Lexmark C720

5024-001
Extracted From Service Manual

Advertisement

loading

Related Manuals for Lexmark C720

Summary of Contents for Lexmark C720

  • Page 1: Lexmark C720

    Lexmark C720 5024-001 Extracted From Service Manual...

  • Page 2: United States Government Restricted Rights

    You can purchase additional copies of publications related to this product by calling 1-800-553-9727. In other countries, contact your point of purchase. Lexmark, Lexmark with diamond design, MarkNet, and MarkVision are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.

  • Page 3: How To Use This Parts Catalog

    5024-001 7. Parts Catalog How to Use this Parts Catalog • SIMILAR ASSEMBLIES: If two assemblies contain a majority of identical parts, they are shown on the same list. Common parts are shown by one index number. Parts peculiar to one or the other of the assemblies are listed separately and identified by description.
  • Page 5 5024-001 Assembly 1: Part Units Description Number Toner Cartridge -Y 1 - 1 (Supply, customer order only) Toner Cartridge -M (Supply, customer order only) Toner Cartridge -C (Supply, customer order only) Toner Cartridge -K (Supply, customer order only) OPC Belt Cartridge (Supply, customer order only) Fuser Oil Bottle (Supply, customer order only)
  • Page 7 5024-001 Assembly 1 (cont.): Part Units Description Number Power Cord, HV, Brazil 1 - 16 1339520 Power Cord, HV, Chili 1339524 Power Cord, HV, UK, Ireland 1339528 Power Cord, HV, Austria, Belgium, EURO English, Finland, France, Germany, 1339529 Greece, Netherlands, Norway, Poland, Portugal, Russia, Slovakia/Czech/Hungary Spain, Sweden, Turkey Power Cord, HV, Israel...
  • Page 9 5024-001 Assembly 2: Part Number Units Description Top Cover Assembly (includes 35) 2 - 1 12G7015 Side Cover (R) 12G7016 Side Cover (L) 12G7017 Upper Side Cover (L) 12G7018 Front Cover 12G7019 Paper Exit Unit Cover (includes 13) 12G7020 Paper Exit Front Cover 12G7021 Base Cover (R) 12G7022...
  • Page 11 5024-001 Assembly 2 (cont.): Part Number Units Description Paper Exit Roller 2 - 27 12G7039 Paper sensor (PFUL) 12G7037 Operator Panel Assembly 12G7360 Paper Exit Gear Z19 12G7041 FCS Cover Assembly 12G7042 Paper Size Sensor 12G7043 BC Terminal 2 12G7044 Control Panel Base 12G7161 Paper Exit Button...
  • Page 13 5024-001 Assembly 2 (cont.): Part Number Units Description DC Guide L 2 - 50 12G7177 DC Guide (R) 12G7019 Waste Toner U Spring 12G7179 TR Terminal Base Assembly 12G7180 Interlock Switch 12G7070 Parts Packet, Screws 12G7341 Parts Packet, Cable Clamps, Retainers, 12G7340 Miscellaneous Note: Reference the foldout wiring diagram, in the back of this...
  • Page 15 5024-001 Assembly 3: Part Number Units Description Paper Feeding Clutch (PCLU) 3 - 1 12G7045 Registration Clutch (RECL) 12G7046 Fuser Clutch (FUCL) 12G7047 Developer Clutch 12G7048 Transfer Cam Clutch (TRCM) 12G7049 Cleaner Cam Clutch (FBCM) 12G7049 Cleaner Clutch (FBCL) 12G7051 Main Motor (MM) 12G7052 BD Gear Assembly...
  • Page 17 5024-001 Assembly 3 (cont.): Part Number Units Description Fuser Connector 3 - 25 12G7069 Interlock Switch, Front Door 12G7070 IOD2 P.W.B. 12G7073 Cooling Fan (CTFAN) 12G7074 Waste Toner Feeder Unit (Upper) 12G7075 Erase Lamp 12G7076 Erase Holder (2 pieces) 12G7077 Oil Sensor 12G7078 Belt Sensor (PBS)
  • Page 19 5024-001 Assembly 4: Part Units Description Number Paper Feed Roller 4 - 1 12G7098 Separator Pad 12G7099 OHP Sensor 12G7100 Paper Sensor (PEU) 12G7037 Paper Sensor (PT1) 12G7037 Paper Guide (UL) Assembly 12G7103 Paper Guide (UR) 12G7104 Transfer Unit Rear Band 12G7186 Transfer Unit Hinge Support Bracket 12G7187...
  • Page 20 5024-001 Assembly 5: Controller RIP Card 7-18 Service Manual...
  • Page 21 5024-001 Assembly 5: Controller RIP Card Part Units Description Number Controller RIP Card Network 5 - 1 12G7226 Controller RIP Card 12G7227 SIMM Code 12G7228 4MB SDRAM DIMM 99A1752 32MB SDRAM DIMM 99A1755 Riser Card Assembly 12G7229 Hard Disk Mounting Bracket 12G7231 Hard Disk 99A0459...
  • Page 22 5024-001 Assembly 6: Printer Cable Harness Sets 7-20 Service Manual...
  • Page 23 5024-001 Assembly 6: Printer Cable Harness Sets Part Units Description Number Harness WH (A) Wiring Diagram #1 6 - 1 12G7342 Harness WH (B) Wiring Diagram #2 12G7343 Harness WH (C) Wiring Diagram #3 12G7344 Harness WH (D) Wiring Diagram #4 12G7345 Harness WH (I1/SEN) Wiring Diagram #5 12G7346...
  • Page 24 5024-001 Assembly 7: Miscellaneous (No illustration) 7-22 Service Manual...
  • Page 25 5024-001 Assembly 7: Miscellaneous Part Number Units Description Card Assembly, SIMM IPDS/SCS/TNE 12G1704 Cable, Coax 13A0297 Cable, Twinax 13A0296 Hard Disk, 2.1GB 99A0459 Adapter, Serial 99A0545 MarkNet N2000t 4/16 Token Ring 12G1696 MarkNet N2002e 10Base2/10BaseT 12G1697 MarkNet N2001e 10/100 Ethernet 99A1830 4MB SDRAM DIMM 99A1752...
  • Page 26 5024-001 Assembly 8: Lower Feed Unit 7-24 Service Manual...
  • Page 27 5024-001 Assembly 8: Lower Feed Unit Part Units Description Number Paper Sensor (PEL) 8 - 1 12G7037 Paper Size Sensor (PSL) 12G7043 Paper Feed Clutch (PKCL) 12G7045 Paper Feed Roller 12G7098 Separator Pad (2) 12G7099 LF Side Cover R 12G7121 LF Side Cover L 12G7122 LF Clutch Drive, Transport Roller (DPKCL)
  • Page 28 5024-001 Assembly 8 (cont.): Lower Feed Unit (cont.) 7-26 Service Manual...
  • Page 29 5024-001 Assembly 8 (cont.): Lower Feed Unit (cont.) Part Units Description Number LFU / Duplex Parts Packet, Screws 12G7135 LFU / Duplex Parts Packet, Retainers 12G7136 LFU / Duplex Parts Packet, Cable Tie / 12G7137 Guides LFU / Duplex Parts Packet, Springs 12G7139 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information.
  • Page 30 5024-001 Assembly 9: Duplex Unit 7-28 Service Manual...
  • Page 31 5024-001 Assembly 9: Duplex Unit Part Units Description Number Cover Top (C) Assembly 9 - 1 12G7105 Cover Top (L) 12G7106 Cover Top (R) 12G7107 Cover Top (B) Assembly 12G7108 Cover Low (L) 12G7109 Cover Low (R) 12G7110 Cover Low (B) Assembly 12G7111 Paper Guide Bottom Assembly (includes 19, 12G7112...
  • Page 32 5024-001 Assembly 9 (cont.): Duplex Unit (cont.) 7-30 Service Manual...
  • Page 33 5024-001 Assembly 9: Duplex Unit Part Units Description Number Cover Bottom 9 - 23 12G7120 Spring (contains 2 springs) 12G7139 D Roller (contains 20 rollers) 12G7126 3 Belts 12G7127 Lid-WH Bottom 12G7128 D Sensor Bottom Bill of Material 12G7129 D Sensor Middle Bill of Material 12G7130 D Gear Cover 12G7131...
