Options
. .
. .

Storage Devices

. .
. .
When multiple storage devices are configured with
. .
. .
the system, specify which devices should be
. .
. .
installed inside the system cabinet, inside the
. .
system expansion cabinet, or installed in the
. .
. .
external StorageWorks cabinet. Line item
. .
. .
sequencing allows Manufacturing to configure
. .
storage options in the appropriate cabinet.
. .
. .
List storage options to be integrated in system
. .
. .
cabinet immediately following system part
. .
. .
number.
. .
. .
List storage options to be integrated in
. .
StorageWorks cabinet immediately following
. .
. .
StorageWorks cabinet part number.
. .
. .
. .

Internal Storage

. .
. .
System cabinet provides space for up to four
. .
. .
BA36R-RC/RD StorageWorks shelves; each
. .
. . shelf holds a maximum of two 5.25 devices and
. .
one 3.5 device or seven 3.5 devices.
. .
. .
System cabinet includes one UltraSCSI
. .
. .
StorageWorks shelf (BA36R-RC) and one PCI
. .
. . shelf (DWLPB-DA).
. .
. . UltraSCSI Options
. .
. . Each UltraSCSI StorageWorks shelf requires SCSI
. .
controller and SCSI cable to connect controller to
. .
. .
shelf; refer to UltraSCSI Configuration Guidelines
. .
. . (EK-ULTRA-CG.C01).
. .
. . UltraSCSI single-channel
. .
StorageWorks shelf (included) with
. .
. .
16-bit I/O personality module (DS-
. .
. . BA35X-FA), 180W AC power
. .
supply, DC fans, RETMA
. .
. .
rackmounting hardware; supports
. .
. . 16-bit UltraSCSI devices and some
. .
8-bit narrow SCSI devices
. .
. .
depending on compliance with
. .
. . minimum revision levels
. .
. . UltraSCSI dual-channel StorageWorks
. .
shelf, includes 16-bit I/O personality
. .
. .
module (DS-BA35X-FB), 180 W AC
. .
. . power supply, DC fans, RETMA
. .
rack-mounting hardware; supports
. .
. .
16-bit UltraSCSI devices and some
. .
. . 8-bit narrow SCSI devices,
. .
depending on compliance with
. .
. .
minimum revision levels.
. .
. .
Power Option for BA36R Shelves
. .
. .
An additional power supply provides N+1 power for
. .
. . StorageWorks shelves; power supply uses 3.5
. .
slot in StorageWorks shelf, reducing total number
. .
. .
of devices supported by one.
. .
. .
180W 120 VAC Redundant Power
. .
. . Supply for StorageWorks shelf
. .
. . SCSI Signal Converter
. .
. . UltraSCSI StorageWorks DOC
. .
Signal Converter, required to
. .
. .
convert FWD signals from
. .
. . KZPBA-CB to single-ended for
. .
connection to DS-BA35X-FA
. .
. .
personality module in Storage-
. .
. . Works shelf, field installed only
. .
. .
. .
. .
. .
.
6
DA-10352-00A-001
Compaq AlphaServer GS60E
Internal Storage (continued)
SCSI Signal Converter (continued)
Fast20 Personality Module for BA356
single-ended-to-single-ended
1-channel, field installed only
Fast20 Personality Module for BA356
single-ended-to-single-ended
2-channel, field installed only
Cable for above
UltraSCSI Hubs
UltraSCSI hubs are supported with KZPBA-CB PCI
differential SCSI adapters.
UltraSCSI Hub with three differential
ports (two host ports and one
storage port), no single-ended
ports, in 3.5 SBB, UltraSCSI
cables not included
UltraSCSI Hub with five differential
ports, no single ended ports,
consists of four host ports and
one storage port in 5.25 SBB,
UltraSCSI cables not included
UltraSCSI Hub with one differential
port and two single-ended ports
in 3.5 SBB, UltraSCSI cables
not included
16-bit Wide Drives
36.4-GB 10,000 rpm 16-bit
BA36R-RC
UltraSCSI disk drive SBB (not
supported on KZPAC controllers)
18.2-GB 10,000 rpm 16-bit
UltraSCSI disk drive SBB (not
supported on KZPAC controllers)
18.2-GB 7200 rpm 16-bit UltraSCSI
disk drive SBB (not supported on
KZPAC controllers)
9.1-GB 10,000 rpm 16-bit UltraSCSI
BA36R-RD
disk drive SBB
9.1-GB 7200 rpm 16-bit UltraSCSI
disk drive SBB
Tape Devices
Tape drives not supported with KZPAC RAID
controller
8-GB DAT 3.5 SCSI tape drive in
StorageWorks carrier; requires
OpenVMS V6.2-1H3 or later or
Tru64 UNIX V3.2C or later and
System Console Firmware
Revision 3.0-9
32/64-GB DAT tape loader in
StorageWorks carrier
CK-BA35X-HH
12/24-GB 4mm DAT SCSI tape drive
in StorageWorks carrier
20/40-GB DLT SCSI tape drive in
DS-BA35X-DA
5.25 StorageWorks carrier
35/70-GB DLT SCSI tape drive in
5.25 StorageWorks carrier
Solid State Disks
Supported with KZPBA controller
DS-BA35X-FA
DS-BA35X-FB
BN38C-02
DS-DWZZH-03
DS-DWZZH-05
DS-DWZZH-21
DS-RZ1FB-VW
DS-RZ1ED-VW
DS-RZ1EA-VW
DS-RZ1DD-VW
DS-RZ1DA-VW
TLZ09-VA
TLZ9L-VA
DS-TLZ10-VA
TZ88N-VA
DS-TZ89N-VW
