5.6.3.3 Sustained Ultra DMA data in burst
5.6.3.2 contains the values for the timings for each of the Ultra DMA Modes.
DSTROBE
at device
t
DVH
t
DVHIC
DD(15:0)
at device
DSTROBE
at host
DD(15:0)
at host
Note:
DD (15:0) and DSTROBE signals are shown at both the host and the device
to emphasize that cable setting time as well as cable propagation delay shall
not allow the data signals to be considered stable at the host until some time
after they are driven by the device.
Figure 5.12 Sustained Ultra DMA data in burst
