Options
. .
. .
Networks and Communications (continued)
. .
. .
PCI LAN Communications Controllers (continued)
. .
. .
PCI ATMworks 351 bus adapter
. .
. .
(uses
. .
. .
one PCI slot); Tru64 UNIX
. .
supports two per PCI, maximum
. .
. .
of two per system; DGLPA-
. .
. .
FA/UA are not supported on the
. .
same system as DGLPB-AB.
. .
. .
PCI-to-ATMworks 155 Mb Adapter –
. .
. .
Fibre; Tru64 UNIX and
. .
. .
appropriate patch kits (patch kit 1
. .
for V4.0F; patch kit 2 for V4.0E)
. .
. .
support a maximum of six per
. .
. .
system; refer to
. .
http://www.service.digital.com for
. .
. .
patch kit availability SN-PBXNP-
. .
. .
AC PCI Token Ring Adapter is
. .
not supported in same system
. .
. .
with ATM 155 (DAPBA) adapter;
. .
. .
if ATMworks 351 (DGLPA) NIC
. .
card is installed, follow that
. .
. .
adapter's configuration rules;
. .
. .
only one ATM adapter can be
. .
installed on same bus as
. .
. .
ATMworks 351 network interface
. .
. .
card
. .
. .
PCI-to-ATMworks 622 Mb Adapter –
. .
Fibre; Tru64 UNIX and
. .
. .
appropriate patch kits (patch kit 1
. .
. .
for V4.0F; patch kit 2 for V4.0E)
. .
support a maximum of two per
. .
. .
system. Refer to
. .
. .
http://www.service.digital.com for
. .
patch kit availability SN-PBXNP-
. .
. .
AC PCI Token Ring Adapter is
. .
. .
not supported in the same
. .
system with the ATM 622
. .
. .
(DAPCA) adapter; if ATMworks
. .
. .
351 (DGLPA) NIC card is
. .
installed, follow that adapter's
. .
. .
configuration rules; only one
. .
. .
ATM adapter can be installed on
. .
same bus as ATMworks 351
. .
. .
network interface card
. .
. .
Same as above except UTP
. .
. .
PCI Token Ring Adapter, Tru64
. .
. .
UNIX and OpenVMS support four
. .
per PCI, maximum of four per
. .
. .
system; minimum system
. .
. .
console support required V4.0
. .
AXP CD release; requires
. .
. .
BC26M cable
. .
. .
PCI Asynchronous 4-port adapter,
. .
. .
Tru64 UNIX and OpenVMS
. .
support two per PCI, maximum of
. .
. .
two PBXDA-xx per system
. .
. .
PCI Asynchronous 8-port adapter,
. .
. .
Tru64 UNIX and OpenVMS
. .
support two per PCI, maximum of
. .
. .
two PBXDA-xx per system.
. .
. .
PCI Asynchronous 16-port adapter,
. .
. .
Tru64 UNIX and OpenVMS
. .
. . support 2 per PCI, maximum 2
. .
PBXDA-xx per system
. .
. .
.
8
DA-10352-00A-001
Compaq AlphaServer GS60E
Networks and Communications (continued)
PCI LAN Communications Controllers (continued)
PCI Synchronous 2-port controller,
DGLPA-FA/UA
Tru64 UNIX and OpenVMS support
two PBXDP-xx per system.
PCI Synchronous 4-port controller,
Tru64 UNIX and OpenVMS support
two PBXDP-xx per system.
PCI Synchronous 8-port controller,
3X-DAPBA-FA
Tru64 UNIX and OpenVMS support
two PBXDP-xx per system.
Local and Wide Area Communications
Servers/Network Connectivity Products
Each communications server requires 802.3/Ethernet
connection. Depending on server selected, either
ThinWire BNC type connection (e.g., BC16M
cable) or thick wire 15-pin AUI transceiver cable
(e.g., BNE3x) is required. Additional items also
required—see the Network Products Guide.

MEMORY CHANNEL

Up to two PCI System Area Network controllers are
supported on GS60E with Console Firmware V5.5-
x or later.
Tru64 UNIX Systems
Requires Tru64 UNIX V4.0F with TruCluster V1.6 or
later
3X-DAPCA-FA
Each system node in a MEMORY CHANNEL cluster
requires a TruCuster Production Server
(QB-3RLAG-KA) or TruCluster MEMORY
CHANNEL (QB-4ZCAG-AA) software license.
TruCluster MEMORY CHANNEL license
(QB-4ZCAG-AA), normally used for high-
performance technical computing applications, is
not required if systems include a TruCluster
Production Server license (QB-3RLAG-KA).
The following options are currently not supported with
MEMORY CHANNEL: DJ-ML200, CIPCA.
OpenVMS Systems
Requires OpenVMS V7.1-2 or later and OpenVMS
Cluster license (QL-MUZAG-AA)
2-node clusters can be configured by ordering a
CCMAB-AA for each system and one BN29B-04
or BN29B-10 cable; cable connects directly to
3X-DAPBA-UA
CCMAB-AA in each system.
SN-PBXNP-AC
For three or four system clusters, order one CCMAB-
AA adapter and one BN29B-04 or BN29B-10
cable for each system and one CCMHB-AA hub
for the cluster.
CCMHB-AA includes four CCMLB-AA line cards and
supports up to four nodes; expansion up to eight
system nodes can be achieved by adding up to
PBXDA-AA
four additional CCMLB-AA line cards
If two or more CCMAB-AA controllers are configured
in each system, a second CCMHB-AA hub is
required for clusters with more than two nodes; in
PBXDA-AB
2-node clusters the CCMAB-AA may be directly
connected.
PBXDA-AC
PBXDP-AA
PBXDP-AB
PBXDP-AC
