Lexmark C720 Setup Manual

Lexmark C720 Setup Manual

Color laser printer
Hide thumbs Also See for C720:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual, Service Manual
C720
Setup Guide
November 2000
www.lexmark.com

Advertisement

Table of Contents
loading

Related Manuals for Lexmark C720

Summary of Contents for Lexmark C720

  • Page 1 C720 Setup Guide November 2000 www.lexmark.com...

  • Page 2: Safety Information

    Kentucky 40550, U.S.A. In the United Kingdom and Eire, send to Lexmark International Ltd., Marketing and Services Department, Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

  • Page 3: Table Of Contents

    Using your documentation ........1 Step 1: Select a location for your printer ......3 Step 2: Unpack and position the optional drawer .

  • Page 5: Using Your Documentation

    CD to install printer drivers and utilities. When you have completed setup and if you need more information about your printer, refer to the Lexmark C720 online information either on the Publications CD or on the Lexmark Web site at www.lexmark.com. Information is...
  • Page 6 Note: A note provides auxiliary infor- mation you may find useful. Warning! A warning identifies some- thing that might damage your printer hardware or software. CAUTION! A caution identifies some- thing that might cause you harm. Use the table to locate your next step.

  • Page 7: Step 1: Select A Location For Your Printer

    Allowing enough Choosing the correct location for your new Lex- mark C720 printer is vital to ensuring the printer provides you with the quality of service you expect. When selecting a place to set up your printer con- sider: •...
  • Page 8 (44 in.) (20 in.) (28 in.) Select a location for your printer When selecting a location for your printer, make sure you have at least the amount of space indi- cated in the figure at left. 710 mm (28 in.) 203 mm (8 in.)

  • Page 9: Duplex Unit

    711 mm (28 in.) 1434 mm (57 in.) When choosing a place to set up the printer, make sure the location you select is: • A firm, level, and stable surface • Well ventilated • Away from the direct airflow of air condi- tioners, heaters, or ventilators •...
  • Page 10 Use the table to locate your next step. Select a location for your printer In the future if you’re going to move the printer, remember the following: • The printer weighs approximately 39 kg (86 lb) and two people are required to lift it safely.

  • Page 11: Step 2: Unpack And Position The Optional Drawer

    Save the carton and packing material in case you need to repack the drawer. If any items are missing or damaged, refer to the registration card for the Lexmark phone number for your country. Remove any shipping tape and packing material from the drawer and tray.
  • Page 12 Unpack and position the optional drawer Place the optional drawer in the location you have selected for your printer. Lock Loosen the locking clip thumbscrew by rotating counterclockwise. Rotate the locking clip so that it hangs down.

  • Page 13: Step 3: Unpack And Position The Printer

    Remove the supplies box and accessories bag from the printer carton. Save the printer carton and packing materi- als in case you need to repack the printer. Supplies box Accessories Printer Unpack and position the printer...
  • Page 14 Lexmark phone number for your country. In addition to the Publications CD, you can access your C720 online information on our site on the World Wide Web at www.lex- mark.com. There you can obtain up-to-date...

  • Page 15: Position The Printer

    When- ever you lift the printer use the hand- holds located on the sides of the printer. information about Lexmark and Lexmark products. If you have an optional drawer follow the “Printer with optional drawer” procedures. Otherwise go follow the “Printer without optional drawer”...
  • Page 16 Note: If you align the sides and cor- ners of the printer with the optional drawer and then lower the printer, the pins and connector align easier. Unpack and position the printer Align the pins on top of the optional drawer with the holes on the bottom of the printer.
  • Page 17 CAUTION! This printer weighs 39 kg (86 Ib) and requires two people to lift it. Anytime you move or lift the printer make sure you have someone help you. When- ever you lift the printer use the hand- holds located on the sides of the printer.
  • Page 18 This will help you during printer setup. We use the same terms throughout this book, the Publications CD and on the Lexmark C720 online information. Top door and output bin Top door release latch...

  • Page 19: Step 4: Set Up The Optional Drawer

    Step 4: Set up the optional drawer Remove tray 1. Set up the optional drawer...
  • Page 20 Move the drawer unit lock to the right until it locks into place. The lock is located between the optional drawer and printer. You must reach through the printer tray opening to move the lock. Slide in the paper tray.
  • Page 21 Remove the connector cover. The connector cover is located as shown. Press in and rotate the cover downward or use a small flathead screwdriver to remove the connector cover. Set up the optional drawer...
  • Page 22 Slot Set up the optional drawer Make sure the locking clip thumbscrew is loose enough to rotate the locking clip. Rotate the locking clip and place the top of the clip inside the slot. Tighten the locking clip thumbscrew.
  • Page 23 Align and attach the white drawer connec- tor to the white printer connector. If you have an optional duplex unit skip steps 10 and 11. Locate your next step using the table on page 21. Set up the optional drawer...
  • Page 24 Set up the optional drawer Install the left side access panel. Place the slot on the rear of the panel onto the pin at the rear of the printer. Rotate the panel toward the front of the printer until it snaps into place.
  • Page 25 Use the table to locate your next step. If you need to… Install the memory or network options Install the optional duplex unit Install supplies Set up the optional drawer See page…...
  • Page 26 Set up the optional drawer...

  • Page 27: Step 5: Install Memory And Network Options

    CAUTION! This printer weighs 39 kg (86 Ib) and requires two people to lift it. Anytime you move or lift the printer make sure you have someone help you. When- ever you lift the printer use the hand- holds located on the sides.
  • Page 28 CAUTION! If you are installing internal options after initial printer setup, turn the printer off and unplug the power cord. If you have any other devices connected to the printer, turn them off as well and unplug any cables going to the printer.
  • Page 29 You must replace the system board before you can operate the printer. Use the table to locate your next step. Pull the system board out of the printer. If you need to… Install a memory card Install a flash memory card...

  • Page 30: Installing Memory

    Installing memory Note: Memory options designed for other Lexmark printers may not work with your printer. For more information, refer to the Lexmark C720 online infor- mation. Resident code card DO NOT REMOVE Memory connectors Option slot Option slot cover...
  • Page 31 Warning! The memory card is easily damaged by static electricity. Touch something metal before you touch the memory card. Connection points Open the latches on both ends of the con- nector socket you are going to use. Unpack the memory card. Unpack each memory card separately just before installing it.
  • Page 32 Repeat steps 3 through 7 to install other memory cards. If you need to… Install a flash memory card Install a hard disk Install a printer option card Install the system board See page…...

  • Page 33: Flash Memory Option

    Refer to the Technical Reference for more details about using your flash memory option. If you need to remove a flash memory card, refer to the Lexmark C720 online information. card Complete the steps in “Removing the system board” on page 23 if the system board is still installed.
  • Page 34 DO NOT REMOVE Memory connectors Option slot Option slot cover Note: Your printer may not have a resi- dent code card. Install memory and network options Locate the memory connectors on the sys- tem board. Each connector can support either a printer memory card or a flash memory card.
  • Page 35 Warning! The flash memory card is easily damaged by static electricity. Touch something metal before you touch the memory card. Connection points Unpack the flash memory card. You can install a 2MB, 4MB, 8MB, or 16MB flash memory card. Unpack the flash memory card just before installing it.
  • Page 36 It may require some force to fully seat the card. Make sure the latches fit over the notches on each end of the connector card. If you need to… Install a hard disk Install a printer option card Install the system board See page…...
  • Page 37 Installing a hard disk Warning! System board electrical com- ponents are easily damaged by static electricity. Touch something metal before you touch any system board electronic components or connectors. Ribbon cable Attachment screws Mounting plate You can purchase a hard disk option from Lex- mark.
  • Page 38 Hard disk connector Install memory and network options Align the ribbon cable connector to the connector pins on the hard disk. The connector ends on the ribbon cable slightly differ from each other. The connec- tor end that has pin holes not drilled is the connector that attaches to the hard disk.
  • Page 39 System board connector Hard disk connector Note: If the holes on the mounting plate do not align with the holes on the system board, the mounting plate has been incorrectly installed on the hard disk. Refer to step 5 on page 34 for proper mounting plate installation.
  • Page 40 Install memory and network options Press the mounting plate posts into the three holes on the system board until they snap into place. If you need to… Install a printer option card Install the system board See page…...
  • Page 41 Its IEEE 1284C connector requires a 1284 A–C cable. You can purchase a 3 m (9.8 ft) cable, Lexmark part number 43H5171, meeting these specifications. Refer to the docu- mentation that came with your interface card or adapter for more information.
  • Page 42 Install memory and network options You need a number 2 Phillips screwdriver to install a printer option card. To remove a printer option card first, refer to the Lexmark C720 online information. Complete the steps for “Removing the system board” on page 23 if the system board is still installed.
  • Page 43 Insert the screw you saved in step 2 (or the extra screws shipped with the printer option card) through the holes at each end of the option slot and into the printer option card. Gently tighten the screws to secure the printer option card.
  • Page 44 You must replace the system board before you can operate the printer. Install memory and network options Align the system board with the top and bottom slots inside the back of the printer as shown. Insert the system board into the printer.
  • Page 45 Align the two screws in the rear cover with the holes on the printer frame. Tighten the two screws to secure the rear cover and system board to the printer. If you installed internal options after initial printer setup, connect the printer cables and power cord, and turn the printer on.
  • Page 46 Install memory and network options...

  • Page 47: Step 6: Install The Optional Duplex Unit

    Your printer supports an optional duplex unit that provides two-sided color or monochrome print- ing. To install a duplex unit, you must have previ- ously installed the optional drawer (see page 15 for instructions).
  • Page 48 Note: If you are installing the duplex unit after initial printer setup, you must have previously installed an optional drawer. Top access panel Tabs Install the optional duplex unit Remove the top access panel. Push in on the bottom edge of the top access panel.
  • Page 49 Insert the lower left and right pins on the duplex unit into the slots of the optional drawer as shown. Lift the duplex unit and place the tabs into the holes of the printer. Lower the duplex unit into place. Install the optional duplex unit...
  • Page 50 Install the optional duplex unit Open the duplex unit top cover. Align the thumbscrews on the duplex unit with the holes on the printer. Tighten the thumbscrews to secure the duplex unit to the printer. Close the duplex unit top cover.
  • Page 51 Rotate the panel toward the front of the printer until it snaps into place. If you installed the duplex unit after initial printer setup, connect the printer cables and power cord, and turn the printer on. Continue with “Install supplies” on page 49.
  • Page 52 Install the optional duplex unit...

  • Page 53: Step 7: Install Supplies

    Note: If a duplex unit is installed, open the duplex unit top door also. Your printer ships with an oil bottle and cleaning roll that you must install to operate your printer. Oil lubricates the fuser and the cleaning roll removes excess toner and other contaminants from the fuser.
  • Page 54 Once the oil bottle has been installed, do not tilt or move the printer. Oil can drip and cause damage. For information on removing the oil bottle, refer to the Lexmark C720 online infor- mation. Oil bottle locking levers Install supplies...
  • Page 55 Roller release levers Align the oil bottle with the slots in the printer. Lower the oil bottle into the printer. Move the green fuser roller release levers toward the rear of the printer. It may require some force to move the levers.
  • Page 56 Align the cleaning roll with the slot in the printer. Lower the cleaning roll into the printer. Turn the left and right green oil bottle locking levers to lock the oil bottle and cleaning roll in the printer.
  • Page 57 Photo developer locking levers Your printer ships with a photo developer car- tridge that must be installed for your printer to operate. The photo developer cartridge creates and carries the image from the toner cartridges to the transfer drum.
  • Page 58 Warning! Do not touch the glossy green film in the photo developer car- tridge. Touching the photo developer film damages it and reduces print quality. Metal shipping pin Cover Metal shipping pin Install supplies Remove the photo developer cartridge from the packing material. Photo developer film Pull the two metal shipping pins away from the photo developer cartridge to...
  • Page 59 Photo developer locking levers Align the photo developer cartridge with the slots in the green locking levers. Lower the photo developer cartridge into the printer until it is firmly seated. Rotate the green photo developer locking levers down. Install supplies...
  • Page 60 Close the top door. If a duplex unit is installed, close the duplex unit top door also. Install supplies...
  • Page 61 Front door release latch Your printer ships with four color-coded toner car- tridges. These cartridges must be placed inside the front of the printer. Each cartridge has its own color-coded position inside the printer. To install the four toner cartridges: Pull the front door release latch toward the front of the printer.
  • Page 62 Warning! Do not touch the toner roller surface under the cover. Touching the surface of the toner roller may damage it. Roller Install supplies Remove the cover and any other packing material or tape from the toner cartridge. Cover...
  • Page 63 Align the toner cartridge with the appro- priate slot in the front of the printer. The letter C, M, Y, or K on the toner car- tridge corresponds with the letter inside the printer.
  • Page 64 Attach the Quick Reference Card Quick Reference sleeve Note: Do not cover the vent holes on the printer. Install supplies Repeat steps 4 through 8 to install the remaining cartridges. Close the front door. Find a convenient location for the Quick Reference card.

  • Page 65: Step 8: Attach The Cables

    If you’re attaching a serial cable, we recom- mend Lexmark part number 1038693 (50 ft). Attach the cable to the serial connector on the optional tri-port interface card you installed in the printer.
  • Page 66 Parallel connector Attach the cables To attach a cable to your printer: At the right rear of printer, locate the paral- lel or the optional port connector. Depending on the options you have installed, additional parallel, serial, USB, or network connectors may be available.
  • Page 67 Turn the printer on. Continue with “Load the paper tray” on page 65. Attach the cables...
  • Page 68 Attach the cables...

  • Page 69: Step 9: Load The Paper Tray

    1. For details about the types of media your printer supports, refer to the Lexmark C720 online information. If you installed an optional paper drawer, the instructions are the same for loading paper in that tray.
  • Page 70 Release the snap locks. The position of the front paper guide tells the printer the size of the paper in the tray. If the front paper guide is in the wrong posi- tion, you may experience paper feeding problems or incorrect page formatting.
  • Page 71 Do not exceed the maximum stack height Maximum stack height indicated on the label inside the paper tray. If you’re loading preprinted letterhead, place the top of the page at the rear of the tray. Slide the paper tray into the printer. Load the paper tray...

  • Page 72: Loading Envelopes

    Release the snap locks. The position of the front paper guide tells the printer the size of the envelope in the tray. For some envelopes, you may have to set the envelope size through the operator panel.
  • Page 73 Straighten the edges on a level surface. Load the envelopes with the recommended print side face up and the return address area toward the front of the printer. Maximum stack height Do not load stamped envelopes. Do not exceed the maximum stack height indicated on the label inside the paper tray.
  • Page 74 Loading the optional legal paper tray Load the paper tray Slide the paper tray into the printer. The optional legal paper tray replaces tray 1, the standard 250-sheet tray. In addition to legal size paper, you can load all the paper sizes and types supported by the standard tray 1.
  • Page 75 Release the snap locks. The position of the front paper guide tells the printer the size of the paper in the tray. If the front paper guide is in the wrong posi- tion, you may experience paper feeding problems or incorrect page formatting.
  • Page 76 Load the paper tray Before loading the paper, flex the sheets back and forth to loosen them, and then fan them. Straighten the edges on a level surface. Load the paper with the recommended print side face up. Maximum Do not exceed the maximum stack height stack height indicated on the label inside the paper tray.
  • Page 77 Slide the paper tray into the printer. Load the paper tray...
  • Page 78 Load the paper tray...

  • Page 79: Step 10: Verify Setup

    If you see an error code on the operator panel display, refer to the Troubleshooting section in the Lexmark C720 online informa- tion. After the printer completes its internal tests and warms up, the Ready appears.

  • Page 80: Utilities Menu

    A4 or letter size paper. If you use a paper type other than plain paper, you need to set the printer to the correct type. Refer to the Lexmark C720 online information for more infor- mation on paper sizes and sources.
  • Page 81 For these reasons, it’s important to change the setting each time you change the media in the trays. Refer to the Lexmark C720 online information for more detailed information about the paper types supported by each paper source, as well as ways...

  • Page 82: Paper Menu

    PAPER TYPE Select Menu Verify setup to use the Paper Type setting to make printing more efficient. If you need to change a Paper Type setting: From the printer operator panel, press Menu> PAPER MENU the display. Return Press Stop Press and release appears on the second line.

  • Page 83: Plain Paper

    80, otherwise continue with “Load MarkVision and drivers” on page 89. appears on the second line of the again if you want to change the Menu> <Menu to scroll through a <Menu Select to return the printer Verify setup...

  • Page 84: Setup Menu

    Make sure you have plain paper loaded in tray 2 margin tray 1 and tray 2. From the printer operator panel, press Menu> on the second line of the display. Press Return...
  • Page 85 LEFT MARGIN Tray 2 Return Select Menu Stop Tray 2 = 5* Return Select Menu Stop Press Menu> on the second line of the display. Press Select appears on the first line and the cur- Tray 2 rent default value appears on the second line of the display.
  • Page 86 Note: After the margin adjustment pages are printed, the printer returns to Ready Instructions Tray 1 page Tray 2 page Verify setup Adjusting the tray 2 margin Each page has 15 vertical lines printed across the page. The tray 2 page has adjustment instructions in the upper left corner and a numerical value above each vertical line.
  • Page 87 Tray 2 = 8* Return Select Menu Stop Hold the pages up toward the light and find the lines that most closely form a sin- gle vertical line. The numerical value above the lines that most closely forms a vertical line is your new setting.
  • Page 88 Tray 1 page Tray 2 page Verify setup Press ting and print the two alignment pages. Tray 2 page Place the page from tray 2 on top of the page from tray 1. Tray 1 page Hold the pages up toward the light and find the lines that most closely form a sin- gle vertical line.
  • Page 89 “Determining the correct duplex unit mar- gin”. Otherwise continue with “Load MarkVision and drivers” on page 89. Make sure you have plain paper loaded in tray 1. From the printer operator panel, press Menu> on the second line of the display. Press Select Press Menu>...
  • Page 90 LEFT MARGIN Duplex Select Menu Duplex = 5* Select Menu Verify setup Press on the second line of the display. Return Stop Press Duplex rent default value appears on the second line of the display. Return Stop Press page. Printing Alignment Page play.
  • Page 91 Adjusting the duplex unit margin Note: After the margin adjustment pages are printed, the printer returns to Ready Duplex = 8* Return Select Menu Stop Each page has 15 vertical lines printed across the page. The back page has adjustment instructions in the upper left corner.
  • Page 92 Verify setup Hold the pages up toward the light and find the lines that most closely form a sin- gle vertical line. If the numerical value above the matching vertical lines has an * alongside it, the mar- gins are aligned properly. If the lines that most closely form a single line do not have the numerical value and an *, your margin is not adjusted properly.

  • Page 93: Step 11: Load Markvision And Drivers

    Lexmark drivers on your system. If you use drivers designed for printers other than the Lexmark C720, you may not be able to control all of the printer’s functions. For more information about these functions, refer to the driver online Help.
  • Page 94 Help. Refer to the CD Readme file for the latest information about the contents of the You have successfully set up your Lexmark C720. If you need to configure your printer for use on a network, continue with Step 12: “Configure the network printer”...

  • Page 95: Step 12: Configure The Network Printer

    However, you can override it with an optional locally administered address (LAA) if you want a particular physical address for this print server. Use the printer operator panel to print the net- setup page work setup page. You will need this information during network setup.

  • Page 96: Network Menu

    NETWORK MENU NETWORK OPTION 1 Select Menu NETWORK OPTION 1 NETWORK 1 SETUP Select Menu Configure the network printer To print the network setup page: From the operator panel, press <Menu Continue to press and release <Menu Press NETWORK OPTION 1 line of the display.
  • Page 97 Menu Stop Press Select Press Menu> the second line of the display. Press Select Print Setup Page of the display. Press Select until you see <Menu Print appears on the second line to print the page. Configure the network printer...

  • Page 98: Set The Ip Address

    • If you don’t have DHCP, there are other methods you can use to manually assign the address such as the printer operator panel, static ARP and telnet, RARP and telnet, BOOTP, MarkVision, or other Lexmark util- ity. Instructions for these methods follow. See page…...
  • Page 99 Printer operator panel A simple way to set the IP address, netmask, and gateway inside the print server is to use the opera- tor panel. You need to be standing at the printer to use this method. From the operator panel, choose...
  • Page 100 Note: If you are using Windows 2000 or Windows NT Server 4.0 or later and running TCP/IP, you can use Network Plug and Print to automate your printer setup process. Configure the network printer Set up to print There are many ways to send a print job including FTP, TFTP, LPR/LPD, point-to-point (LexIP), and various queue-based methods.
  • Page 101 Point-to-point printing (LexIP) You can print from any Windows 95/98/Me, Win- dows 2000, or Windows NT computer directly to a Lexmark printer located anywhere on the IP net- work. No server is required. Install the TCP/IP software component on the computer.
  • Page 102 Configure the network printer Create a printer object on the computer. Click Start, Settings, Printers, Add Printer. Access the Lexmark Network Printer Monitor. Select one of the following two operat- ing systems and follow the instruction. Windows 95/98/Me: –...
  • Page 103 Windows 2000 or Windows NT: – Click File, Properties, Ports, Add Port. Click Other, Lexmark Network Printer Monitor, and then click OK. A list of available print servers appears. If your print server does not appear in the list, click Add Adapter and then fol- low the instructions on the screen until it appears.

  • Page 104: Novell Netware

    If you have MarkNet print servers in an NDPS environment, we recommend that you install the Lexmark NDPS IP Gateway. This allows your printers to be tightly integrated with NDPS so that you can easily monitor, control, and print to them.

  • Page 105: Create A Desktop Printer

    If prompted to reset the print server, select Yes to immediately begin servicing the queues. Each Macintosh user on the AppleTalk network who wants to use the printer should do the follow- ing steps. In the Chooser, select the LaserWriter 8 driver.

  • Page 106: Change The Zone And Printer Name

    Script Printer Description), you need to install the proper PPD from the Drivers, MarkVision and Utilities CD. To do this, launch the CD, click Lexmark Installer, select the appropriate PPD for your printer, and then click Install. Go back to the Chooser and try to create the new printer again.
  • Page 107 For expanded troubleshooting information, look on the Drivers, MarkVision and Utilities CD. Click View Documentation and look for the MarkNet link. Also, free firmware updates for any Lexmark print server are available on our Web site at www.lexmark.com. TCP/IP Make sure the TCP/IP protocol is turned on (activated) in the print server.
  • Page 108 (for example, TCP/IP). Try printing again. If you are still having trouble, contact Lex- mark for help at 1-800-LEXMARK (1-800- 539-6275) or on the Web at www.lexmark.com. NDPS (Novell Distributed Print Services) Make sure the TCP/IP protocol is turned on (activated) in the print server.
  • Page 109 Place a job in the queue using a Novell utility such as PCONSOLE. If the job doesn’t print, contact Lexmark for help at 1-800-LEXMARK (1-800-539-6275) or on the Web at www.lexmark.com. Configure the network printer...

  • Page 110: Windows Nt Server

    – If it doesn’t, the print server may have down-level firmware. – If it does but you still cannot print, try removing, then re-adding the Lexmark Network Port on the printer object. Reset both the print server and the printer.
  • Page 111 (for exam- ple, TCP/IP). This also helps MarkVision run faster. Try printing again. If you are still having trouble, contact Lex- mark for help at 1-800-LEXMARK (1-800- 539-6275) or on the Web at www.lexmark.com. AppleTalk Make sure the AppleTalk protocol is turned on (activated) in the print server.
  • Page 112 These tips can save you a great deal of time. When you install MarkVision for Macintosh, these documents are automatically written to a folder on your desktop. If you are still having trouble, contact Lex- mark for help at 1-800-LEXMARK (1-800- 539-6275) or on the Web at www.lexmark.com.

  • Page 113: Index

    adjusting margins 80 attaching cables 61 cable connectors LocalTalk 61 parallel 61 serial 61 cables, attaching 61 cartridge, photo developer 53 Cautions 2 CD, launching 89 changing paper type settings 77 cleaning roll 49 configuring and printing 94 conventions 2 drawers See optional drawers drivers 89...
  • Page 114 LocalTalk support 37 location for the printer, choosing 3 Macintosh support 89 margin adjustment tray 2 80 margin adjustment, duplex unit 85 MarkNet Pro adapter 61 MarkNet S adapter 37, 61 MarkNet XLe adapter 61 MarkVision 89 memory, installing 26, 29...
  • Page 115 37 troubleshooting network printer setup 103 unpacking the printer 9 USB adapter 37 verifying printer setup 75 Warnings 2 Windows support 89 World Wide Web 1 Index...
  • Page 116 Viewing the User’s Guide CD Insert the CD into the CD-ROM drive. If the CD does not launch automatically: Select your CD-ROM drive. Double-click START.PDF (or double-click the CD icon on your desktop and then click START.PDF if you are using a Macintosh computer).
  • Page 117 P/N 11X1111 E.C. 1X1111 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. © 2000 Lexmark International, Inc. 740 West New Circle Road Lexington, Kentucky 40550 www.lexmark.com...
