SPF200-USB Fingerprint Sensor
(Front view)
Features
• All-in-one Fingerprint module with USB connector.
• Easy to integrate with other devices
• Uses Fujitsu MBF200 Fingerprint Sensor
• Low Power
– 18 milliamps: Operating
– 500 microamps: Standby
• USB 1.1 compatible (to 13 FPS)
• 256 x 300 Pixel Array (50 µm pixel pitch)
Description
The Fujitsu SPF200-USB is an all-in-one USB device. Simply
connect it to your USB cable and you have a working fingerprint
sensor! The SPF200-USB is ideal for integrating into devices
where USB is the communication interface such as computer
peripherals and embedded applications. Mount the SPF200-
USB into your device and you have a completed product
without going through the expense of board layout and debug.
• 500 DPI resolution
• 8-bit grayscale (256 gray levels)
• On board A/D Converter
• Programmable gain control for image optimization
• 12.8mm x 15mm image area
• Lead-Free and ROHS compliant parts available
• Windows XP USB signed drivers
Users will no longer be required to remember and enter
cumbersome passwords or PIN codes. Fingerprint authentication
provides a reliable, quick and user friendly alternative to
passwords. The SPF200-USB fingerprint sensor has the USB 1.1
controller logic built right into the sensor, no external hardware is
required. Merely plug the sensor into the USB cable, the power
and data communications is managed by the USB protocol.
(Back view)
