity, router power off, no cable or no powered
device is connected to the LAN port.
IP connected (device has a WAN IP address from IPCP or
DHCP and DSL is up or a static IP address is configured,
PPP negotiation has completed successfully (if used),
and DSL is up. (WAN IP AVAILABLE)
Router power off, router in bridge mode or ADSL
connection not present.
Device attempted to become IP connected and failed
(no DHCP response, no PPPoE response, PPPoE
authentication failed, no IP address from IPCP, etc.).
(WAN IP NOT AVAILABLE)
4
